Meet PAT The One MP-TO-01-C Installation and operation manual

Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
Indoor “The One” Water Bottle Refill and Drinking Fountain
MP-TO-01-C
Information Booklet

Page 2
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
Disclaimer and Safety
Here at Meet PAT™ we are very safety conscious. We design and manufacture water
related products with the safety of you, the user, foremost in mind. In addition, we
ask that you exercise a degree of care when using any Meet PAT™ product.
IMPORTANT SAFEGUARDS FOR YOUR MEET PAT UNITS
• Carefully read all instructions before operation and save them for future reference.
• Find a suitable, stable location for the units.
• Do not set the units up near live exposed electrical connections or wiring.
• Check the quality and potability of the water source and that there is correct pressure.
• Set up all connections before turning on the water supply.
• Once the water supply is turned on check each unit’s connections for leakages. If a
leakage is found turn off the water supply and remove the pressure from the units by
pressingtherellbuttons.Unplugtheleakingconnectionandcheckfordamageordirt.
Do not use if any leaks are prevalent.
• Units can be heavy to install, use the appropriate number of people and equipment.
• Ensure the units are regularly cleaned and serviced.
• Ifapplicable,ensurethewaterltersarereplacedasrequired.
Meet PAT™ takes no responsibility for suitability of install location, clearance for trafc, pedestrians or
other clearance requirements. Meet PAT™ recommends that the chosen locations are reviewed for OHS
and suitable other parties (including council) to ensure compliance. Meet PAT™ takes no responsibility for
the structural integrity of the mounting surface chosen and recommends consultation with an engineer or
suitable other parties prior to mounting.
For individual material, component or further installation details, please contact Meet PAT™ sales. Meet
PAT units have a maximum working pressure of 6 bar - 600kpa (87 psi/ 0.6MPa). Customer or installer to
check water pressure and install pressure relief valve on supply side if required.
Meet PAT™ products must be installed in accordance with the provisions of AS/NZS3500 and any
relevant local regulations. Installations not complying with AS/NZS3500 may void the product and
performance warranty provisions.
All recommendations within this document should be used as a guide only. Users and
installers should seek suitable assistance to ensure units comply with all standards and are
safe for use.

Page 3
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
Cleaning and Maintenance
When purchasing a Meet PAT product, we ask you the customer to “help us out”
Being an owner of a Meet PAT water station we ask you to look after and care for
your water station through regular cleaning and maintenance. Often, public amenities
(for example toilets) are regularly cleaned however public drinking fountains are often
over looked! We want to change this.
We’re aiming for the cleanest and most desirable water stations in the world
and know that there is better adoption, user engagement and respect if they are
well maintained. By following a few key steps in the installation (see Installation
considerations) of your unit and having a cleaning plan in place. You will get the best
out of your unit and increase the user satisfaction.
CLEANING RECOMMENDATIONS:
• Meet PAT recommends cleaning the unit every 2-4weeks (Subject to use and location).
• Clean and wipe down all external surfaces including mesh drainage area. Use a non-
acidic, non-abrasive cleaner and a brush if required.
• Check base of graphics panel for any residual moisture or dirt. If required, remove panel
as per unit instruction book, clean panel and base area of unit and check drain holes for
blockages.
• Check that the buttons and unit is functioning properly Check the water is clean, clear
and tasting great.
DETAILED SERVICE:
Meet PAT recommends a detail service every 6 -12months or
6000Ltofwater–whicheverisrst.
This service should include:
• Changetheowmeterbatteries.(seeowmeterinstructionswithinunitinstructionbook)
• Detailedexternalandinternalsurfaces(includingttings)clean.
• Check drainage is working correctly
• Inspectionofallthettingsandhosing.Replaceanydamagedorleakingparts.
• Foradditionalsafeguard,ushlineswithdilutedhydrogenperoxidesolutionorsimilar.
We recommend using a Meet PAT cleaning kit to maintain product warranty.
• Changethelter(ifinstalledintheunit)-(refertolterreplacementguidewithinunit
instruction book)

Page 4
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
Permanent “The One” Water Station With Chiller
“TheOne”isanallinonebottlerellanddrinkingfountain.Incorporatingbothawaterbottle
rellstationanddrinkingfountainwithbeautifuluninterruptedgraphicsandtheaddedbenetof
cool, fresh water. “The One” incorporates Meet PAT’s revolutionary system that provides fresh
drinking water to sporting events, schools and festivals can now be securely and permanently
installed.
Water Window
and Catch
Symbolic shape constructed from aluminium and marine grade stainless steel.
Hygienic easy clean with replaceable drain cover.
Tough and
Strong
// Chassis is 5mm thick galvanised and powder coated steel hidden within the units.
// Graphics panels are made from clear high impact, spray paint, uv and scratch
resistant polycarbonate sheet.
// The external chassis is made from heavy duty aluminium, powder coated with
dulux industrial coating with marine grade 316 stainless steel components.
Water Chiller Waterworks IC8 built in water chiller. Enjoy the benets of cool refreshing water.
Water Meter Inbuilt digital water ow meter with read out. See how much water is consumed or
plastic bottles saved during an event.
Wheel Chair
Accessible
Lower, easy to press stainless steel taps and accessible drinking nozzles. Dual
sided and compliant with AS 1428.1 2009
PAT Connect
Every PAT can be tted with a wi and bluetooth beacons as an optional extra. This
allows users to engage with specic data, tailored push notication and location
information.
Graphics Panels
Removable and interchangeable branding. Each unit comes standard with custom
printed artwork. Meet PAT provides artwork templates for your team to prepare or
alternatively we can help.

