McIntosh MS500 User manual

McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: [phone] www.mcintoshlabs.com
MS500
Music Streamer
Owner’s Manual

2
Your decision to own this McIntosh MS500 Music
Streamer ranks you at the very top among discrimi-
nating music listeners. You now have the best. The
McIntosh dedication to precision performance assures
many years of musical enjoyment.
Please take a short time to read the information in this
guide. We want you to be as familiar as possible with
all the features and functions of your new McIntosh.
Thank You
Please Take A Moment
Technical Assistance
If at any time you have questions about your McIntosh
product, contact your McIntosh Dealer who is familiar
with your McIntosh equipment and any other brands
that may be part of your system. If you or your Dealer
wish additional help concerning a suspected problem,
you can receive technical assistance for all McIntosh
products at:
McIntosh Laboratory, Inc.
2 Chambers Street
Binghamton, New York 13903
Phone: [phone]
Fax: [phone]
Customer Service
If it is determined that your McIntosh product is in
need of repair, you can return it to your Dealer. You
can also return it to the McIntosh Laboratory Service
Department. For assistance on factory repair return
procedure, contact the McIntosh Service Department
at:
McIntosh Laboratory, Inc.
2 Chambers Street
Binghamton, New York 13903
Phone: [phone]
Fa x: 607-723-1917
The serial number, purchase date and McIntosh Dealer
name are important to you for possible insurance
claim or future service. The spaces below have been
provided for you to record that information:
Serial Number: _______________________________
Purchase Date: _______________________________
Dealer Name: ________________________________
Copyright 2017 © by McIntosh Laboratory, Inc.
Safety Instructions ..................................................... 2
(Separate Sheet) ................... Important Additional
Operation Information Guide
Thank You and Please Take a Moment....................... 2
Technical Assistance and Customer Service .............. 2
Table of Contents ........................................................ 2
Trademark and License Information .......................... 2
General Information ................................................... 3
Connector and Cable Information .............................. 3
Introduction................................................................. 4
Performance Features ................................................. 4
Dimensions ................................................................. 5
Installation .................................................................. 6
Rear Panel Connections .............................................. 7
AC/DC Adapter .......................................................... 8
MS500 Connections............................................. 10 -11
Front Panel Display and Push-button........................ 12
How to use the Remote Control................................ 13
How to Operate the Setup Mode ......................... 14-15
How to Operate the MS500 ................................. 16 -23
Photos........................................................................ 25
Specifications............................................................ 26
Packing Instructions ................................................. 27
Table of Contents
The McIntosh MS500 incorporates copyright protec-
tion technology that is protected by U.S. patents and
other intellectual property rights.
Trademark and License Information
Important Safety Information is supplied in a separate document “Important Additional Operation Information Guide”

