medemagroup Mini Crosser X-Joy User manual

User Manual Mini Crosser X-Joy
1533-2007-B ver. 1.0.5 - June 2020 GB
medemagroup

User guide 1533-2007-B 2 of 60 Version 1.0.5 -2020
Medema A/S
This vehicle was supplied by: Date: /
Serial number: ___-______________-______-_______
Delivery date: ________________ Year 20______
Medema A/S
Enggårdvej 7
Snejbjerg
DK-7400 Herning
Denmark
Telefon: [phone]
Mail: [email protected]
Dealer:
For this product You can expect to nd the following documentation:
• User manual
• Service manual
• Spare parts list
• Presell information.

User guide 1533-2007-B 3 of 60 Version 1.0.5 -2020
Medema A/S
Contents
Intended occupant................................................................. 5
Help for the visually impaired .............................................. 5
FSN (Field Safety Notice)...................................................... 5
Symbols.................................................................................. 6
Warning!................................................................................. 6
Joystick.................................................................................. 6
Contagion!.............................................................................. 6
Introduction............................................................................ 7
Declaration of conformity..................................................... 8
Medema A/S Warranty........................................................... 9
Designations.......................................................................... 10
Designations Joystick........................................................... 11
Designations functions......................................................... 12
Joystick lock / unlock ........................................................... 13
Safety check Joystick........................................................... 13
General care and maintenance ............................................ 14
Insurance................................................................................ 15
Preparations / Adjustments prior to use............................. 16
Seat rotation........................................................................... 18
Serial number......................................................................... 19
Driving the Mini Crosser X-Joy ........................................... 20
Lap belt................................................................................... 23
Specic driving situations.................................................... 25
Anti-tilt wheels / stabilisers.................................................. 27
Batteries................................................................................. 28
Battery weight........................................................................ 28
Charging................................................................................. 28
Battery disposal..................................................................... 30
Storage................................................................................... 30
Cleaning ................................................................................. 30
Changing the wheels............................................................. 31
Fuses...................................................................................... 33
Brakes..................................................................................... 34
Disengagement...................................................................... 35
Transporting by motor vehicle............................................. 36
Securing to vehicle oor with belts..................................... 37
Transporting by plane........................................................... 40
Towing.................................................................................... 40
Dimensioned drawing, Mini Crosser X-Joy ........................ 41
Introduction to the Ergo2 seat ............................................. 42
Basket on seatback............................................................... 47
Introduction to the Eblo seat................................................ 48

User guide 1533-2007-B 4 of 60 Version 1.0.5 -2020
Medema A/S
Flame resistance ................................................................... 49
Electric functions .................................................................. 50
Troubleshooting .................................................................... 51
Troubleshooting ................................................................... 52
Programming......................................................................... 53
Technical data........................................................................ 54
Weight of the seats................................................................ 57
Own notes.............................................................................. 58

User guide 1533-2007-B 5 of 60 Version 1.0.5 -2020
Medema A/S
Intended occupant
The intended occupant of the wheelchair is a person with lim-
ited ability of walking themselves.
The wheelchair is equipped with a joystick control which makes
it usable for an occupant who only has low functionality in the
ngers. It can be driven with only one hand either left or right.
The occupant must be able to see in order to register tra󰀩c sig-
nals and other road users when driving in tra󰀩c. The occupant
can be deaf and/or speechless.
The occupant must have a cognitive ability to understand the
operation of the joystick and its buttons and icons.
The maximum occupant weight is 150 kg.
Help for the visually impaired
If you have di󰀩culty reading small print in the user manual, we
recommend that you visit our website, where you can read this
manual in PDF format. You can enlarge the PDF manual on
your PC monitor to suit your needs and preferences.
If you nd it di󰀩cult to understand the manual and have general
questions about the product, please feel free to contact us. You
can nd our contact info on page two in this user manual.
You can nd manuals for all our products on our web page
www.medema.dk. Or contact Medema A/S, and we can send
the manuals in a mail for you. Find the contact information on
page two in this manual.
FSN (Field Safety Notice)
All information concerning safety can be found at www.mede-
ma.com, which is always updated with the latest safety informa-
tion. In the event of important safety-related changes, we will
notify our customers directly (FSN).

