MEADE INSTRUCTION MANUAL
80mm | 3.1”
90mm | 3.5” Alt-azimuth Refracting Telescope
102mm | 4.0”
www.meade.com
INFINITY SERIES
80, 90, 102mm Telescopes

WARNING!
Never use a Meade®telescope to look at the Sun! Looking
at or near the Sun will cause instant and irreversible
damage to your eye. Eye damage is often painless, so
there is no warning to the observer that damage has
occurred until it is too late. Do not point the telescope at
or near the Sun. Do not look through the telescope or
viewfinder as it is moving. Children should always have
adult supervision while observing.

1
INTRODUCTION
Your telescope is an excellent beginner’s
instrument, and is designed to observe
objects in the sky and also on land. It can
be your personal window on the universe or
allows you to intimately study the behavior of
nesting birds on a distant hillside.
The telescope is shipped with the following
parts:
• Optical tube
• Alt-azimuth mount with slow motion con-
trols
• Stainless Steel tripod with accessory tray
• Three 1.25” eyepieces:
MA26mm, MA9mm, MA6.3mm
• 90 degree erect-image diagonal prism
• 2X Barlow
• Red-dot viewfinder with bracket
The Infinity series of telescopes come in sev-
eral sizes (apertures) of optical tubes. The
heart of the optical tubes is the front lens. It
collects and focuses the incoming light from
distant objects.
The lens diameter is one of the most
important pieces of information about the
telescope. The size of the objective lens
determines how much detail you will be able
to see in your telescope.
Each optical tube also has a focal length
which is the distance the light travels inside
the optical tube before it comes to focus.
The focal length information is also important
and will help later on to calculate magnifica-
tion.
Setting up your telescope involves these
simple steps:
• Setting up your tripod
• Attach the accessory tray
• Attach the slow motion controls
• Attach the optical tube to the mount
• Attach the viewfinder
• Attach the diagonal prism and eyepiece
• Align the viewfinder
Study the picture on the next page and
become acquainted with the parts of your
telescope. Then proceed to “Setting up your
tripod.”

Inset C
Inset B
Figure 1: Meade Infinity Alt-azimuth Refracting Telescope
Inset A: Accessory Tray Assembly
Inset B: Tripod Leg
Inset C: Viewfinder Assembly
FIGURE 1
1. Eyepiece
2. Viewfinder (see Inset C)
3. Viewfinder alignment screws (2) (see Inset C)
4. Optical tube assembly
5. Horizontal lock knob
6. Dovetail mounting rail
7. Tripod legs
8. Accessory tray
9. Leg brace
10. Red dot viewfinder power switch
11. Azimuth slow motion control knob
12. Altitude slow motion control knob
13. 90 degree erect-image prism
14. Objective lens cell
15. Focuser drawtube and thumbscrews
16. Alt-azimuth mount
17. Adjustable sliding center leg extension
(see Inset B)
18. Tripod leg lock thumbscrew (see Inset B)
19. Dew shield/lens shade
20. Front lens cap (not shown)
21. Focusing knob
22. Viewfinder bracket (see Inset C)
23. Viewfinder bracket locking knob (see Fig. 5)
24. Optical tube attachment knob
25. Focuser lock knob
2
Inset A