3
concerning battery disposal.
8. If it should become necessary to replace the sup-
plied AC / DC Power
Adapter, order part
number 32059900
from the McIntosh
Parts Department.
9. For additional information on other McIntosh
Products please visit the McIntosh Web Site at
www.mcintoshlabs.com.
10. Mobile Device Apps for remote control operation
of the MS500, are available. Go to the McIntosh
Web Site at http://www.mcintoshlabs.com/us/Sup-
port/Pages/Manuals.aspx
Under “PRODUCT CATEGORY” select “Media
Streamers” then under “MODEL NUMBER”
select “MS500”. Click on “SEARCH” then click
on the MS500 Music Streamer App (iPhone, iPad
or Android) for your mobile device.
1. For additional connection information, refer to the
owner’s manual(s) for any component(s) connected
to the MS500 Music Streamer.
2. When the MS500 Music Streamer is connected to
an audio system, playback of music already stored
on it may be listened to. To take full advantage of
the many features the MS500 is capable of, such
as importing and storing additional music on the
Music Streamer, requires connection to a Com-
puter Network System.
3. For best performance, the speed of the Computer
Network the MS500 Music Streamer would be
connected to should be 1 Gigabit or faster.
4. The MS500 internal Digital to Analog Converter
Circuitry is designed to decode 2-channel PCM
(Pulse Code Modulation) Digital Signals up to
24Bit 192kHz. The Digital Output Signal present
at the Coaxial and Optical Output Connectors is a
2-channel PCM (Pulse Code Modulation).
5. The MS500 is designed to be compatible with the
majority of Audio Power Amplifiers. However,
do to a wide range of Power Amplifier Designs, it
is important the input sensitivity of the amplifier
be at least 2 Volts. This will assure the playback
of most music recordings are reproduced with ad-
equate dynamic range. Check with your McIntosh
Dealer for additional information.
6. The IR Input, with a 3.5mm mini phone jack, is
configured for non-McIntosh IR sensors such as
a Xantech Model DL85K Kit. Use a Connection
Block, such as a Xantech Model ZC21, when two
or more IR sensors need to be connected to the
MS500.
7. When discarding the unit, comply with local rules
or regulations. Batteries should never be
thrown away or incinerated but disposed
of in accordance with the local regulations
phone plug and allow the connection
of other brand IR Receivers to the
MS500.
Power Control Connector
The Power Control Input Jack receives Power On/
Off Signals (+12 volt/0 volt) when connected to other
McIntosh Components. The Power Control Output
Jack sends Power On/Off Signals (+12 volt/0 volt)
when connected to other McIn-
tosh Components. An additional
connection is for controlling the
illumination of the Power Out-
put Meters on McIntosh Power
Amplifiers. A 3.5mm stereo mini phone plug is used
for connection to the Power Control Jacks.
Ethernet RJ45 Socket
1. Transmit Data (+) 5. N/C
2. Transmit Data (-) 6. Receive Data (-)
3. Receive Data (+) 7. N/C
4. N/C 8. N/C
Ethernet Cable - Straight Thru Connections
Pin Number - Wire Color Pin Number - Wire Color
 1.Orange/White → 1.Orange/White
 2.Orange → 2.Orange
 3.Green/White → 3.Green/White
 4.Blue → 4.Blue
 5.Blue/White → 5.Blue/White
 6.Green → 6.Green
 7.Brown/White → 7.Brown/White
 8.Brown → 8.Brown
General Information
Connector and Cable Information
XLR Connectors
Below is the Pin configuration for the XLR Balanced
Output Connectors on the MS500. Refer to the dia-
gram for connection:
PIN 1: Shield/Ground
PIN 2: + Output
PIN 3: - Output
Data and IR Input Port Connectors
The MS500 Data In Port receives Remote Control
Signals. A 3.5mm stereo mini phone
plug is used for connection. The IR
Ports also use a 3.5mm stereo mini
PIN 1 PIN 2
PIN 3
Data
Signal
N/C
Data
Ground
IR Data
Control
Ground
N/C
Power
Control
Ground
Meter
Illumination
Control
Pass Thru
Pin 1
Pin 8
Pin 1
Pin 8