User guide 1533-2007-B 6 of 60 Version 1.0.5 -2020
Medema A/S
Symbols
Used in the manual to indicate sections describing situations
where extra care is required owing to the risk of personal injury.
Used to indicate sections on electromagnetic compatibility (EMC).
Warning!
For safety reasons the vehicle must not be lent to persons who
are not completely familiar with it. The vehicle is designed for
one person only.
The Mini Crosser X-Joy has been designed for users weighing
max. 150 kg.
Joystick
The joystick control box must not be exposed to extremes
of temperature or kept in a damp environment for extended
periods.
The joystick control box must not be subjected to heavy knocks.
Do not switch o󰀨 the control box while driving, except in an
emergency, as this may damage the electronics.
For cleaning, use a damp cloth with slightly soapy water.
Do NOT allow any water or moisture to enter the control box.
Contagion!
A standard Mini Crosser is equipped with tyres that does not
contage, but if another type of tyres are used, it can sometimes
rub o󰀨 on oor coverings, particularly linoleum. Medema A/S as-
sumes no responsibility in case of contagion.
To prevent this, we recommend that you protect delicate oors
with some sort of driving surface.

User guide 1533-2007-B 7 of 60 Version 1.0.5 -2020
Medema A/S
Introduction
Congratulations on your new Mini Crosser X-Joy electric mobil-
ity wheelchair.
You are now the owner of an electric mobility wheelchair devel-
oped for use indoors as well as outdoors. It is what is called a
Class C vehicle according to the European standard EN 12184.
To get the best out of this vehicle - and to avoid breakdowns
and accidents - we recommend that you read this User Manual
carefully. If you are a new user, you should pay particular atten-
tion to the section “Driving the Mini Crosser X-Joy”.
The Mini Crosser X-Joy is designed to stay safe to use for at
least 10 years, up to a maximum of 5,000 hours, providing it
has service and safety inspections every third year, which is
equivalent to around 1500 operating hours. The service must be
carried out either by Medema A/S or an authorised workshop.
IMPORTANT! For safety reasons it is of the utmost importance
that service and safety check intervals are complied with, as
this minimises the risk of brake failure and short-circuits in the
wiring, which could generate heat and cause a re.
We o󰀨er a wide range of accessories for the Mini Crosser X-
Joy that can make everyday life easier for you. You are always
welcome to contact us for further information on special acces-
sories and adaptations.
Medema A/S is not responsible for any damage or injuries
caused by inappropriate or unsafe use of the Mini Crosser X-
Joy.
If you have any further questions about the Mini Crosser X-Joy
or this User Manual, you are always welcome to get in touch.
Our contact details are as follows:
Medema A/S
Phone: [phone]
Email: [email protected]
Internet: www.medema.dk
NB: Errors and omissions excepted. We reserve the right to
update this manual as required.

User guide 1533-2007-B 8 of 60 Version 1.0.5 -2020
Medema A/S
Declaration of conformity
Model: Mini Crosser X-Joy
Medema-A/S declares on our sole responsibility that the product
range mentioned below are manufactured in accordance with our
incorporated standards and are in conformity with the following
directives and standards if they are used according to our instruc-
tions:
Regulation (EU) 2017/745 of the European Parliament and of
the Council of 5 April 2017 on medical devices.
EN 12184:2014 Electrically powered wheelchairs, scooters and
their chargers - Requirements and test methods
Risk analysed according to ISO 14971:2012, Medical devices –
Application of risk management to medical devices.
Type of use : Transporting walking disabled people
Risk Class : I
The product range in the Mini Crosser model-X-Joy includes the
following items
Product name Basic UDI-DI
Mini Crosser X-Joy 4W 10 km/h 5707299MCXJ-4W10FU
Mini Crosser X-Joy JR 4W 10 km/h 5707299MCXJJR-4W10WT
Mini Crosser X-Joy 4W EL 10 km/h 5707299MCXJ-4WEL10L2
Mini Crosser X-Joy 4W EL JR 10 km/h 5707299MCXJ-4WELJR10FY
Mini Crosser X-Joy CAB 10 km/h 5707299MCXJ-4WCAB10BB
The Mini Crosser or parts (fx. batteries) af the Mini Crosser
can, for a fee, be taken to the nearest dealer for disposal in ac-
cordance with current environmental regulations.
Manufacturer: Medema A/S
Address: Enggårdvej 7, DK-7400 Herning
Tel. [phone]
Date: 16.03.2020 Signature: _____________________
Managing director Finn Dose

