MECHLINE HyGenikx+ HGX-W-10-S Installation instructions

INSTALLATION&OPERATINGMANUALREVISION:04/2020|page1of16





CONTENTS:
ChapterDescriptionPage
1. Introduction .......................................................... 1
2. RatingsandSpecifications .................................... 2
3. ProductSafety ....................................................... 3
4. Structure ............................................................... 5
5. LocationAdvice ..................................................... 5
6. OperatingInstructions........................................
10
7. BioCeptorUnitSizingGuide................................15
8. ModelInformation ............................................... 9
9. OperatingInstructions ........................................ 10
10. On-GoingMachineRequirements ..................... 15
11. AfterSalesandServiceSupport ......................... 15


Chapter1.INTRODUCTION

ThankyouforpurchasingMechline’sHyGenikxTMair&surfacesterilisersystem.Whencorrectlyinstalled,andoperated
inaccordancewiththisOperatorManual,itwillprovidemanyyearsofservice.
HyGenikxisanadvancedandcompact,wallmountedsterilisersystem,proventoeradicatevirusesandbacteria
throughoutfoodserviceandhospitalityenvironments,washrooms,changingroomsandbeyond.
Utilisingacombinationofthemosteffectiveairandsurfacesterilisationtechnologiesavailable-Germicidal
Oxidation,GermicidalIrradiation,DualwavebandPlasmaQuatro-HyGenikxprovidesround-the-clockhygieneand
safetyprotection,controlsodoursandhasalsosignificantlybeenproventoprolongthelifeoffreshperishablefoods.
Mechline’sHyGenikxsystemhasbeenthroughrigoroustesting,providingcustomerswiththeutmostconfidencein
itseffectivenessandquality.




LEAVE THIS MANUAL WITH THE OPERATOR AFTER INSTALLATION
INSTALLATIONINSTRUCTIONS
6.Unit ........................................................................ 6
7.LampandBattery .................................................. 7

INSTALLATION &
OPERATING MANUAL

Air & Surface Steriliser System
REVISION:04/2020|page2of16INSTALLATION&OPERATINGMANUAL
Chapter2.RATINGSandSPECIFICATIONS


Modelnumbers
CommercialFOODSERVICEmodels:
HGX- W/T -10/20/30/15- S/F/R
OFFICEmodels:
HGX - W /T-0 5/25 - O 
RegionUKandEUROPE
AirpurifyingtechnologyNano-titaniumdioxidephotocatalyticoxidation+UV-C
UV-Clamptube1x18wPLLcompositetube
UV-Cintensityinsidechamber15000µW/cm2
UV-ClamptubelifeApprox.8000hours
Airresidencetimeinsidechamber>0.5seconds
Numberofphotocatalytic
baseplates
4pieces
Noiselevel@1metre<39dB
Airflowrate20m3/hr
Suggestedcoverage10-30m210-40m2
InstallationWallmount
HousingmaterialAluminiumalloy–internal,polycarbonatefront,ABSbase
ColourFront–White/Titanium,Back–Grey
UV-Clamptubemodel
S–18/27/54mg
F–27/54/80mg
R–100mg
O–9/18mg
BATTERYSPECIFICATIONS
Mechline’smodelsHGX -W/T…arepoweredbyER14250battery
TypeLithiumThionylChloride
Voltage3.6V
ELECTRICALSPECIFICATIONS
Powerconsumption9-13W
Voltage220V
Frequency50Hz
InputsupplyrequirementsTobeconnectedtosuitablyisolatedsocketorfusedspur
Cordset2Core0.75mm2(L+N),1.8mtotallength,IEC60227-5
Inputprotection3Aprotection
DIMENSIONS&WEIGHTS
Dimensions400mm(L)X135mm(W)X110mm(D)
Weight1.9kg

