mecalac TA3H User manual

Site Dumper
TA3H, TA3SH & TA3.5SH
1 May 2017
English (EN)
2.0
1108
Original Instructions
OPERATOR’S MANUAL
Issue Date:
Language:
Revision No:
Reference No:

Mecalac Construction Equipment UK Ltd
Central Boulevard
Prologis Park
Coventry
CV6 4BX
United Kingdom
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Portal: Oneface.Mecalac.com
WWW.MECALAC.COM
Serial Number
Date of Delivery
Dealer Stamp
Notice
Year of Construction

TA3H, TA3SH & TA3.5SH Table of Contents - 1
Table of Contents
Table Of Contents
1 Introduction
1.1 Important Information .................................................................1.1
1.2 Safety Alert System ....................................................................1.1
1.3 Intended Use ..............................................................................1.1
1.4 Operations Manual .....................................................................1.1
1.5 Identification Plate ......................................................................1.2
1.6 Warranty Registration .................................................................1.4
1.7 Warranty and Maintenance ........................................................1.4
1.8 Service and Replacement Parts Enquiries .................................1.4
1.9 Official Documents European Community Only .........................1.4
1.10 California Proposition 65 ............................................................1.6
1.11 Bulletin Compliance ....................................................................1.6
1.12 Contacting the Manufacturer ......................................................1.6
1.13 Transfer of Machine ownership ..................................................1.7
2 Safety
2.1 Safety Alert System ....................................................................2.1
2.2 ANSI Hazard Classification System ...........................................2.1
2.3 Personal Protective Equipment (PPE) ........................................2.3
2.4 General Safety Information .........................................................2.4
2.5 Seat Belt .....................................................................................2.6
2.6 ROPS .........................................................................................2.6
2.7 Lockout and Tag Out ..................................................................2.6
2.8 Hydraulic Fluid ............................................................................2.7
2.9 Fluid Levels ................................................................................2.7
2.10 Battery Electrolyte ......................................................................2.7
2.11 Fires ............................................................................................2.7
2.12 Water Cooled Engines ................................................................2.8
2.13 Lubricants ...................................................................................2.8
2.14 Oil or Fuel Spillage .....................................................................2.8
2.15 Working on a Gradient ................................................................2.9
2.16 Responsibilities .........................................................................2.10
2.17 Overturning ...............................................................................2.10
2.18 Safety Signs .............................................................................2.10
3 Technical Data
3.1 Dimensions .................................................................................3.1
3.2 Turning Circle .............................................................................3.3
3.3 Data ............................................................................................3.4
3.4 Noise Emissions .........................................................................3.5
3.5 Vibration Levels ..........................................................................3.5
4 Description
4.1 TA3H Dumper - Forward Tip Skip ..............................................4.1
4.2 TA3SH Dumper - Swing Skip .....................................................4.2
4.3 Description ..................................................................................4.2
4.4 Skip .............................................................................................4.4