User guide 1533-2007-B 9 of 60 Version 1.0.5 -2020
Medema A/S
Medema A/S Warranty
1:
There is a 2-year warranty, with the exception of worn parts
such as tires, hoses, fuses, light bulbs, bushings and brake
pads.
2:
If you want to make a claim for a part under the warranty, it
must be intact. The warranty will be void if the product has been
removed or appears to have been mishandled.
3:
There is a 5-year warranty against breakage and corrosion of
the undercarriage.
4:
For the warranty to cover batteries, the charger used must be
sold by Medema A/S.
The fabric, type and serial number must be indicated on the
warranty specication, otherwise, warranty coverage may be
denied.
5:
Items returned under a warranty claim must be suitably pack-
aged to prevent damage during transport. Items damaged
during transport due to poor packaging will not covered by the
warranty.
6:
The warranty does not cover freight costs.
7:
The warranty requires service inspection and maintenance of
the Mini Crosser by authorised professionals.

User guide 1533-2007-B 10 of 60 Version 1.0.5 -2020
Medema A/S
Designations
The following designations refers to the explanation later in the
instruction book.
Joystick
Control panelHeadrest
Thermal fuse
Manual
Disengagement lever
Seat rotation
Release handle
forw. / backw.
Eye for restraints
Charging
socket
Serial number on
vehicle.
Eye for
restraints
Hand brake
Electric
Disengagement Stop light
Basket
Support handle
Indicator
lights
Indicator
lights

User guide 1533-2007-B 11 of 60 Version 1.0.5 -2020
Medema A/S
Designations Joystick
P&G R-net
1 Start/stop-button
2 Battery indicator
3Driving prole
4 Warning blinkers
5 Mode LED
6 Light
7 Mode button (electric functions)
8 Blinkers left/right
9Mode LED
10 Joystick
11 Speed increase / decrease
12 Horn
1
5
6
12
7
8
2
4
3
9
11
10

User guide 1533-2007-B 12 of 60 Version 1.0.5 -2020
Medema A/S
Designations functions
P&G R-net
1 Press the button 1 to start the Mini Crosser. Wait until the battery indicator is
stable (3-5 sec).
2 Battery indicator
Show a more precis indication after approximately one minute of driving.
When all the LED is lit, the batteries are fully loaded. When only a couple of
yellow lights are visual - charge as soon as possible. If only the red LED are
showing, or if they are blinking - charge right away.
3Driving prole show what the maximum speed are set to. There are ve
LED. One LED refer to lowest speed and ve LED refer to maximum speed.
4Warning blinkers - all blinkers are activated. Even if the vehicle is turned of,
it will not stop blinking. To turn of the warning blinkers, the vehicle must be
turned on, and press the button for warning blinkers button (4) again.
5Mode LED - lights up when the associated function is active
6Light - turn the front- and backlight on. Turn it o󰀨 again by pressing the light
button (6) again.
7 Mode button - (electric functions). Scrolls through the available electric
functions. Use joystick up/down to adjust.
8Blinkers (right and left) start blinkers on the side the arrow shows.
9 Mode LED - lights up when the associated function is active
10 Joystick - controls the direction and speed of the vehicle.
11 Speed increase/decrease - increase or decrease the maximum speed.
12 Horn - powerful electric horn.
1
5
6
12
7
8
2
4
3
9
11
10

