MDC CRUIZER SLIDE User manual

Copyright © Market Direct Group Pty Ltd 2021 All Rights Reserved
Phone: [phone]
OWNER’S MANUAL
EDITION: 2021 - Version 1
CRUIZER SLIDE
FORWARD FOLD OFFROAD CAMPER
www.marketdirect.com.au
* January 2020 AU Model shown.

Contentswww.marketdirect.com.au Ph: 1300 494 494
Contents
Use of Product .......................................................................1
Servicing...................................................................................1
My Cruizer Slide....................................................................1
Section 1. Introduction.......................................................2
Terminology & Abbreviations..........................................3
Tow vehicle and Trailer Compatibility ..........................3
Specications .........................................................................4
Store Locations......................................................................5
Contact Details......................................................................5
Safety Information ...............................................................6
Jacking Your Camper ..........................................................7
Electrical Safety ....................................................................8
Vehicle Electrical Requirements.....................................9
Brake Controller ...................................................................9
Correct Vehicle Wiring for MDC Campers ................9
Trailer Lights Australia..................................................... 10
Charging Camper............................................................... 10
Vehicle with smart alternator ....................................... 10
Gas & Appliance Safety ................................................... 11
Gas Certication................................................................ 11
General Safety .................................................................... 11
Gas Cylinder Safety .......................................................... 11
Rated Shackles.................................................................... 12
Attaching Chains................................................................ 12
Connecting the Electrics................................................. 12
Connecting the Breakaway ........................................... 12
Using the Camper.............................................................. 13
Load Distribution Guide.................................................. 13
Ball Weight........................................................................... 13
Effects of Weight Distribution ..................................... 13
Tyre Pressures .................................................................... 14
Pre-Trip Inspection............................................................ 14
Tyres ....................................................................................... 14
Wheel Nuts.......................................................................... 14
Hitch and Chains................................................................ 14
Fire Extinguisher................................................................ 14
Brakes & Breakaway System......................................... 14
Lights ...................................................................................... 14
Hitches................................................................................... 15
Towing with Trucks ........................................................... 15
Hitch ....................................................................................... 15
How to Hitch your coupling........................................... 16
Coupling ................................................................................ 18
Uncoupling ........................................................................... 20
Canvas Care......................................................................... 21
Seasoning the Canvas ...................................................... 21
Protecting Seams and Screens ..................................... 21
Zipper Care .......................................................................... 21
Protecting from Mould.................................................... 21
Setting up your Camper.................................................. 22
Choosing a Spot to Set Up.............................................. 22
Levelling Your Camper..................................................... 22
Site Power............................................................................. 22
Using Wheel Chocks and Ramps ................................. 23
Operating the Jockey Wheel ........................................ 23
Pole Diagram....................................................................... 24
Preparing for Bad Weather ........................................... 25
High Winds........................................................................... 25
Packing Away Your Camper .......................................... 26
Storage & Care.................................................................... 27
Long Term Storage ............................................................ 27
Interior................................................................................... 27
Exterior.................................................................................. 27
Care of Paint and Surfaces............................................. 27
Paintwork ............................................................................. 27
Washing................................................................................. 27
Polishing ................................................................................ 27
Protection............................................................................. 27
Internal Surfaces................................................................ 27
Securing Your Camper..................................................... 28
Maintenance........................................................................ 28
Camper Body Maintenance........................................... 28
Locks and Latches ............................................................. 28
Rubber Seals........................................................................ 28
Sealants ................................................................................. 28
Mechanical Maintenance ............................................... 29
Wheels and Tyres .............................................................. 29
Brakes .................................................................................... 29
Bearings and Seals............................................................. 29
Suspension ........................................................................... 29
Torque Settings ..................................................................30
Wheel Nuts..........................................................................30
Hitch .......................................................................................30
Trailing Arm Pivot Bolts...................................................30

