MCZ ALEA AIR 7 S1 User manual

INSTALLATION GUIDE GB
SEALED PELLET STOVE
ALEA AIR 7 S1
Instructions in English

II
TABLE OF CONTENTS
TABLE OF CONTENTS .................................................................................................. II
INTRODUCTION ..........................................................................................................1
1WARNINGS AND WARRANTY CONDITIONS .................................................................2
2INSTALLATION.........................................................................................................9
3DRAWINGS AND TECHNICAL SPECIFICATIONS ..........................................................18
4UNPACKING...........................................................................................................21
5 SMOKE OUTLET.....................................................................................................23
6INSTALLATION AND ASSEMBLY ...............................................................................25
7OPENING THE DOORS .............................................................................................29
8CONNECTION TO ADDITIONAL DEVICES....................................................................30
9LOADING THE PELLETS ...........................................................................................31
10ELECTRICAL CONNECTION.....................................................................................32
11FIRST STARTUP...................................................................................................33
12CONTROL PANEL ..................................................................................................35
13MENU ENTRIES AND OPERATION...........................................................................36
14SAFETY DEVICES ..................................................................................................44
15ALARMS ..............................................................................................................45
16RECOMMENDATIONS FOR SAFE USE.......................................................................50
17CLEANING ...........................................................................................................51
18FAULTS/CAUSES/SOLUTIONS.................................................................................58
19CIRCUIT BOARD ...................................................................................................60

1
INTRODUCTION
Technical Dept. - All rights reserved - Reproduction prohibited
Dear Customer,
Our products are designed and manufactured in accordance with standards in force, with high quality materials and using our extensive
experience in the transformation processes.
To get the best performance, we suggest you read the instructions in this manual carefully.
This installation guide is an integral part of the product: ensure that the manual is always supplied with the appliance, even if it changes
owner. If the manual is lost, you can request another copy from the local Technical Dept. or download it directly from the company’s
website.
All local regulations, including those referring to national and European standards, must be observed when installing the appliance.
In Italy, for the installation of systems with a biomass below 35KW, refer to the Ministerial Decree 37/08 and the qualied installation
technician with the suitable requirements must issue a certicate of compliance for the system installed. (By system we intend
Stove+Flue+Air inlet).
REVISIONS TO THE PUBLICATION
The content of this manual is strictly technical and the property of MCZ Group Spa.
No part of this manual may be translated into other languages, adapted and/or reproduced, even in part, in other mechanical and/or
electronic form or media, for photocopies, recordings or other, without the prior written authorisation of MCZ Group Spa.
The company reserves the right to make changes to the product at any time without prior notice.The owner company reserves its rights
according to law.
CARE OF THE MANUAL AND HOW TO CONSULT IT
•Take care of this manual and store it in an easily and quickly accessible place.
•Should this manual be lost or destroyed, request a copy from your retailer or directly from the authorised Technical assistance
department. It can also be downloaded from the company’s website.
•“Bold text”requires special attention.
•“Text in italics”is used to draw attention to other paragraphs in the manual or for any additional clarications.
•“Note”provides the reader with additional information.
SYMBOLS USED IN THE MANUAL
ATTENTION:
carefully read the relative message as failure to comply with the information provided may result in
serious damage to the product and danger to the persons who use it.
INFORMATION:
failure to comply with these provisions will compromise use of the product.
OPERATING SEQUENCES:
sequence of buttons to be pressed to access the menus or perform adjustments.
MANUAL
carefully read this manual or the relative instructions.

2
1-WARNINGS ANDWARRANTY CONDITIONS
SAFETY PRECAUTIONS
•Installation, electrical connection, operating check and maintenance
must only be carried out by authorised and qualied personnel.
•Installthe product inaccordancewithall local andnational legislation
and regulations in force in the region or state.
•Only use the fuel recommended by the manufacturer. The product must not be
used as an incinerator.
•It is strictly forbidden to use alcohol, petrol, liquid fuel for lanterns, diesel, bio-
ethanol, uids for lighting charcoal or similar liquids to light/rekindle the ame
in these devices. Keep these ammable liquids well away from the appliance
when in use.
•Do not put any fuel other than wood pellets in the hopper.
•The instructions provided in this manual must always be complied with to
ensure the product and any electronic appliances connected to it are used
correctly and to prevent accidents.
•This appliance can be used by children aged 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge provided they are supervised or have
been given instructions regarding use of the appliance in a safe way
and understand the hazards involved. Children must not play with the
appliance. Cleaning and maintenance to be performed by the user
must not be carried out by children without supervision.
•The user, or whoever is operating the product, must read and fully understand
the contents of this installation guide before performing any operation. Errors or
incorrect settings may cause hazardous conditions and/or incorrect operation.
•Do not climb on or lean on the product.