Air & Surface Steriliser System
INSTALLATION&OPERATINGMANUALREVISION:04/2020|page3of16
Chapter3.PRODUCTSAFETY
3.1GENERALADVICE
Electrical–AllHyGenikxproductsrequireanelectricalconnectionviaafusedswitchspuroraplugsocket.Powermust
alwaysbedisconnectedpriortocarryingoutanywork.Ifyouareunsurehowtodisconnectthepower,orifthereisany
damagetosockets,cables,connections,ortheunititselfpleasestopworkimmediatelyandrequestadvicefrom
Mechlineoraqualifiedelectrician.
Ultravioletlight–DuetotheHyGenikxunitdesign,UVexposureisnotpossibleduringstandardoperation.Beawaredirect
exposuretoUltravioletlightcanbeharmfultoskinandeyescausingirritationoreventemporaryblindness.Ifthereisany
damagetotheunitpleasedisconnectpowerandcontactMechline.
Ozone–WhilstHyGenikxisnotanozonegenerator,averysmallvolumeofozoneisreleasedasaby-productbythe
combinationoftechnologiesused.Atthelowlevelsproducedthereisnopotentialhealthriskduringcorrectoperation.
OurHGX-W-15-R/HGX-T-15-Rrefusemodelisouronlyunitdesignedforuseinunoccupiedareas.Athigherlevelsozone
cancauseirritationtothroat,cough,headachesorshortnessofbreath,thesesymptomsshouldonlybeshorttermandbe
resolvedwhentheindividualisremovedtofreshair.Ifthereareanyconcernsabouttheozoneproducedpleasedisconnect
powertotheunitandcontactMechline.Moreaboutozoneonpage13.
Injury–HyGenikxunitsshouldalwaysbesecurelymountedinasafeposition,ensuringcablesarenotapotentialtrip
hazardandthateveryunitcanbeeasilyreachedforservicing,withanyrelevantelectricaloutletseasilyaccessible.Inthe
eventofabrokenlamp,caremustbetakentoavoidcutstohands(thecompleteunitcanbereturnedtoMechlineforthis
worktobecarriedoutifrequired)andappropriateprotectionshouldalsobeworn.
3.2SYMBOLS
MEANING/DESCRIPTIONSYMBOL
DangerousVoltage
Toindicatehazardsarisingfromdangerousvoltages.

TotallyInsulated
Toindicatetheequipmentisdoubleinsulatedandtherefore
hasnoearthwire.Allinternalelectricallyenergised
componentsaretotallyenclosedwithinaninsulatedbodythat
preventsanycontactwith“live”parts.

Warning/Caution
Anappropriatesafetyinstructionshouldbefollowedorcaution
toapotentialhazardexists.

RefertoManual
Refertotherelevantinstructionsdetailedwithintheproduct
manual.

 
Beforeoperatingtheunit,readtheseinstructionscarefully.Correctinstallationandoperationwillprovideoptimum
performanceandalongerlifeforthishigh-qualityair&surfacesterilisersystem.
 

Air & Surface Steriliser System
REVISION:04/2020|page4of16INSTALLATION&OPERATINGMANUAL
3.2SAFETYINSTRUCTIONS

 






























3.3PRODUCTCONFORMITY
3.3.1Mechline’sHyGenikxair&surfacesterilisersystemconformstotheessentialsafetyrequirementsofthe
LowVoltageDirective(LVD)2014/35/EU,ElectromagneticCompatibilityDirective(EMC)2014/30/EU
andismanufacturedinaccordancewithfollowingstandards:EN60335-1:2012+A11:2014+A13:2017+
A14:2019,EN60335-2-65:2003+A1:2008+A11:2012,EN55014-1:2017,EN61000-3-2:2014,
EN61000-3-3:2013,EN55014-2:2015.
DesignedandmanufacturedtoEUOTA(EuropeanOzoneTradeAssociation)requirements.
Mechline’sHyGenikxair&surfacesterilisersystemissuppliedtothemarketplacehavingbeen
producedunderthecontrolofourcomprehensiveBSIISO9001:2015QualityManagementSystem
(certificateFS616985).
3.2.1Ensuretheunitisinstalled,operatedandmaintainedbytrainedandauthorisedpersonnel.
3.2.2Childrenshouldnotbeallowedtoplaywiththeunit.
3.2.3Theunitshouldbeusedasprovidedandnotbealteredortamperedwithasthesafetyoftheunitmay
becompromised.
3.2.4Onlyconnecttheunittoasingle-phasesocketorasuitablyfusedandisolatedspurwithmainsvoltage,as
specifiedonthe“RatingsandSpecifications”section.
3.2.5Beforeattemptingservicingormaintenancetasks,theunitMUSTbeisolatedfromthepowersource
anddisconnected.
3.2.6Shouldafaultoccurwiththeunit,immediatelyisolateanddisconnectfromthepowersource.
3.2.7Ensuresafestorage/positioningoftheelectricalcablingwhennotinuse.Shouldtheelectricalcable
becomedamagedatanytime,doNOToperatetheunit.
3.2.8Donotusetheunitoutdoorswhereitcanbeexposedtomoisture.
3.2.9Donothandletheplugortheunitwithwethands.
3.2.10Donotoperatetheunitnearwater.Iftheunitcomesintocontactwithliquid,isolatethepower
immediately.
3.2.11Anymodificationstotheelectricalsupplyorconnectionstotheunitmustonlybecarriedoutbya
qualifiedelectricianinaccordancewiththeappropriateCodesofPractice.
3.2.12Themainssocketorfusedoutletmustbeinstalledinanaccessiblelocationclosetotheunittoenable
disconnection.
3.2.13Mechlinerecommendsperiodicinspectionandverificationoftheintegrityoftheelectricalconnectionsin
accordancewithrecommendationsofBS7671,IEEWiringRegs.
3.2.14Keepforeignobjectsawayfromtheunit’sairinletandoutletareas–thismaycauseelectricalproblems
anddamagetheunit.
3.2.15Inpublicareaswewouldrecommendtheunitbehardwiredintoafusedspur.
3.2.16Keeptheunitanditspowercableawayfromhotsurfaces.
3.2.17Donotusetheunitwherecombustiblegasesorvapoursmaybepresent.