Table of Contents - 2 TA3H, TA3SH & TA3.5SH
Table of Contents
4.5 Chassis .......................................................................................4.4
4.6 Hydraulic System ........................................................................4.5
4.7 Transmission System ..................................................................4.8
4.8 Battery Isolator ............................................................................4.9
4.9 Circuit Breakers & Audible Warning ..........................................4.10
4.10 Hour Meter ................................................................................4.11
4.11 Control Panel and Switch Functions .........................................4.12
4.12 Start Interlock ............................................................................4.15
4.13 Start/Stop Switch ......................................................................4.16
4.14 Direction Indicator Switch - When Fitted ...................................4.16
4.15 Machine Lighting .......................................................................4.17
4.16 Orange Flashing Beacon ..........................................................4.17
4.17 Parking Brake ...........................................................................4.19
4.18 Skip Control Lever ....................................................................4.20
4.18 Seat Belt ....................................................................................4.21
4.19 Tow Hitch ..................................................................................4.22
5 Transportation
5.1 Loading on to a Trailer or Lorry Using Ramps ............................5.1
5.2 Loading or Unloading using a Crane ..........................................5.1
5.3 Articulation Lock ..........................................................................5.2
5.4 Tie Down Points ..........................................................................5.3
5.5 Tie Down .....................................................................................5.4
6 Initial Setup & Adjustments
6.1 Delivery Checks ..........................................................................6.1
6.2 Setup ...........................................................................................6.1
6.3 Start Up and Adjustments ...........................................................6.2
7 Standard Operating Procedures
7.1 Pre Start Checks .........................................................................7.1
7.2 To Set the ROPS in the Work Position. ......................................7.1
7.3 To Lower the ROP’s for Transport ..............................................7.2
7.4 Seat .............................................................................................7.2
7.5 To Start the Engine .....................................................................7.5
7.6 To Stop the Engine .....................................................................7.6
7.7 To Move the Machine .................................................................7.6
7.8 Loading the Skip .........................................................................7.6
7.9 Skip Operation ............................................................................7.7
7.10 Parking the Machine After Use ...................................................7.9
8 Emergency Operating Procedures
8.1 Running Out of Fuel on a Slope ..................................................8.1
8.2 To Support or Lower the Skip with the Engine “Dead”.................8.1
8.2 “Jump Starting” the Machine .......................................................8.1
8.3 Towing the Machine ....................................................................8.2
9 Maintenance & Lubrication
9.1 General Information ....................................................................9.1
9.2 Maintenance Notes .....................................................................9.1
9.3 Cleaning The Machine ................................................................9.1
9.4 Battery Disposal ..........................................................................9.2
9.5 Hydraulic Oil Under Pressure .....................................................9.2

TA3H, TA3SH & TA3.5SH Table of Contents - 3
Table of Contents
9.6 Skip Support ...............................................................................9.2
9.7 Articulation Lock .........................................................................9.3
9.8 ROPS ..........................................................................................9.4
9.9 Floor Plate Removal ...................................................................9.4
9.10 Battery Removal .........................................................................9.5
9.11 Air Cleaner ..................................................................................9.6
9.12 Engine Oil ...................................................................................9.8
9.13 Engine Coolant .........................................................................9.10
9.14 Hydraulic System ......................................................................9.12
9.15 Hydraulic Tank ..........................................................................9.13
9.16 Hydraulic Tank Removal ..........................................................9.16
9.17 Transmission Pump ..................................................................9.16
9.18 Hydraulic System Return Filter .................................................9.18
9.19 Hydraulic Hoses ........................................................................9.18
9.20 Fuel System ..............................................................................9.19
9.21 Braking System ........................................................................9.21
9.22 Axle Breathers ..........................................................................9.24
9.23 Front Axle .................................................................................9.24
9.24 Rear Axle/Transfer Box ............................................................9.25
9.25 Axle Bolts ..................................................................................9.27
9.26 Centre Pivot ..............................................................................9.27
9.27 Skip ...........................................................................................9.29
9.28 Wheels and Tyres .....................................................................9.29
9.29 Maintenance Schedule .............................................................9.30
9.30 Lubrication Schedule Forward Tip ............................................9.31
9.31 Lubrication Schedule - Swing Skip ...........................................9.33
10. Troubleshooting
10.1 General Troubleshooting ..........................................................10.1
10.2 Electrical Troubleshooting ........................................................10.1
10.3 Hydraulic Troubleshooting ........................................................10.2
11. Recovery
11.1 Towing 1....................................................................................11.1
11.1 Lifting with a Crane ...................................................................11.1
12 Storage, Decommissioning & Disposal
12.1 Long Term Storage ...................................................................12.1
12.2 Decommissioning .....................................................................12.1
12.3 Recommissioning .....................................................................12.1
12.4 Disposal ....................................................................................12.2
12.5 Disposal of Used Batteries .......................................................12.2
13 Glossary of Terms
Appendix 1 - Electrical Diagrams
Appendix 2 - Hydraulic Diagrams

