medemagroup Mini Crosser X2 User manual

User Manual Mini Crosser X2
1533-2002-B ver. 1.0.0 - 2018-06 GB
medemagroup

Medema A/S
User guide 1533-2002-B 2 of 68 Version 1.0.0 - 2018
Medema A/S
Serial number: ___-______________-______-_______
Delivery date: ________________ Year 20______
This vehicle was supplied by: Date: /
Medema A/S
Enggårdvej 7
Snejbjerg
DK-7400 Herning
Denmark
Telefon: [phone]
Mail: [email protected]
Dealer:
For this product You can expect to nd the following documentation:
• User manual
• Service manual
• Spare parts list
• Presell information.

Medema A/S
User guide 1533-2002-B 3 of 68 Version 1.0.0 - 2018
Medema A/S
Contents
Intended occupant................................................................. 5
Help for the visually impaired .............................................. 5
FSN (Field Safety Notice)...................................................... 5
Symbols.................................................................................. 6
Warning! ................................................................................. 6
Alarm ...................................................................................... 6
Contagion!.............................................................................. 6
Introduction............................................................................ 7
Declaration of conformity..................................................... 8
Medema A/S Warranty........................................................... 9
Control panel ......................................................................... 10
User menu.............................................................................. 11
Programming the User Menu ............................................... 14
Preparations / Adjustments prior to use ............................. 16
Electric seat adjustment ....................................................... 18
Seat rotation........................................................................... 19
Steering column .................................................................... 20
Serial number......................................................................... 21
Driving the Mini Crosser X2 ................................................. 22
Lap belt................................................................................... 25
Specic driving situations.................................................... 27
Long hills/difcult ground .................................................... 29
Anti-tilt wheels / stabilisers .................................................. 30
General care and maintenance ............................................ 31
Insurance................................................................................ 32
Batteries ................................................................................. 33
Battery weight........................................................................ 33
Charging................................................................................. 33
Battery disposal..................................................................... 34
Standby power....................................................................... 35
Storage ................................................................................... 37
Cleaning ................................................................................. 37
Changing the wheels............................................................. 38
Fuses ...................................................................................... 43
Brakes..................................................................................... 44
Disengagement...................................................................... 45
Transporting by motor vehicle............................................. 46
Securing to vehicle oor with belts..................................... 47
Transporting by plane........................................................... 50
Towing .................................................................................... 50
Dimensioned drawing, Mini Crosser X2 3W........................ 51
Dimensioned drawing, Mini Crosser X2 4W........................ 52
Introduction to the Ergo2 seat ............................................. 53

Medema A/S
User guide 1533-2002-B 4 of 68 Version 1.0.0 - 2018
Medema A/S
Basket in front ....................................................................... 57
Basket on seatback............................................................... 58
Introduction to the Eblo seat................................................ 59
Flame resistance ................................................................... 60
Troubleshooting .................................................................... 61
Programming ......................................................................... 64
Technical data........................................................................ 64
Weight of the seats................................................................ 67

Medema A/S
User guide 1533-2002-B 5 of 68 Version 1.0.0 - 2018
Medema A/S
Intended occupant
The intended occupant of the Mini Crosser X is a person with
limited ability of walking themselves.
The occupant must be able to see in order to register trafc sig-
nals and other road users when driving in trafc. The occupant
can be deaf and/or speechless.
The occupant must have a cognitive ability to understand the
operation of a scooter and its buttons and icons.
The Mini Crosser can be driven with only one hand either left or
right.
The maximum occupant weight is 175 kg.
Help for the visually impaired
If you have difculty reading small print in the user manual, we
recommend that you visit our website, where you can read this
manual in PDF format. You can enlarge the PDF manual on
your PC monitor to suit your needs and preferences.
If you nd it difcult to understand the manual and have general
questions about the product, please feel free to contact us. You
can nd our contact info on page two in this user manual.
You can nd manuals for all our products on our web page
www.medema.dk. Or contact Medema A/S, and we can send
the manuals in a mail for you. Find the contact information on
page two in this manual.
FSN (Field Safety Notice)
All information concerning safety can be found at www.mede-
ma.com, which is always updated with the latest safety informa-
tion. In the event of important safety-related changes, we will
notify our customers directly (FSN).