Page 5
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
TECHNICAL DATA
MP-TO-01-C
REGULAR
Mounting Options 1. Fixed at base
2. Edge mounted
Indoor Suitable for indoor applications only.
Tapware/Push Buttons 316 stainless steel Easy-press stainless steel buttons.
Versatile
PAT permanent can mount over the existing tap or outlet. Optional water
outlet can be included the base of the unit accessible via security tap (key)
on side of unit.
Chassis Aluminium and galvanised mild steel
Graphics Panels Polycarbonate. Custom printing supplied as standard.
Base Bollard Powder coated mild steel. M10 Screws. Plate size: 280 x 220mm
Nozzle 316 stainless steel
Water Pressure Max. 600kpa operating pressure
Filter 5 micron carbon lter
Flow Rate 5L per minute (pressure dependent)
Flow Meter Digital in litres
Chilling Speed From 29 deg C to 10 deg C in 21.6 min
Chilling Capacity ~6 litres per hour
Electrical 240 Volts, 50 Hz, 10 Amp Single Phase. (1.8 meter electrical cord)
Water Supply Connection 1/2” inch supply line with 1/2” inch male compression tting
Drainage 50mm PVC preferred (drainage can be customised based on location.
Warranty 3 Year (refer to Meet PAT warranty documentation for details)
Meet PAT™ products must be installed in accordance with the provisions of AS/NZS3500 and any relevant local regulations. Installations not complying with AS/
NZS3500 may void the product and performance warranty provisions. All information and images contained in the document are © Meet PAT™ - Products and
Things Pty Ltd (as a trustee for Meet Pat Unit Trust) or their respective owners. They are not be used without consent from Meet PAT™. As improvements in the
design and performance of Meet PAT products are continuous, specications may be subject to change without notice. This technical sheet is copyright and
owned by Meet PAT™ - Products and Things Pty Ltd (as a trustee for Meet Pat Unit Trust) ABN 42634465637. All rights are reserved.
230mm
470mm
445mm
1220mm
385mm
100mm
435mm

Page 6
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
120
478
522
1600
384
240v CHILLER UNIT
232
NOTE: All Dimensions are in MM
TOP VIEW
HOLE PLACEMENT FOR DIRECT MOUNTING
MP-RS-01-C - Indoor Chiller- Installation
MP Chiller Stand
Reference size for suitable
placement
240v Chiller
The unit comes with a 240v water
chiller unit mounted in the base.
This unit plugs directly into an
existing 240v wall plug. The unit is
supplied with a 1m cable.
Fixings
Preferred, Ramset 063100 - M12
threaded inserts (not supplied) or
installer to use suitable alternative.
Drill hole size to be as per suitable
xings.

Page 7
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
Direct mounting where unit is fastened directly to concrete slab or other suitable surface
Water Supply Connection
½” inch supply line with ½” inch male
compression tting 200-250mm from
ground preferred.
Drainage
50mm PVC preferred (drainage can be
customised based on location)
NOTE: Water Supply and Drainage
connection cannot exceed outside
of this area. Piping orientation not
important.
Fixings
Preferred, Ramset 063100 - M12
threaded inserts (not supplied) or
installer to use suitable alternative. Drill
hole size to be as per suitable xings.
43
70
30
214
240v CHILLER UNIT
NOTE: All Dimensions are in MM
NOTE: Cutaway
view is only for
clarity. All pipes
are concealed
Panels remove
to access the
chiller unit and the
mounting holes
TOP VIEW
MP-RS-01-C - Indoor Chiller- base plumbing - Installation

Page 8
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
Direct mounting where unit is fastened directly to concrete slab or other suitable surface
Drainage
50mm PVC preferred (location can be
placed anywhere in the dened area)
Water Supply Connection
½” inch supply line with ½” inch male
compression tting.(location can be
placed anywhere in the dened area)
NOTE: Water Supply and Drainage
connection cannot exceed outside
of this area. Piping orientation not
important. (Locations to be cutout on
location by a 3rd party)
Fixings
Preferred, Ramset 063100 - M12
threaded inserts (not supplied) or
installer to use suitable alternative. Drill
hole size to be as per suitable xings.
455
50
343
NOTE: All Dimensions are in MM
REAR VIEW
MP-RS-01-C - Indoor Chiller- REAR plumbing - Installation