4
General Information, Cable Information, Disc Information, Introduction and Performance Features
Introduction
Performance Features
•Built-in Networking Capability
The MS500 has the ability to connect to an existing
network for connecting to other devices also connect-
ed to the network, including the Internet (the Cloud).
•High Storage Capacity
The MS500 incorporates a massive 500 Gigabyte
Hard Drive capable of storing the contents of a large
Music Collection.
•Expand the Music Server System
The MS500 can provide seamless access to music
contained on other MS500(s) from different physical
locations. It can also access music stored on other de-
vices such as Computers and NAS (Network Assisted
Storage) Devices connected to the same network as
the MS500. This provides for unlimited music storage
capacity.
•USB 3 and USB 2 Inputs
Connect external storage devices to the MS500 for
increased music storage capacity.
•Internet Streaming Services
The MS500 also allows for listening to Internet Sta-
tions when connected.
•Local AM/FM Radio Stations
The MS500 also allows for listening to AM/FM Sta-
tions via the Internet Connection.
•Select your Music
Listen to the music you want by creating your own
play lists and/or groups of music types.
•Digital Audio Outputs
There is a Coaxial and an Optical Digital Audio Out-
put (SPDIF) for connection to other components.
• Balanced and Unbalanced Analog Outputs
The MS500 has both Unbalanced Outputs and Bal-
anced Outputs which permit long cable lengths with-
out a loss in sound quality.
•Graphical User Interface
When connected to a TV/Monitor, the On Screen
Display provides information such as Album Name,
Artist Name, Song Name, Playing Time and Location
for each of the selections. This allows for easy song
selection from multiple rooms in your home.
• HD Video Outputs
The MS500 has HDMI and VGA Connections for
providing High Definition Video Signals of 1080p or
720p resolutions.
•On Screen Setup
The On Screen Setup allows for customizing various
settings such as audio, video, network and external
control to match the components in your system.
• Quiet Fan Less Operation
Enjoy your music even at low system volume settings.
• Power Control
The Power Control Input connection provides conve-
nient Turn-On/Off of the MS500 when connected to a
McIntosh System with Power Control.
• Remote Control
The Remote Control with illuminated push-buttons,
provides control of the MS500 operating functions. A
Data Port Connection to a McIntosh A/V Processor or
Preamplifier allows for convenient system operation
using one Remote Control. An External IR Sensor
Input allows for remote operation when the MS500 is
located behind closed doors.
• Illuminated Glass Front Panel
The famous McIntosh Glass Front Panel is evenly
illuminated by multiple extra long life Light Emitting
Diodes (LEDs), arranged with a special orientation.
The pristine beauty of the MS500 will be retained for
many years.
The McIntosh MS500 Music Streamer offers the latest
in audio technology, providing state of the art audio
reproduction with the convenience of instant access
to your music library. When the MS500 is added to a
McIntosh System, the music from this source may be
enjoyed in your home. The advanced design ensures
many years of smooth trouble free operation.

5
Dimensions
The following dimensions can assist in determining
the best location for your MS500.
Dimensions
Rear View of the MS500
Side View of the MS500
Front View of the MS500
17-1/2"
44.5cm
2-17/32"
6.4cm
3-9/32"
8.3cm 3-7/8"
9.8cm
17-1/32"
43.3cm
2-11/32"
6.0cm
13-1/4"
33.7cm
13"
33.0cm
12-1/16"
30.6cm
1-5/8"
4.1cm
29/32"
1.8cm
9-1/16"
23.0cm
1-3/8"
3.5cm
2-11/32"
6.0cm
MS500 MUSIC STREAMER

6
Installation
Installation
The MS500 can be placed upright on a table or
shelf, standing on its four feet. It also can be custom
installed in a piece of furniture or cabinet of your
choice. The four feet may be removed from the bottom
of the MS500 when it is custom installed as outlined
below. The four feet together with the mounting
screws should be retained for possible future use if the
MS500 is removed from the custom installation and
used free standing. The required panel cutout, ventila-
tion cutout and unit dimensions are shown.
Always provide adequate ventilation for your
MS500. Cool operation ensures the longest possible
operating life for any electronic instrument. Do not
install the MS500 directly above a heat generating
component such as a high powered amplifier. If all
the components are installed in a single cabinet, a
quiet running ventilation fan can be a definite asset in
maintaining all the system components at the coolest
possible operating temperature.
A custom cabinet installation should provide the
following minimum spacing dimensions for cool
operation.
Allow at least 3 inches (7.6cm) above the top, 2
inches (5.1cm) below the bottom and 1 inch (2.5cm)
on each side of the Music Streamer, so that airflow is
not obstructed. Allow 17 inches (43.2cm) depth behind
the front panel. Allow 29/32 of an inch (1.8cm) in
front of the front panel for clearance. Do not block the
openings on the top cover or the three rows of louvers
opening on the bottom of the MS500. Be sure to cut
out a ventilation hole in the mounting shelf according
to the dimensions in the drawing.
2-3/4"
7.0cm
17-1/8"
43.5cm
Cutout Opening for Custom Mounting
MS500 Front Panel
Custom Cabinet Cutout
Support
Shelf
Chassis
Spacers
MS500 Side View
in Custom Cabinet
MS500 Bottom View
in Custom Cabinet
14-17/32"
44.5cm
6-9/16"
16.7cm
2-27/32"
7.2cm
MS500 MUSIC STREAMER
Cabinet
Front
Panel
3"
7.6cm
Opening
for Ventilation
Note: Center the cutout Horizontally on the unit.
For purposes of clarity, the above
illustration is not drawn to scale.
2-19/32"
6.6cm
13/16"
2.0cm
Cutout Opening
for Ventilation
10-1/2"
26.7cm
11-7/8"
30.2cm
Cutout Opening for Ventilation

