MCS MCS-8 User manual

MCS-8
INSTALLATION GUIDE

M
DX00008
MCS-8 Installation Guide 1V3
Page 2 of 10
CONTENTS
1) Pre-Installation & Required Tools ................................................................................................. 3
1.1) Crimping Tools.................................................................................................................. 3
1.2) Replacement Pins .............................................................................................................. 3
2) Mounting ........................................................................................................................... 4
3) Wiring ............................................................................................................................... 5
3.1) Speaker Outputs (CON1) ................................................................................................... 5
3.1.1) Bypass Diode Outputs (CON2) .......................................................................................... 5
3.1.2) Power Inputs (CON3) ........................................................................................................ 5
3.1.3) Auxiliary I/O’s (CON4) ..................................................................................................... 6
3.1.4) Lin Bus (Con5) .................................................................................................................. 7
3.1.5) CAN Bus (Con6) ............................................................................................................... 7
NOTE: For compatibility reasons, adapters that plug into the MCS-8 CAN Bus (Con6) Connector are
typically 6 way. These are designed to fit into the 8 way connector. .......................................................... 7
3.1.6) RS485 (Con7) .................................................................................................................... 7
3.1.7) USB (Con8) ....................................................................................................................... 8
4) Diagnostics ................................................................................................................................... 8
5) Volume Setting ............................................................................................................................. 9
6) Installation Requirements .............................................................................................................. 9
7) Version History ............................................................................................................................. 9

M
DX00008
MCS-8 Installation Guide 1V3
Page 3 of 10
1) Pre-Installation & Required Tools
1.1) Crimping Tools
CTX64 Receptacle 6A Female Pin Crimp Tool
Molex part number: 63819-3800
 http://www.digikey.co.uk/ Part Number: 0638193800-ND
 http://www.mouser.co.uk Part Number: 538-63819-3800
 http://www.ttieurope.com Part Number: 63811-1000
Universal Molex Crimp Tool. (Can be used for all connectors)
Molex part number: 0638111000
 http://www.digikey.co.uk/ Part Number: WM9999-ND
 http://www.mouser.co.uk Part Number: 538-63811-1000
 http://uk.rs-online.com/ Part Number: 710-6499
 http://www.ttieurope.com Part Number: 63811-1000
1.2) Replacement Pins
Senior Fit Female - 0428150134
 http://www.digikey.co.uk/ Part Number: 0428150134-ND
 http://www.mouser.co.uk Part Number: 538-42815-0134
Mini Fit Female - 50-34-8582 or 0039000211
 http://www.digikey.co.uk/ Part Number: 0050348582-ND or WM14176CT-ND
 http://www.mouser.co.uk Part Number: 538-50-34-8582
Mate n’ Lock Male - 350561-2
 http://www.digikey.co.uk/ Part Number: A14299CT-ND
 http://www.mouser.co.uk Part Number: 571-350561-2-CT
 http://www.ttieurope.com Part Number: 350561-2
CTX64 Large Female - 1326030-4
 http://www.digikey.co.uk/ Part Number: 1326030-4-ND
 http://www.mouser.co.uk Part Number: 571-1326030-4-CT
 http://www.ttieurope.com Part Number: 1326030-4 (Min 6900)
CTX64 Small Female - 34803-3212
 http://www.digikey.co.uk/ Part Number: WM16246CT-ND
 http://www.mouser.co.uk Part Number: 538-34803-3212-CT
 http://uk.rs-online.com/ Part Number: 842-8181
 http://www.ttieurope.com Part Number: 0348033212 (Min 60 000)

M
DX00008
MCS-8 Installation Guide 1V3
Page 4 of 10
2) Mounting
4 x M4 holes are supplied for mounting the unit to a base panel.

M
DX00008
MCS-8 Installation Guide 1V3
Page 5 of 10
3) Wiring
Power In and I/O’s
3.1) Speaker Outputs (CON1)
Pin
Name
Function
1 Low Low output to an 8 or 11 ohm speaker
2 Low Low output to an 8 or 11 ohm speaker
3 High High output to an 8 or 11 ohm speaker
4 High High output to an 8 or 11 ohm speaker
3.1.1) Bypass Diode Outputs (CON2)
Pin Name Connector Supply Polarity switching Current Max / Output
1 Bypass 1 4 pin 3 Bank B Positive output 10 Amps
2 Bypass 2 4 pin 4 Bank A Positive output 10 Amps
3.1.2) Power Inputs (CON3)
Pin
Name
Fun
ction
1 Secondary Batt
Bank B
Power Supply to B-Bank Outputs
2 Primary Batt Power supply to input voltage sense for primary battery.
3 Ground System Ground \ Chassis
4 Secondary Batt
Bank A
Power Supply to A-Bank Outputs and the Siren.

