1General
1.1 Introduction
Power Supply Unit B10E is used to supply voltage to
the Circuit Breaker (CB) coils and spring-charging mo-
tor during installation and/or field service.
Since the high-quality voltage available at the coil
outputs is very load-independent, the power supplied
resembles what is encountered under normal oper-
ating conditions. Circuit breaker functionality thus
remains virtually unchanged.
B10E enables you to test CB functions easily at the
specified voltage levels.
1.2 Service and support
For technical assistance please contact your local
Megger representative or direct your request to the
office in Sweden.
Contact Information
Internet: www.megger.com
E-mail: [e-mail]
Tel: [phone]
Checklist before calling/e-mailing
for support
▪Read the manual
▪Restart the instrument(-s), redo test connections and try
again
▪Try to repeat the failing operation if possible
▪Identify the instrument model and serial number.
Shipping
If you are going to send the instrument with parcel
service use the original transport box or one with
equivalent strength. Megger can not take responsibil-
ity for transport damages.
6B10E ZP-BG02E BG0140ME
1 GENERAL

BG0140ME ZP-BG02E B10E 7
1 GENERAL

2.1 General
▪Always follow the local safety regulations that apply to
work with high-voltage equipment.
▪Read and comply with the following safety instructions.
Symbols on the instrument
Caution, refer to accompanying docu-
ments.
Protective conductor terminal.
WEEE, Waste Electrical and Electronic
Equipment. Please utilize your local
WEEE collection facilities in the dispo-
sition of this product and otherwise
observe all applicable requirements.
The unit can also be returned to Megger
at any time at no charge for the disposal.
2Safety
2.2 Safety instructions
WARNING
1Always make certain that the DC system in the
substation is disconnected before connecting
B10E.
2Always ground the B10E.
3Before connecting B10E, turn off its master ON/
OFF switch.
4Only connect B10E to an outlet protected with
max 16 A overcurrent protection
5High voltage/current on input/output terminals.
6Do not attempt to service the instrument your-
self. Opening or removing covers may expose
you to dangerous voltage. If you attempt to
service the instrument yourself the warranty is no
longer valid.
7Do not use any accessories that are not intended
for use together with the instrument.
8Disconnect the instrument from the mains before
cleaning. Use a damp cloth for cleaning. Do not
use liquid cleaners or aerosol cleaners.
8B10E ZP-BG02E BG0140ME
2 SAFETY

IMPORTANT
1Always use safety connecting leads.
2Never leave the instrument unattended while it is
turned on.
3Use only approved mains detachable cable set
with the instrument. Main supply cables shall be
rated for the maximum current for the equip-
ment and the cable shall meet the requirements
of IEC 60227 or IEC 60245. Mains supply cables
certified or approved by a recognized testing au-
thority are regarded as meeting this requirement.
4Unplug the instrument from the mains supply
when it is left unattended or not in use.
5Refer all servicing to Megger authorized person-
nel.
6If you need to return the instrument, please use
either the original crate or one of equivalent
strength
BG0140ME ZP-BG02E B10E 9
2 SAFETY

3Control panel
1Output for DC voltage supplied to closing/
breaking coil
2Output for AC voltage supplied to closing/
breaking coil
3F2. 4 A fuse for AC outputs
4Changeover switch used to select either DC or
AC coil outputs
5Changeover switch used to select either coil
outputs or spring-charging motor outputs
6DC voltage outputs for spring-charging motor.
Provide unsmoothed, half-wave rectified DC
ranging up to 18 A
7Button for turning on spring-charging motor
voltage
8Current shunt output used to measure current,
in coils or spring-charging motors (max 5 A
continuous)
9Voltmeter
10 Input for external trig signal or short-circuiting
jumper
11 Button for manual trigging pulse via coil out-
puts. (Switch 12 set to voltage position)
12 Changeover switch used to select either con-
tact sensing or voltage sensing at the trig input
13 Reset button for thermal, overload and/or time-
limit cut-outs
14 Variable transformer
15 Master ON/OFF switch
16 Inlet for mains power
17 F1. 7 A miniature circuit breaker for DC spring-
charging motor
18 Grounding terminal
19 Changeover switches (A) and (B) for incoming
power 115/230/135/250 V AC
❻
❼❸ ❹ ❺
❽ ➒
❿
➊
⓫ ⓬ ⓭
⓮
⓯
⓰
❷
⓱
⓳
⓲
⓫ ⓬
10 B10E ZP-BG02E BG0140ME
3 CONTROL PANEL