SETTING UP YOUR TRIPOD
The tripod is the basic support for your tele-
scope and comes pre-assembled from the
factory; except for the accessory tray. The
tripod height may be adjusted so that you
can view comfortably.
Note: Number in brackets, e.g., (3), refer
to the item numbers in Fig. 1.
1. To setup the tripod, spread the legs out
evenly and place it on a solid surface.
2. Set the height of your tripod:
a. Rotate and loosen the leg lock thumb-
screw (18) to unlock the leg lock.
b. Slide the inner portion of the leg (17) in
or out to the desired length. Repeat for
the other two legs.
c. Rotate and tighten the leg lock thumb-
screw to re-lock the leg lock.
d. Repeat for the other two legs.
ATTACH THE ACCESSORY TRAY
The accessory tray attaches at the center of
the tripod legs and is a convenient place to
hold eyepieces and other Meade accessories
while observing, such as the Barlow lens.
To attach, place the hole in the center of the
accessory tray over the attachment point as
shown in Fig 2. Then rotate the tray until the
wings of the tray snap into place on the tripod
leg brace supports(9).
To remove the tray, rotate the tray so it
unlocks from the leg brace supports (9), then
remove.
ATTACH THE SLOW-MOTION CONTROLS
The slow motion control cables (11 & 12) allow
you to make fine adjustments to the pointing
position of the optical tube. When viewing
objects in the night sky, you will notice that
the object moves slowly in the eyepiece. This
is caused by the Earths rotation. Use the slow
motion controls to follow (or “track”) these
objects as you observe. Note that each
axis has its own slow motion control
which is independently controlled.
To install, attach the flexible cables
(11 & 12) to the mount as shown in Fig 3.
The cables are secured in place with a firm
tightening of the thumbscrews located at the
attachment ends of each cable.
3
Fig. 2
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.
Fig. 3
Attachment point
Thumbscrew
Slow motion cable

hole near the center of the dovetail rail.
3. Turn the optical tube attachment knob
(24) counter-clockwise until firm.
4. To remove the optical tube, first support
the optical tube in one hand. Next, turn
the attachment knob (24) clockwise until
the OTA detaches from the mount.
ATTACH THE VIEWFINDER
An eyepiece (1) has a narrow field of view.
The included viewfinder (2) has a wider field
of view and red dot to make it even easier
to locate the viewing object. The red dot
viewfinder also comes with an easy to install
dovetail bracket.
1. To install the red dot viewfinder, slide the
viewfinder bracket into the dovetail adapter
(Fig 5).
2. Next, secure the viewfinder in place with
the single locking knob.
ATTACH THE DIAGONAL PRISM AND
EYEPIECE
The erect-image diagonal prism reflects the
light from the optical tube to a more com-
fortable viewing position. It also corrects the
image orientation so the image is right side
up, and correct left-to-right.
1. To install, slide the diagonal prism (13)
into the focuser draw tube (15).
2. Tighten the draw tube thumbscrew to hold
the diagonal prism securely (15).
3. Next, slide the MA 26mm eyepiece (1)
into diagonal prism.
4. Tighten the diagonal prism thumbscrew to
hold the eyepiece securely.
ALIGN THE VIEWFINDER
Perform the first part of this procedure during
the daytime and the last step at night.
1. Point the telescope at an easy-to-find land
object such as the top of a tele-
ATTACH THE OPTICAL TUBE TO THE
MOUNT
The optical tube gathers distant light
which is focused in the eyepiece. It
attaches to the mount using the optical tube
attaching knob (24) and dovetail mounting rail
(6).
1. To attach the optical tube, first locate the
threaded hole on the bottom side of the
dovetail mounting rail(6) (Fig 4).
2. Using the optical tube attaching knob
(24), place the dovetail onto the top of the
mount, lining up the threaded
4
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.
Fig. 4
Fig. 5
Mounting holes
Mounting screw
Attachment knob (24)
Locking
knob