Medema A/S
User guide 1533-2002-B 6 of 68 Version 1.0.0 - 2018
Medema A/S
Symbols
Used in the manual to indicate sections describing situations
where extra care is required owing to the risk of personal injury.
Used to indicate sections on electromagnetic compatibility
(EMC).
Warning!
For safety reasons the vehicle must not be lent to persons who
are not completely familiar with it. The vehicle is designed for
one person only.
The Mini Crosser X2 has been designed for users weighing
max. 175 kg. Can be supplied in a HD version as standard for a
max person weight of 250 kg.
Alarm
Temperature sensor, alarm system and tilt alarm are built into
the same box that can be acquired as an option for the Mini
Crosser X2.
Note!
The alarm is always turned off on delivery. See the chapter
about ”Programming the User Menu” to turn on the alarm.
Contagion!
A standard Mini Crosser is equipped with tyres that does not
contage, but if another type of tyres are used, it can sometimes
rub off on oor coverings, particularly linoleum. Medema A/S as-
sumes no responsibility in case of contagion.
To prevent this, we recommend that you protect delicate oors
with some sort of driving surface.

Medema A/S
User guide 1533-2002-B 7 of 68 Version 1.0.0 - 2018
Medema A/S
Introduction
Congratulations on your new Mini Crosser X2 electric mobility
Mini Crosser.
You have now taken possession of an electric mobility Mini
Crosser developed for outdoor driving by active users. It is what
is called a Class C vehicle in according to the European stand-
ard EN 12184.
For optimum enjoyment of this vehicle - and to avoid break-
downs and accidents - we recommend that you read this User
Manual carefully. As a new user, you should pay particular at-
tention to the section entitled “Driving the Mini Crosser X2”.
The Mini Crosser X2 is designed for safe travel for at least 10
years, up to a max. of 5,000 hours, providing it has service
and safety inspections every third year, which is equivalent to
around 1500 hours of operation. The service must be carried
out by an authorised workshop.
IMPORTANT! For safety reasons it is of the outmost importance
that service and safety check intervals are complied with, as
this minimises the risk of brake failure and short-circuits in the
wiring, which could generate heat and cause a re.
We offer a wide range of accessories for the Mini Crosser X2
that can make everyday life easier for you. You are always
welcome to contact us for further information on special acces-
sories and adaptations.
Medema A/S is not responsible for any damage or injuries
caused by inappropriate or unsafe use of the Mini Crosser X2.
If you have any further questions about the Mini Crosser X2 or
this User Manual, you are always welcome to get in touch. Our
contact details are as follows:
Medema A/S
Tel: [phone]
Email: [email protected]
Internet: www.medema.com
NB: Errors and omissions excepted. We reserve the right to
update this manual as required.

Medema A/S
User guide 1533-2002-B 8 of 68 Version 1.0.0 - 2018
Medema A/S
Declaration of conformity
Medema A/S hereby declares that:
Machine: Electric mobility scooter
Use: Transport of walking-disabled people
Model No: Mini Crosser X2
Type of use Class C
Complies with the Medical Device Directive 93/42/EEC
The product is accredited according to standard DS/EN 12184
- Electrically powered wheelchairs, scooters and their chargers -
Requirements and test methods.
The product is risk analysed in accordance with the harmonized
standard DS/EN ISO 14971:2007-04-10 2. edition - Medical
devices - Application of risk management to medical devices.
The Mini Crosser or parts (fx. batteries) af the Mini Crosser can,
for a fee, be taken to the nearest dealer for disposal in accord-
ance with current environmental regulations.
Manufacturer: Medema A/S
Address: Enggårdvej 7, DK-7400 Herning
Tel. [phone]
Date: 31.01.2018 Signature: _____________________
Managing director Finn Dose

Medema A/S
User guide 1533-2002-B 9 of 68 Version 1.0.0 - 2018
Medema A/S
Medema A/S Warranty
1:
There is a 2-year warranty, with the exception of worn parts
such as tires, hoses, fuses, light bulbs, bushings and brake
pads.
2:
If you want to make a claim for a part under the warranty, it
must be intact. The warranty will be void if the product has been
removed or appears to have been mishandled.
3:
There is a 5-year warranty against breakage and corrosion of
the undercarriage.
4:
For the warranty to cover batteries, the charger used must be
sold by Medema A/S.
The fabric, type and serial number must be indicated on the
warranty specication, otherwise, warranty coverage may be
denied.
5:
Items returned under a warranty claim must be suitably pack-
aged to prevent damage during transport. Items damaged
during transport due to poor packaging will not covered by the
warranty.
6:
The warranty does not cover freight costs.
7:
The warranty requires annual inspection and maintenance of
the Mini Crosser by authorised professionals.