3
1-WARNINGS ANDWARRANTY CONDITIONS
Technical Dept. - All rights reserved - Reproduction prohibited
•Do not dry laundry on the product. Any drying racks or the like must be kept at
a safe distance from the product. Fire hazard.
•All liability for improper use of the product is entirely borne by the user and relieves
the manufacturer of any civil and criminal liability.
•Any type of tampering or unauthorised replacement with non-original spare
parts may be hazardous for the operator’s safety and relieves the company of
any civil and criminal liability.
•Many surfaces of the product get very hot (door, handle, glass, smoke outlet
pipes, etc.). Avoid coming into contact with these parts without
adequate protective clothing or suitable equipment, such as gloves
with thermal protection or“cold handle”operating systems.
•It is forbidden to operate the product with the door open or the glass
broken.
•The doors/covers on the appliance must remain closed when it is not
being used.
•The product must be powered by an electrical system that is equipped with an
eective earthing device.
•Switch the product o in the event of a fault or malfunction.
•Accumulated unburnt pellets in the burner after each“failed ignition”must be
removed before lighting again. Check that the burner is clean and positioned
properly before lighting again.
•Do not wash the product with water. Water may penetrate inside the unit and
damage the electrical insulation and cause electric shocks.
•Do not stand for a long time in front of the product in operation. Do not overheat
the room you are in and where the product is installed. This may harm one’s
physical conditions and cause health problems.
•Install the product in rooms that do not pose a re hazard and are equipped
with power and air supplies and smoke outlets.
•In the event of re in the chimney, turn o the device, disconnect it from the
mains and do not open the door whatsoever. Then contact the competent
authorities.
•The product and the cladding must be stored in a dry place and must not be

4
1-WARNINGS ANDWARRANTY CONDITIONS
exposed to weathering.
•It is recommended not to remove the feet that support the product in order
to ensure adequate insulation, especially if the ooring is made of ammable
materials.
•In the event of a malfunction of the ignition system, do not force it on by using
ammable materials.
•Special maintenance must only be performed by authorised and qualied
personnel.
•Assess the static conditions of the surface on which the weight of the product
will rest and provide suitable insulation if it is made of ammable material (e.g.
wood, tted carpet or plastic).
•Live electrical parts: only power the product once it has been fully assembled.
•Disconnect the product from the 230V power supply before performing any
maintenance operations.
•Improperuseorpoormaintenanceoftheproductcancausehazardoussituations
to develop.
•It is forbidden to manually load the fuel into the brazier. Failure to
follow this warning can lead to hazardous situations.
•Before the product is restarted, always remove any unburnt pellets
building up in the brazier due to failed ignition, the emptying of the
hopper or any situation that may cause this condition.