SUN WARNING
NEVER USE YOUR TELESCOPE
TO LOOK AT THE SUN!
LOOKING AT OR NEAR THE SUN WILL CAUSE
INSTANT AND IRREVERSIBLE DAMAGE TO YOUR
EYE. EYE DAMAGE IS OFTEN PAINLESS, SO
THERE IS NO WARNING TO THE OBSERVER THAT
DAMAGE HAS OCCURRED UNTIL IT IS TOO LATE.
DO NOT POINT THE TELESCOPE OR ITS VIEW-
FINDER AT OR NEAR THE SUN. DO NOT LOOK
THROUGH THE TELESCOPE OR ITS VIEWFINDER
AS IT IS MOVING. CHILDREN SHOULD ALWAYS
HAVE ADULT SUPERVISION WHILE OBSERVING.
phone pole or a distant mountain or tower.
Look through the eyepiece in and turn the
focuser knob (21) until the image is sharp-
ly focused. Center the object precisely in
the eyepiece’s field of view.
2. Turn on the red-dot viewfinder by rotating
the large knob under the viewfinder lens
clockwise (10). Turn the knob to adjust the
intensity of the red dot as desired.
3. Look through the viewfinder. Turn one or
both of the viewfinder’s alignment screws
(3) until the red-dot is precisely over the
same object as you centered in the eye-
piece.
4. Check this alignment at night on a ce-
lestial object, such as the Moon or
a bright star, and use the viewfinder’s
alignment screws to make any necessary
refinements.
5. When finished, turn off the viewfinder
by turning the large knob (10) under the
viewfinder lens counter-clockwise until it
clicks.
TO MOVE THE TELESCOPE
Your telescope is alt-azimuth mounted.
Alt-azimuth is just a complicated way of say-
ing that your telescope moves up and down
and from side to side. Other telescopes may
be mounted in different ways.
1. To move the telescope in the horizontal
direction (azimuth), slightly loosen the
horizontal lock knob (5). Loosening this lock
allows the telescope to be moved from side
to side.
2. To move the telescope in the vertical direc-
tion (altitude), use the pan handle on the
rear of the mount to make coarse adjust-
ments. Note the vertical direction does
not have a locking knob and can be
moved at any time.
3. Once an object is found, re-tighten
the horizontal lock knob (5). You can
then rotate the slow motion controls
(11 & 12) to make smooth and precise
movements and follow (or “track”) an ob-
ject horizontally and vertically as it moves
in the eyepiece.
THE MOST IMPORTANT RULE
We have one very important rule that you
should always follow when using your tele-
scope:
Have Fun!
THE MEADE 4M COMMUNITY
You haven’t just bought a telescope, you have em-
barked on an astronomy adventure that never ends.
Share the journey with others by accepting your free
membership in the 4M community of astronomers.
Go to www.Meade4M.com to activate your membership
today.
5
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.

Have a good time when you’re observ-
ing. You may not know everything that
there is to know about a telescope or
what all the sights in the universe are,
but that’s OK. Just point and observe at first.
You will enjoy your telescope even more as
you learn more about it. But don’t be scared
off by difficult terms or complicated proce-
dures. Don’t panic! Just relax and enjoy your
scope.
You will begin to grow and learn more about
astronomy the more you observe. Browse
the internet or go to the library and read
some books about the stars and planets.
Read about astronomers of old. Many of
them had telescopes no bigger than the one
you are using right now. Galileo, who is one
of the first astronomers to use a telescope,
discovered four of the moons of Jupiter with
a telescope about the same size as yours
(and his didn’t even focus very well!).
OBSERVING
Observe during the daytime: Try out your
telescope during the daytime at first. It is
easier to learn how it operates and how to
observe when it is light.
Pick out an easy object to observe: A dis-
tant mountain, a large tree, a lighthouse or
skyscraper make excellent targets. Point the
optical tube so it lines up with your object.
Unlock the lock knob: To move the tele-
scope horizontally you will need to unlock
the horizontal lock knob (just rotate to unlock
or lock; when locking, only tighten to a “firm
feel,” do not over tighten).
Use the viewfinder: If you have not done so,
align the viewfinder (2) with the telescope’s
eyepiece (1) as described earlier. Look
through the viewfinder until you can see the
object. It will be easier to locate an object
using the viewfinder rather than locating with
the eyepiece. Line up the object using the
viewfinders red dot.
Look through the eyepiece: Once you
have the object lined up in the viewfind-
er, look through the optical tube’s eye-
piece. If you have aligned your viewfinder,
you will see the object in your eyepiece.
Focus: Look through the eyepiece and prac-
6
TOO MUCH POWER?
Can you ever have too much power? If the type of
power you’re referring to is eyepiece magnification,
yes you can! The most common mistake of the
beginning observer is to “overpower” a telescope
by using high magnifications which the telescope’s
aperture and atmospheric conditions cannot
reasonably support. Keep in mind that a smaller,
but bright and well-resolved image is far superior
to one that is larger, but dim and poorly resolved.
Powers above 400x should be employed only under
the steadiest atmospheric conditions.
tice focusing on the object you have chosen.
Try out the coarse and fine adjustment
controls: Practice using the fine adjustment
control (11 & 12) to move the telescope.
These can come in very handy, especially
when you wish to move the telescope in very
small (fine control) steps.
Observe the Moon: When you feel comfort-
able with the viewfinder, the eyepieces, the
locks and the adjustment controls, you will
be ready to try out the telescope at night.
The Moon is the best object to observe the
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.