Medema A/S
User guide 1533-2002-B 10 of 68 Version 1.0.0 - 2018
Medema A/S
Control panel
Avoid subjecting the control panel to jarring and knocks. Take
care when driving and avoid hitting obstacles.
The manufacturer accepts no liability in respect of the unauthor-
ised opening, adjustment or modication of the control panel.
Lever for adjusting the angle of the
handlebars
Charging socket
Key switch
Accelerator
(four-nger control)
Indicator lights, R/L
Horn
Indicator lights,
R/L
Horn
Speed selector
Hazard warning lights
Battery indicator
Handbrake
Light switch
Actual speed
Accelerator
(four-nger control)
Speed
regulation
Menu / information
Trip meter
Mileage
Light sensor
Extra Switch
Can be used
for optional
functions.
anti-theft alarm

Medema A/S
User guide 1533-2002-B 11 of 68 Version 1.0.0 - 2018
Medema A/S
User menu
Term Description
Menu / information Press the button and a menu at the top of the display
switches between ”Date”, ”Time”, ”Complete km”,
”Complete running time”, ”Battery Voltage” Service
”and” inclination ”.”Slope” is optional, and appears
only if it is engaged.
Button Menu / information are also used to modify the
user parameters.
Access these parameters by holding the menu button
for approx. 3 sec.
Key switch To start the vehicle:
Turn the key to position (1). The rst half second after
the Mini Crosser is on, the control is making a safety
check of the electrical system. If the accelerator is af-
fected during this time, the Mini Crosser will not be able
to run, before the key again has been turned at 0 and
back to 1 again.
Speed selector The turtle indicates lowest speed range. 0-6 km / h.
The hare indicates the highest speed range. Up to 15
km / h. Increase/decrease with + / - button.
The icons turtle/hare can be turned on/off from the
User menu.
Battery indicator The left side of the display shows battery level indicator.
Indicates that after approx. ½ seconds, the battery state
of
charge. Provides a more accurate indication after ap-
prox. 1
minute drive. When both red, yellow and green box
lights are the batteries fully charged. Can be divided
into 10 or 3 boxes. When the view is down the bottom
of the yellow batteries should be recharged as soon as
possible. If there is only light in the red boxes or ash-
ing the batteries must be charged immediately.
Trip meter TRIP button resets the trip meter. Can be used while
driving.
Hand brake Works on the left rear wheel and should only be used
as extra brake / emergency brake and parking brake.
It can be blocked in the locked position. Also available
as a foot brake.

Medema A/S
User guide 1533-2002-B 12 of 68 Version 1.0.0 - 2018
Medema A/S
Term Description
Accelerator
Forw. / Backw.
Front arm activates slowly and the Mini Crosser will
start running forward. The more press, the faster it will
run. When the lever is released, the arm ips itself back
to the starting position and Mini Crosser stops.
Upon activation of the posterior arm, the Mini Crosser
run backward. The Magnetic brake on the rear wheels
will strike at standstill, corresponding to the parking
brake on a car. With speed regulation, speed can also
be regulated downhill. The engine will then act as a
brake.
Light switch Turns on the front and rear lights. The key switch must
however be turned to position 1 (drive).
Hazard warning lights Turns on all lamps at once. Also works when the key
is removed, or turned to 0 (stop position).
Indicator lights switch Arrow left: lamp left side. Arrow Right: lamp right side.
Activate the same button again to turn off ashing
lights.
Horn Electric horn which can be programmed in volume in
the User Menu. Activated by pressing the horn button.
Charging socket Turn off the Mini Crosser (key in position 0) during
charging. Note that it is not possible to run while the
batteries recharge. See also the section ”Batteries and
Charging.”