5
1-WARNINGS ANDWARRANTY CONDITIONS
Technical Dept. - All rights reserved - Reproduction prohibited
INFORMATION:
Please contact the retailer or qualied personnel authorised by the company to resolve a problem.
•Only use the fuel specied by the manufacturer.
•When the product is switched on for the rst time, it is normal for it to emit smoke due to the paint heating up for the rst time.
Therefore make sure the room it is installed in is well-ventilated.
•Check and clean the smoke outlet pipes regularly (chimney tting).
•The product is not a cooking appliance.
•Always keep the cover of the fuel hopper closed.
•Store this installation and user manual with care as it must accompany the product for the duration of its useful life. If the product is
sold or transferred to another user, always ensure the manual is also handed over.
INTENDED USE
The product only works with wood pellets and must be installed indoors.
PRODUCT PERFORMANCE CHECKS.
All our products undergo ITT TESTS carried out by a notied laboratory (system 3) and in accordance with (EU) Regulation number
305/2011“Construction products”, according to standard EN 14785:2006 (pellets) and“Machinery Directive”EN 303-5 (boilers).
In the case of tests for any market surveillance or inspections by third parties, please consider the following warnings:
•to reach the declared performance levels, the product must perform an operating cycle of at least 15/20 hours beforehand
•use the average draught of the combustion smoke specied in the“product technical specications”table
•the type of pellets used must comply with current EN ISO 17225-2 regulations
•the amount of fuel may vary according to the length and caloric value of the fuel. This may require some adjustments to stay in
line with the hourly consumption specied in the“product technical specications”table. A1 pellets ensure an overall caloric value
within tight margins compared to the test pellets used. However, size considerably aects performance, therefore on average it must
not be less than 24 mm long and with a 6mm diameter
•in the case of a wood-burning product, check the correct residual moisture content of the fuel, which must not be less than 12% or
more than 20%. As the moisture increases, dierent combustion air settings are required. The settings are to be carried out via the
combustion air register, thereby modifying the mixture between primary and secondary air
•it is required to check the operation of devices that can aect performance (for example air fans or electrical safety devices) in case
of damage due to handling.
•maximum performance can be achieved at the maximum ame and ventilation power.
•strictly comply with the withdrawal points required by regulations both in terms of emissions and temperature.
WARRANTY CONDITIONS
The company guarantees the product, with the exception of parts subject to normal wear (listed on the following page), for a
period of 2 (two) years from the date of purchase attested by:
•a document that serves as proof of purchase (invoice and/or receipt) that shows the name of the vendor and the date that the
purchase was made on;
•forwarding of the completed warranty certicate within 8 days of purchase.
Furthermore, in order for the warranty to be valid, the device must be installed and calibrated by qualied personnel, and where necessary,
the user must be issued with a declaration of conformity and correct product operation.
We recommend performing a functional test of the product before completion with the relative nishes, if applicable (claddings, painting
of walls, etc.).
Installations that do not meet the current standards, improper use and lack of maintenance as required by the manufacturer, void the
product warranty.
The warranty is valid on the condition that the instructions and warnings contained in the user and maintenance manual are observed,

6
1-WARNINGS ANDWARRANTY CONDITIONS
and therefore the product is used correctly.
Replacement of the entire system or repair of one of its components does not extend the warranty period, and the original expiry date
remains unchanged.
The warranty covers the replacement or free repair of parts recognised as being faulty at source due to manufacturing defects.
In the event of a fault, to benet from the warranty, the customer must keep the warranty certicate and provide it along with the
document given at the time of purchase to the Technical Service Centre.
EXCLUSIONS
The warranty does not cover malfunctions and/or damage to the appliance that arise due to the following causes:
•Damage caused during transport and/or handling
•all parts that develop faults due to negligence or improper use, incorrect maintenance, installation that does not comply with the
manufacturer’s instructions (always refer to the installation guide provided with the appliance)
•incorrect sizing with regard to the use or faults in the installation or failure to implement the necessary measures to ensure proper
execution
•improper overheating of the equipment, i.e. the use of fuels not conforming to the types and quantities indicated in the provided
instructions
•further damage caused by incorrect user operations in an attempt to x the initial fault
•worsening of the damage caused by the user continuing to operate the appliance even after the fault has been detected
•in the presence of a boiler, any corrosion, deposits or breakage caused by water ow, condensation, hardness or acidity of the water,
improperly performed descaling treatments, water outage, mud or limescale deposits
•ineciency of chimneys, ues or parts of the system aecting the appliance
•damage caused by tampering with the appliance, atmospheric agents, natural disasters, vandalism, electrical discharges, res, faults
in the electric and/or hydraulic system.
•Failure to have yearly stove maintenance performed by an authorised technician or qualied personnel shall render the warranty
void.
The following are also excluded from this warranty:
•parts subject to normal wear such as gaskets, glass, cladding and cast iron grilles, painted, chrome-plated or gilded parts, handles
and electric cables, bulbs, indicator lights, knobs, all parts which can be removed from the rebox.
•Variations in colour of the painted or ceramic/serpentine parts and crazed ceramics as they are natural characteristics of the material
and product use.
•masonry work
•system parts (if included) not supplied by the manufacturer
Any technical operations on the product to remove the aforementioned defects and consequent damage must be agreed upon with the
Technical Service Centre, who reserves the right to accept the relative job or not. However, said operations shall not be carried out under
warranty but as technical support to be granted as part of any potentially and specically agreed conditions and in accordance with the
fees in force for the work to be carried out.
The user will also be charged for any costs incurred to remedy the incorrect technical operations, tampering or damage to the appliance,
not attributable to original faults.
Without prejudice to the legal or regulatory limits, the warranty does not cover the containment of atmospheric and acoustic pollution.
The company declines all liability for any damage which may be caused, directly or indirectly, to persons, animals or objects as
a consequence of non compliance with any provision specied in the manual, especially warnings regarding installation, use
and maintenance of the appliance.