BG0140ME ZP-BG02E B10E 11
3 CONTROL PANEL

4Operating instructions
4.1 Circuit breaker trigging
Important
Read the manual and comply with the
Safety instructions before using B10E.
Always comply with local safety regula-
tions.
When the master ON/OFF switch on B10E is turned
on, you are ready to proceed with testing. As a rule,
output is set for the coil outputs before B10E is
started. Moreover, the coil outputs are usually set for
DC and the trig input is set for voltage sensing.
Warning
If the coil current is below 50 mA the 1 sec
automatic interruption will not work. A
potential hazard for burning the trip coil.
Note The COIL DC and AC outputs, CLOSING/
BREAKING, cannot be used simultaneously. A
time limit is imposed on the DC outputs. If the
DC outputs are loaded with minimum 50 mA,
the current will be interrupted after about
one second to protect the automatic control
circuitry.
The AC outputs can be loaded for up to 30
minutes at maximum specified power.
1] Ground B10E.
2] Switch off the master ON/OFF switch.
3] Check that the substation voltage is discon-
nected from the circuits in which B10E is to
be connected.
4] Turn the variable transformer to zero.
5] Make connections to the CB operating cir-
cuits.
6] Connect B10E to the mains power.
7] Switch on B10E.
Note The current inrush on starting is high and can
trip/blow a 10 A fuse.
8] Select the desired trig function and output.
You can select either manual or external trig-
ging via the coil outputs.
For manual trig, set the trig input to voltage
sensing.
For external trigging, you can select either
zero-potential contact sensing or 8–15 V
voltage sensing. Since B10E is usually used
together with a circuit breaker analyzer,
external contact sensing is normally selected
and the trip input is normally provided with
a short-circuiting jumper
9] Set the voltage to desired level using the
variable transformer.
10] Operate the CB.
Note If any of the protective cut-outs on B10E trip,
a lamp marked PROTECTION will light up.
Reset by pressing the RESET button. However,
you must wait a while before the thermal cut-
out can be reset.
Application examples
Manual trigging of CB
1] Make certain that the mains are de-ener-
gized on both sides of the CB, and then
ground the CB on both sides.
2] Ground B10E.
3] Set the master ON/OFF switch on B10E to the
OFF position.
4] Connect the CB coil circuits to B10E, CLOS-
ING/BREAKING. Use the appropriate outputs
DC or AC. Connect the CB spring-charging
motor to B10E, MOTOR.
5] Connect B10E to the mains power.
6] Switch on the B10E master ON/OFF switch.
7] Check that B10E is set for the coil outputs,
and for the correct type of voltage, DC or AC.
8] Set the desired output voltage.
9] Select voltage sensing for the trig input.
10] Press the TRIG button (8) to start the desired
operation.
12 B10E ZP-BG02E BG0140ME
4 OPERATING INSTRUCTIONS

B10E together with a circuit breaker
analyzer
1] Make certain that the mains are de-ener-
gized on both sides of the CB, and then
ground the CB on both sides.
2] Ground B10E.
3] Set the B10E master ON/OFF switch to the
OFF position.
4] If the CB has a common negative terminal,
connect the positive side of CB operating
mechanism’s close and open circuits to the
circuit breaker analyzer outputs marked
CLOSE and OPEN. Connect the spring-charg-
ing motor’s positive and negative terminals
to the MOTOR outputs on B10E. Then con-
nect one of B10E’s COIL outputs, DC or AC,
to the negative input to the circuit breaker
analyzer (marked INPUT).
5] Connect B10E to the mains power.
6] Switch on the B10E master ON/OFF switch.
7] Check that B10E is set for the coil outputs
and for DC.
8] Select contact sensing for the trig input.
9] Check that the trig input is short-circuited.
10] Select the desired operation on the circuit
breaker analyzer’s sequencing unit and oper-
ate the CB from the circuit breaker analyzer.
4.2 Troubleshooting
Fault Cause
B10E does not start Master ON/OFF switch is at OFF
position
No output voltage
from B10E
Miniature circuit breaker has
tripped or fuse has blown
Impossible to trip
CB via the DC coil
Contact-sensing changeover
switch is at wrong position
Impossible to load
the AC outputs
Glass-tube fuse F2 has blown
Impossible to load
the DC outputs
Miniature circuit breaker F1 has
tripped
No DC voltage at
spring-charging
motor outputs
Motor/Coils changeover switch
is at wrong position
Voltage not supplied to spring-
charging motor
AC/DC changeover switch is at
wrong position
BG0140ME ZP-BG02E B10E 13
4 OPERATING INSTRUCTIONS