Contentswww.marketdirect.com.au Ph: 1300 494 494
Brakes and Handbrake - Electric................................. 31
Features................................................................................. 31
Operation ............................................................................. 31
Hand Brake .......................................................................... 31
Adjuster Cable Type ......................................................... 31
Adjuster Automotive Type............................................. 32
Correct Use of Your Electric Brakes........................... 33
Important Safety Notice................................................. 33
Brake Adjustment.............................................................. 33
Brake Cleaning and Inspection..................................... 33
Brake Lubrication .............................................................. 33
Magnets................................................................................. 34
Shoes and Linings ..............................................................34
Corrosion Prevention.......................................................34
Wheels and Tyres .............................................................. 35
Highway................................................................................. 35
Off Road................................................................................ 35
Suspension ........................................................................... 35
Shock Absorbers & Bushes............................................ 35
Electrical Systems.............................................................. 36
Chargers & Inverters........................................................ 36
Battery Care ........................................................................ 36
12 Volt Wiring Diagram .................................................. 37
Control Panel (Old Style) ................................................38
Control Panel (New Style).............................................. 38
Gas & Water Systems....................................................... 39
Hot Water System............................................................. 39
Water Pumps....................................................................... 39
Connecting the Gas .......................................................... 39
Useful Accessories ............................................................40
Levelling Blocks ..................................................................40
Wheel Chocks.....................................................................40
Covers ....................................................................................40
Stone Protection ................................................................40
Trouble Shooting................................................................ 41
Electrical ............................................................................... 41
Water...................................................................................... 42
Gas........................................................................................... 42
Brakes ....................................................................................43
Handy Tips ...........................................................................44
Driving Off Road................................................................44
Trip Planning........................................................................ 45
Warranty Statement ........................................................46
Maintenance & Parts........................................................ 50
Hub Assembly..................................................................... 50
Trailing Arm Bushes...........................................................51
Spare Part Numbers......................................................... 52
Travel Record ...................................................................... 53
Maintenance Schedule .................................................... 55
Supplier Contact Details................................................. 67
Video Tutorials.................................................................... 69
Handover Video ................................................................. 69
Set Up Guide Main Tent .................................................. 69
Awning Set Up Guide ....................................................... 69
Setting Up Annex............................................................... 69
Packing Up Guide .............................................................. 69

www.marketdirect.com.au Ph: 1300 494 494
Copyright © Market Direct Group Pty Ltd 2021 All Rights Reserved
All les and information contained in this Owner’s Manual are copyright by Market Direct Group Pty Ltd, and may
not be duplicated, copied, modied, or adapted, in any way without our written permission. Our Owner’s Manual may
contain our service marks or trademarks as well as those of our afliates or other companies, in the form of words,
graphics, and logos.
Your use of our Owner’s Manual does not constitute any right or license for you to use our service marks or trademarks,
without the prior written permission of Market Direct Group Pty Ltd.
Our Content, as found within our Owner’s Manual, is protected under Australian and foreign copyrights. The copying,
redistribution, use or publication by you of any such Content, is strictly prohibited. Your use of our Owner’s Manual
does not grant you any ownership rights to our Content.
DISCLAIMER: This manual is provided in good faith and Market Direct Group Pty Ltd.
may amend or update this owner manual from time to time.
Use of Product
The intent and purpose of this manual is to assist owners in the correct use and operation of the product and outline the servicing
schedule to be followed, ensuring the correct maintenance of the product.
Servicing
Servicing information contained in this owner manual is provided for those who have appropriate technical skills and relevant to
the subject matter the publication deals with in regard to maintenance and repairs. The servicing content of this manual assumes
a satisfactory technical knowledge and mechanical skills and experience. It is not suitable for people who are not trained or
qualied in the subject matter it deals with. If you do not have the appropriate skills and experience, or if you do not have access
to appropriate tools and equipment, you may injure yourself or others around you and/or you may cause damage to the Caravan
you are working on, including making it unsafe. Users of this owner manual must:
• Read all content thoroughly. It is especially important to have a good understanding of all the contents shown in the
INTRODUCTION and SAFETY Sections of this publication.
• Use only the correct tools and equipment for all repairs and servicing.
• If part replacement is necessary, replace the part with the same part number or equivalent part. DO NOT replace it with a
part of inferior quality.
• Observe all ‘Cautions’ and ‘Notices’ to reduce the risk of personal injury during service or repair, or improper service or repair
that may damage the Caravan or render it unsafe.
• Understand that the ‘Cautions’ and ‘Notices’ in this publication are not exhaustive because it is impossible to warn of all
possible hazardous consequences that might result from failure to follow the instructions in this publication.
• You must carry out your own risk assessments as you work.
Market Direct Group Pty Ltd. does not accept any and all liability which may arise because a user of this
publication fails to follow directions in the publication or safe work methods associated with use and
maintenance of the product.
Those without the required skills, knowledge, tools, and experience to work on and maintain this product should seek the services
of a suitably qualied person or business. This publication is based on the latest product information at the time of release.
However, specications and procedures are subject to change without notice.