Air & Surface Steriliser System
INSTALLATION&OPERATINGMANUALREVISION:04/2020|page5of16
Chapter4.STRUCTURE

HYGENIKXUNIT

LAMP

BATTERY
A AirinletventI UVlampNER14250battery
B
Powercable
J
Cap–colourcoded
O
Batterycompartment
C
Airoutletvent
K
Sheath
(foodsafelampsonly)

PLEDbatterywarninglight
(withaudiblealarm)
D
Aluminiumairdiffuserplates
L
Quartzpartoflamp
E
UVlampbase
M
Endterminal


F
Safetymicroswitch




G
Lid 




H On/Offindicatorlight


Chapter5.LOCATIONADVICE
Forgeneraladvice–refertoSection9.4.11 
Theunitshouldbeplacedinaventilatedarea.Someinitialodourcausedbytheelectricalcomponentswillbe
released.Afteroneortwodaystheodourwilldisappear.TheHyGenikxunitisdesignedtobewallmounted,
verticallyinstalled,withthelogoandcableatthetopoftheunit.Thebottomoftheunitshouldbeataminimum
heightof1.8mAFFL.
•Donotinstalltheunitinapositionwheretheairinletandoutletcouldbeblocked.Thiswillaffect
itsefficiency.
•Avoidinstallingincloseproximitytomechanicalextractionandopenwindows.

Air & Surface Steriliser System
REVISION:04/2020|page6of16INSTALLATION&OPERATINGMANUAL
Chapter6.INSTALLATIONINSTRUCTIONS
6.1INSTALLATIONSTEPS
6.1.1Equipmentneeded:




6.1.2Itisimportanttofirstidentifythebestlocationfortheunit.EnsureyouhavereadChapter5LocationAdvice.
6.1.3 Measure2.2metresAFFL.Markanddrillholesusingtemplateprovidedonpackingbox.

6.1.4 Insertwallplugsintodrilledholes.Usehammertofitwallplugsintoposition.Insertscrewsprovidedinto
wallplugsandscrewintoposition,leaving5mmtohangtheHyGenikxunit.
6.1.5 AlignpocketsonthebackpanelwithscrewsandhangtheHyGenikxunitintopositionasshown.

6.1.6 Connectthepowercabletoasuitablyisolatedsocketorfusedspur.
6.1.7 Beforetheunitisreadytouse,youwillneedtoinstallthelampandbattery.ProceedtoChapter7.


Air & Surface Steriliser System
INSTALLATION&OPERATINGMANUALREVISION:04/2020|page7of16
Chapter7.UV-CLAMPandBATTERY
7.1IMPORTANTADVICE
•Donottouchtheanodizedaluminiumairdiffuserplates.
•DonottouchthequartzpartoftheUVlamp.HandletheUVlampbythecapandendterminalonly.
•Anydirtonthequartzpartofthelampcanbecleanedwithadrycloth.

•Afterapproximately8000hoursor12monthsofcontinuousburning,theUV-Clampwilllose20%to30%of
itspowerandmustbereplaced.
•Thelampsandbatterymustbereplacedevery12monthstoensureoptimumperformanceofthesystem.
•Iftheindicatorlight(showninChapter4aspartPinthediagram)isflashingandanaudiblealarmisheardit
istimeforthelampandbatterytobereplaced.
7.2 LAMPANDBATTERYREPLACEMENT/INSTALLATION
7.2.1 Disconnectfrompower.Unscrew2xfront
covercaptivescrewsanddetachcover.
     
7.2.2 IfyouareremovinganOLDlamp,firmlygrip
lampterminal/connectorend(orendcap)
andcarefullyslidelampoutofthesocket.
Carefullyliftlampawayfromthespringclip
andsocket.

IfyouarefittingaNEWlamp,firmlygriplampterminal/connectorend(orendcap)andcarefullyslide
lampintothesocketandspringclip.
7.2.3 RemoveOLDbatteryand/orfitNEWbatteryasshown.

