Media Technologies Matrix User manual

Assemble tables only as described in this
guide. All fasteners must be tightened
securely and checked regularly. Failure to
do so could cause instability and injury.
!
CAUTION
Mod-eez studs
Mod-eez clips
(come installed)
Matrix Modular Workstations
Tables
1
2
Underside
of worksurface
#12 x 1” Screws
Lip engages groove in
underside of worksurface
Z Bracket
Angle Brackets
3
4 4
Wire Manager
5

Assemble tables only as described in this
guide. All fasteners must be tightened
securely and checked regularly. Failure to
do so could cause instability and injury.
!
CAUTION
Step 1: To Attach end and intermediate panels to back panels, screw Mod-eez stud screws into
holes in vertical center line of double end/intermediate panels or back edge of single
end/intermediate panels. Note: Mode-eez clips on back panels are installed at the factory.
Slide Mod-eez studs into factory installed Mod-eez clips on either end of back panels.
Step 2: To attach angle brackets, finger tighten M6 x 10mm PH Screw through “Z” bracket into
brass inserts in end/intermediate panels finger tight only for now.
Step 3: Attach Work surfaces by positioning the worksurface onto the “Z” brackets. Make sure the
short end of the “Z” bracket sits in the groove. Screw angle brackets to the underside of the work
surface using #12 x 1" screws (lip engages groove in underside of worksurface). THEN tighten bolts
from Step 2.
Step 4:
Attach Wire Management Trough using #8 x 5/8" PH screws.
Step 5:
Adjust levelers up or down depending on need in order to level carrels.
If applicable, attach knee-space support to back panel before installing worksurface using Mod-eez
fasteners. Fasten support to panel to worksurface with 1” x 1” x 2” “L” bracket using
(4) - #8 x 5/8” PH screw.
* Worksurfaces 48” or less do not require kneespace support.
Matrix Modular Workstations
Tables
instructions-matrix-191211
Tools Required:
• #3 Phillips Head Screwdriver
• #2 Phillips Head Screwdriver
Hardware Included:
M6 x 10mm
Pan Head Screw
#12 x 1”
Pan Head Screw
MOD-EEZ
Stud
M/F MOD-EEZ
Stud
1” x 1” x 2”
L Bracket
#8 x 5/8”
PH Screw
16-1/2”
Z-bracket