Medema A/S
User guide 1533-2002-B 13 of 68 Version 1.0.0 - 2018
Medema A/S
Term Description
Extras
Anti-theft alarm (Extra) With this parameter set to ON, the anti-theft
alarm is turned on every time you turn off the Mini
Crosser. An activated alarm is turned off by turning the
key to 1 (drive).
If you have no opportunity to get to the Mini Crosser
with the key, the alarm will stop after approx. 20
seconds. Shake the Mini Crosser again, the alarm will be
activated again.
Tilt Tilt-symbols.
Tilt Alarm sideways By exceeding the preset value, the symbol ashes and
the horn hoots, if the parameter is enabled.
Tilt Alarm forw./backw. By exceeding the preset value, the symbol illuminate
and the horn hoots, if the parameter is enabled.
Overheating step 1 Step 1: The symbol ashes and the speed is reduced to
half power. Wait for 3-5 min and start again.
Overheating step 2 Step 2: The symbol will illuminate and Mini Crosser
stops. Wait 3-5 minutes and start again.

Medema A/S
User guide 1533-2002-B 14 of 68 Version 1.0.0 - 2018
Medema A/S
Programming the User Menu
Access the menu by holding the Menu/information button for
approx. 3 sec. Scroll up and down with the + / -button under the
display. The active parameter is highlighted with yellow writing
and blue background. Access the value of the selected param-
eter by pressing Enter. Change the value using the +/- button.
Conrm with Enter and exit with the Menu/information button.
Parameter description
Date Format Choose between:
ddmmyy - day/month/year
mmddyy - month/day/year
yymmdd - year/month/day
Temp. unit
(Temp. unit is extra)
Choose between Celsius or Fahrenheit. Displays ambient
temperature.
Limited speed
(On/Off)
Limited speed On/Off.
To edit this function you will be asked for a 4 digit code.
From the factory this code is set to be 1234, but it can be
altered by a service technician.
Use the +/- button to each digit. Go to the next digit with the
“Next” button. Conrm with “Enter” Turn this parameter On/
Off – Conrm with “Enter”.
Limited speed (value) Limited speed - value.
To edit this function you will be asked for a 4 digit code.
From the factory this code is set to be 1234, but it can be
altered by a service technician. Use the +/- button to set
% value, that you want the Mini Crosseres max speed
reduced to. Move in increments of 5%.
Backlight (value) The displays backlight can be changed in increments of
5%. Typically used in winter or when driving in darkness,
where the intense light from the display may seem annoy-
ing.
Backlight auto
(On/Off)
Selecting ”On” reduced intensity of the backlight
automatically when darkness falls or when driving into
a tunnel or similar. Light sensor sits just above the light
switch. See the Control panel.
Backlight threshold Here max. light intensity is shown in%. Move in increments
of 5%.
Reverse Buzzer (Off/
Beep/Buzze)
Same warning horn as it is known from trucks in reverse
gear.
Choose from ”Off”, ”Beep” - low horns, or ”Buzzer” - sharp
horns.
Keyboard sound
(On/Off)
With ON / OFF select whether to be acknowledged with a
little beep when you press the contacts on the dashboard.
These are: ashing, lights, hazard, menu, arrows and
MENU keys.
Blinker sound (Off/
Beep/Buzze)
Choose whether you want a sound when ashing lights on
the Mini Crosser is on. Just as we know it from a car. You
can
select ”Off”, ”Beep” - low horns, or ”Buzzer” - sharp horns.
Clock Set time and date using the up / down with arrows. Moving
to the next digit by pressing the ”next” button. Quit with the
”Enter”

Medema A/S
User guide 1533-2002-B 15 of 68 Version 1.0.0 - 2018
Medema A/S
Parameter description
Hazard enabled
(On/Off)
By default hazard (emergency lights) is operable even if the
Mini Crosser is switched off and the key is removed.
If you wish the hazard not be activated with the Mini
Crosser
turned off, you should select ”Off.” here.
Alarm enabled
(On/Off) Extra
With this switch ”On”, the burglar alarm is turned on every
time you turn off the Mini Crosser. The small lamp next to
the
”Trip meter” will  ash a few seconds interval.
An activated alarm is turned off by switching the key on the
Mini Crosser. If you have no opportunity to get to the Mini
Crosser
with the key, the alarm will switch off after approx. 20th
seconds. Shake / move the Mini Crosser again, the alarm
will be
activated again.
Tilt Present (On/Off)
Extra
With this parameter set to ”On”, will turn the tilt icons to red
and blinking, and there will be a whining tone (if enabled) if
you are running on a slope that is steeper than allowed.
P&G fault log Here are the faults that P & G engine management has
registered. The system can record 8 different types of
faults. Each fault can be recorded up to 30 times.
The newest registered fault is written at the top of the list.
They are shown as follows:
[1502] 2
None
None
None
None
None
None
In this case, the fault 1502 appeared twice. If you press
ENTER on the fault you will get an explanatory text. In this
case, ”Solenoid brake fault”
None means that there have not been other faults.
In case of fault on the Mini Crosser, it will be a great help if
the fault type can be given to the Mini Crosser or his
representative during troubleshooting.
Temperature sensor, alarm system and tilt alarm are built into
the same box that can be acquired as an option for the Mini
Crosser X2.