Table of Contents - 4 TA3H, TA3SH & TA3.5SH
Table of Contents

TA3H, TA3SH & TA3.5SH Page 1 - 1
1. Introduction
1 Introduction
1.1 Important Information
Please read and follow this manual carefully. If you use the machine correctly:
• You will stay safe.
• Your machine will perform better and last longer.
We strongly recommend
• That your machine is properly maintained and regularly serviced, as specified in this manual.
• That you use original spare parts obtained from a Mecalac dealer.
We continually make improvements to these machines. We reserve the right to amend the
machine without changing these instructions.
Any modification to this machine which has not been approved by Mecalac in writing is prohibited
and immediately invalidates the manufacturer’s warranty.
The operator of this machine must be a competent person who has received thorough training
in the use of this type of machine. The operator must be supervised by a knowledgeable
supervisor.
For further information, please contact the Mecalac Service Department who will be happy to
help you.
1.2 Safety Alert System
The Safety Alert System identifies important safety messages in this manual. When you see this
symbol, adhere to all safety messages that follow to avoid possible injury or death.
1.3 Intended Use
The machine has been designed and tested to carry out the function of transporting various free
flowing materials. If used correctly, it will provide an effective means of transportation and meet
the appropriate performance standards and regulations.
This machine is not suitable for under ground working or use in hazardous environments.
Use of this product in any other way is prohibited and contrary to its intended use
1.4 Operations Manual
This manual is a guide to the safe operation of the machine and the layout and position of all
controls. It also contains details of checks and procedures within the scope of the operator to
keep the machine in a safe and serviceable condition.
This manual is not a training manual. Contact Mecalac or your local dealer for details of suitable
training courses.
Any person who intends to use this equipment must read this operations manual carefully before
operating the machine.
Make sure this operations manual is kept with the machine at all times and is in good condition
- replace the manual immediately if it becomes dirty, damaged or has been lost. The manual
holder is located in the back of the seat (Figure 1.1) and is lockable

Page 1 - 2 TA3H, TA3SH & TA3.5SH
1. Introduction
Replacement or additional copies of this publication can be ordered from your dealer.
Figure 1.1 - Operations Manual Location
1.5 Identification Plate
The Vehicle Identification Number is recorded on a plate (Figure 1.2) located on the right hand
side of the rear chassis frame.
Figure 1.2 - Vehicle Identification Number Plate Location
You are advised to keep a record of your machines VIN number and the information recorded on
the plate in a safe place
COV00001
1

TA3H, TA3SH & TA3.5SH Page 1 - 3
1. Introduction
.
Figure 1.3 - Vehicle Identification Plate Information - CE Machines
Figure 1.4 - Vehicle identification Plate - German
Figure 1.5 - Vehicle Identification Plate Non CE
1. Company Address
2. Vehicle Identification Number
3. Machine Model
4. Designation
5. Operating Mass (Unladen)
6. Payload
7. Engine Power
8. Year Of Manufacture
9. Model Year
10. Bar Code
11. Works Order Number
1. Company Address
2. Vehicle Identification Number
3. Model
4. Designation
5. Operating Mass (Laden)
6. Maximum Front Axle Load
7. Maximum Rear Axle Load
8. Engine Power
9. Build Year
10. Model Year
11. Bar Code
12. Works Order Number
1. Company Address
2. Vehicle Identification Number
3. Machine Model
4. Designation
5. Operating Mass
6. Payload
7. Engine Power
8. Year Of Manufacture
9. Bar Code
10. Works Order Number

