Meade®DS-2130ATS
130mm (5.1") Altazimuth Reflector
LARGE APERTURE GO TO TELESCOPE
Reflectors have long been a favorite with amateur
astronomers. The large 130mm diameter mirror of the
Meade DS-2130ATS provides 469% brighter images and a
tremendous increase in fine detail, compared to common
60mm telescopes.
The standard equipment #494 AutoStar® Computer Control
System permits automatic object location and tracking of
more than 1400 objects in the AutoStar database at the
touch of a button.
See fainter and more distant objects in far greater detail.
Several thousand star clusters, galaxies and nebulae are
within range of this telescope. This model is highly
recommended for astronomical applications; however, due
toits image orientation it is not recommended for land
viewing.
Includes two premium 4-element Super Plössl eyepieces.
SPECIFICATIONS
Meade Model DS-2130ATS (P/N: 20132) — Supplied complete
with aluminized and multi-coated primary mirror (D = 130mm,
F=1000mm, f/7.7) •Motorized tracking mount (requires eight
user-supplied AA-size batteries) •#494 AutoStar Computer Control
System •Meade PC-compatible astronomical software •Full-length
adjustable aluminum tripod with accessory shelf •6x30mm
viewfinder; two premium eyepieces (1.25"): SP 9.7mm, and
SP 26mm •Operating instructions •Giftbox.
DSSERIES
Includes
AutoStar®
Computer
Controller
BONUS
StarNavigator™
Software

3
Meade 114EQ-AST
and Meade 114EQ-A
114mm (4.5") Equatorial Reflectors
LARGE APERTURE MANUAL TELESCOPES
Because the earth rotates once on its axis every 24 hours,
celestial objects move rapidly through the telescopic field,
particularly at higher powers. The equatorial mount of both
the Meade 114EQ-AST and 114EQ-A greatly facilitates object
tracking, simply by manually turning one or both of the
control cables.
The large 114mm-diameter mirror of these models gathers
361% morelightthan 60mm telescopes. Fainter, more
distantobjects can be seen in far greater detail.
The beginning amateur who intends to use a manual
telescope on a regular basis will find the equatorial mount
to be a valuable investment.
SPECIFICATIONS
Meade Model 114EQ-A (P/N: 04055) — Deluxe model supplied
complete with overcoated primary mirror and aluminum optical
tube assembly, (D=114mm, F=910mm, f/8) •Rack-and-pinion
focuser (1.25") •Equatorial mount with unique covered worm-gear
slow-motion control •Setting circles •Deluxe latitude control with
scale •Two eyepieces (1.25"): MA9mm (101X) and MA25mm (36X)
•5 x 24mm viewfinder •Adjustable aluminum tripod with shelf
•Planetarium software for the PC •Operating instructions •Giftbox.
SPECIFICATIONS
Meade Model 114EQ-AST (P/N: 04056) — Basic model includes the
same diameter mirror as above, but includes a special relay lens
which shortens the tube length and yields a 1000mm focal length
(f/8.8). Includes a somewhat smaller mount and tripod than the
model above. The exact same accessories are present in both
models.
114EQ-A
114EQ-AST
EQSERIES
BONUS
StarNavigator™
Software

4
Meade®DS-2080AT
80mm (3.1") Altazimuth Refractor
HIGH-PERFORMANCE GO TO TELESCOPE
Feel like a professional astronomer your first night under the
stars. Revolutionary AutoStar® computer technology allows
you to navigate the heavens effortlessly at the touch of few
buttons. Just enter the object you desire in the AutoStar
display,press GO TO,and AutoStar places the object in the
telescopic field of view, and tracks it automatically! Provides
pristine, ultra high-contrast images of Saturn’s awesome
rings, the cloud belts of Jupiter, and the essential structure of
deep space objects. AutoStar has over 1400 fascinating
celestial objects in its database.
Features built-in internal tracking motors, gears and cords.
The single-tine forkmount design and quick release tripod
with accessory tray offers a sleek contemporary appearance.
Includes two premium 4-element Super Plössl eyepieces.
SPECIFICATIONS
Meade Model DS-2080AT (P/N: 20084) — Supplied complete with
coated objective lens (D = 80mm, F = 800mm, f/10) •Motorized
altazimuth mount (requires eight user-supplied AA-size batteries) •
#494 AutoStar Computer Control System with 1400-object
database •Meade PC-compatible astronomical software •
Adjustable aluminum tripod with accessory shelf •5x24mm
viewfinder •Diagonal mirror (1.25
" )•Twopremium eyepieces
(1.25"): SP 9.7mm and SP 26mm •Operating instructions •Giftbox.
DSSERIES
BONUS
StarNavigator™
Software
Includes
AutoStar®
Computer
Controller

