MBW GP5800H User manual

OPERATOR’S SAFETY
AND SERVICE MANUAL
MBW, Inc.
250 Hartford Rd • PO Box 440
Slinger, WI 53086-0440
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.mbw.com
MBW (UK) Ltd.
Units 2&3 CochraneStreet
Bolton BL3 6BN
England, UK
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
MBW FRANCE S.A.R.L.
Phone:[phone]
L20016 / 05.19.G
©MBW, Inc. 2015
Printed in the USA
GP5800
This manual covers the following serial numbers
and higher for each model listed:
GP5800.................................5800001
VIBRATORY PLATE

- 2 -
19791
WARNING
OPERATION OF THIS EQUIPMENT MAY
CREATE SPARKS THAT CAN START FIRES
AROUND DRY VEGETATION. A SPARK
ARRESTER MAY BE REQUIRED. THE
OPERATOR SHOULD CONTACT LOCAL FIRE
AGENCIES FOR LAWS OR REGULATIONS
RELATING TO FIRE PREVENTION


 
  
! " #$$ %&
'&('
) &#&& #&" %
* +& #&##
, &#+& #&-.#&#&#&&
&'+&
/ 0## &."1++
( +&'.$ 1$$$ &
 +(# '
2 +&-&#&#&&&'+&.
++&+"&.+ 
!)2
20019
Wear approved hearing
protection, foot protection, eye
protection and head protection.
STOP
Read the Operating Instructions before
operating this piece of equipment.
Keep unauthorized and untrained
people away from this equipment.
ROTATING & MOVING PARTS!
Make sure all guards and safety
devices are in place.
SHUT OFF the motor before servic-
ing or cleaning.
DO NOT RUN in an enclosed area.
The engine produces carbon
monoxide, a POISONOUS GAS.
Failure to comply could result in serious bodily injury.
CAUTION
Avoid breathing dust from operating
machine, wear OSHA specified dust
mask/respirator.
12573
WARNING
ROTATING PARTS
can crush and cut.
Keep hands away!
CAUTION
HOT SURFACE
DO NOT TOUCH
SURFACE CHAUDE
NE PAS TOUCHER
CAUTION
AP3550=254 lbs (115 kg)
GP5800=300 lbs (136 kg)
16402
GP2000=165 lbs (75 kg)
AP2000=193 lbs (88 kg)
GP3550=226 lbs (103kg)
Machine may fall and cause injury or damage if
lifted improperly. Lift by handles or rollcage only.
WARNING
Operating, servicing and maintaining this equipment
can expose you to chemicals, including engine
exhaust, phthalates and lead, which are known to the
state of California to cause cancer and birth defects or
other reproductive harm. Avoid breathing engine
exhaust. Do not operate equipment in confined areas.
For more information go to www.P65Warnings.ca.gov
21820
21742
Safety Decals (Decal Set #12100)
21139
09311
12573
20019
16402
19791
13482
12500
21140
21820
21742

- 3 -
SPECIFICATIONS
GP5800H
Centrifugal Force 5800 lbf (25.8 kN)
Exciter Speed 4800 vpm
Travel Speed 130 ft./min. (39.6 m/min.)
Compaction Depth 20 in (51 cm)
Plate Size (W x L) 23 x 24 in (58 x 61 cm)
Operating Weight 289 lb. (131 kg)
Engine Speed 3400 rpm
Operating Noise Level196 dBA
Compaction Area 14950 sqft/h (1389 sqm/h)
Engine Model Honda GX270
Specifications subject to change without notice.
- No universal method or formula has been accepted for determining “Compaction Force”. All manufactures
employ their own method or formula.

- 12 -
24
18
10
8
4
17
25
21 7
5
20
12 27
28
23
11
14
15
9
10
16
3
13
19
6
21
2
26
1
22
Exciter Assembly