Page 1 - 4 TA3H, TA3SH & TA3.5SH
1. Introduction
1.6 Warranty Registration
Your dealer will have registered you as the owner with Mecalac at the time of sale. Should you
have any queries please consult your dealer in the first instance.
1.7 Warranty Terms and Conditions
Full terms and conditions of the machines warranty will be found on the warranty certificate
incorporated in or accompanying this manual.
1.8 Service and Replacement Parts Enquiries
Please state the vehicle type and the Vehicle Identification Number (VIN) when making enquiries
or orders and in all written correspondence.
1.9 Official Documents European Community Only
(1) CE mark
The Machinery Safety directive is intended to harmonise all the machinery safety regulations
throughout the community so that there will be no technical barriers to trade.
Compliance with the essential safety requirements of the EEC directives 2006/42/EC
(machinery), 2000/14/EC (Noise) and 2004/108/EC, permits companies to CE mark their
products.
The directive affects almost every equipment supplier and user in the community and in
particular, applies to this type of machine.
The regulations require that potential hazards from machinery are properly addressed and
guarded against.
The EC declaration of conformity is a requirement of CE marking. The declaration for this
machine (Figure 1.6) follows.

TA3H, TA3SH & TA3.5SH Page 1 - 5
1. Introduction
Figure 1.6 - Copy of CE Certificate
Contents of the EC Declaration of Conformity
2006/42/EC Machinery Directive
Manufacturer: Mecalac Construction Equipment UK Limited
Central Boulevard
Prologis Park
Keresley End
Coventry
CV6 4BX
United Kingdom
Name of Person to Compile Technical File: Steve Price
Address of Person to Compile Technical File: Mecalac Construction Equipment
UK Ltd
Generic Denomination: Compact Dumper
Machine Function: Earth-moving machinery
Model / Type : TA3H
TA3SH
TA3.5SH
Serial/VIN number
Commercial Name: Same as Model /Type
Mecalac Construction Equipment UK Limited hereby declares that the above piece of machinery is in conformity with
the relevant provisions of the Machinery Directive 2006/42/ EC
Mecalac Construction Equipment UK Limited hereby declares that the above piece of machinery is in conformity with
the provisions of the following other EC-directives: Noise - Equipment Used Outdoors (2000/14/EC), Emissions - Non-
Road Engines (97/68/EC) and Electromagnetic Compatibility (2004/108/EC).
Mecalac Construction Equipment UK Limited hereby declares that the following European harmonised standards have
been used:
EN474-1 & EN474-6
Place of Issue: Coventry, United Kingdom
Date of Issue:
Empowered signatory
Gregg Horne
General Manager

Page 1 - 6 TA3H, TA3SH & TA3.5SH
1. Introduction
1.10 California Proposition 65
California (USA) state law stipulates that the manufacturers of machines operated within its
borders must provide a clear warning to customers regarding exposure to substances commonly
associated with the machine that are recognized by the state as harmful. Mecalac complies with
this requirement by providing the following information.
1.11 Bulletin Compliance
• You must take action and comply with any safety bulletins transmitted to you by your dealer or
by Mecalac.
• Make sure the details of ownership of the machine are recorded by your dealer and the
information is accurate and up to date. Failure to do so may result in critical safety information
being withheld.
• Bulletins can only be issued to the recorded owner or keeper of the equipment. It is your
responsibility to make sure that your dealer or Mecalac has your correct details.
• If you are the new owner contact your local dealer with your details and quote the machines
VIN number to make sure you receive any future bulletins or updates.
1.12 Contacting the Manufacturer
At times it may be necessary to contact the manufacturer of this machine. You must supply the
Model and VIN Number of the machine together with your name and contact details.
You must contact Mecalac for:-
• For any product modifications to your machine.
• To report an accident involving Mecalac equipment.
• Product applications and safety.
• Standards and regulations compliance.
• To report change of ownership or ownership details (if not reported to a Mecalac dealer).
California
Proposition 65
Warning: This product contains and/or emits lead and
leadcompounds,dieselengineexhaust,andusedengine
oil, chemicals known to the state of California to cause
cancer
California
Proposition 65
Warning:This product contains and/or emits lead, lead
compounds and carbon monoxide chemicals known to
the state of California to cause birth defects or other
reproductive harm

TA3H, TA3SH & TA3.5SH Page 1 - 7
1. Introduction
1.13 Transfer of Machine ownership
If you sell or otherwise dispose of your machine you must tell your dealer or otherwise Mecalac.:-
• The name and address of the new owner
• The model and VIN number of the machine
• The date of transfer or disposal.