www.marketdirect.com.au Ph: 1300 494 494 1
My Cruizer Slide
DISCLAIMER: By receiving this handbook, you confirm there you have read and agree to all
the terms and conditions and understood the use and maintenance care of MDC®
NAME:
MODEL:
VIN:
BUILD DATE:
TARE:
ATM:
TYRE SIZE:
DEALER:
ADDRESS 1:
ADDRESS 2:

www.marketdirect.com.au Ph: 1300 494 494 2
Section 1. Introduction
WELCOME TO MDC
Off road caravanning is a rewarding way to travel and see our great country. Owning an AusRV Caravan or Hybrid
Caravan will afford you the opportunity to travel to remote places and stay in comfort. It is the intention of MDC
for you to have the best possible owner experience and enjoy the great outdoors.
ATM (Aggregate Trailer Mass) Rating: The total permissible mass of the Trailer. This includes the coupling mass
and whatever you add as payload (e.g. water, gas, luggage)
up to the specified rating. The ATM Rating must not be exceeded.
GTM (Gross Trailer Mass) Rating: The total permissible mass that can be supported by the wheels/ tyres of
the Trailer. This includes whatever you add as payload (e.g. water, gas, equipment and luggage), but does not include
the mass supported by the tow vehicle.
The GTM Rating must not be exceeded.
Tare Weight: The total weight of the trailer (load on tyres plus coupling load) with all options and fittings as
supplied by the manufacturer, with empty water tanks, excluding fluids not essential for operation on public
roads, and without luggage or personal effects.
Campers for illustration purposes only.

www.marketdirect.com.au Ph: 1300 494 494 3
Terminology & Abbreviations
Ball Weight: The downward load exerted on the tow point of the vehicle by the trailer.
GCM: (Gross Combination Mass): This is the total allowable combined mass of tow vehicle and trailer as
determined by the tow vehicle manufacturer.
Camber: Camber angle is the measure in degrees of the difference between the wheel’s vertical alignment
perpendicular to the surface. If a wheel is perfectly perpendicular to the surface, its camber would be 0 degrees.
Camber is described as negative when the top of the tyre begins to tilt inward towards the chassis rail.
Toe In/out: Negative toe, or toe out, is the front of the wheel pointing away from the centreline of the vehicle.
Positive toe, or toe in, is the front of the wheel pointing towards the centreline of the vehicle.
Toe can be measured in linear units, at the front or rear of the tyre, or as an angular deflection. In the case of MDC
products, the “toe in” is measured in millimetres at the front of the tyre from the chassis rail.
Tow vehicle and Trailer Compatibility
Your tow vehicle manufacturer has applied a maximum towing capacity to the vehicle which is the Aggregate Trailer
Mass (ATM) and a maximum Gross Combination Mass (GCM). These specifications MUST NOT be exceeded. It is
your responsibility to know, understand and follow these specifications. Vehicle manufacturers may also specify or
recommend “Weight Distribution Bars” when towing under certain conditions. You MUST ensure this is
compatible. with the vehicle and trailer combination.
DANGER – Exceeding manufacturer weight and combination limits can result
in loss of control leading to death or serious injury. Your tow vehicle and hitch
must be rated for the Gross Vehicle Weight of the trailer.
DANGER

www.marketdirect.com.au Ph: 1300 494 494 4
Specifications
LENGTH 5.3m
TENT COLOUR Khaki / Sand
HEIGHT (HIGHEST) 3.2m
DRAWBAR 100 x 50 x 3mm RHS extended
TOWBALL WEIGHT 150kg
TARE WEIGHT Approx. 1540kg
ATM 2000kg
SIZE CLOSED 2,100 x 1,800 x 725mm
OPENED 5,110 x 1,800 x 2,250mm
STYLE Hard oor - forward fold
SUSPENSION Independent suspension with dual shock absorbers, trailing arm and coil
spring
WHEEL/TYRE INFO 265/75 R16 mud terrain Goodride, 4x16” alloy rims
STONE GUARD Stone guard & stone tamers
BRAKES 4WD 12” electric with hand brake
GAS CYLINDERS 2 x 4kg gas cylinder holders
KITCHEN CONSTRUCTION 3 Burner Smev stove
WATER TANK 120L poly tank with 3mm alloy bash plate with 12V automatic electric
pump
HOT HEATER Country Comfort LPG gas instant - 6L p/m, not plumbed
BATTERIES AGM deep cycle, 2 x 100ah
INVERTER 600W modied Sine 240V inverter
STEREO SYSTEM Kenwood stereo & speakers
SOLAR 180W folding solar panel
JOCKEY WHEEL 10” Swing-up and lockable
STABILISER LEG 4 x heavy duty lockable and adjustable drop-down
LIGHTS LED submersible taillights and number-plate light
CHARGER Projecta 15A 7 stage full auto 240V charger
HITCH ADR 62/02 Poly block off road hitch, (360 degrees)
TENT A huge 22sqm of living space if tent and annex set up
TENT SIZE 4.2m x 1.8m
TENT HEIGHT 1.8m (lowest) - 2.8m (highest)
MATTRESS BED BASE SIZE High density foam mattress included 1.95m x 1.65m
POLES Galvanized steel pole, dia19/22/25mm
WINDOWS Mosquito & midge proof netting