first time you go out at night. Pick a night
when the Moon is a crescent. No shadows
are seen during a full Moon, making it ap-
pear flat and uninteresting.
Look for different features on the Moon. The
most obvious features are craters. In fact
you can see craters within craters. Some
craters have bright lines about them. These
are called rays and are the result of material
thrown out of the crater when it was struck
by a colliding object. The dark areas on the
Moon are called maria and are composed of
lava from the period when the Moon still had
volcanic activity. You can also see mountain
ranges and fault lines on the Moon.
Use a neutral density filter (often called a
“moon filter”) when observing the Moon.
Neutral density filters are available from Me-
ade as an optional accessory and enhance
contrast to improve your observation of lunar
features. Spend several nights observing the
Moon. Some nights, the Moon is so bright
that it makes other objects in the sky difficult
to see. These are nights that are excellent
for lunar observation.
Observe the Solar System: After observing
the Moon, you are ready to step up to the
next level of observation, the planets.
There are four planets that you can easily
observe in your telescope: Venus, Mars,
Jupiter and Saturn.
Nine planets (maybe more!) travel in a fairly
circular pattern around our Sun. Any system
of planets orbiting one or more stars is called
a solar system. Our Sun, by the way, is a
single, yellow dwarf star. It is average as far
as stars go and is a middle aged star.
Beyond the planets are clouds of comets, icy
planetoids and other debris left over from the
birth of our sun. Recently astronomers have
found large objects in this area and they may
increase the number of planets in our solar
system.
The four planets closest to the Sun are rocky
and are called the inner planets. Mercury,
Venus, Earth and Mars comprise the inner
planets. Venus and Mars can be easily seen
in your telescope.
Venus is seen before dawn or after sunset,
because it is close to the Sun. You can
observe Venus going through crescent
phases. But you cannot see any surface
detail on Venus because it has a very
thick atmosphere of gas.
When Mars is close to the Earth, you can
see some details on Mars, and sometimes
even Mars’ polar caps. But quite often, Mars
is further away and just appears as a red dot
with some dark lines crisscrossing it.
Jupiter, Saturn, Uranus, Neptune and Pluto
comprise the outer planets. These planets,
except for Pluto, are made mostly of gases
and are sometimes called gas giants. If they
7
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.

you’re missing a real treat! Each night, the
moons appear in different positions around
the Jovian sky. This is sometimes called
the Galilean dance. On any given night, you
might be able to see the shadow of a moon
on the face of Jupiter, see one moon eclipse
another or even see a moon emerge from
behind Jupiter’s giant disk. Drawing the posi-
tions of the moons each night is an excellent
exercise for novice astronomers.
Any small telescope can see the four Gal-
ilean moons of Jupiter (Fig 6), plus a few
others, but how many moons does Jupiter
actually have? No one knows for sure! Nor
are we sure how many Saturn has either. At
last count, Jupiter had over 60 moons, and
held a small lead over Saturn. Most of these
moons are very small and can only be seen
with very large telescopes.
Probably the most memorable sight you will
see in your telescope is Saturn. Although
you may not see many features on the
surface of Saturn, its ring structure will steal
your breath away. You will probably be able
to see a black opening in the rings, known as
the Cassini band.
Saturn is not the only planet that has rings,
but it is the only set of rings that can be seen
with a small telescope. Jupiter’s rings cannot
be seen from Earth at all—the Voyager
spacecraft discovered the ring after it passed
Jupiter and looked back at it. It turns out,
only with the sunlight shining through them,
can the rings be seen. Uranus and Neptune
also have faint rings.
Optional color filters help bring out detail and
contrast of the planets. Meade offers a line
of inexpensive color filters.
Fig. 6
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.
had grown much bigger, they may have
become stars. Pluto is made mostly of
ice.
Jupiter is quite interesting to observe.
You can see bands across the face of
Jupiter. The more time you spend observing
these bands, the more details you will be
able to see.
One of the most fascinating sights of Jupiter
are its moons. The four largest moons are
called the Galilean moons, after the as-
tronomer Galileo, who observed them for
the first time. If you’ve never watched the
Galilean moons in your telescope before,
8