7.2.4 Replacethefrontcoverusingthe2xcaptivescrews.Reconnectthepowertotheunit.


Air & Surface Steriliser System
REVISION:04/2020|page8of16INSTALLATION&OPERATINGMANUAL
7.2SERVICINGINFORMATION
7.2.1 Inspectionofarea:
•IfyouarecarryingoutaservicecheckonaHyGenikxunitsometimeafterinstallationpleaseensure
theareaissafeandsecuretoworkin.
Appropriatesignageshouldbevisibletowarnpublicthatworkisbeingcarriedout.
•Arethereanyobviousbadodoursources?
TheHyGenikxunitwillhelptocontrolodoursbutitisimportantthatbadodoursourcesonsitecontinue
tobeaddressed.Overflowingbins,unflushedtoilets,leaksetc.shouldallberectified.RefertoSection9.2
forsomeusefulcheckpoints.
7.2.2 Inspectionofeachunit:
•Istheindicatorilluminatedonunitfront,withlamplightalsovisiblethroughtheventsofunit?
IfnotpleaserefertoSection9.3Lamp/UnitFailureChecklist.
•Isthereanodourpresentintheenvironmentthatyouthinkiscomingfromtheunit?
Afterinstallationitisnotunusualfortheunittoproduceaslightlymetallicodourwithinthefirst48hours
ofuseduetothelampbeddingin.Iftheunitisworkingcorrectlybutodourremainsafterthistimeplease
refertoSection9.1.3.
•Istheunitoperational24/7?
Itisimportanttoconfirmwiththesitethattheunit/powertotheareaisnotdisconnectedatanypoint
(withunitsconnectedtolightingcircuits–checkturninglightsoffdoesnotdisconnectunit).
Fortechnicalassistancee-mail[e-mail],quotingtheHyGenikxmodelnumber.Themodelnumber
canbefoundonbothsidesoftheunit.

Air & Surface Steriliser System
INSTALLATION&OPERATINGMANUALREVISION:04/2020|page9of16
Chapter8.MODELINFORMATION
8.1MODELREFERENCECHART

8.2REPLACEMENTLAMP&BATTERYKITS
ReferenceDescription
HGX-10-S LAMP(YELLOW)+BATTERYfor10m
2
GENERALhospitalityareas
HGX-20-S LAMP(GREEN)+BATTERYfor20m
2
GENERALareas
HGX-30-S LAMP(RED)andBATTERYfor30m
2
GENERALareas
HGX-10-F LAMP(ORANGEwithfoodsafeshatterproofsheath)+BATTERYfor10m
2
FOODSERVICEareas
HGX-20-F LAMP(BLUEwithfoodsafeshatterproofsheath)+BATTERYfor20m
2
FOODarea
HGX-30-F LAMP(PURPLEwithfoodsafeshatterproofsheath)+BATTERYfor30m
2
FOODareas
HGX-15-R LAMP(GREY)+BATTERYforuseinREFUSE(non-occupied)areas
HGX-05-O LAMP(BROWN)+BATTERYforOFFICE&SMALLERareasupto10-20m
2

HGX-25-O LAMP(WHITE)+BATTERYforOFFICE&SMALLERareasupto20-40m
2


8.2.1EXAMPLESoflampandbatterykits:


Air & Surface Steriliser System
REVISION:04/2020|page10of16INSTALLATION&OPERATINGMANUAL
Chapter9.OPERATINGINSTRUCTIONS
9.1GENERALADVICEandTROUBLESHOOTING
Thefollowingaregeneralguidelinesfortheoperatoroftheunit.Ifanyquestionsarise,pleasedonothesitateto
contactMechlineoryourMechlinedealer.
9.1.1Unitnotoperatingatall
•Ensurethatthepowersupplyisconnectedandworking
•Checkunitpowerplugconnections
•Tryalternativelamp
9.1.2 Excessivemetallic/electricalodourfromHyGenikxunit
•Thisisharmlessandquitenormalduringthefirstfewdaysofinstallation
•Ifodourcontinueschecklampisclean-thiscanbewipedwithanalcoholbasedcleaner
•Changeforloweroutputlamp
9.1.3 Unitisworkingcorrectlybuttheroomodourremains!
•Checkthattheunitistherighttypeandstrengthforthearea.ContactMechlineifyouareunsure
•Replace/upgradelamp
•Ifunitpreviouslyworkedwell,cleanthoroughlyfollowingthemanufacturer’sinstructions
•RefertoSection9.2ChecklistifRoomOdourRemains
9.2CHECKLISTIFROOMODOURREMAINS(washrooms,refuse,etc.)
9.2.1Checktheunitiscorrectlysizedfortheroomarea
Measurelengthxwidthofroomtogivem2
9.2.2Confirmelectricalsupplyiscontinuousandnotbeingswitchedoffinerror
Somelocationssuchasshoppingcentreshaveacentralswitchoff
9.2.3 Checktheunitlocation
•Ataminimumheightof1.8metres–unitsmustbewallmountedvertically
•Keepinmindsourcesofstrongairflowwhichmaydisrupttheunitdistribution
•RefertoChapter5LocationAdvice
9.2.4 Washroomspecificpoints
•Confirmtheindividualcistern/watermanagementsystemtoeachurinalisflushingcorrectly
•Ensuretrapsareclean,drainingcorrectlyandwatersealsareintact
•Rectifyanyleaks,keyareastocheckarebehindmelaminepanelsandconnectionsbetweenearthenware
pipesfromplasticurinalwaste
•WithStainlesssteelurinalscheckforcalciumbuild-up,bacterialevelscanbehigherthannormalwith
theseurinalssoconsiderupgradinglamp
•Checkfloorbelowurinalsisnotporousandthatgroutinghasnotbrokendown
•Checkthattherearenomissingsealsarounddrainormanholecovers
9.2.5 Generalpoints
•Cantheoutputairfromtheunitaccesstheodour?Checkandrectifyanypossiblesourceofthebadodour
thatcouldbetrappedbehindpanelsorsubfloors(i.e.unsealedconcretefloors).
•Isstrongexternalairflowpreventingairfromtheunitdistributingcorrectly
•Istheodoursourcewet-leaksmustbecompletelydriedoutinordertoeradicateodours
•Istheodourextremeandongoing–mayneedtoincreaseunitoutput
•Confirmstandardcleaningpracticesareinplace