TA3H, TA3SH & TA3.5SH Page 2 - 1
2. Safety
2 Safety
This manual is designed as a guide to the Machines Controls, Operation and Maintenance. IT IS
NOT A TRAINING MANUAL
2.1 Safety Alert System
The Safety Alert Symbol is used to alert you to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury or death
2.2 ANSI Hazard Classification System
(1) Only Applicable to ANSI Safety Signs)
ANSI safety signs are only fitted to machines used in the US, Canada, Australia and New
Zealand
A multi-tier hazard classification system is used to communicate potential personal injury
hazards.
The following signal words used with the safety alert symbol indicate a specific level of severity
of the potential hazard
All are used as attention getting devices on safety signs fixed to the machinery to assist in
potential hazard recognition and prevention
bDANGER
DANGER - (Always used with a safety alert symbol and white letters on a red background)
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
bWARNING
WARNING - (Always used with a safety alert symbol and black letters on an orange background)
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
bCAUTION
CAUTION - (Always used with a safety alert symbol and black letters on a yellow background)
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

Page 2 - 2 TA3H, TA3SH & TA3.5SH
2. Safety
(2) Property Damage
(3) Procedure
NOTICE
NOTICE - (Used without a safety alert symbol and white italic letters on a blue background) Is
used to address practices not related to personal injury
PROCEDURE
PROCEDURE - (Used without a safety alert symbol and black letters on a green background).
This indicates a procedure that must be followed step by step for safe operation. Make sure all
safety notes have been considered before beginning the procedure.

TA3H, TA3SH & TA3.5SH Page 2 - 3
2. Safety
2.3 Personal Protective Equipment (PPE)
You must wear the PPE shown in the tables below at all times when operating this equipment.
Do not wear rings, scarves or open jackets. Make sure that all loose clothing is tightly secured.
Long hair must be restrained.
You must wear the following PPE when site conditions dictate.
You must wear the following PPE when performing maintenance on the machine.
You must wear the following PPE when site conditions dictate when performing
maintenance on the machine.
Protective
Helmet A protective helmet must be worn at all times to
prevent injury from falling
objects
Safety
Boots Safety boots must be worn at all times when operating
this equipment
Ear
Defenders Ear protection must be worn at all times when
operating or near this
equipment
Safety
Glasses Safety glasses must be worn at all times to prevent
eye injury from flying
objects
High
Visibility
Clothing
High visibility clothing must
be worn at all times when
operating this equipment.
Seat Belt The seat belt must be worn
at all times when operating
this equipment
Protective
Gloves Protective gloves must be worn when necessary to
prevent injury from sharp
objects.
Face
Shield Aface shield must be worn when conditions dictate to
prevent eye or facial injury
from flying objects
Dust Mask A dust mask must be worn
when site conditions dictate Respirator A respirator must be worn when site conditions dictate
Protective
Clothing Protective clothing must be
worn when site conditions
dictate
Safety
Glasses Safety glasses must be worn at all times to prevent
eye injury from flying
objects.
Safety
Boots Safety boots must be worn at all times to prevent
injury.
Protective
Clothing Protective clothing must be worn when conditions
dictate.
Protective
Gloves Protective gloves must be worn when conditions
dictate
Dust Mask A dust mask must be worn
when conditions dictate Face Shield Aface shield must be worn when conditions dictate to
prevent eye or facial injury
from flying objects