5
Meade 80EQ-A
80mm (3.1") Equatorial Refractor
HIGH-PERFORMANCE MANUAL TELESCOPE
This large aperture 80mm diameter telescope with deluxe
equatorial mount provides contrast-rich, high-resolution
images of Saturn, Jupiter, the Moon and many deep-space
objects, as well as landmarks and nature.
The Meade 80EQ-Apermits moreadvanced study than
smaller telescopes and enables observation of the Cassini
Division in Saturn’s rings. Jupiter’s surface now takes on
added detail as the cloud belt begins to show their
essential structure, and transits of the planet’s satellites
across the planetary disk may now be seen. In deep-space,
open star clusters,such as the Pleiades (M45) in Taurus,
displayhundreds of stars in one telescopic field of view.
Includes two 3-element 1.25" eyepieces, deluxe equatorial
mount with covered worm-gears that facilitate slow-motion
tracking control of fast moving sky objects, heavy-duty
aluminum tripod, and much more.
SPECIFICATIONS
Meade Model 80EQ-A (P/N: 04051) — Supplied complete with
coated achromatic objective lens made of grade-A crown and flint
glass •Diagonal mirror •Deluxe equatorial mount with slow-motion
controls •Deluxe latitude adjuster •Adjustable aluminum tripod •Two
3-element eyepieces (MA9mm, MA25mm) •6x30 viewfinder
•Software for the PC •Operating instructions •Giftbox.
EQSERIES
BONUS
StarNavigator™
Software

6
Meade®NG-70 / NGC-70
Advanced 70mm (2.8") Refractor
NEW GENERATION TELESCOPES: ADVANCED MANUAL
MOUNT WITH COMPUTER CAPABILITY
Meade engineers have thoroughly updated the traditional
entry-level telescope to a new standard for the 21st Century.
These New Generation telescopes incorporate advanced
industrial designyielding a striking,ultramodern
appearance. Large, precision bearing surfaces provide
smooth manual motions in both altitude and azimuth.
An advanced computerized model (NGC) offers all the
feature enhancements of the previously described NG
model, plus includes the significant performance advantage
of a built-in computer finding system with manual slow-
motions controls.
Both models include two premium 4-element Super Plössl
eyepieces.
SPECIFICATIONS
Meade Model NGC-70 Refracting Telescope (P/N: 20211) —
Supplied complete with multi-coated, achromatic objective lens
(D=70mm, F=700mm, f/11.7) •Built-in, self-guided GO TO
computer control system offering 1400-object database (requires
one 9 Volt user-supplied battery) •Altazimuth mount with slow-
motion controls •PC-compatible astronomical software •
Adjustable aluminum tripod with accessory shelf •5x24mm
viewfinder •Diagonal mirror •Two eyepieces (1.25"): SP 26mm
and SP 9.7mm •Operating instructions •Giftbox.
SPECIFICATIONS
Meade Model NG-70 Refracting Telescope (P/N: 20210) —
Identical in all specifications to Model NGC-70 above, but without
computer control system.
NG-70
NGC-70
NGSERIES
BONUS
StarNavigator™
Software

7
Meade 70AZ-A
70mm (2.8") Altazimuth Refractor
AQUALITY TELESCOPE AT A GREAT PRICE
The Meade 70AZ-A is a high performance 70mm refractor
ideally suited tothe beginning astronomer or terrestrial
observer: the rings of Saturn, four satellites of Jupiter, and
hundreds of Moon craters are only the beginning of what
can be observed through this telescope.
The Meade 70AZ-A includes an altazimuth mount with a
slow motion control in vertical. The coated, achromatic
(color-corrected) objective lens yields sharp, clear images
for viewing both astronomical and terrestrial subjects. The
Meade 70AZ-A includes two 3-element 1.25" barrel-
diameter eyepieces (MA9mm, MA25mm), adjustable
aluminum tripod,and planetarium software for the PC with
10,000-object database.
SPECIFICATIONS
Meade Model 70AZ-A (P/N: 04041) — Supplied complete with
coated objective lens assembly •(D=70mm, F= 700mm, f/10) •Rack-
and-pinion focuser •Altazimuth yoke type mount with vertical slow-
motion control •Two eyepieces (1.25"): MA9mm (78X) and MA25mm
(28X) •5 x 24mm viewfinder •Diagonal mirror •Adjustable aluminum
tripod with shelf •Planetarium software for the PC •Operating
instructions •Giftbox.
AZSERIES
BONUS
StarNavigator™
Software