Air & Surface Steriliser System
INSTALLATION&OPERATINGMANUALREVISION:04/2020|page11of16
9.3LAMP/UNITFAILURECHECKLIST
9.3.1Unitwiredtosharedspur(i.e.handdryer)canmeanpowersurgescausinglampfailure
Thisisincorrect,theunitrequiresadedicatedspur
9.3.2Intermittentpowersupplyorpowerswitchedoffatnightcanshortenlamplife
Relocateunitorunitwillrequireadditionallampchanges
9.3.3 Debrisblockingairintakescanreduceairflowcausinglamps,orelectricalballaststooverheat
Reduceperiodbetweenunitcleanstopreventre-occurrence
9.3.4 Unitfittedinahighmoistureenvironmentordirectlyaboveawatersourcesuchasurinalscanleadto
watervapouringress
•Re-siteawayfrommoisturesource
•Increaseventilationofenvironment
•Considerswitchingtoafan-poweredunit.E-mailMechlineforfurtheradvice*
9.3.5 Lampnotpushedfullyhomecancauseshortcircuits
•Checkandconnectlampcorrectly.RefertoChapter7LampandBattery
9.3.6 Touchingtheglassoflampswithbarefingerscanshortenlamplife
•Useglovesortissuewhenchanginglamps
•Iftouchedinerror,cleanglasswithalcoholbasedcleaner
•WhenfittinglamppleaserefertoChapter7LampandBattery
9.3.7 Looseconnectioninpowersupplytounitorinternalwiring
•Checkallvisibleconnections
•IfproblemspersisttheunitmayneedtobereturnedtoMechlineforinspection*
9.3.8 Unidentifiedfault,suspectedpartfailure
•Checklamp,forotherpartsreturntoMechlineforinspection*
*Fortechnicalassistancee-mail[e-mail],quotingtheHyGenikxmodelnumber.Themodelnumber
canbefoundonbothsidesoftheunit.