7
PWR CTRL (Power Control) IN re-
ceives turn-on signals from a McIn-
tosh component and POWER CON-
TROL OUT sends turn-on signals on
to another McIntosh Component
Connect the supplied
AC/DC Power Adapter
DC Output Connnector
IR IN for connecting
an IR Receiver
DATA IN receives control data
from a McIntosh Control Center
COAXial and OPTICAL AUDIO OUTPUTS
send a Digital Audio Signal to a Preamplifier
or an A/V Control Center with a D/A Con-
verter or a decoder
BALANCED AUDIO OUTPUTS
supply analog audio signals to
connect to Balanced Inputs of
other components
UNBALANCED AUDIO
OUTPUTS supply analog audio
signals to Unbalanced Inputs of
other components
Rear Panel Connections
USB (version 3.0) 1for connection of
an external storage device capable
of transferring data at high speed
HDMI (High-Definition Multimedia Inter-
face) Output (Audio and Video Digital Sig-
nals) for connecting to a HDTV or Monitor
with a HDMI Input with a video resolution
720p or 1080p
NETwork Connector for
connecting the MS500 to a
Broadband Ethernet Network
USB (version 2.0)1for connection of
an external storage device capable
of transferring data
USB (version 2.0) 1for connection of
an external storage device capable
of transferring data
VGA (Video Graphics Array) Ana-
log Video Output for connecting to
a TV or Monitor with a VGA Input
1One at a time, of the three USB Connectors on the MS500 has
the ability to output Digtal Audio Signal for music playback to
an external audio device compatible with USB current opera-
tional standards

8
Connect to the DC IN connector on
the Rear Panel of the MS500 Music
Streamer
Connect to a live AC outlet (always On)
using the supplied AC Power Cord. Re-
fer to information on the power supply
to determine the correct voltage.
The AC/DC Power Adapter supplied
with the MS500 Music Streamer
AC/DC Adapter power
On LED Indicator