What’s Next? Beyond the Solar System:
Once you have observed our own system
of planets, it’s time to really travel far from
home and look at stars and other objects.
You can observe thousands of stars with
your telescope. At first, you may think stars
are just pinpoints of light and aren’t very
interesting. But look again. There is much
information that is revealed in stars.
The first thing you will notice is that not all
stars are the same colors. See if you can find
blue, orange, yellow, white and red stars.
The color of stars sometimes can tell you
about the age of a star and the temperature
that they burn at.
Other stars to look for are multiple stars.
Very often, you can find double (or binary)
stars, stars that are very close together.
These stars orbit each other. What do you
notice about these stars? Are they
different colors? Does one seem brighter
than the other?
Almost all the stars you can see in the sky
are part of our galaxy. A galaxy is a large
grouping of stars, containing millions or
even billions of stars. Some galaxies form
a spiral (like our galaxy, the Milky Way) and
other galaxies look more like a large football
and are called elliptical galaxies. There are
many galaxies that are irregularly shaped
and are thought to have been pulled apart
because they passed too close to—or even
through—a larger galaxy.
You may be able to see the Andromeda
galaxy and several others in your telescope.
They will appear as small, fuzzy clouds.
Only very large telescope will reveal spiral or
elliptical details.
You will also be able to see some nebulas
with your scope. Nebula means cloud. Most
nebulas are clouds of gas. The two easiest
to see in the Northern Hemisphere are the
Orion nebula during the winter and the Triffid
nebula during the summer. These are large
clouds of gas in which new stars are being
born. Some nebulas are the remains of
stars exploding. These explosions are called
supernovas.
When you become an advanced observer
you can look for other types of objects such
SURF THE WEB
• The Meade 4M Community:
http://www.meade4m.com
• Sky & Telescope:
http://www.skyandtelescope.com
• Astronomy:
http://www.astronomy.com
• Astronomy Picture of the Day:
http://antwrp.gsfc.nasa.goc/apod
• Photographic Atlas of the Moon:
http://www.lpi.ursa.edu/research/lunar_orbiter
• Hubble Space Telescope Public Pictures:
http://oposite.stsci.edu/pubinfo/pictures.html
as asteroids, planetary nebula and
globular clusters. And if you’re lucky,
every so often a bright comet appears
in the sky, presenting an unforgettable
sight.
The more you learn about objects in the
sky, the more you will learn to appreciate the
sights you see in your telescope. Start
a notebook and write down the observations
you make each night. Note the time and
the date.
Use a compass to make a circle, or trace
around the lid of a jar. Draw what you see
9
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.

