McCulloch MS1640NTCC Guide

N/A
SPECIFY MODEL NO. WHEN ORDERING PARTS DATE
REVISED DATE
16" Electric Chain Saw 7/29/2004
MODEL NO. MS1640NTCC / 41AZ64NQ777
SERVICE SPARE PARTS LIST

N/A
No. STK CODE Parts No. Description QNo. STK CODE Parts No. Description Q
1 MC-6228-211402 HOUSING (R) 1 36 MC-6024-211507 SPRING 1
2 MC-6228-211504 CHAIN COVER ASS'Y 1 37 MC-6SQABB04-20 SCREW 1
3 MC-6012-210501 WASHER 1 38 MC-6181-211501 CLUTH 1
4 MC-6017-210103 OIL COVER 1 39 MC-6181-211502 CLUTH 1
5 MC-6SDABB04-18 SCREW 13 40 MC-6024-211503 SPRING 1
6 MC-6043-211302 ADJUSTMENT PLATE 1 41 MC-6014-211501 WASHER 1
7 MC-6050-211301 OIL WASHER 1 42 MC-6154-211301 CONNECTING BAR 1
8 MC-6220-210201 CHAIN 1 43 MC-6SQABB04.5-30 SCREW 1
9 MC-6038-211503 HOUSING (R) 1 44 MC-6154-211504 CONNECTOR 1
10 MC-9040-310111 BAR 1 45 MC-6017-211503 FRONT-HAND GUARD 1
11 MC-6101-210502 COVER 1 46 MC-6228-211303 FIXED ACC'Y 1
12 MC-6228-211506 OIL PIPE ASS'Y 1 48 MC-6SDABB04-16 SCREW 2
13 MC-6076-210503 WASHER 1 49 MC-6079-211503 SPRING 1
14 MC-6056-211501 SWITCH BUTTON 1 50 MC-6038-211504 HOUSING (L) 1
15 MC-6066-211501 OIL TENK 1 51 MC-6086-211501 REAL COVER 1
16 MC-6028-211501 TRIGGER 1 52 MC-6228-211401 MOTOR GEAR BOX ASS'Y 1
17 MC-6022-211502 SWITCH 1 53 MC-6022-211501 SWITCH 1
18 MC-6024-211501 SPRING 1 54 MC-6SDABB04-10 SCREW 7
19 MC-6CY-08 RING 1 55 MC-6011-211502 POWER CORD 1
20 MC-6079-211501 SPRING, BRAKE 1 56 MC-6043-840001 STRAIN RELIEF 1
21 MC-6073-211501 GEAR 1 57 MC-6059-855001 CORD GUARD 1
22 MC-6059-210201 ADJUSTMENT COVER 1 58 MC-6012-211501 RUBBER STOP 1
23 MC-6115-211502 PIN 1 59 MC-6024-211506 SPRING 1
24 MC-6154-211502 CONNECTION 1 60 MC-6PC05-14.7 PIN 1
25 MC-6CG-9.5 C RING 1 61 MC-6PC4.4-35 PIN 1
26 MC-6014-210502 WASHER 1 62 MC-6SQAB-04-06 SCREW 1
27 MC-6228-210104 GEAR BEARING ASS'Y 1 63 MC-6WFB-03-12 WASHER 1
28 MC-6077-211501 COVER 1 64 MC-6SDABB03-15 SCREW 1
29 MC-6057-210102 WASHER 1 65 MC-6158-211502 PLATE 1
30 MC-6CC-10 C RING 1 66 MC-6SLABB03-06 SCREW 2
32 MC-6SDABB03-18 SCREW 1 67 MC-6010-211301 WIRE 1
33 MC-6228-210105 OIL PUMP ASS'Y 1 68 MC-6SDABB04-14 SCREW 3
34 MC-6188-211501 PULL BAR 1 69 MC-6120-211401 CARRY CASE 1
35 MC-6114-211501 PULL PLATE 1
Stocking Codes are:
A - Dealer stocked B - Distributor stocked C - Factory stocked
DATE REVISED
DATE
7/29/2004
MODEL NO.
SPECIFY MODEL NO. WHEN ORDERING PARTS
16" Electric Chain Saw
MS1640NTCC / 41AZ64NQ777
SERVICE SPARE PARTS LIST