9
AC/DC Adapter Connections and Notes

10
MS500 Connections
The MS500 has the ability to be remotely switched
On/Off from a McIntosh Preamplifier or A/V Proces-
sor via the Power Control connection. The MS500
Data Port Connection allows for the remote operation
of basic functions using the Preamplifier, Integrated
Amplifier or A/V Control Center Remote Control.
With an external sensor connected to the MS500, re-
mote control operation is possible from another room
and/or when the MS500 is located in a cabinet with
the doors closed.
The connection instructions below together with
the MS500 Connection Diagram on the next page is
an example of a typical audio or audio/video system.
Your system may vary from this, however the actual
components would be connected in a similar manner.
For additional information refer to “Connector and
Cable Information” on page 3.
Power Control Connections:
1. Connect a Control Cable from the Preamplifier,
Integrated Amplifier or A/V Processor Power
Control MAIN (or ACC) Jack to the PWR CTRL
(Power Control) IN Jack on the McIntosh MS500
Music Streamer.
2. Optionally, connect a Control Cable from the
MS500 Music Streamer PWR CTRL OUT Jack to
another component.
3. Connect any additional components in a similar
manner, as outlined in steps 1 thru 3.
Data Control Connections:
4. Connect a Control Cable from the Preamplifier,
Integrated Amplifier or A/V Processor Data Port
1 Jack to the McIntosh MS500 Music Streamer
DATA IN Jack.
Sensor Connections:
5. Optionally, connect an IR Sensor to the McIntosh
MS500 Music Streamer IR IN Jack.
Digital Audio Connections:
6. Optionally, connect a Cable from the McIntosh
MS500 Music Streamer AUDIO OUTPUT SPDIF
OPTICAL Output to the Digital Audio Input Opti-
cal 1 Input on the Preamplifier, Integrated Ampli-
fier or A/V Processor.
Note: Coaxial connections may be used instead of
the Optical Connections.
Analog Audio Connections:
7. Connect a Cable from the McIntosh MS500 Music
Streamer AUDIO OUTPUT BALANCED connec-
tors to the Preamplifier, Integrated Amplifier or
A/V Processor Balanced 1 Input connectors.
Note: Unbalanced connections may be used instead
of the Balanced Connections.
Digital Video Connections:
8. Connect a HDMI Cable between the HDMI Socket
on the Rear Panel of the MS500 Music Streamer to
a HDMI Input Socket on the HD Monitor/TV.
Notes: 1. If the Monitor/TV has a VGA Input and
no HDMI input, then connect a VGA
cable between the MS500 and the Moni-
tor/TV.
2. The MS500 HDMI Output Socket
provides Video Signals only. For Audio
Signal Playback, perform connections in
step 6 or 7.
Network Connections:
9. Using a CAT 5/6 Ethernet Cable, connect the cable
from the Router to the NET (Network) connector
on the Rear Panel of the MS500.
10. Optionally, connect another CAT 5/6 Ethernet
Cable from the Computer (Network Connector) to
the Router.
Note: For additional information on Networks and
Network Connections refer to the documenta-
tion supplied with the Router and Computer.
AC Power Cords Connections:
11. Locate the plug at the end of the cable coming out
of the supplied AC/DC Power Supply and connect
it to the DC Input connector on the Rear Panel of
the MS500 Music Streamer.
12. Connect the supplied AC Power Cord between the
socket on the AC/DC Power Supply and a live AC
outlet (that is always On).

11
MS500 Connections
Optional Computer
Network Router
(Wireless or Wired)
Preamplier
MS500 supplied
AC/DC
Power Supply
Connect to a
live AC Outlet
(always On)
Connect to a
live AC Outlet
(always On)
HD Monitor/TV
IR Sensor
(optional Digital Audio Connection)

12
MS500 MUSIC STREAMER
Front Panel Display and Push-button
STANDBY/ON Push-button with indicator
switches the MS500 ON or OFF (Standby)
and resets the microprocessors
IR Sensor receives commands
from a Remote Control

13
How to use the Remote Control
The Remote Control is capable of performing most
Operating Functions for the MS500 Music Streamer.
Note: Refer to the “How to Operate” Section of this
manual for additional information using this
Remote Control.
Dual Function Push-buttons
The five push-buttons located at the top/front of the
Remote Control, in the circular molded area, are dual
function. When music is playing, the (+) Push-button
increases the volume level1and the (-) Push-button
decreases the volume level1. Push the :Push-button
for the next selection or push the 9Push-button for
the previous selection.
During the time a MS500 Menu is being ac-
cessed, the push-buttons at the top/front of the Remote
Control provide the ability to navigate the menus and
select the desired choice or function. The (+) Push-but-
ton is used to move the cursor Up through the menu.
Likewise, the (-) Push-button is used to move Down.
The 9Push-button is used to move to the Left, the :
Push-button is used to move to the Right and the ►
Push-button is used to Select the highlighted choice.
1Adjusting the volume level using the Remote Con-
trol requires a change to the default setting located
in the Setup Mode, refer to pages 14 and 15 for ad-
ditional information.
How to use the Remote Control
SELECTS the cur-
rent menu item and
also starts playback
and pauses playback
Selects the previous
selection
Moves forward in time
through a selection
Momentarily
press to Power the
MS500 ON or OFF
Indicates when a
Remote Control
Command has been
sent
Selects the next
selection
Selects available
information
Selects a Menu
Current selection
is liked
Current selection
is disliked
Increases the
volume level
Decreases the
volume level
Directional Push-buttons; Ê(Up),▬(Down),
9(Left), :(Right)and►(SELECTS)
Reserved for
future use