in your eyepiece inside the circle. The
best exercise for drawing is to observe
the moons of Jupiter every night or so.
Try to make Jupiter and the moons
approximately the same size as they look in
your eyepiece. You will see that the moons
are in a different position every night. As you
get better at drawing, try more challenging
sights, like a crater system on the moon or
even a nebula.
Go your library or check out the internet for
more information about astronomy. Learn
about the basics: light years, orbits, star
colors, how stars and planets are formed,
red shift, the big bang, what are the different
kinds of nebula, what are comets, asteroids
and meteors and what is a black hole. The
more you learn about astronomy, the more
fun, and the more rewarding your telescope
will become.
SOME OBSERVING TIPS
Eyepieces: Always begin your observa-
tions using the 26mm low-power eyepiece.
The 26mm eyepiece delivers a bright, wide
field of view and is the best to use for most
viewing conditions. Use the high-power 9mm
eyepiece to view details when observing
the Moon and planets. If the image become
fuzzy, switch back down to a lower power.
Changing eyepieces changes the power or
magnification of your telescope.
You can also change magnification by using
a Barlow lens. The Barlow lens included with
your telescope doubles the power of your
telescope. Place the Barlow into the eye-
piece holder before you insert the eyepiece.
Meade offers a complete line of eyepieces
and Barlows for your telescope. Most astron-
omers have four or five low-power and high
power eyepieces to view different objects
and to cope with different viewing conditions.
Objects move in the eyepiece: If you are
observing an astronomical object (the Moon,
a planet, star, etc.) you will notice that the
object will begin to move slowly through
the telescopic field of view. This movement
is caused by the rotation of the Earth and
makes an object move through the tele-
scope’s field of view. To keep astronomical
10
STAR CHARTS
Star charts and planispheres are useful for a variety of
reasons. In particular, they are a great aid in planning a
night of celestial viewing.
A wide variety of star charts are available in books,
in magazines, on the internet and on CD Roms.
Meade offers AutoStar SuiteTM software. Contact your
local Meade dealer or Meade’s Customer Service
department for more information.
Astronomy and Sky and Telescope magazines print
star charts each month for up-to-the-minute maps of
the heavens.
objects centered in the field, simply move
the telescope on one or both of its axes—
vertically and/or horizontally as needed—try
using the telescopes coarse and fine adjust-
ment controls(11 & 12). At higher powers,
astronomical objects will seem to move
through the field of view of the eyepiece
more rapidly.
Place the object to be viewed at the edge
of the field and, without touching the tele-
scope, watch it drift through the field to the
other side before repositioning the telescope
so that the object to be viewed is again
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.

placed at the edge of the field, ready to be
further observed.
Vibrations: Avoid touching the eyepiece
while observing through the telescope. Vibra-
tions resulting from such contact will cause
the image to move. Avoid observing sites
where vibrations cause image movement (for
example, near railroad tracks). Viewing from
the upper floors of a building may also cause
image movement.
Let your eyes “dark-adapt:” Allow five or
ten minutes for your eyes to become “dark
adapted” before observing. Use a red-fil-
tered flashlight to protect your night vision
when reading star maps, or inspecting the
telescope. Do not use a regular flash-light or
turn on other lights when observing with a
group of other astronomers. You can make
your own red filtered flashlight by taping red
cellophane over a flashlight lens.
Viewing through windows: Avoid setting
up the telescope inside a room and observ-
ing through an opened or closed window
pane. Images may appear blurred or distort-
ed due to temperature differences between
inside and outside air. Also, it is a good idea
to allow your telescope to reach the ambient
(surrounding) outside temperature before
starting an observing session.
When to observe: Planets and other
objects viewed low on the horizon often lack
sharpness—the same object, when ob-
served higher in the sky, will appear sharper
and have greater contrast. Try reducing
power (change your eyepiece) if your image
is fuzzy or shimmers. Keep in mind that
a bright, clear, but smaller image is more
interesting than a larger, dimmer, fuzzy one.
Using too high a power eyepiece is one of
the most common mistakes made by new
astronomers.
Dress Warm: Even on summer nights, the
air can feel cool or cold as the night wears
on. It is important to dress warm or to have a
sweater, jacket, gloves, etc., nearby.
Know your observing site: If possible,
know the location where you will be observ-
ing. Pay attention to holes in the ground and
other obstacles. Is it a location where wild
animals, such as skunks, snakes, etc., may
appear? Are there viewing obstructions
such as tall trees, street lights, headlights
and so forth? The best locations are dark
ASTRONOMY RESOURCES
• The Meade 4M Community
27 Hubble, Irvine, CA 92618
• Astronomical League
Executive Secretary
5675 Real del Norte, Las Cruces, NM 88012
• The Astronomical Society of the Pacific
390 Ashton Ave., San Francisco, CA 94112
• The Planetary Society
65 North Catalina Ave, Pasadena, CA 91106
• International Dark-Sky Association, Inc.
3225 N. First Avenue, Tucson, AZ 85719-2103
locations, the darker the better. Deep
space objects are easiest to see under
dark skies.
But it is still possible to observe even in
a city.
Surf the Web and visit your local library:
The internet contains a huge amount of
astronomical information, both for children
and adults. Check out astronomy books from
your library. Look for star charts—these are
available on a monthly basis in Astronomy
and Sky and Telescope magazines.
11
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.

