Mega LED Lighting MJ-3108-4IN1 User manual

5. DMX function：
Channel Value Function
CH1
0~8
OFF
9~134
R,G,B,W liner dimmer
135~239
Strobe form slow to fast
240~255
Main dimming
CH2
0-255
Red dimming from dark to bright
CH3
0-255
Green dimming from dark to bright
CH4
0-255
Blue dimming from dark to bright
CH5
0-255
White dimming from dark to bright
CH6
0~2 No function
3~223 Macro function
224~255
Sound 1
Important notice:
Before open the LED pin spot light and if you want to do the repair work,
please make sure the power source is at the separation condition.
Unceasingly carries on the product improvement about our company the
policy, in this instruction booklet carries the data will have the possibility to
be able to change in the future, when no longer separate notice change
matters concerned. Our company retains when the product improvement
changes the related specification the authority. This instruction booklet
publisher cannot be responsible regarding this instruction booklet in
information accuracy, also cannot the related consequence which causes
regarding these information be responsible.
Mini LED Pin Spot Light
MJ-3108-4IN1
User Manual
Thank you for choosing our mini LED pinspot light. For the sake of your
safety, please read this manual carefully before use and keep this manual
in a safe place for future reference.

1. Installation:
1.This light can work normally between the Voltage of AC100-240V.
2. In order to secure the safe installation of the light, always use it in the
well-ventilated environment.
3. Always keep this light with a safe distance from any flammable materials.
4. Never install, dismantle and maintain this light when it is powered; and all
work aforesaid must be conducted by professionals.
5. The packing list of this light is as follows:
1) Light --------------------------------------------1pcs
2) User Manual----------------------------------1pcs
2. Effect
1. This light can achieve the effect of variable colors and flashing (with speed
adjustable)
2. The program of this light can automatically operate, sound, accept DMX512
signal control and be connected for use.
3. Menu display function
Menu
Value
Description
A___
001~512
DMX address and /slave model
Run_
0
Off
1
R,G, B,W color jumping
2
Red ON，G, B,W color jumping
3 Green ON，R, B,W color jumping
4 Blue ON，R, G,W color jumping
5
White ON
，
R, G, B color jumping
6 R,G, B,W color fade and speed slow
7
R,G, B,W color fade and speed fast
8
R,G fade B,W Off
9
R,B fade G,W Off
A B,G fade R,W Off
b R,G, B,W color fade
C
R,G, B,W color mix
Sou 1
Sound 1
Sou 2
Sound 2
Sou 3
Sound 3
colr
r000~255
R dimming by hand
g000~255
G dimming by hand
b000~255
B dimming by hand
y000~255
W dimming by hand
LEon LEon LED ON
LOFF LED OFF
4. Technical Parameters
Voltage: AC100-240V, 50Hz/60Hz
Power Consumption: 15 Watts
LED: 1pc CREE 4in1 LED
LED Power: 12 Watts (x 1 pc)
LED Current: 500mA / 1 pc
LED Beam Angle: 6°
LED Lifetime: 80,000-100,000 hours
Possible Color Combinations: 16.7 million
Dimming: 0-100% with regulated constant color control
Strobe: 10 Flashes per second (any color)
Operation Modes: DMX512, Manual, Sound, Internal Program
DMX Control: 6 Channels
Control Panel: Digital 4 Character Alphanumeric
Maximum Ambient Temperature: 40° C
Gross Weight: 0.5 kg