Page 2 - 4 TA3H, TA3SH & TA3.5SH
2. Safety
2.4 General Safety Information
Consult your dealer or distributor for details of training courses.
All the time you are working on or with the machine you must consider any possible hazards and
how to avoid them.
Only authorised persons must be allowed to operate this machine.
Unauthorised use of this machine may invalidate your insurance.
Operators and maintenance staff must always comply with the following precautions. These
precautions are given here for your protection. Review them carefully before operating the
machine and before performing general maintenance or repairs. Supervising staff must develop
additional precautions relating to the specific work area and local safety regulations.
Warnings about the Operator
• Before operating the machine make sure you have had proper training and are fully
conversant with the machine and its operation - If in doubt ASK!
• Make sure you, and anyone else who uses the machine, have been trained to operate it
correctly and are physically and mentally fit.
• Do not operate the machine if you are unfit to do so because of alcohol or drugs etc.
• Personal Protective Equipment must be used as specified on pages 2 - 2 and 2 - 3.
• Read this instruction manual carefully before operating the machine. Make sure this
instruction manual is kept with the machine at all times and is in good condition - replace the
manual immediately if it becomes dirty, damaged or lost.
• Read and understand all safety signs before operating the machine.
• Check seat belts daily. YOU MUST ALWAYS WEAR A SEAT BELT WHEN OPERATING THE
MACHINE.
• If the machine is fitted with ROPS and the machine should roll over, the Operator must grip
the steering wheel firmly allowing the seat belt to restrain him/her in the seat until the machine
comes to rest.
Warning for the supervisor
• Establish a training programme for all operators to make sure they are fully familiar with its
operation.
Warnings about other people
• Make sure all bystanders are made fully aware of the safety instructions associated with this
machine and are kept well clear of the operating area.
• Do not carry passengers.
Warnings about the machine
• Make sure the ROPS is not damaged and has no unauthorised modifications.
• Always make sure there is adequate ventilation around the machine. Never run the engine in
an enclosed area without good ventilation or next to combustible materials.

TA3H, TA3SH & TA3.5SH Page 2 - 5
2. Safety
• Stop the engine before refuelling, if there is a spillage mop it up and do not start the engine
until it has been done.
• The exhaust gets extremely hot. Do not place anything on top of it and keep all combustible
materials clear. Do not attempt any maintenance on a hot engine.
• Check your local laws and regulations, the engine may require a spark arrester etc.
• Before performing any maintenance on the machine, place a warning tag on the machine to
prevent accidental start-up and remove the start key and battery isolator. Put the locking bar
into position to prevent the front and rear chassis moving and creating a crushing zone.
• Do not inspect or clean the machine with the engine running.
• Make sure all guards or shields are in place before using the machine.
• Before carrying out maintenance on the hydraulic system make sure the hydraulic fluid is cool
and there is no residual pressure in the hydraulic circuit - hydraulic fluid leaking under
pressure can penetrate the skin.
• Do not operate the machine if it is damaged, improperly adjusted or not completely and
correctly assembled.
• Keep footplates and steps free from dirt, oil, snow, ice etc.
• Do not remove the radiator cap when the engine is hot. Do not add coolant to a hot engine.
• Tyre changes and repairs to punctured tyres MUST only be carried out by fully trained
operatives using the correct equipment. The manufacturer of this machine recommends a
competent firm is employed to carry out these tasks.
Warnings about the work environment
• Be familiar with all prohibited work areas such as excessive slopes and dangerous terrain
conditions.
• Do not drive on slopes or gradients that exceed the safe limits stated for this machine in this
manual.
• If the machine is to be used on the public highway or at night lighting in accordance with
national requirements of the country concerned must be fitted.
• Always use driveways approved by site management when driving around the site.
• In the event of an electrical/lightening storm park the machine in a safe place, dismount and
seek shelter
• Always park machine correctly on firm, level ground where it will not cause an obstruction or
danger - chock the wheels if necessary. DO NOT LEAVE THE ENGINE RUNNING or the start
key in the start switch.
• Before taking the machine on public roads make sure that the machine complies with all road
traffic regulations and obey all driving laws.Warnings about using the Skip
• Do not work under a raised skip unless the props/supports are fitted and locked in position.
• Only fill skip with free flowing loads.