User guide 1533-2007-B 13 of 60 Version 1.0.5 -2020
Medema A/S
Safety check Joystick
Daily safety check: (User)
The electronic system has an integrated safety check which
runs up to 100 times per minute. To supplement this check, you
should carry out the following regular checks.
• Switch o󰀨 the electronic system (no lights in the display)
• Check if the joystick is bent
• Check if the joystick is damaged in any other way
• Check that it returns to the central position when you release it
If the check reveals any problems, contact a competent service
engineer before using the Mini Crosser again.
Weekly safety check: (User)
Parking brake: This test must be carried out on a at surface
with at least one metre of free space around the Mini Crosser.
• Start the Mini Crosser and slowly move the joystick forward.
There is a clicking sound. (The Mini Crosser may start to move in
this setting).
• Immediately release the joystick and listen for the clicking sound,
which should occur within one second.
Joystick lock / unlock
X-Joy can be locked, so unauthorized persons cant use it.
• Turn on the Joystick
• Push and hold the on/o󰀨 button. After 1 sec, you will hear a short
audio signal.
• Let go of the on/o󰀨 button. Move the joystick forward until you
hear a short audio signal.
• Move the joystick backward until you hear a long audio signal.
• X-Joy is locked.
It is now impossible to drive the X-Joy.
Unlock:
• Turn on the Joystick
• Move the joystick forward until you hear a short audio signal.
• Move the joystick backward until you hear a short audio signal.
• Let go of the joystick and you will hear a long audio signal.
• X-Joy is now unlocked.

User guide 1533-2007-B 14 of 60 Version 1.0.5 -2020
Medema A/S
General care and maintenance
A Mini Crosser X-Joy does not require much maintenance. It
should be kept in a generally good condition, however. The fol-
lowing should be checked regularly:
• Tyre pressure (if pneumatic tyres are tted)
• Tyre wear
• Keep the control panel, the charging socket and the electronics
box under the seat dry.
• Battery charging
Never wash the Mini Crosser with a high-pressure cleaner or di-
rect water jet! This could damage the Mini Crosser’s electronics.
To keep the Mini Crosser in good condition safety-wise, we rec-
ommend the following regular checks:
Daily: (User)
• Test the indicators and driving lights before using the Mini Crosser
in the dark or poor visibility.
Every three months: (User)
Test the brakes and motor disengagement
With the disengagement lever up, it must not be possible to
push the Mini Crosser.
Repeat in all directions.
• Check that the rubber bellows around the joystick is intact. This is
important, as the bellows prevent moisture getting into the elec-
tronic system.
• Check that the control box is properly secured.
If the check reveals any problems, contact a competent service
engineer before using the Mini Crosser again.
Monthly check: (User)
Check the tyre pressure at least once a month. See technical
data for correct pressure.

User guide 1533-2007-B 15 of 60 Version 1.0.5 -2020
Medema A/S
Service: (Technician)
The Mini Crosser X-Joy is designed for safe travel for at least
10 years, up to a max. of 5,000 hours, provided it is serviced
and safety-checked every third year, corresponding to 1500
hours of operation. The service must be carried out by an au-
thorised workshop.
IMPORTANT! For safety reasons it is of the utmost importance
that the servicing and safety check intervals are complied with,
as this minimises the risk of brake failure and short-circuits in
the wiring, which could generate heat and cause a re.
(For further information, consult the Service Manual.)
Insurance
In the eyes of the law a Mini Crosser X-Joy with a maximum
speed of 13 km/h is a bicycle, so separate insurance is not
required.
Most contents/home insurance policies include third-party liabil-
ity insurance for cyclists and so also cover Mini Crosser X-Joy
users.
We recommend that you talk to your insurance company about
this when the vehicle is delivered. If necessary, comprehensive
insurance will have to be taken out separately.
Test the brake disengagement function
When the brake disengagement lever is down, the battery indi-
cator should ash to show an error if the Mini Crosser is turned
on. In this case the Mini Crosser must not be able to move
when the joystick is activated.
Test the hand brake.
Apply the hand brake for a couple of seconds at low speed.
This will ensure that the lever arm and brake shoes do not seize
up.
Lubricate the lever arm on the brake hub with acid-free oil - left-
hand rear wheel.