www.marketdirect.com.au Ph: 1300 494 494 5
QUEENSLAND
Brisbane
3/711 Beaudesert Rd
Rocklea QLD 4107
Caboolture
4 Boeing Place
Caboolture QLD 4510
NEW SOUTH WALES
Sydney
1/12 Avalli Road,
Prestons NSW 2170
Newcastle
Unit 1, 2364 Pacic Hwy
Heatherbrae NSW 2324
VICTORIA
Melbourne
126 Canterbury Rd
Kilsyth South VIC 3137
Campbelleld
1551 Sydney RD
Campbelleld VIC 3061
WESTERN AUSTRALIA
Welshpool
18 Bellows Rd
Welshpool WA 6106
SOUTH AUSTRALIA
Adelaide
1246 South Rd
Clovelly Park SA 5042
Store Locations
NATIONAL TOLL FREE WARRANTY HOTLINE SPARE PARTS
1300 4X4 4X4
1300 494 494
1300 MDC CARE
1300 632 2273
1300 MDC PARTS
1300 632 72787

www.marketdirect.com.au Ph: 1300 494 494 6
Safety Information
WARNING - Before using this product, you should read this manual, and those manuals
supplied by component manufacturers applicable to this product.
This manual is supplied as a reference to required maintenance of the product. Failure to use and maintain the
product in accordance with what is outlined in this manual may affect your warranty.
Incorrect and/or insufcient maintenance may cause product failure resulting in property loss, damage or injury
or death. Maintenance intervals are critical for normal use, extreme use may require shorter or additional maintenance
intervals. Manual content does not imply express or other any warranty, the owner should read the limited warranty
terms included in this booklet.
Before using this product, you should be certain your tow vehicle is suitably rated and equipped to tow the product
safely and legally. The trailer and vehicle pairing must we within the safe “Maximum Towing Capacity”,
“Ball Weight Capacity” and “Gross Combination Mass” as stated by the vehicle manufacturer.
This camper is fitted with electric brakes. An electric brake controller is mandatory.
WARNING: BALL LOADING (DOWNWARD LOAD ON TOW HITCH) MUST NOT EXCEED 200KG OR THE
MAXIMUM ALLOWABLE LOAD BY THE VEHICLE MANUFACTURER OR TOW BAR RATING, WHICH EVER IS
THE LOWEST. Exceeding these limits may result in an accident causing serious injury or death and/or property
damage.
It is important to load your camper correctly to distribute weight evenly and achieve a suitable ball weight load and
prevent loading in a manner that can cause a Camper to sway and/or roll excessively left and right. The industry
optimum ball weight on a camper is between 9 and 11% of the total Camper weight. MDC Campers t into this
category and 10% should be used as the starting point.
Modications to The Product
Gas Systems
The installed gas system on this product is an approved and certied installation. Any changes, modications or
adjustment may render the system non-compliant and dangerous. Market Direct Group Pty Ltd does not condone,
recommend, or otherwise consent to any modications, adjustment, addition or tampering in any way with the installed
gas system on any and all products.
Chassis
All MDC chassis are fully engineered and veried using Finite Element Analysis (FEA) software. This ensures that
the chassis for each model passes the relevant regulations and design rules as originally provided to the customer.
Any modication to the chassis or drawbar whatsoever (no matter how minor) will inevitably change this – whether it
impacts the towing dynamics, expected loads and stress points, safety chain attachment points, overall trailer length
etc.
Market Direct Group Pty Ltd does not condone, recommend, or otherwise consent to any modications, adjustment,
addition or tampering in any way with the drawbar, safety chains or safety chain attachment points.