14
Note: If the “Server IP Address” number appears
as 0.0.0.0, the MS500 was unable to obtain an
IP Address from the computer network. Power
down the MS500, wait several minutes and then
Switch it back On. If the MS500 is still unable
to obtain an IP Address, the default automatic
configuration setting (DHCP, Dynamic Host
Configuration Protocol) might have to be set
manually. Contact your Computer Dealer or
the Computer Manufacture for assistance.
3. Using a computer connected to the same network
as the MS500, launch the Internet Web Browser
Application and type in on the “URL-Address
line”, the following:
The IP Address Number written down in step 2
HTTP://__.__.___.___/config
Then press Enter on the computer keyboard. Refer to
figure S1. The Setup Tabs at the top of the window:
Setup Option Tabs Figure Number
Server Settings S1
Display Settings S2
Source Settings S3
Content S4
Schedule S5
Firmware S6
The McIntosh MS500 is factory configured for imme-
diate enjoyment of superb audio. If you wish to make
changes to the factory default settings, a Setup Feature
is provided to customize the operating settings using a
PC Computer (not supplied) and with the MS500 con-
nected to a HD Monitor/TV. Start the Setup Mode by
performing the following steps:
1. Press the MS500 Front Panel STANDBY/ON
Push-button or press the (Power) Push-button
on the Remote Control to switch On the MS500.
Refer to page 13 for information on using the
Remote Control. The LED above the STANDBY/
ON Push-button will illuminate. The MS500 will
go through a startup initialization which might
take upwards of 1.5 minutes with it connected to a
HD Monitor/TV indicating the progress. Refer to
figures 1 and 2.
2. When the initialization is completed, the opera-
tional screen will appear and in the upper left cor-
ner is the “Server IP Address: _ _ . _ _. ___. ___.
Write down the IP Address Number, as it will be
used in the next step. Refer to figure 3.
How to Operate the Setup Mode
Figure 1
Figure 2
Figure 3
IP Address location
Figure S1

15
Each of the tabs has subheadings with current settings
status information along with various setup options.
There are explanations located to the right of the vari-
ous options and settings.
4. Select “Display Settings”. Refer to figure S2.
5. To change the “Screen Resolution” from the defaut
setting of 720p to 1080p, click on the circle ahead
of “ 1080p 1920x1080”.
6. To implement the Setup change just made, Click
on the Display Settings Button “Save Changes”.
Then press the MS500 Front Panel STANDBY/ON
Push-button or press the (Power) Push-button
on the Remote Control to switch OFF the MS500.
7. Press the Front Panel STANDBY/ON Push-button
or press the (Power) Push-button on the Remote
Control to switch ON the MS500.
8. After any other changes have been made and
saved, proceed to “How to Operate” starting on
page 16.
Setup
Figure S2
Figure S3
Figure S4
Figure S5
Figure S6