Page 9
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
Panel replacement
3mm Allen Key
Screws
x 3
Clockwise
to loosen
1 2
3
3mm Allen Key
Screws
x 4
Clockwise
to loosen
3mm Allen Key
Screws
x 2
Anti
Clockwise
to loosen
4
5
3mm Allen Key
Screws
x 2
Clockwise
to loosen
8mm Allen Key
Screws
x 2
Anti
Clockwise
to loosen
6

Page 10
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
Panel replacement
8mm Allen Key Screws
x 1 Anti
Clockwise
to loosen
78
9Putting it back together
All finished and need to put the unit back
together?
Follow the steps in reverse
9,8, 4,3,2,1
* Remember to reattach any water
pipes disconnected during disassembly.
Only 3-4 turns to loosen do not
unscrew completely.
Remove screw completely.

Page 11
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
Filter replacement
1
3mm Allen Key
Screws
x 2
Anti
Clockwise
to loosen
2
3
Water Flow
Check the water
flow direction on
the new filter
abPush fit the
correct pipes
into the filter
4
Once the new filter is installed
Connect the unit to a pressurized water
source and check for any leaks.
* If a leak is found turn off the water
supply and check connections.
Disconnect water supply
Disconnect or turn off the water supply.
De-pressure the unit by pushing the buttons.
First Flush
The first flush of water from the unit will be
Black in colour.
This is normal and will disappear after a
few seconds of water flow from the unit.
Reset Flow meter after filter change
* See flow meter instructions
Press down on
the locking ring
a b Pull up on the
pipe to remove
* Some models will not
have a bracket
*Once a panel has been removed.
Locate the filter inside the unit
I look like this
3mm Allen Key
Screws
x 2
Clockwise
to tighten
5

Page 12
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
Flow Meter - instructions
Re-Setting
*The display will automatically turn off
after a few seconds
Press the “DISPLAY” button and the
“RESET” button together for 4 seconds.
The unit will beep once reset.
0lt
Reading the Display
*The display will automatically turn off
after a few seconds
Press the “DISPLAY” button once to
display real-time flow rate.
Press the “DISPLAY” button again to
display the total liter count up.
3000lt
Attention
1. Do not spray water into or around the
flow meter.
2. Be-careful to not damage the wires
when removing the flow meter.
3. For replacement parts and
troubleshooting please contact MeetPAT.
Beeping
When the battery is low, the buzzer will
beep twice and the battery symbol blink
to notify the user to change the battery.
1. LCD Display
2. Display Button
3. Reset Button
2
3
1
Each MeetPAT unit is fitted with a digital flow meter. This is set to count up the amount of
liters that have flowed through the unit.
This is important so you know when to change the carbon cartridge (if in the unit), when a
service is due and to provide valuable marketing data.
*The flow meter will automatically
turn on when there is water flowing
through the sensor.
It will automatically turn off in 10
seconds when there is no water
flowing.

Page 13
Meet PAT™ | Products and Things Pty Ltd | meetpat.com.au | Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [email protected]
Meet PAT™ | Meet PAT Limited NZ | meetpat.co.nz | 12 Bethlehem Road, Bethlehem, Tauranga, 3100
flow meter - battery change
3* Permanent model - flow
meter lifts off bracket
2
4mm Allen Key
Screws
x 4
Anti
Clockwise
to loosen
* Only portable models
will have a bracket
4x 2
1
I look like this
Record flow meter data
If still displayed, record the flow meter data.
Once the batteries are removed this data can
be lost.
*Once a panel has been removed.
Locate the flow meter inside the unit
Once batteries are installed
Attach the flow meter back into place.
Check the unit is working by pressing
the display button.
* If the display is not working check the
battery positions and battery
connections.

All information and images contained in the document are © Meet PAT™ - Products and Things Pty
Ltd (as a trustee for Meet Pat Unit Trust) or their respective owners. They are not be used without
consent from Meet PAT™.
As improvements in the design and performance of Meet PAT products are continuous, specications
may be subject to change without notice. This technical sheet is copyright and owned by Meet
PAT™ - Products and Things Pty Ltd (as a trustee for Meet Pat Unit Trust) ABN 42634465637. All
rights are reserved. All products and sales are subject to Meet PAT™ terms and conditions.
Meet PatTM | Products and Things Pty Ltd | meetpat.com.au
HEAD OFFFICE: Level 1, 419 Townsend Street, Albury, NSW, 2640, Australia
Phone: [phone] Email: [e-mail]
Meet PatTM | Meet PAT Limited NZ | meetpat.co.nz
12 Bethlehem Road, Bethlehem, Tauranga, 3100
