Medion Smartphone User manual

Instruction manual
Smartphone
MEDION®

1 of 69
Content
1. About these instructions....................................4
1.1. Symbols and keywords used in these
instructions ........................................................... 5
1.2. Proper use.............................................................. 7
1.3. Usage limitations ................................................8
1.4. Making calls while driving...............................8
1.5. Additional costs for Internet and
roaming usage...................................................12
2. Safety instructions............................................13
2.1. Cleaning and care.............................................15
2.2. Data backup........................................................16
2.3. Information about the display .....................17
2.4. Notes on batteries ............................................17
2.5. Environmental requirements .......................19
2.6. Faults .....................................................................20
2.7. People with pacemakers................................21
2.8. People with hearing aids................................21
2.9. Emergency calls.................................................22
2.10. Saving a number for use in emergencies.23
3. Package contents..............................................24
3.1. Overview of the device...................................25
4. Preparations for using the smartphone..........28
4.1. SIM card................................................................28
4.2. Installing the SIM card.....................................29
4.3. Installing the microSD card...........................29
4.4. Installing the battery .......................................30
MD 98428 Generisch ENG Final Content.indd 1MD 98428 Generisch ENG Final Content.indd 1 06.11.2013 12:34:2406.11.2013 12:34:24

2 of 69
4.5. Charging the battery .......................................30
5. First startup.......................................................31
5.1. Switching on the Smartphone.....................31
5.2. Touch control .....................................................31
5.3. Using the Google™-account .........................32
6. Initial setup .......................................................32
6.1. Switching your Smartphone off ..................34
6.2. Switching to standby mode..........................35
6.3. Waking up from standby mode...................35
6.4. Main screen.........................................................36
6.5. Managing notifications...................................38
6.6. Using the notification field............................40
6.7. Notification LED.................................................41
6.8. Making/checking settings.............................42
6.9. Favorites list ........................................................46
6.10. Making the first call..........................................46
6.11. SMS/MMS.............................................................48
6.12. Google Mail™......................................................49
7. Connecting to the internet...............................50
7.1. Adding a new data network
connection ..........................................................51
7.2. Additional costs for Internet and
roaming usage...................................................52
7.3. Internet.................................................................53
7.4. Roaming...............................................................53
7.5. Limiting data usage .........................................54
7.6. Changing the data volume ...........................55
7.7. Activating Wi-Fi..................................................56
MD 98428 Generisch ENG Final Content.indd 2MD 98428 Generisch ENG Final Content.indd 2 06.11.2013 12:34:2706.11.2013 12:34:27

3 of 69
8. Recycling and disposal.....................................57
8.1. Declaration about conformity......................58
9. Technical Data...................................................59
10. Licence information .........................................60
11. Legal notice .......................................................68
12. Index ..................................................................69
MD 98428 Generisch ENG Final Content.indd 3MD 98428 Generisch ENG Final Content.indd 3 06.11.2013 12:34:2706.11.2013 12:34:27

4 of 69
1. About these instructions
Read these operating instructions carefully
before using the device for the first time. Note
the warnings on the device and in the opera-
ting instructions.
Always keep the operating instructions close
to hand. If you sell the equipment or give it
away, make sure you also hand over these ins-
tructions and the warranty card.
MD 98428 Generisch ENG Final Content.indd 4MD 98428 Generisch ENG Final Content.indd 4 06.11.2013 12:34:2706.11.2013 12:34:27

5 of 69
1.1. Symbols and keywords used in
these instructions
DANGER!
Warning of immediate risk of fatal
injury!
WARNING!
Warning: possible mortal danger
and/or serious irreversible injuries!
CAUTION!
Warning: possible light or moder-
ate injuries!
CAUTION!
Please follow the guidelines to avoid
property damage.
PLEASE NOTE!
Additional information on using the device!
PLEASE NOTE!
Please follow the guidelines in the opera-
ting instructions.
MD 98428 Generisch ENG Final Content.indd 5MD 98428 Generisch ENG Final Content.indd 5 06.11.2013 12:34:2806.11.2013 12:34:28

