MegaTec MT-LA-MP User manual

MEGATEC Lever Arm Multi Press MT-LA-MP Assembly Walkthrough
The Megatec Lever Arm Multi Press comes in 2 boxes. The dimensions are:
Carton 1
Carton 2
Length
Width
Depth
Length
Width
Depth
1.42
0.32
0.44
1.06
0.70
0.21

Unpack the boxes and place all the parts on the ground. You will also have the pack with all the nuts and bolts in it.

It would be great idea to label the hardware packs at the beginning. You can use the instructions to do this.
NOTE: Do not tighten the nuts and bolts until the end, unless told otherwise. Some of the parts may also come pre
installed.
Connect parts #12 and #18 using #9 bolts.
Bolts #9
Part #12
Part #18

You can then connect both parts #14 to either side of #12 using #4 bolts and #13 plates.
Bolts #4
Plate #13
Part #14

Bolt together Part #19 to either side of #14 using #3 bolts.
Bolt #3
Part #19
Part #14

Part #15 can then bolted on at the bottom with Part #12 using #9 bolts.
Part #15 also needs to be bolted to the top of #19 using #6 bolts.
Part #15
Part #12
Bolt #9
Part #15
Part #19
Bolts #6

Part #34 can be bolted onto #19 using #5 bolt. Once it is tight, you can then place the rubber ring on.
Part #34
Part #19
Bolt #5

Part #17 is placed through the top of #15 and then bolted in the back by #7 bolts.
Then you place Part #20 into one of the adjustment holes on #15.
Part #17
Part #15
Bolts #7
Part #20
Part #15

You can then place the arms Part #16 onto the axle Part #17. Please ensure that the rubber strip is on the underside
of the bench arm.
Each arm Part #16 can then be locked on with Part #18 and then bolted on.
Part #16
Part #17
Part #16
Part #18

Part #23 can be bolted on using #8 bolts.
Part #24 can be bolted on using #7 bolts.
Part #23
Bolts #8
Part #24
Bolts #7

Bolts #8
Bolts #8
Bolts #8

Bolts #7