7
1-WARNINGS ANDWARRANTY CONDITIONS
Technical Dept. - All rights reserved - Reproduction prohibited
SPARE PARTS
In the event of a malfunction, consult the retailer who shall forward the call to the Technical Assistance Department.
Only use original spare parts. The retailer or service centre can provide all necessary information regarding spare parts. We do not
recommend waiting for the parts to get worn out before having them replaced. It is crucial to perform regular maintenance checks.
The company declines all liability if the product and any other accessory is used improperly or modied without
authorisation.
All parts must be replaced with original spare parts.
Information for management of waste electrical and electronic equipment containing batteries and
accumulators
This symbol appears on the product, on the batteries, on the accumulators or on their packaging or on their documentation; it indicates
that the product and the batteries or the accumulators included must not be collected, recycled or disposed of with household waste at
the end of their service life.
Improper management of waste electrical and electronic equipment, batteries or accumulators can cause the hazardous substances
contained within to leak out. In order to avoid harming the environment or health, the user is required to separate this equipment, and/
or the batteries or accumulators included, from other types of waste and deliver them to the local collection centre. The distributor can
be asked to collect the waste electrical and electronic equipment under the conditions and according to the procedures laid down by
Legislative Decree 49/2014.
Separate collection and correct treatment of waste electrical and electronic equipment, batteries and accumulators contribute to
conserving natural resources, respect for the environment and ensure the protection of health.
For more information on collection centres for waste electrical and electronic equipment, batteries and accumulators, contact the
competent public Authorities for issue of the authorisations.
WHY SEALED
Products built with a perfectly sealed structure do not consume the room’s oxygen but draw all the air from the outer environment (if
suitably ducted) and may therefore be installed in all houses that require a high degree of insulation such as “passive” or “high energy
eciency”houses. Thanks to this technology there is no risk of smoke emissions in the room, hence no air inlets and relevant ventilation
grilles are required in the installation premises.
Consequently, there will be no more draughts of cold air in the room, which would otherwise make it less comfortable and reduce the
overall eciency of the system.The sealed stove may even be installed in the presence of forced ventilation or in premises that might have
negative pressure with respect to the outside.

8
1-WARNINGS ANDWARRANTY CONDITIONS
Our solid bio-combustible products, (hereinafter called “Products”) are designed and manufactured in compliance with one of the
following European standard harmonised to Regulation (UE) no. 305/2011 for construction products:
EN 14785:“Residential space heating appliances red by wood pellets”
EN 13240:“Roomheaters red by solid fuel.”
EN 13229:“Inset appliances including open res red by solid fuels”
EN 12815:“Residential cookers red by solid fuel”
The products also comply with the essential requirements of Directive 2009/125/EC (Eco Design) and, where applicable, Directives:
2014/35/EU (LVD - Low Voltage directive)
2014/30/EU (EMC - Electromagnetic Compatibility directive)
2014/53/EU (RED – Radio Equipment directive)
2011/65/EU (ROhS)
Having specied the above, we highlight and report that:
•This manual and technical data sheet, also available on our website, bear all of the specic indications and necessary and
essential information to choose the product, to install it correctly and to properly size the smoke expulsion system;
•the Products must be installed, controlled and serviced by qualied personnel, according to the instructions in this manual
and in compliance with local laws and installation and maintenance standards in force in individual countries, so as to provide an
ecient heating system, properly sized according to the needs of the home;
•if the Products are thermally stressed, constantly operating for several hours at high power (e.g. 3, 4 hours a day at outputs P4
or P5), we recommend more frequent cleaning and reducing the interval between routine maintenance operations according to the
operating condition of the product. We furthermore point out that these operating conditions increase the risk of premature wear of
the product, especially those parts exposed to the direct heat of the re (e.g. combustion chamber), the original condition of which
can undergo modications and deterioration which, among other things, could generate noise during operation of the unit due to
mechanical expansion.
The manufacturer will not be held liable if the above information is ignored.
We therefore recommend, in addition to complying with the cleaning, routine and extraordinary maintenance instructions provided, to
make meticulous use of the unit using the intended Timer and modulation programs, to correctly manage the internal temperature of
the structure.