M
DX00008
MCS-8 Installation Guide 1V3
Page 6 of 10
3.1.3) Auxiliary I/O’s (CON4)
Pin Name Function Supply
High Power
Outputs
1
Output 1
Programmable Positive Switching Output
Secondary Batt
Bank A
2 Output 2 Programmable Positive Switching Output Primary Batt
3 Output 3 Programmable Positive Switching Output Secondary Batt
Bank B
4 Output 4 Programmable Positive Switching Output Secondary Batt
Bank B
Low Power
Outputs
IP1 Output / Input 1 Low power output 1 or assignable input 1 Bank A
IP2
Output / Input 2
Low power output 2 or assignable
input 2
Bank A
IP3
Output / Input 3
Low power output 3 or assignable input 3
Bank B
IP4 Output / Input 4 Low power output 4 or assignable input 4 Bank B
Programmable
Inputs
IP5 Input 5 Negative or Positive assignable switching
input 5
IP6 Input 6 Negative or Positive assignable switching
input 6
IP7
Input 7
Negative or Positive assignable switching
input 7
IP8
Input 8
Negative or Positive assignable switching
input 8
IP9
Input 9
Negative or Positive assignable switching
input 9
IP10
Input 10
Negative or Positive assignable switching
input 10

M
DX00008
MCS-8 Installation Guide 1V3
Page 7 of 10
Inputs and Peripherals
3.1.4) Lin Bus (Con5)
Pin
Name
Function
1
Lin
Lin Bus for automotive low speed communication modules
2 Mic In Audio in LIN peripheral
3 Ground
4 Supply Output 1200mA fused output supply for peripherals
3.1.5) CAN Bus (Con6)
Pin Name Function
1 Supply Output 1200mA fused output supply for peripherals common to LIN supply
2 CAN 1 High Use CAN1 with MCS System Handsets and Expansion Modules
3 CAN 1 Low
4
Radio Audio
Radio re
-
broadcast audio
5
Ground
6
CAN 2 High
Use CAN2 with Vehicle CAN Only.
7 CAN 2 Low
8 Mic in Audio in from handset
NOTE: For compatibility reasons, adapters that plug into the MCS-8 CAN Bus (Con6)
Connector are typically 6 way. These are designed to fit into the 8 way connector.
3.1.6) RS485 (Con7)
Pin
Name
Function
1
Microphone Input
2 Ground Common
3 B RS485 Data
4 A RS485 Data

M
DX00008
MCS-8 Installation Guide 1V3
Page 8 of 10
5 12VDC 12V Supply Output 1000mA Max.
6
PTT Sw
PTT Active Low.
3.1.7) USB (Con8)
4) Diagnostics
POWER /
STANDBY
Red (Steady): Device in use, normal power mode.
Red (Flashing): Over Temperature.
Amber: Device idle, ready for low power mode.
Steady Green: Shutting down.
Green Pulse: Standby / Low Power Mode
SIREN Off: Siren has not been configured in software
Slow Pulsing Green: Siren in in low power standby mode (Not enabled)
Fast Pulsing Green: Siren is internally powered and ready to operate
Green: Siren output is operating (speaker is sounding)
Red: Over-current Safety – Siren system disabled (reset required)
Amber: Low voltage dropout (the siren is disabled because supply is too low)
LOCAL
CAN
Off: No local CAN devices in use
Green: All local CAN devices ok
Red: One or more local CAN devices faulty
EXT. CAN Off: Vehicle CAN not in use
Green: Vehicle CAN detected
Red: Vehicle CAN not detected
INPUTS Indicates the state of any input 1 through 10
OUTPUTS
Indicates the state of any output LP1
-
LP4 and HP1
-
HP4

M
DX00008
MCS-8 Installation Guide 1V3
Page 9 of 10
5) Volume Setting
To set the volume levels for the MCS-8, follow the following procedure:
5.1) Left volume knob is for Mic in and increases volume in a clockwise direction
5.2) Right volume knob is for Radio re-broadcast and increases the volume in a clockwise direction.
5.3) Knobs can be removed once volume has been set to prevent tampering.
5.4) Knobs are on the same side as the CAN and LIN Bus connectors.
6) Installation Requirements
6.1) Both the Bank A and Bank B Supply lines MUST be protected by a fuse, rated 40 Amp or less,
preferably at (or near to) the battery terminal.
6.2) If the primary sense input is used, the input MUST be protected by a fuse, rated 20A or less,
preferably at (or near to) the primary battery terminal.
6.3) DO NOT obstruct fan vents along the top, side or under surfaces of the MCS-8. Do not install
any equipment on top or underneath the MCS-8.
The above installation requirement must be followed for safe operating and extended product
lifetime
7) Version History
Current Word Revision: 11
Version Word
Revision
Changes Responsible
Person(s)
Date
1V0 Initial document release SW 16 Oct
2017
1V1 5 Updates to revision system & minor corrections. GH 17 Oct
2017
1V2
10
Cover Image Updated
GH
18 Oct
2017
1V3
11
Corrected output supply notes.
Renamed ignition sense primary.
Noted CAN 6 Way / 8Way connection.
GH
31 Aug
2018