HAVE A GOOD TIME,
ASTRONOMY IS FUN!
SPECIFICATIONS
Infinity 80 model:
Objective lens diameter 80mm(3.2”)
Optical tube focal length 400mm
Focal ratio f/5
Mounting type Alt-azimuth
Viewfinder Red-dot
Infinity 90 model:
Objective lens diameter 90mm(3.5”)
Optical tube focal length 600mm
Focal ratio f/6.7
Mounting type Alt-azimuth
Viewfinder Red-dot
Infinity 102 model:
Objective lens diameter 102mm(4.0”)
Optical tube focal length 600mm
Focal ratio f/5.9
Mounting type Alt-azimuth
Viewfinder Red-dot
What do the specifications mean?
Optical tube focal length is the distance light
travels in the telescope before being brought
to focus in you eyepiece. Depending on the
telescope model, the focal length is either
400mm or 600mm long. Look at the specifi-
cation table to find out your telescopes focal
length.
Objective lens diameter is how big the
front lens is on your scope. Telescopes are
always described by how large their objec-
tive lens is. Depending on your telescope
model, the lens diameter is either 80mm, 90
or 102mm.
Other telescopes are 50mm, 8 inches, 16
inches, or even 3 feet in diameter. The
12
Hubble Space Telescope’s objective lens
has a diameter of 2.4 meters (that’s 7.8 feet
across!).
The focal ratio helps determine how fast the
photographic speed of a telescope is. The
lower the focal ratio number, the faster the
exposure. f/5 is faster than f/10. The faster
the ratio, the shorter the exposure time is
needed when a camera is hooked up to the
telescope. For example, the Infinity 80 tele-
scope has fast focal ratio at f/5. Sometimes,
astronomers use focal reducers to make
slow exposure telescopes have faster focal
ratios.
Alt-azimuth mounting simply means your
telescope moves up and down (altitude
or “alt”), and side to side, (azimuth or “az”).
Other mounting configurations are available
for other telescopes, such as equatorial
mounting.
USE THE SPECIFICATIONS TO CALCU-
LATE THE MAGNIFICATION OF YOUR
EYEPIECE
The power of a telescope is how much it
magnifies objects. For an Infinity 90, the
26mm eyepiece magnifies an object 23.1
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.

times. The 9mm eyepiece magnifies objects
66.7 times.
If you obtain other eyepieces, you can calcu-
late how much magnification they have with
your telescope. Just divide the focal length
of the telescope by the focal length of the
eyepiece.
Focal Length of the Telescope
÷
Focal Length of the Eyepiece
=
Magnification
Look at the specifications. For the Infinity
90, you will see that the focal length of this
scope is 600mm. Let’s say that you have
obtained a 13mm eyepiece. You can tell that
what the focal length of your eyepiece is as
it is always printed on the side of an eye-
piece. Divide: 600 ÷ 13, which equals 46.15.
Round this off to the nearest whole number
and the new 13mm eyepiece magnifies
objects 46 times.
A great accessory for your telescope is
a Barlow lens If you use a Barlow lens
with one of your eyepieces, it doubles the
magnification of your eyepiece. Other types
of Barlows can triple or further increase the
power of an eyepiece. To find out how much
the magnification is when you use a Barlow,
multiply your eyepiece’s magnification
by two.
Eyepiece’s magnification x 2
=
Magnification with a 2X Barlow lens
For the Infinity 90 the 26mm low-power eye-
piece magnifies an object 23 times. Multiply
23 by 2 and you get 46 times magnification
with a Barlow.
It’s worth repeating: Keep in mind that a
bright, clear, but smaller image is more
interesting than a larger, dimmer, fuzzy one.
Using too high a power eyepiece is one of
the most common mistakes made by new
astronomers. So don’t think that higher
magnification is necessarily better—quite
often the best view is with lower magnifica-
tion value!
TAKING CARE OF YOUR TELESCOPE
Your telescope is a precision optical instru-
ment designed for a lifetime of reward-
ing viewing. It will rarely, if ever, require
factory servicing or maintenance.
Follow these guidelines to keep your
telescope in the best condition:
• Avoid cleaning the telescope’s lenses.
A little dust on the front surface of the
telescope’s correcting lens will not cause
loss of image quality.
• When absolutely necessary, dust on the
front lens should be removed with very
gentle strokes of a camel hair brush or
blown off with an ear syringe (available
at most pharmacies).
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.
JOIN AN ASTRONOMY CLUB, ATTEND A STAR
PARTY
One of the best ways to increase your knowledge of
astronomy is to join an astronomy club. Check your
local newspaper, school, library, or telescope dealer/
store to find out if there’s a club in your area.
Many groups also hold regularly scheduled Star
Parties at which you can check out and observe
with many different telescopes and other pieces of
astronomical equipment. Magazines such as Sky and
Telescope and Astronomy print schedules for many
popular Star Parties around the United States and
Canada.
13