- 13 -
ITEM PART NO. DESCRIPTION QTY
1. 00001 EXCITER HOUSING 1
2. 00066 FILTER RETAINER 1
3. 00259 SHIM, EXCITER (AS REQUIRED)
4. 01000 RETAINING RING, INTERNAL 1
5. 01072 FILTER, FELT 1
6. 01107 SHAFT SEAL 1
7. 05559 PLUG, PLASTIC 2
8. 07456 ROLLER BEARING 1
9. 07458 SPERICAL ROLLER BEARING 1
10. 07469 RETAINING RING, EXTERNAL 2
11. 14993 WASHER, COUNTERSUNK 1
12. 18700 HEX HEAD CAP SCREW, 5/8-11 x 6”LG. GRADE 8 4
13. 18701 HEX NUT, 5/8-11 4
14. 19135 SHAFT KEY, 1/4” SQUARE x 3/4” LONG 1
15. 19629 EXCITER PULLEY 1
16. 19991 COVER, FRONT 1
17. 19992 EXCITER SHAFT, 5800 1
18. 19993 COVER, BACK 1
19. 19986 BASE PLATE, GP5800 1
20. F0205SP SPIROL PIN, 1/8: DIA. x 5/8” LONG 1
21. F051804HCS HEX HEAD CAP SCREW, 5/16-18 x 1/2 LG. 3
22. F051806FWS FLANGE LOCK SCREW, 5/16-18 x3/4 LG. 6
23. F051808FSS FLAT HEAD SCOCKET SCREW, 5/16-18 x 1” LG. 1
24. F051808FWS FLANGE LOCK SCREW, 5/16-18 x1 LG. 6
25. F05BFW BRASS FLAT WASHER 1
26. F0618SPP SOCKET PIPE PLUG, 3/8-18 NPT 1
27. F10LW LOCK WASHER, 5/8 4
28. F10PW PLAIN WASHER, 5/8 4
REPLACEMENT KITS:
19990 EXCITER ASSEMPLY COMPLETE
18719 KIT, PAVER PAD

- 14 -
6
17385
13
10
11
12
9
4
2
16 15
14
16
Engine Assembly

- 15 -
ITEM PART NO. DESCRIPTION QTY
1. 00808 SHAFT KEY, 1/4” SQUARE X 1-3/4” lg. 1
2. 01011 SHOCK MOUNT 5
3. 05881 V-BELT, A37 1
4. 12968 ENGINE MOUNTING BAR 2
5. 14992 WASHER, COUNTERSUNK 1
6. 15674 HONDA ENGINE, GX270 1
7. 19127 CLUTCH, CENTRIFUGAL 1
8. 19136 SHAFT SPACER 1
9. 19994 ENGINE DECK ASSEMBLY 1
10. F061616HCS HEX HEAD CAP SCREW, 3/8-16 x 2” LG. 4
11. F06LW LOCKWASHER, 3/8” 4
12. F06SW STANDARD FLAT WASHER, 3/8” 4
13. F072008FSS FLAT HEAD SOCKET SCREW, 7/16-20 x 1” LG. 1
14. F081305HCS HEX HEAD CAP SCREW, 1/2-13 x 5/8” LG. 5
15. F081307HCS HEX HEAD CAP SCREW, 1/2-13 x 7/8” LG. 5
16. M12ETLW EXTERNAL TOOTH LOCK WASHER, M12 10
KITS:
20190 Service kit GP5800 Honda; includes the following.
#01000 (5) Shock Mount
#1690 (4) Shock Mount
#05881 V-Belt, A37
#19951 Oil, 10W30, One Quart
#20186 Exciter Oil, 8 oz. Bottle
#Q17210ZE2515 AIR CLEANER ELEMENT
#Q9807956846 SPARK PLUG

- 16 -
7
9
6
8
1615
10
1
3
3
17
6
5
14
4
13
12
11
16
15
10
2
Roll Cage Assembly

- 17 -
ITEM PART NO. DESCRIPTION QTY
1. 01019 HANDLE BUSHING, INNER 2
2. 15830 HANDLE ATTACHMENT NUT 2
3. 16191 HANDLE BUSHING, OUTER 2
4. 16189 SHOCKMOUNT 2
5. 21665 KIT, LIFT HANDLE 1
6. 16908 SHOCK MOUNT, HANDLE 4
7. 19999 ROL CAGE, 5800 1
8. 20009 BELT GUARD 1
9. 20010 HANDEL ASSEMBLY (Includes items #1 & #3) 1
10. F051806FWS FLANGE HEAD LOCK SCREW, 5/16-18 x 3/4” LG. 2
11. F061608HCS HEAX HEAD CAP SCREW, 3/8-16 x 1” LG. 4
12. F06LW LOCK WASHER, 3/8” 4
13. F06SW FLAT WASHER, 3/8” 4
14. F081305HCS HEAX HEAD CAP SCREW, 1/2-13 x 5/8” LG. 8
15. F081306HCS HEAX HEAD CAP SCREW, 1/2-13 x 3/4” LG. 4
16. F08LW LOCKWASHER, 1/2” 4
17. M12ETLW LOCK WASHER, M12 EXTERNAL TOOTH 8