Air & Surface Steriliser System
REVISION:04/2020|page12of16INSTALLATION&OPERATINGMANUAL
9.4QUESTIONSandANSWERS
Thefollowingaregeneralguidelinesfortheoperatoroftheunit.Ifanyquestionsarise,pleasedonothesitatetocontact
MechlineoryourMechlinedealer.
9.4.1HowdoIknowtheHyGenikxunitisworking?
Firstly,thegreencrosslightindicatorwillbeilluminatedonthefrontoftheunittoshowtheproductisoperating.
After12monthsofusethebuilt-inwarningsystemwilltellyouwhenthelamp(andbattery)requires
replacementtoensurepeakefficiency.
Therewillbeadefinitechangeintheenvironmentalairquality.Internalenvironmentsthathaveausuallingering
backgroundodour,whetherfromcooking/food,bodyodour,cleaningproducts,wastematerial,oracombination
ofthese,willsmellnoticeablyfresher.Thischangewillbemostobviousatthestartofaworkingday,clearly
demonstratingtheunitisworking.
Areaswhereitiseasiertomonitorperformancearethosewithobviousodourissues,suchasawashroom,
changingroomorbinstore.Here,odourswillbesignificantlyreducedoreliminatedcompletely.
9.4.2 Howareyourproductsdifferenttofragranceunits?
(General)Theygofarbeyondodourcontrol.Ratherthanmaskingodourstheyremovesmellsbytargetingand
killingtherootcause,whichisusuallymicroorganisms.(Food)Infoodstoragemicroorganismsareresponsiblefor
spoilageandtheshorteningoffoodlife.Independenttestinghasdemonstratedhowweextendfoodlife
(specificallyvegetablesandsoftfruits)byreducingthemicroorganisms.Note:Thisunitisnottoreplaceproduct
“useby”date.
9.4.3 Whatdotheysmelllike?Isthereafragrance?
Theabsenceofunpleasantbackgroundodoursisusuallythefirstthingcustomersnotice.The'smell'isdescribed
as"cleanandfresh"andhasoftenbeenlikenedtomountainair.Nomaskingfragrancesareused.Note:Within
thefirst48hoursofuseitisnotunusualfortheunittoproduceaslightlymetallicodour,thisiscausedbythelamp
beddingin.Thisshoulddissipatewithin48hours.
9.4.4 Inadditiontoodours,whatarethemicroorganismsthatarereducedbythistechnology?
Bacteria,Viruses,Mould,Fungi.Multipleindependenttestsdemonstratetheefficacyagainstthemostprevalent
oftheseincludingListeria,Ecoli,Staphylococcusaureus,Staphylococcusepidermis,Aspergillusfumigatus,MS-2
Coliphage,MRSAandClostridiumdifficile.
9.4.5 Doesairneedtopassthroughaunittobesanitised?
No,ourtechnologyusesbothinternalandexternalprocessessoalthoughcontaminatespassingthroughtheunit
willbesanitised,italsoproducescleaningairwhichcirculatesthroughout.ThisiswhyHyGenikxcancoversucha
largearea.
9.4.6 Willunitsreducebacteriaonwallsandsurfacesorjustintheair?
Cleaningairfromtheunitwilltargetandreduceallcontaminationwhereverthe‘clean’aircanreach.Testresults
showsubstantialreductioninbothairandsurfacecontaminationinrelativelyshortperiodsoftime.
9.4.7 Howwouldyouexplainyourtechnologyinsimpleterms?
ThespecialistGermicidalUVlampcombinedwithTitaniumDioxidecatalystcleaningplateseliminateanyodours
andharmfulmicroorganismsdrawnintotheunit.Thelampalsoproducesapurifyingplasma(PlasmaQuatro),
whichconvectsfromtheunitandcirculatesaroundtheroomsanitisingtheairandsurfaces.Partoftheprocess
alsohasanionisingeffect,whichwillreducetheamountofairbornedustanddebris.
9.4.8Canyouexplainyourtechnologyinmoredepth?
HyGenikxunitsarefittedwithpowerfuldualwavebandUltravioletlamps.Ahigh-intensitybroadspectrum
ultravioletlamp,withUVC254nmgermicidallightwavelengthsisthefirstpartofphotocatalyticairpurification
technology.Awidersetofultravioletwavelength185nmareemployedforcatalystactivation.AlthoughUVlight
alonewilldegradetoxicorganiccompounds,reactionratesaremuchfasterwithphotocatalyticassistance.
ThecatalystmaterialintheHyGenikx[photocatalyticpurifier]isTitaniumDioxide,TiO2.