• Fingerprints and organic materials
on the front lens may be removed with
a solution of 3 parts distilled water to
1 part isopropyl alcohol. You may also
add 1 drop of biodegradable dishwashing
soap per pint of solution. Use soft, white
facial tissues and make short, gentle
strokes. Change tissues often.
CAUTION: Do not use scented or lotioned
tissues or damage could result to the optics.
DO NOT use a commercial photographic
lens cleaner.
CHANGING THE VIEWFINDER BATTERY
If the viewfinder red dot does not illumi-
nate, verify the viewfinder is on by rotating
the knob (10) below the viewfinder lens
clockwise. If the red dot does not illumi-
nate, the battery may need replacing.
To replace the battery, press the left side
of the viewfinder housing labeled “push”.
The battery compartment will slide out on
the right side of the viewfinder (see Fig.
7). Replace the battery with a Lithium
CR2032 battery with the positive side up.
Then push the battery compartment back
14
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.

into the viewfinder and power on.
OPTIONAL ACCESSORIES
Additional Eyepieces (1.25” barrel
diameter): For higher or lower
magnifications with the telescopes that
accommodate 1.25” eyepieces, Meade
Series 4000 Super Plössl eyepieces,
Fig. 7
available in a wide variety of sizes, provide a
high level of image resolution and color
correction at an economical price. Contact
your Meade Dealer or see the Meade
catalog for more information. Visit us on the
web at www.meade.com.
15
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the Sun. Do not look through the telescope as it is moving.
Push side here to open
battery compartment
CR2032
battery
Battery
compartment
OBSERVING TIPS
• Try to pick an observing site away from
street and house lights and car headlights.
While this is not always possible, the
darker the site, the better.
• Give your eyes about ten minutes to adjust
to the darkness before observing. Give
your eyes a rest from observing every ten
or fifteen minutes to relieve eyestrain.
• Try not to use a standard flashlight.
Experienced observers use red LED flash-
lights, the red utility light on the Autostar
handbox, or tape red cello-phane over
their flashlights to use for setup and map
reading so they don’t have to continually
readjust their eyes to the darkness. Be
careful not to shine bright lights if there
are other observers in the area. Do not
shine a flashlight into the telescope while
someone is observing!
• Dress warmly. It gets chilly when you’re
sitting for prolonged periods of time.

©2014 Meade Instruments Corp.

DRAWING OF IMAGE
photocopy this page
OBSERVER:
OBJECT NAME:
DATE & TIME OBSERVED:
CONSTELLATION:
EYEPIECE SIZE:
SEEING CONDITIONS: EXCELLENT GOOD POOR
NOTES:
OBSERVATION LOG

www.meade.com
Meade Instruments Corp.
27 Hubble, Irvine,
California 92618
1-800
626-3233
©2014 Meade Instruments Corp. All rights
reserved. Specications subject to change
without notice.