16
Power On and Off
Your McIntosh MS500 has been factory configured
for default operating settings that will allow immedi-
ate enjoyment of superb audio without the need for
further adjustments. To make changes to the default
settings, refer to the Setup Mode on page 14.
1. Press the STANDBY/ON Push-button on the Front
Panel or press the (Power) Push-button on the
Remote Control to switch On the
MS500. Refer to figures 5, 6 and 7.
The LED above the STANDBY/ON
Push-button will start flashing dur-
ing the MS500 startup initialization
process, which might take upwards
of 30 seconds. The HD
Monitor/TV connected to
the MS500 will indicate
the startup initialization
procedure progress. Refer
to figures 8, 9 and 10.
2. To switch Off the MS500,
press the STANDBY/
ON Push-button on the
Front Panel or press the
(Power) Push-button on
the Remote Control. Refer
to figures 5 and 6.
the ▬(Down) Push-button on the Remote Con-
trol, select the “Music Menu” followed by pressing
the ►(SELECT) Push-button to select “Album
Menu”. Refer to figures 11 and 12.
2. Press the ►(SELECT) Push-button on the Re-
mote Control to view the available Albums. Refer
to figure 13.
3. Use the Ê(Up)or ▬(Down) Push-button on
the Remote Control to select the desired al-
bum. In this instance, select “Various Artists -
Beethoven:Symphonies Nos. 5&9 Choral; Piano
Concert”. Then press the ►(SELECT) Push-
button to select the album. Refer to figure 14.
Start Music Playback
Music was imported into the MS500 Music Streamer,
at the factory, for your enjoyment. To start listening to
the music, perform the following:
1. Press the (MENU) Push-button on the Remote
Control to select the Operation Menu. Then using
How to Operate the MS500
Figure 7
MS500 MUSIC STREAMER
Figure 6
Figure 5
MS500 MUSIC STREAMER
Figure 12
Figure 13
Figu re 11
Figure 8
Figure 9
Figure 10

17
There are many pre-setup Internet Radio Sites to
choose from, including Deezer, Murfie, Pandora In-
ternet Radio, SiriusXM Internet Radio, Slacker Radio,
Spotify, TIDAL, etc. Some Internet Radio Sites re-
quire registering and in some instances a subscription
fee in order to enjoy their music services. Using the
MS500 Setup Mode on pages 14 and 15, refer to the
Contents tab and then the Online Credentials for ad-
ditional information. In the following example, TuneIn
Radio will be selected to stream music from local FM/
AM radio stations.
3. Using the Ê(Up)or ▬(Down) Push-button on
the Remote Control, select TuneIn Radio from the
menu. Refer to figure 21.
4. Refer to figure 22 on the next page, then press
the ►(SELECTS) Push-button to select Local
Radio.
4. Referring to figure 15, the track for the album just
selected will appear. In this instance there is one
track “ Symphony No. 9 (Scherzo)”. Press the ►
(SELECT) Push-button on the Remote Control to
start playback of the first track. Refer to figure 16.
The TV/Monitor will start to display various scenes
while the music is playing. Refer to figures 17 and 18.
5. To pause playback of the music, press the ►(SE-
LECT) Push-button on the Remote Control. To
resume playback, just press the same Push-button
again. To see the status of the track currently play-
ing, press the MENU Push-button and refer to
information located at the bottom of the screen.
Refer to figure 15 and 16.
Figure 14
Figure 16
Figure 17
Figure 18
Figure 15
How to Stream Music
The MS500 Music Streamer provides access to virtu-
ally unlimited music by streaming music from the
Internet. To start streaming music from the Internet,
perform the following:
1. Press the (MENU) Push-button on the Re-
mote Control to select the Home Menu. Refer to
figure 19.
2. Press the ►(SELECTS) Push-button on the
Remote Control to select the “Streaming Menu”.
Refer to figure 20.
Figure 19
How to Operate the MS500
Figure 20
Figure 21

18
5. There are now menu choices AM, FM or Internet
only radio stations. Referring to figure 23, use
the Ê(Up)or or ▬(Down) Push-button to select
FM, followed by pressing the the ►(SELECTS)
Push-button.
6. Referring to figure 24, it follows the same proce-
dure as in step 5, select the fourth choice, “89.3
WSKG-FM (Classical Music)”. The sound from
the station will start, refer to figure 25.
Note: The operation of the MS500 using the Web
Browser is similar to using the MS500 con-
nected to a monitor/TV along with the supplied
Remote Control. The major difference is the
computer pointing device (mouse) is used for
selection and navigation.
On the left side is a column of buttons for select-
ing music sources (Streaming, Local Music, Favorites,
Playlists and Queue) along with Back and Next control
commands. Along the bottom are buttons for standard
control functions such as Previous, Play, Pause, Next,
Shuffle and Replay.
After the MS500 has powered up and completed
initialization, the IP Address assigned to the Music
Streamer will appear in the upper left corner. Refer to
figure 26.
1. Using a computer connected to the same network
as the MS500, launch an Internet Web Browser
Application (such as Windows Internet Explorer).
Type in on the “URL-Address line” the following:
The IP Address Number
HTTP://__.__.___.___/MediaBridge
2. A connection progress indicator will appear in the
Web Browser. Refer to figure 27.
3. When the connecting process is completed, the-
Music Streamer interface will appear in the Web
Browser. Refer to figure 28.
Figure 27
How to Operate the MS500 via a Computer
How to Operate the MS500, con’t
Figure 28
Figure 22
Figure 23
Figure 24
Figure 25
Figure 26
IP Address Location