Air & Surface Steriliser System
INSTALLATION&OPERATINGMANUALREVISION:04/2020|page13of16
Titaniumdioxideisalsoasemiconductor.Whenasemiconductorisbombardedwithlightofcertainwavelengths,
electronsinthematerial’svalencebandareexcitedintotheconductionband.Thismeanstheyarefreetomove
andtheirenergyendsupsplittingnearbywatermoleculesintotwoparts,hydroxylradicalsandsuper-oxideions.
Freeradicalsareunchargedatomsormoleculeswithunpairedelectrons.Unpairedelectronsarehighlyreactive,
sofreeradicalsquicklyengageinchemicalreactions.Hydroxylradicalsareamongthemostpowerfuloxidizersin
theworld,strongerthanchlorine,ozone,andperoxide,andalsoveryshortlived.
Superoxideiscreatedbytheadditionofoneelectrontooxygen.Thisfreeradicalhasarelativelylonghalf-life:
lessthanonesecond.
Bacteria,virusesandvolatileorganiccompounds(VOCs),areheldtogetherbycarbon-carbon,carbon-oxygenor
carbon-hydrogenbonds.Oxidizersdestroythesebondsandfragmentthemoleculeintosmallercompounds
whicharebrokendownuntilonlycarbondioxideandwaterareleft.
Aphotocatalyticpurifiercaneliminateparticlesdownto0.001micronsfromair,includingtheverytinylung
penetratingparticles.MostHEPAairfilterscannotremoveparticlessmallerthan0.3microns.
Pollens,dustmiteallergens,petdander,mould,bacteria,andvirusesintheair,areonthelistofitemsremoved
throughPhotocatalyticreaction.HyGenikx,incorporatingthistechnology,caneliminatetoxicgasVOCpollutants
includingformaldehyde,exhaustfumes,benzene,toluene,andodourslikeammoniaandhydrogensulphide
fromourair.
•GermicidalIrradiationbydualUVlight(Ultraviolet)killsmicroorganisms(bacteria,virusesandmould)by
disruptingtheirDNAandremovingtheirreproductivecapabilities.
•PCO–PhotocatalyticOxidation,UVreactswithourCatalyst(Ti02TitaniumDioxide)toformhighlyreactive
butshortlivedoxidisingHydroxylRadicals(OH)whichbreakdownVolatileOrganicCompounds(VOCs).
•InteractionoftheDualwavebandUVwiththeTiO2heterogeneouscatalystbothcreatesandbreaksdown
OxygenmoleculestransformingOxygenintoahighlyreactivestatesofOzoneandSuperoxideIonswhich
leavetheunitas“PlasmaQuatro”.
•PlasmaQuatroisthegasenergizedbythehighintensityUVlight.Itleavestheunitwiththeairflowand
consistsofamixtureofactivatedoxygen,triatomicoxygenandsuperoxideions.Theseinteractwitheach
othergivingaveryefficientpurificationoftheairandallexposedsurfaces.Manytimesmoreefficientthan
ozoneorUVlightworkingalone.
9.4.9 Theunitproducesozone.Isthisdangerous?
WhilstHyGenikxisnotanozonegenerator,averysmallvolumeofozoneisreleasedasaby-productofthe
combinationoftechnologiesused.Thisuniquecombinationoftechnologiesisguaranteedtobothachieveresults
andbecompletelysafeinoperation.Ineverycasetheozonelevelspresentfallwellbelowthelowest
internationalsafetylevelsworldwide(WorldHealthOrganization-0.05ppm),asstipulatedbyEUOTA.Thishas
beenverifiedforallunitvariationswithindependentlaboratorytestingcarriedoutby“Odournet”.
 Weallbreatheozone,everydayofourlife,infactwhatweperceivetobefreshairisapproximately0.013ppm
ofozone.
Iftherewasathunderstormnaturewouldproducebetween0.3/0.05ppmwhichgivesusthatnicefreshsmell
thatfollows.
Ozone(O3)isaformofoxygen.Itisacolourlessgaswithadistinctiveodourandisanormalconstituentofthe
earth’satmosphere.Itisabout1.6timesheavierthanair(density2.144g/I).Ozoneisproducednaturallyfrom
oxygenwheneversufficientultraviolet(UV)radiationorelectricaldischargesoccur,forexampleathighaltitudes
orbytheactionoflightning.Suchnaturaloccurrencesareunlikelytoproducehazardousconcentrationsat
groundlevel.Themajorityofozonefoundneargroundlevelisformedbyphotochemicalreactionsinvolving
oxidesofnitrogenandhydrocarbons.
HSEUK-COSHH–ForareasofContinuousoccupation–HSElimit0.1ppm
WorldHealthOrganization–Continuousoccupationdesiredlevel–0.05ppm