Medema A/S
User guide 1533-2002-B 16 of 68 Version 1.0.0 - 2018
Medema A/S
Preparations / Adjustments prior to use
Adjusting the height of the seat
Lift both armrests up, and fold the seatback. Release the handle
so the seat can turn. Turn a little and lift the seat off.
Make sure you keep your back straight when lifting the seat,
which is very heavy.
Lift the seat off the seat tube.

Medema A/S
User guide 1533-2002-B 17 of 68 Version 1.0.0 - 2018
Medema A/S
The release button pressed in. Press the
button out to release the seat tube.
Release button pressed out. Now the
seat tube can be moved up/down to
the height you wish. Press the release
button again and make sure it is tted in
one of the 5 holes in the seat tube.
Hight adjustment seat post with position bolt (option)
Hight adjustment seat post standard
Loosen the counter nut.
Use spanner, 17 mm.
Adjust the seat post to the desired
position. The seat post is marked with a
ring at each centimetre.
Be aware that the black line is holding its position after movement, so the seat is
straight in front of the steering.
Tighten the screw, here after the counter nut.
Mount the seat. Adjust the lining if necessary.

Medema A/S
User guide 1533-2002-B 18 of 68 Version 1.0.0 - 2018
Medema A/S
Seat tube in top position. There are ve
holes for adjusting the seat tube. The
release must be in a hole for the seat to
be stable.
Electric seat adjustment
The Mini Crosser can be tted with electric seat adjustment as
an optional extra.
To raise the seat, press the switch up. To lower the seat, press
the switch down. If the switch is released, the seat will stop au-
tomatically. (See gure below.)
For safety reasons, a switch has been incorporated that reduc-
es the speed by 50% when the seat is raised more than 7.5 cm.
Electric seat adjustment. If the switch is pressed up, the seat
is raised. If the switch is pressed down, the seat is lowered.
Switch for electric
seat adjustment
Seat tube
Release

Medema A/S
User guide 1533-2002-B 19 of 68 Version 1.0.0 - 2018
Medema A/S
IMPORTANT!
The Mini Crosser is most stable when the seat is in its lowest
position. Always drive carefully when the seat is raised. Never
use the seat adjustment when driving on an uneven surface or
in hilly terrain.
Take extra care when lowering the seat on a Mini Crosser using
electric seat adjustment. Make sure that nothing is trapped in
the space between the seat and the chassis.
Avoid trapping anything when lowering the seat.
Release lever for seat rotation. Release lever for seat forward/back.
Seat rotation
Pull the release lever back. The seat can be rotated 90° to
either side. When the lever is released, it engages with the seat
and holds it in place at 45° intervals.
Other seats that can be supplied for the Mini Crosser work on
similar principles. The release lever is normally mounted on the
right, but can be put on the left if so wished.

Medema A/S
User guide 1533-2002-B 20 of 68 Version 1.0.0 - 2018
Medema A/S
Steering column
Can be adjusted forward/back with the release lever. Pull down
on the lever and pull the handlebars closer for a good driving
position. Use the lever again and push the steering column for-
ward to make it easier to get out.
The height of the steering column can be adjusted approx. 11
cm up/down. First remove the rubber plug covering the Allen
screw. Adjust the height using a 4 mm Allen key.
This applies to both the 3W and the 4W model. Remember to
retighten properly after adjusting.
Adjusting the height of
the handlebars. Applies
to both the 3W and the
4W model.
Lever for adjusting the angle of
the handlebars
Adjusting the height of
the handlebars. Applies
to both the 3W and the
4W model.
Allen screw for height
adjustment