6 of 69
WARNING!
Warning: danger of electric shock!
WARNING!
Warning: danger due to excessive
volume!
• Bullet point/information on operating steps
and results
Tasks to be performed
MD 98428 Generisch ENG Final Content.indd 6MD 98428 Generisch ENG Final Content.indd 6 06.11.2013 12:34:2906.11.2013 12:34:29

7 of 69
1.2. Proper use
This device offers various options in terms of its use:
• The device is intended for private use only and not for
industrial/commercial use.
Please note that we shall not be liable in case of impro-
per use:
• Do not modify the device without our consent and do
not use any auxiliary equipment which we have not
approved or supplied.
• Use only spare parts and accessories which we have
supplied or approved.
• Follow all the instructions in these directions for use,
especially the safety information. Any other use is
deemed improper and can cause personal injury or
damage to the product.
• Do not use the device in extreme ambient temperatu-
res and conditions.
MD 98428 Generisch ENG Final Content.indd 7MD 98428 Generisch ENG Final Content.indd 7 06.11.2013 12:34:2906.11.2013 12:34:29

8 of 69
1.3. Usage limitations
It is essential to turn off the smartphone in the following
situations:
• Before boarding an aircraft or before packing it in your
luggage. The use of radio devices in aircraft can have
dangerous effects on the flight controls and interrupt
radio contact and is thus prohibited.
• In hospitals, clinics or other health centres and in any
locations in the direct vicinity of medical devices.
• In all locations where there is a risk of explosion (e.g.
petrol stations; in dust-filled environments, e.g. where
there is metal dust).
• In locations where the use of radio-controlled devices
is prohibited, e.g. on construction sites or locations
where people are working with explosives.
• While driving a motor vehicle (if no hands-free car kit
is available).
1.4. Making calls while driving
As making calls can reduce concentration lev-
els (while driving a car or riding a bicycle), this
can lead to accidents. The following instructions
should be followed exactly.
It is an offence to hold a telephone in your hand
(or between your head and your shoulder) to
make a call while driving. It is also illegal to write
SMS, e-mail or use other programs while driv-
MD 98428 Generisch ENG Final Content.indd 8MD 98428 Generisch ENG Final Content.indd 8 06.11.2013 12:34:2906.11.2013 12:34:29

9 of 69
ing. Failure to comply will result in fines and in
your name being entered in the central traffic
offenders register.
The use of hands-free sets is allowed.
WARNING!
A wired headset is not a hands-free set
and may not be used while driving.
Warning!
The use of headphones/earphones
with a high volume can lead to last-
ing damage to your hearing. Set the
volume to the lowest level before
reproducing any sound. Start the
sound reproduction and increase the
volume to the level that is comforta-
ble for you. Changing the basic set-
tings of the equaliser can also cause
damage to the hearing of the listen-
er.
It can cause damage to the hearing
ability of the listener if a device is op-
erated through earphones with an in-
creased volume for a long period.
MD 98428 Generisch ENG Final Content.indd 9MD 98428 Generisch ENG Final Content.indd 9 06.11.2013 12:34:2906.11.2013 12:34:29

10 of 69
Hands-free systems should only be installed by
suitably qualified professionals. Incorrect instal-
lation or maintenance can have hazardous con-
sequences and may also void your guarantees
– also that of the car. Irradiation of the car’s on-
board electronics can cause serious defects and
result in danger to life and limb for you and oth-
ers.
Do not use voicemailbox while driving. Do not
listen to your messages until you have parked
the car and switched the motor off. If you ac-
cept a call via the hands-free set while driving,
keep the call as short as possible. Concentrate
on your driving. Try to to find a parking area be-
fore making a call.
Please comply with all national regulations if
you use you mobile while driving abroad.
If you need to call often while driving, you
should have a hands-free system installed in
your car. These systems have been specially de-
veloped for this purpose.
Ensure that neither your smartphone nor the
hands-free system can interfere with the func-
tionality of the safety equipment in your car.
For vehicles with airbags: Bear in mind that the
MD 98428 Generisch ENG Final Content.indd 10MD 98428 Generisch ENG Final Content.indd 10 06.11.2013 12:34:3006.11.2013 12:34:30