User guide 1533-2007-B 16 of 60 Version 1.0.5 -2020
Medema A/S
Preparations / Adjustments prior to use
Adjusting the height of the seat
Lift both armrests up, and fold the seatback. Release the handle
so the seat can turn. Turn a little and lift the seat o󰀨.
Make sure you keep your back straight when lifting the seat,
which is very heavy.
Lift the seat o the seat tube.

User guide 1533-2007-B 17 of 60 Version 1.0.5 -2020
Medema A/S
Hight adjustment seat post standard
The release button pressed in. Press the
button out to release the seat tube. Release button pressed out. Now the seat tube can be moved up/down to
the height you wish. Press the release
button again and make sure it is tted in
one of the 5 holes in the seat tube.
Loosen the counter nut.
Use spanner, 17 mm.
Adjust the seat post to the desired
position. The seat post is marked with a
ring at each centimetre.
Be aware that the black line is holding its position after movement, so the seat is
straight in front of the steering.
Tighten the screw, here after the counter nut.
Mount the seat. Adjust the lining if necessary.
Hight adjustment seat post with position bolt (option)

User guide 1533-2007-B 18 of 60 Version 1.0.5 -2020
Medema A/S
Seat tube in top position. There are ve
holes for adjusting the seat tube. The
release must be in a hole for the seat to
be stable.
Seat tube
Release
IMPORTANT! The Mini Crosser is most stable when the seat
is in its lowest position. Always drive carefully when the seat
is raised. Never use the seat adjustment when driving on an
uneven surface or in hilly terrain.
Take extra care when lowering the seat on a Mini Crosser using
electric seat adjustment. Make sure that nothing is trapped in
the space between the seat and the chassis.
Avoid trapping anything when lowering the seat.
Seat rotation
Pull the release lever back. The seat can be rotated 90° to
either side. When the lever is released, it engages with the seat
and holds it in place at 45° intervals.
Other seats that can be supplied for the Mini Crosser work on
similar principles. The release lever is normally mounted on the
right, but can be put on the left if so wished.

X-Joy
2020
User guide 1533-2007-B 19 of 60 Version 1.0.5 -2020
Medema A/S
Serial number
All vehicles have a serial number plate showing the year of pro-
duction, and serial number. The same serial number can also
be found on page two of the User Manual.
Please quote this number when making inquiries about servic-
ing, spare parts, etc.
Maximum user weight
Vehicle’s unladen weight inc.
batteries and seat
Position of serial number plate on vehicle.
Serial number
Model description
Year of production Max. speed
13
Release lever for seat rotation. Release lever for seat forward/back.

User guide 1533-2007-B 20 of 60 Version 1.0.5 -2020
Medema A/S
Driving the Mini Crosser X-Joy
Getting on and o󰀨
It is important to learn a safe technique for getting on and o󰀨 the
Mini Crosser.
In general the following method should be followed:
• Make sure that the Mini Crosser X-Joy is turned o󰀨.
• Make sure that the brake is on. (Lever for disengaging motor in
top position.)
• If necessary, turn the seat through 45° or 90° and make sure that
it is locked in position (clicked into place).
• If necessary, raise the armrest.
For some users the assistance of an attendant can be recom-
mended. The attendant should:
• Take care not to injure him/herself when lifting/lowering/supporting
the user.
• Make sure that the Mini Crosser is stable and unable to move.
Turn o󰀨 the Mini Crosser and check that the brake is on and the
seat has been rotated until it clicks into place at either 45° or 90°.
• Make sure that the seat the user is being moved to is stable.
Turn the Mini Crosser o, rotate the seat
and raise the armrest.