19
3. Referring to figure 34, select the second choice,
“89.3 WSKG-FM (classical)”. The sound from the
station will start and figure 35 will appear.
How to Stream Music
The MS500 Music Streamer provides access to viru-
ally unlimited music by streaming music from the
Internet. To start streaming music from the Internet,
perform the following:
1. Click on the Streaming button and the Radio
sources menu will appear. Refer to figure 31.
In the following example TuneIn Radio will be select-
ed to stream music from local FM/AM radio stations.
2. Select and click on TuneIn Radio. Click on Local
Radio followed by selecting FM. Refer to figures
32 and 33.
How to Playback Music
McIntosh Music was imported into the MS500, at the
factory, for your enjoyment. To start listening to the
music, perform the following:
1. Click on the Local Music button. Refer to
figure 28.
2. Click on “Albums”, then select “Beethoven”. Refer
to figure 29.
3. Click on the track listing of “1 Symphony No. 9
(Scherzo) 1:15” and click on “Play now”. Refer to
figures 29 and 30.
4. Return to the previous menu selection of “Play
now, Play next, Replace queue, Add to queue or
Add to playlist” by clicking on the Track (Name)
currently playing.
How to Operate the MS500, con’t
Figure 29
Figure 30
Figure 31
Figure 32
Figure 33
Figure 34
Figure 35

20
to activate the chosen choice. Refer to figures 38,
39 and 40
Using External Drives with the MS500
The MS500 has three different uses for connected
External Drives “ADD, IMPORT or MOUNT”. Before
proceeding with the steps below, switch power Off to
the MS500. Then connect the External Drive (HDD,
SDD or USB Flash Memory) to an USB connector on
the Rear Panel of the MS500. After the MS500 has
powered up and completed initialization, note the IP
Address in the upper left corner.
1. Using a computer connected to the same network
as the MS500, launch an Internet Web Browser
Application (such as Windows Internet Explorer).
Type in on the “URL-Address line” the following:
The IP Address Number
HTTP://__.__.___.___/config
2. Then press enter on the computer keyboard. Refer
to figure 36 (partial view).
3. Click on the “Content” Tab (located along the
top), then scroll down to “Storage”. Referring to
figure 37, the three options for the external USB
Connected Drive appears next to the “Free” Space
Listing. The option choices include “ADD, IM-
PORT or MOUNT”. When any one three choices
are selected, a new window will appear explaining
the functioning, any possible limitations and “OK”
How to Operate the MS500, con’t
Figure 38
Figure 37
MS500 Internal Drive
Name assigned to
the connected
External USB Drive
Three operational
options available for
the connected
External USB Drive
Figure 36 (partial view)
Content Tab
Figure 39
Figure 40
ADD External Storage Space to the MS500
With an Externa1 USB Drive connected to one of the
MS500 Rear Panel USB Connectors, the “ADD” op-
tion will become available.
Note: Do not remove the external drive after the
“ADD” option is activated.
1. Start the ADD process by clicking on the button
“OK, Add the volume”. Refer to figure 38 and then
figure 41.
2. When the external drive is to be removed from
the MS500, select “Remove from server” and then
start the remove process by clicking on the button
“OK, Remove the volume”. Refer to figures 42
and 43.
Fig ure 41
Figure 43
Figure 42