11 of 69
activation of the airbag involves the release of
a large amount of force. Therefore, never install
permanent or temporary telephone equipment
in the in the area above the airbag.
If the smartphone or accessories are incorrectly
installed this can lead to serious injury when the
airbag is activated.
WARNING!
Ignoring this advice can lead to seri-
ous injuries and/or property dama-
ge. Non-compliance can lead to seve-
re penalties!
MD 98428 Generisch ENG Final Content.indd 11MD 98428 Generisch ENG Final Content.indd 11 06.11.2013 12:34:3006.11.2013 12:34:30

12 of 69
1.5. Additional costs for Internet
and roaming usage
Considerable volume-based data costs may apply when
using the mobile Internet. To limit these costs, we recom-
mend that you book an Internet flat rate.
Find out about the various options available from your
mobile network operator. Also ask about the rates for
using your smartphone abroad (roaming) because this
can also result in high charges.
NOTE!
When you use the smartphone for the first
time, data roaming (use of data services in a
different data network than your own home
network provided by your mobile network
operator e.g. abroad) is deactivated!
Check your mobile plan before using the de-
vice and, if required, switch off mobile data
services until you have activated a suitable In-
ternet flat rate.
MD 98428 Generisch ENG Final Content.indd 12MD 98428 Generisch ENG Final Content.indd 12 06.11.2013 12:34:3006.11.2013 12:34:30

13 of 69
2. Safety instructions
• Do not let children play with electrical appli-
ances without supervision. Children are not
always aware of potential hazards.
• Keep packaging material such as plastic film
away from children. There is a risk of suffoca-
tion if used improperly.
DANGER!
Never open the device housing or
the mains adapter housing. There is
a risk of electric shock when the
housing is open.
• Do not insert anything into the device
through the slots and openings. This could
result in an electrical short-circuit, an electric
shock or even ignite a fire which will damage
the product.
• Avoid exposing the device to water droplets
or spray and do not place vases or anything
containing water on the unit. Liquids penet-
rating the device may impair the electrical sa-
fety of the product.
• Plug the mains adapter into AC 100-240V~,
50/60 Hz earthed sockets only. If you are not
MD 98428 Generisch ENG Final Content.indd 13MD 98428 Generisch ENG Final Content.indd 13 06.11.2013 12:34:3106.11.2013 12:34:31

14 of 69
sure about the power supply at the installati-
on location, please ask your power supplier.
• The socket must be close to the device and
easy to access.
• Use only the supplied mains adapter and at-
tached USB cable.
• For extra safety, we recommend using an
overvoltage protection device to prevent the
product from sustaining damage as a result
of power surges or lightning strikes.
• If you want to disconnect the device from the
mains, first pull the mains adapter out of the
wall socket and then out of the socket on the
product. The mains adapter or the product
may be damaged if this process is carried out
in the reverse order. Always take hold of the
plug when disconnecting the cable from the
socket. Never pull on the cable.
• Position the cable so that it cannot be step-
ped on or tripped over.
• To avoid damaging the cable, do not place
any objects on it.
• Do not expose plug-in connections to pres-
sure, e.g. from lateral forces. This could cause
internal and external damage to the device.
MD 98428 Generisch ENG Final Content.indd 14MD 98428 Generisch ENG Final Content.indd 14 06.11.2013 12:34:3106.11.2013 12:34:31

15 of 69
• Do not apply force when connecting cables
and plugs and make sure that connectors are
the right way round.
• In order to prevent short-circuits and cable
breaks, do not crush or bend cables.
• Maintain a distance of at least one metre
from sources of high-frequency and magne-
tic interference (TV sets, loudspeakers, mobi-
le phones, DECT telephones, etc.) in order to
avoid malfunctions and data loss.
• Do not connect any devices to the smart-
phone which do not meet the requirements
set out in the EN60950 standard “Informati-
on Technology Equipment – Safety” or the
EN60065 standard “Audio, video and similar
electronic apparatus - Safety requirements”.
2.1. Cleaning and care
You can increase the lifespan of your device
with the following measures:
• Always unplug the device and disconnect all
cables before cleaning.
• Do not use solvents, corrosive or aerosol de-
tergents to clean the device.
• Use appropriate cleaners to wipe the display,
MD 98428 Generisch ENG Final Content.indd 15MD 98428 Generisch ENG Final Content.indd 15 06.11.2013 12:34:3106.11.2013 12:34:31