5Specifications
Outputs (DC), CATII
COIL, CLOSING/BREAKING
Output voltage 24-300 V DC
Load interval Max 1 s (at currents over 50 mA)
Ripple 2% peak-to-peak of the preset
voltage
No-load voltage (V) Current (A) Load dependency
24 10 < 6 %
48 10 < 3 %
110 6.5 < 2 %
250 3< 2 %
300 1.25 < 2 %
Outputs (AC), CATII
COIL, CLOSING/BREAKING
Output voltage 24-260 V AC
Load current Max 5 A
Load interval Max 30 min
Output DC, CATII
MOTOR
Output voltage 24-300 V DC (loaded)
Open circuit voltage
(V)
Current
(A)
Load voltage
(V)
Max load
interval (s)
44 18 24 20
48 12 40 60
48 18 30 20
120 12 90 60
120 18 70 20
240 6200 60
240 9185 20
Max voltage: Terminals to protective earth (ground)
Terminal Voltage
Coil closing 300 V DC, 260 V AC
Coil breaking 300 V DC, 260 V AC
Motor 250 V AC
Shunt 250 V AC
Trigger closing 8 – 15 V AC
Trigger breaking 8 – 15 V AC
SPECIFICATIONS B10E
Specifications are valid at nominal input voltage and an ambient
temperature of +25°C, (77°F). Specifications are subject to change
without notice.
Environment
Application field The instrument is intended for use in
medium and high-voltage substations
and industrial environments.
Temperature
Operating 0°C to +50°C (32°F to +122°F)
Storage & transport -40°C to +70°C (-40°F to +158°F)
Humidity 5% – 95% RH, non-condensing
CE-marking
LVD 2014/35/EU
EMC 2014/30/EU
RoHS 2011/ 65 / EU
General
Mains voltage 115 / 230 (135 / 250) V AC, 50 / 60 Hz
Power consumption 3300 W (max)
Protection Thermal cut-outs, +80°C (+176°F)
Short-circuit protectors at DC outputs
Dimensions
Instrument 350 x 270 x 220 mm
(13.8” x 10.6” x 8.7”)
Transport case 610 x 290 x 360 mm
(24.0” x 11.4” x 14.2”)
Weight 20.8 kg (45.8 lbs)
29.3 kg (64.6 lbs) with accessories
and transport case
Test lead set, with 4 mm
stackable safety plugs
2 x 0.25 m (0.8 ft), 2.5 mm²
2 x 0.5 m (1.6 ft), 2.5 mm²
8 x 2 m (6.6 ft), 2.5 mm²
Display LCD
Measurement section
Voltmeter – digital
Range 0 – 300 V DC, 0 – 300 V AC
Resolution 1 V
Inaccuracy ±1% of displayed value, DC
±2.5% of displayed value, AC
Current shunt 5 A /50 mV ±0.5% (built-in)
14 B10E ZP-BG02E BG0140ME
5 SPECIFICATIONS

WWW.MEGGER.COM
Your “One Stop” Source for all your electrical test equipment needs
Megger is a leading global manufacturer and supplier
of test and measurement instruments used within the
electric power, building wiring and telecommunication
industries.
With research, engineering and manufacturing facilities
in the USA, UK, Germany and Sweden, combined with
sales and technical support in most countries, Megger
is uniquely placed to meet the needs of its customers
worldwide.
Megger is certified according to ISO 9001 and 14001.
Megger is a registered trademark.
▪Battery Test Equipment
▪Cable Fault Locating Equipment
▪Circuit Breaker Test Equipment
▪Data Communications Test Equipment
▪Fiber Optic Test Equipment
▪Ground Resistance Test Equipment
▪Insulation Power Factor (C&DF) Test Equipment
▪Insulation Resistance Test Equipment
▪Line Testing Equipment
▪Low Resistance Ohmmeters
▪Motor & Phase Rotation Test Equipment
▪Multimeters
▪Oil Test Equipment
▪Portable Appliance & Tool Testers
▪Power Quality Instruments
▪Recloser Test Equipment
▪Relay Test Equipment
▪T1 Network Test Equipment
▪Tachometers & Speed Measuring Instruments
▪TDR Test Equipment
▪Transformer Test Equipment
▪Transmission Impairment Test Equipment
▪Watthour Meter Test Equipment
▪STATES® Terminal Blocks & Test Switches
▪Professional Hands-On Technical and
Safety Training Programs
▪AUSTRALIA
▪BULGARIA
▪CANADA
▪CZECH REPUBLIC
▪CHINA
▪FRANCE
▪GERMANY
▪HUNGARY
▪INDIA
▪INDONESIA
▪KINGDOM OF BAHRAIN
▪KOREA
▪MALAYSIA
▪PAKISTAN
▪PHILIPPINES
▪POLAND
▪ROMANIA
▪RUSSIA
▪SINGAPORE
▪SLOVAK REPUBLIC
▪SOUTH AFRICA
▪SPAIN
▪SWEDEN
▪SWITZERLAND
▪TAIWAN
▪THAILAND
▪UNITED ARAB EMIRATES
▪USA
▪VIETNAM
Megger Group Limited
UNITED KINGDOM
Dover, Kent CT17 9EN
ENGLAND
Postal address: Visiting address:
Megger Sweden AB Megger Sweden AB
Box 724 Rinkebyvägen 19
SE-182 17 DANDERYD SE-182 36 DANDERYD
SWEDEN SWEDEN
T+46 8 510 195 00
[e-mail]
www.megger.com
Subject to change without notice. Printed matter No. ZP-BG02E Doc. BG0140ME V04a 2019