Page 2 - 6 TA3H, TA3SH & TA3.5SH
2. Safety
• When manoeuvring or driving the machine with the skip raised take extreme care as forward
visibility will be restricted.
• Do not drive around the site with the skip raised.
• The operator must get off machine when loading the dumper skip.
• Do not drive the machine on the public highway with the skip in the fully tipped position.
If anyone has any concerns with any safety aspect of the machine the problem must be
reported and the machine must not be used until the safety concerns have been rectified
or an authorised person has checked and satisfied the site personnel the machine is safe
to use.
2.5 Seat Belt
A seat belt is provided for operator safety. It is important that the seat belt is inspected and
checked regularly See Maintenance Section.
Failure to properly inspect and maintain a seat belt can result in death or serious injury.
The seat belt MUST be worn at all times when operating this equipment.
An optional green beacon is available. The green beacon shows from a distance that teh dumper
driver is wearing his seatbelt. The beacon is mounted on the ROPS frame and flashes when in
operation. Do not use the green beacon on a public highway.
2.6 ROPS
A ROPS (Roll Over Protective Structure) is provided for operator safety.
Although ROPS appear to be relatively maintenance-free, regular periodic inspections to make
sure ROPS are damage free and thus capable of functioning in a roll over cannot be over
emphasized.
Through periodic inspections, cracks, loose bolts, damage, and other normal wear and tear
related problems can be eliminated before they become serious.
Proper inspection and maintenance procedures can make sure that ROPS will perform the life
saving function they are designed for and expected to do.
Details on the inspection and maintenance of the ROPS will be found in the Maintenance
Section.
A damaged ROPS must be replaced by a genuine part from the original manufacturer of the
machine and fitted by an authorised dealer.
Do NOT modify or attach items to the ROPS without the manufacturers approval.
Do NOT use the ROPS as an attachment point for towing or pulling equipment.
2.7 Lockout and Tag Out
To prevent unauthorised starting of the machine, before any maintenance you must always:-
• Apply parking brake.
• Place transmission in Neutral
• Remove start key.
• Turn battery isolator to OFF and remove key
• Place warning notice in a prominent position warning others not to attempt to start or drive the
machine.

TA3H, TA3SH & TA3.5SH Page 2 - 7
2. Safety
2.8 Hydraulic Fluid
Fine jets of hydraulic fluid under pressure can penetrate the skin.
Relieve all pressure before dismantling any hydraulic system.
Do not use your fingers to check for small leaks or expose uncovered areas of your body to leaks.
Use a piece of cardboard or thick paper to check for leaks.
Fluid injected into the skin must be surgically removed within a few hours by a doctor familiar with
this type of injury or gangrene will result
2.9 Fluid Levels
Make sure the machine is on firm, level stable ground. It must not be in a dangerous position or
causing an obstruction. Apply the parking brake. Place gear lever is in neutral and the make sure
engine is stopped before checking ALL fluid levels.
2.10 Battery Electrolyte
Contact with battery acid can cause serious burns, blindness or even death. Protective clothing,
gloves and a face shield must be worn at all times when handling or working on a battery.
(1) Skin Exposure
If the skin is exposed to battery electrolyte, the affected skin must be washed immediately with
running water.
If burning is severe seek immediate medical attention.
(2) Eye Contact
If eyes are exposed to battery electrolyte, wash eyes with running water and obtain immediate
professional medical attention.
(3) Battery Charging
When charging the battery hydrogen gas is produced.
Make sure the area is well ventilated to prevent the risk of explosion from a build up of hydrogen.
(4) Frozen Battery Electrolyte
Batteries with frozen electrolyte may explode if used or charged.
Never 'jump start' a machine with a frozen battery.
To help prevent freezing, keep the battery fully charged.
Do Not Use a Machine with Frozen Battery Electrolyte
2.11 Fires
Using water to extinguish an oil fire could spread the fire or give you a shock from an electrical
fire.
Use a carbon dioxide, dry chemical or foam extinguisher whilst waiting for the fire brigade.
Keep fire extinguisher seviceable and have it checked regularly
Do Not Use Water to Extinguish a Machine Fire