8
Meade®60AZ-T,
Meade®70AZ-T
Short Tube 60mm (2.4") and 70mm (2.8")
Table Top Altazimuth Refractors
Whether used as casual telescopes for astronomy or as high-
resolution spotting scopes for land viewing, these short tube
telescopes deliver powerful performance in a small package.
These instruments provide bright, richest-field performance
for observing wide-field astronomical objects like galaxies
and nebula from dark skies, or use the provided Barlow lens
for viewing close-up detail of the Moon, planets, or nature
from your own backyard. Compact and portable—these
scopes travel easily and store in a small space.
Both models includes a quality2-element, coated
achromatic objective lens and two 3-element eyepieces.
SPECIFICATIONS
Meade 70AZ-T (P/N: 04058) — Supplied complete with coated
achromatic lens (D=70mm, F=350mm, f/5) •Table top mount with
dual slow motion controls •Two 1.25" eyepieces: (MA9mm,
MA17.5mm) •2x Barlow lens •5x24 viewfinder •Soft carry case •
Instructions.
SPECIFICATIONS
Meade 60AZ-T (P/N: 04062) — Supplied complete with achromatic
lens (D=60mm, F=350, f/5.8) •Table top tripod with pan-handled
control •Two 1.25" eyepieces: (K9mm, K17.5mm) •2x Barlow lens •
Soft carry case •Instructions.
60AZ-T
70AZ-T
AZSERIES

9
SPECIFICATIONS
ETX-70AT Astro Telescope (P/N: 0705-04-10) — Includes a precision
ground refractive lens with optical coatings (D = 70mm, F = 350mm,
f/5) •Fork mount with built-in tracking motors •9-speed #494
AutoStar computer controller with 1400-object database •Internal
battery compartment accepting six (user-supplied) AA-size batteries
•MA9mm (39X) and MA25mm (14X) eyepieces •#882 Standard Field
Tripod •Operating instructions.
ETX®SERIES
#882 Field Tripod
Standard Equipment
Meade ETX-70AT™
Compact GO TO Refractor
INCLUDES AUTOSTAR® COMPUTER AND FIELD TRIPOD
Locate and explore planets, asteroids, comets, nebulae, star
clusters,galaxies,and hundreds of other deep-space
objects, all at the push of a few buttons. For the novice
astronomer or casual observer, the ETX-70AT opens up the
skies to reveal an amazing level of detail.
• Use the standard-equipment #494 AutoStar controller to
automatically locate over 1400 celestial objects. Enter the
object you wish to observe on to the AutoStar display,
press GO TO,and the telescope moves automatically to
place the object in the field of view and then tracks it.
• Compact, multi-coated 70mm refractive optical system of
Grade-A crown and flint glass with 350mm focal length
yields razor-sharp images.
• Supplied with 3-element MA25mm and MA9mm
eyepieces.
• Includes flip-mirror system, built-in tracking motors, and
electronic control panel.

10
Meade®ETX-90AT,
ETX-105AT,
ETX-125AT
Advanced GO TO Telescopes
INCLUDES ADVANCED #497 AUTOSTAR® COMPUTER
CONTROLLER AND #884 DELUXE FIELD TRIPOD
Revolutionary Meade ETX-90AT, ETX-105AT and ETX-125AT
telescopes go with you anywhere at a moment’s notice, and
presentthe finest optical images,bar none,ever made
available in ultraportable telescopes. Use the standard-
equipment #497 AutoStar Computer Controller for automatic
location and tracking of over 30,000 celestial objects at the
push of a button.
ETX optics are so high in contrast, image brightness, and
resolution that they consistently outperform many instruments
of larger aperture.(See ETXbrochure for more information.)
SPECIFICATIONS
ETX-90AT, ETX-105AT, ETX-125AT Astro Telescopes —Maksutov-
Cassegrain optical tube assembly (D = 90mm, F = 1250mm, f/13.8)
or (D = 105mm, F = 1470mm, f/14) or (D = 127mm, F = 1900mm,
f/15) with EMC super multi-coatings •Internal flip-mirror system for
straight-through or 90° observing position •Fork mount with electric
slow-motion controls, setting circles and locks on both axes;
electronic control panel •9-speed dual-axis motor drive system with
#497 AutoStar Computer Controller •Internal compartment for eight
(user-supplied) AA-size batteries •8x21mm erect-image viewfinder
(ETX-90AT) •8x25mm right-angle viewfinder (ETX-105AT and ETX-
125AT) •Series 4000™ Super Plössl 26mm eyepiece (1.25") •#884
Deluxe Field Tripod •Operating instructions.
ETX-105AT™
ETX-90AT™
#884
Deluxe
Field
Tripod
Included
ETX-125AT™
ETX®SERIES