16 of 69
e.g. glass cleaners or monitor cleaners (availa-
ble from specialist retailers).
• Clean the screen with a soft, lint-free cloth.
• Do not place the screen in strong sunlight or
near ultraviolet light.
• Make sure that no water droplets remain on
the device. Water can cause permanent dis-
colouration.
Store the packaging material in a safe place; al-
ways use this to transport the device.
ATTENTION!
None of the parts inside the device re-
quire cleaning or maintenance.
2.2. Data backup
NOTE!
Back up your data on external storage
media after each update. We do not
accept any liability for claims for com-
pensation arising from loss of data or
any damages incurred.
MD 98428 Generisch ENG Final Content.indd 16MD 98428 Generisch ENG Final Content.indd 16 06.11.2013 12:34:3106.11.2013 12:34:31

17 of 69
2.3. Information about the display
• Do not place any objects on top of the device
and do not exert pressure on the screen. This
could break the screen.
• To avoid damaging the screen, do not touch
it with sharp objects.
• If the screen breaks, there is a danger of inju-
ry. If this happens, pick up the shattered pie-
ces wearing protective gloves and send them
to your service centre for professional dispo-
sal. Finally, wash your hands with soap, as the
pieces may have been contaminated with
chemicals.
• Prolonged exposure to strong sunlight can
lead to display errors if the display is not re-
freshed. These should disappear after refres-
hing the screen.
2.4. Notes on batteries
This device contains a battery. Please note the
following when using batteries:
• Charge the battery regularly and as fully as
possible. Do not leave the battery discharged
for long periods
MD 98428 Generisch ENG Final Content.indd 17MD 98428 Generisch ENG Final Content.indd 17 06.11.2013 12:34:3106.11.2013 12:34:31

18 of 69
• Keep the battery away from heat sources
such as radiators or open flames, e.g. candles.
There is a risk of explosion!
• If the device cannot be switched on even
though it is connected to a power source,
please contact your service centre.
• Do not use chargers or batteries that are da-
maged in any way.
• Use the battery only for its intended purpose
in this smartphone.
• Do not dismantle or deform the batteries.
You could injure your hands or fingers or bat-
tery fluid could come into contact with your
eyes or skin. If this happens, rinse the affec-
ted areas immediately with plenty of clean
water and contact your doctor immediately.
• Keep batteries away from children. If batte-
ries are mistakenly swallowed, consult your
doctor immediately.
• Risk of explosion if battery is replaced by an
incorrect type.
• Before inserting the batteries, check that the
contacts in the device and on the batteries
are clean and, if necessary, clean them.
MD 98428 Generisch ENG Final Content.indd 18MD 98428 Generisch ENG Final Content.indd 18 06.11.2013 12:34:3106.11.2013 12:34:31

19 of 69
• Always observe the correct polarity. Make
sure that the plus (+) and minus (−) poles are
correctly inserted to avoid short circuits.
DANGER!
There is a risk of explosion, if rechar-
geable batteries are replaced incor-
rectly.
• Do not leave the battery in hot or cold loca-
tions, e.g. in a car in summer or winter. Extre-
mes of temperature can adversely affect the
battery’s capability to charge correctly.
• Do not attempt to short circuit the battery. A
short circuit across the contacts can damage
the battery or the object connected to it.
• If you are not going to use your smartphone
for a long time, please remove the battery.
• Dispose of used batteries according to the in-
structions.
2.5. Environmental requirements
• Keep your smartphone dry.
• Do not expose it to extremes of temperature
(hot or cold).
• Do not place your phone next to burning ci-
MD 98428 Generisch ENG Final Content.indd 19MD 98428 Generisch ENG Final Content.indd 19 06.11.2013 12:34:3106.11.2013 12:34:31
