Meanwell SD-15 Series User manual

Installation Manual
Type：DC-DC converter（Families：PSD, SD, RSD）
Introduction
A DC-DC converter is a device used to convert a DC source from one voltage level to another. Mean Well’s DC-DC
converters equipped with internal EMI filter stage that possess the required EMC performance.
Installation
（1）Before commencing any installation or maintenance work, please disconnect your system from the
utility. Ensure that it cannot be re-connected inadvertently!
（2）For PCB type, at least 5mm insulation distance around the unit should be kept.
（3）Allow good ventilation for the unit in use to prevent it from overheating. Also, a 10-15 cm clearance
must be kept when the adjacent device is a heat source.
（4）Mounting orientations other than standard orientation or operate under high ambient temperature
may increase the internal component temperature and will require a de-rating in output current.
Please refer to the specification sheets to receive the optimum mounting position and information
about the de-rating curve.
（5）Input and Output terminal
Terminal Screw
Series
Screw Size
Suggested Torque
SD-15
M3.0
9.2kgf-cm(8lb-inch)
SD-25/50/100/150/200/350
M3.5
13.8kgf-cm(12lb-inch)
SD-500
M4.0
18.4kgf-cm(16lb-inch)
Terminal Screw
Series
Input
Output
Screw Size
Suggested Torque
Screw Size
Suggested Torque
RSD-30/60/100
M3.5
13.8kgf-cm(12lb-inch)
M3.5
13.8kgf-cm(12lb-inch)
RSD-150/200
M3.5
13.8kgf-cm(12lb-inch)
M4.0
18.4kgf-cm(16lb-inch)
RSD-300
M4.0
18.4kgf-cm(16lb-inch)
M4.0
18.4kgf-cm(16lb-inch)
RSD-500
#6
8kgf-cm(6.9lb-inch)
#6
8kgf-cm(6.9lb-inch)
SD-1000
M4.0
18.4kgf-cm(16lb-inch)
M5.0
10kgf-cm(8.7lb-inch)
（6）Torque can be various due to different material, please refer to the following chart.
A Recommend torque for aluminum：
Size of screw (Imperial units)
Recommend torque (kgf-cm)
3-56
4-40
4-48
5-40
5-44
6-32
6-40
8-32
8-36
2.3±20%
3.0±20%
3.3±20%
4.5±20%
4.7±20%
5.6±20%
6.3±20%
10.4±20%
10.8±20%

Installation Manual
Size of screw (Metric Units)
Recommend torque (kgf-cm)
M2.5
M3
M3.5
M4
M5
M6
M7
M8
2.2±20%
4.1±20%
6.5±20%
9.7±20%
19.5±10%
33.1±10%
55.3±10%
80.6±10%
B Recommend torque for iron：
Size of screw (Imperial units)
Recommend torque (kgf-cm)
3-56
4-40
4-48
5-40
5-44
6-32
6-40
8-32
8-36
5.0±20%
6.9±20%
7.0±20%
9.4±20%
9.9±20%
12.0±20%
13.4±20%
21.8±20%
23.0±20%
Size of screw (Metric Units)
Recommend torque (kgf-cm)
M2.5
M3
M3.5
M4
M5
M6
M7
M8
4.6±20%
8.8±20%
13.7±20%
20.4±20%
41.1±10%
69.1±10%
117.5±10%
169.4±10%
If above mentioned is not enough due to special application，Nylok Blue Patch screw is recommend, and extra
torque can be added if needed.
（7）Recommended input/output wires are shown as below.
AWG
18
16
14
12
10
8
Rated Current of
Equipment (Amp)
6A
6-10A
10-16A
16-25A
25-32A
32-40A
Cross-section of
Lead(mm2)
0.75
1.00
1.5
2.5
4
6
Note: Current each wire carries should be de-rated to 80% of the current
suggested above when using 5 or more wires connected to the unit.
（8）For PCB type, compatible mating housing please refers to the specifications
（9）For enclosed type, make sure that all strands of each stranded wire enter the terminal connection and the
screw terminals are securely fixed to prevent poor contact.

Installation Manual
（10）Special instructions for installation of RSD-500 is shown as below.
The mounting hole circled in red is the protective ground. Please use M5 screw with the diameter of the
screw head less than 8mm.
（11）For other information about the products, please refer to www.meanwell.com for details.
Warning / Caution !!
（1）Risk of electrical shock and energy hazard. All failure should be examined by a qualified technician.
Please do not try to fix the converter by yourself!
（2）Risk of irreparable damage. Do not reverse polarity, both input and output.
（3）Please do not install converters in places with high moisture or near the water.
（4）Please do not install converters in places with high ambient temperature or near fire source. Please
refer to the specifications about the maximum ambient temperature limitations.
（5）Output current and output wattage must not exceed the rated values on specifications.
（6）The ground (FG) must be connected to earth ground.
（7）For system considerations, PCB and enclosed type converters may require an additional inrush
current limiting circuit to suppress high inrush current surges. If you are uncertain about that circuit,
contact Mean Well.
（8）All of Mean Well’s converters are designed in accordance with EMC regulations and the related test reports
are available by request. Since they are belong to component power supplies and will be installed inside
system enclosure, when they are integrated into a system, the EMC characteristics of the end system must be
re-verified again.
（9）This product belong to class A information &technology equip. When install in household environment,
radiation interference may occur, user must implement corresponding solution.
（10）The enclosure of surrounding equipments shall comply with V1 of above flammability capability.

Installation Manual