QuestionsandAnswerscontinuedoverleaf…

Air & Surface Steriliser System
REVISION:04/2020|page14of16INSTALLATION&OPERATINGMANUAL
TheUSOSHA[OccupationalSafetyHealthAct]websitecitesseveralACGIH(AmericanConferenceofGovernmental
IndustrialHygienists)guidelinesforozoneintheworkplace:
 • 0.2ppmfornomorethan2hoursexposure
 • 0.1ppmfor8hoursperdayexposuredoinglightwork
 • 0.08ppmfor8hoursperdayexposuredoingmoderatework
‘FreshAir’–Ozonelevel0.013ppm
AfteraThunderstorm–Ozonelevelsmeasuredbetween0.3and0.05ppm
HyGenikxunits–Sizedforappropriateareas–Ozonelevels0.03ppm[Max0.04ppm].
[KielLaboratoriesGermany.ISOSensory/OdourTest.ISOAudited].
HyGenikxunits,willcreateozoneenrichedareas,lessconcentratedthanafterathunderstorm.
TherehasneverbeenaknownprovenhealthissuefromanyHyGenikxUVdevicesthatproducestraceozone.
Otherdevicesthatuseaceramicdiscandelectricalchargesystem[Coronadischarge]knownasOzoneGenerators
canproducemassiveamountsofozonealsoproducenitrousoxideanothergreenhousegas.HyGenikxisnotan
ozonegeneratorandtheUVcatalyticreactiondoesnotproducethesegases.OzoneproducedbyUVisoften
referredtoas‘CleanOzone’.
9.4.10Howdoyouinstallaunit?
Unitsmustalwaysbeverticallyinstalledwiththelogoandcableatthetopoftheunit.Thebottomoftheunit
shouldbeataminimumheightof1.8mAFFL.Airiscirculatedthroughouttheareaviathermalconvectionand
incorrectinstallationwillreduceperformance.Pleasefollowenclosedinstructions.RefertoChapters5and6.
9.4.11Wheredoyouinstallaunit?
Locatingtheunitclosetoextractionsystemsoropenwindowswillvastlyreduceperformanceassanitisingairwill
bepreventedfromcirculatingcorrectly.Alwaysbeconsciousofmovementofairthroughouttheroom.Location
closetoincomingventilation(airinput)willassistairfromtheunitincirculatingthroughouttheenvironment.
Avoidinstallingdirectlywithinacookingzonewherelevelsofheatandgreaseareelevated.
Inareasofloweraircirculation,installingtheunitascloseasispracticaltothestrongodour,orcontamination
source,isrecommended(i.e.nexttofoodstorageincoldstore,abovepreparationareasinkitchen,nexttourinals
ortoiletsinawashroomorabovelockerareasinchangingroom).Airfromtheunitwilldispersethroughout,but
thisallowsthekeyareastobetreatedfirst.
9.4.12 Whyaretheredifferentunitvariationsandlampoptions?
Onesizedoesnotfitall.Wesupplyseveralproductvariationstoensurethebestresultsineachenvironmentand
areasize(awashroompresentsaverydifferentchallengetoacoldstore).Anythinginafoodenvironmentmustbe
“foodsafe”sounitsfortheseareashaveaspecialistfoodsafesheathforthelamp.
Differentunitsaresetupfordifferentenvironmentsandtheiranticipatedbacterialevelsandoutputsvary.
Itisimportanttounderstandthatunitsneedtobesuitablysizedtoensurecorrectoperation.Ifyouareunsure
howtosizetheHyGenikxunitpleaserefertochapter8,oremail[email protected]
9.4.13 Whatdothenumbersandcodesrefertoontheunit?
Forthefoodservicemodelsthenumbersrepresentthesquaremeteragetheunitissetupfor,(lengthxwidth-
heightisnotincludedinthiscalculationasthesanitisingairwillfalltogroundlevelwherethehighest
contaminationispresent).
“W”or“T”issimplyacolourchoiceoptionourWhiteorTitaniumfinishtobestsuityourpersonalpreference.
“F”indicatesaproductsuitableforafoodsafeenvironmentasthelampissheathed(shatterproof).
“S”isastandardgeneraluseproductsuitableformostareas,includingwashroomsandchangingrooms.
Standardlampsarenotshatterproof.
“R”isrefuse,ahigheroutputvariationforareaswithstrongodours.“R”versionsshouldnotbeusedinareasof
generaloccupation.
 “O”isamodelforuseinconstantlyoccupiedareassuchasofficeswithlowventilationandairmovement.
9.4.14 Howoftendothebatteryandlampneedtobechanged?
Lampandbatteryshouldbereplacedevery12months.Theunithasaremindersystembuilt-inwithaflashing
indicatorfollowedbyanaudiblealarmtoensurethisdoesnotgetmissed.PleaserefertoChapter7forfulllamp
andbatteryreplacementinstructions.

Air & Surface Steriliser System
INSTALLATION&OPERATINGMANUALREVISION:04/2020|page15of16
Chapter10.ON-GOINGMACHINEREQUIREMENTS
RefertoChapter3ofthismanual,relatingtosafety.
10.1GENERALCLEANINGMAINTENANCE
Thereislittlecleaningrequired.Avacuumcleanermaybeneededtocleandustordebrisaccumulatedontheinlet
andoutletopenings.
•Donotuseawetclothtocleaninletandoutletopeningsoftheunit.
•Pleasebecarefulwhencleaningisinprogress,switchoffallpower.
•DonottouchthequartzpartoftheUVlampandtheanodizedaluminiumairdiffuserplatesatall.
Theseplatesareself-cleaning.
Chapter11.AFTERSALESandSERVICESUPPORT
Fortechnicalassistance,pleasecontactMechline[e-mail]oryourdealer.PleasehavetheHyGenikx
unitmodelnumbertohand.
11.1WARRANTY
Mechline’sair&surfacehygienesterilisersystemhasaoneyearmanufacturer’swarrantyfromthedateoninvoice,
againstdefectivepartsorfaultyworkmanship.Termsandconditionsapply.
NOTE:Lampandbatterypacksarebasic‘consumable’goodsandarenotsubjecttowarranty.
11.2SPAREPARTS
Individualpartscanbereplacedinallunits,ratherthanremovingtheunitfromsite.ForsparepartscontactMechline
[e-mail]oryourdealer.




©2020 All rights reserved. All material on these pages, including and without limitation text, logos, icons, photographs and all other artwork, is copyright material of Mechline Developments Ltd, unless
otherwise stated. Commercial use of this material may only be made with the express, prior, written permission of Mechline. This includes material provided by any third party, including material obtained through links
to other sites from Mechline’s pages or its affiliates and commercial associates. Material and information included are correct at time of print. Intending buyers and users must satisfy themselves as to the suitability and
safety of the products for their particular purposes and duties. Dimensions shown in mm unless otherwise stated. Product accreditation may not apply to all products in the relevant range. Please contact Mechline to
confirm. Unless otherwise stated, all products carry a warranty of twelve (12) months against manufacturing defect or workmanship on parts with no inclusion for labour or site attendance. (HYG-INS) Rev. 04/2020
MECHLINE DEVELOPMENTS LIMITED | Telephone: [phone] | Email: [email protected] | Web: www.mechline.com
Distributed by:
