Mellerware TURBO GLIDE 2 3 4 5 02 0 0 0 W User manual

Model:
23450
2000W
PLEASE READ ALL INSTRUCTIONS BEFORE USE
turbo glide
steam iron
MW_CO23450_TURBOGLIDE_STEAM_IRON_IM.indd 1MW_CO23450_TURBOGLIDE_STEAM_IRON_IM.indd 1 7/14/2009 3:38:14 PM7/14/2009 3:38:14 PM

Dear customer,
Many thanks for choosing to purchase a Mellerware brand product. Its technology, design and operation
and the fact that it exceeds the strictest quality standards, ensures it will give you full satisfaction for a
very long time.
A
B
C
D
HI
F
E
G
Fig. 1
Description
A Spray button
B Steam blast button
C Steam setting control
D Self-cleaning button
E Spray nozzle
F Filling hole
G Base
H Temperature gauge
I Iron ready pilot light
MW_CO23450_TURBOGLIDE_STEAM_IRON_IM.indd 2MW_CO23450_TURBOGLIDE_STEAM_IRON_IM.indd 2 7/14/2009 3:38:16 PM7/14/2009 3:38:16 PM

Safety advice and warnings
- Read these instructions carefully before switching
the appliance on and keep them for future consul-
tation. Failure to follow and observe these instruc-
tions may result in an accident.
- Some parts of the iron have been lightly greased,
so the iron may produce a little smoke when
plugged in for the first time. This will stop after a
short period of time.
- Before using the iron for the first time, remove the
plastic cover from the base and clean the base with
a soft cloth.
- Pure wool fabrics (100%) can be ironed with the
iron set to steam. Preferably chose a high steam
setting and use a dry ironing cloth.
Use or working environment:
- Keep children and bystanders away when using
this appliance.
- The appliance must be used and placed on a flat,
stable surface.
Electrical safety:
- Fully unravel the power cable.
- Always unplug the iron when not in use, even for
a short period.
- Unplug the iron before filling or emptying the wa-
ter tank.
- Do not leave the appliance out in the rain or ex-
posed to moisture. If water gets into the appliance,
this will increase the risk of electric shock.
- Do not use the appliance if it has fallen on the
floor, if there are visible signs of damage or if it has
a leak.
- Do not use the appliance near bathtubs, showers
or swimming pools.
- Keep the appliance well away from heat sources,
oil, sharp edges or moving parts. Damaged or tan-
gled cables increase the risk of electric shock.
- Do not use the appliance if the cable or plug is
damaged.
- Ensure that the voltage indicated on the name-
plate matches the mains voltage before plugging
in the appliance.
- Connect the appliance to a base with an earthed
socket rated at 16 amps.
- The appliance’s plug must fit into the mains
socket properly. Do not alter the plug. Do not use
plug adaptors.
- Do not use or store the appliance outdoors.
Steam blast:
Steam blasts give an extra steam jet to help remove
tough creases.
- Select the maximum temperature*** on the tem-
perature gauge (H). Wait for the pilot light to go off
(I).
- Press the steam blast button (B). Wait some
seconds until vapour penetrates the fibres before
pushing the button again. For optimum steam qual-
ity, do not apply more than three successive blasts.
The spray button has to be pressed repeatedly to
release the first spray.
Once you have finished using the appliance:
- Select the minimum position (MIN) using the ther-
mostat control.
- Unplug the appliance from the mains.
Cleaning
- Disconnect the appliance from the mains and al-
low to cool before undertaking any cleaning task.
- Clean the equipment with a damp cloth with a few
drops of washing-up liquid and then dry.
- Do not use solvents, or products with an acid or
base pH such as bleach, or abrasive products, for
cleaning the appliance.
- Never submerge the appliance in water or any
other liquid or put it under running water.
Self-cleaning function:
- It is important to self-clean the appliance at least
once a month to remove calcium and any other
built-up minerals inside the iron.
- Fill the tank to the top.
MW_CO23450_TURBOGLIDE_STEAM_IRON_IM.indd 3MW_CO23450_TURBOGLIDE_STEAM_IRON_IM.indd 3 7/14/2009 3:38:16 PM7/14/2009 3:38:16 PM

- Stand the iron upright and press the plug it in.
- Turn the temperature gauge to the ***position.
- Let the iron heat up until the pilot light goes off
and comes back on again.
- Unplug the iron and place it over the sink.
- Push the self-cleaning button (D) and keep it
pushed down.
- Let the water flow out through the steam vents in
the base, while lightly shaking the iron.
- Release the self-cleaning button after a moment
or when the tank has emptied and place the iron in
an upright position.
- Let the iron cool and then clean it.
Anomalies and repair
Go to an authorized Technical Support Service in
the event of malfunctions. Do not try to dismantle or
repair the iron yourself, as this may be dangerous.
If the connection to the mains has been damaged,
it must be replaced, and you should proceed as
you would in the case of damage.
Ecology and recyclability of the product
- The materials of which the packaging of this ap-
pliance consists are included in a collection, clas-
sification and recycling system. Should you wish to
dispose of them, use the appropriate public con-
tainers for each type of material.
- The product does not contain concentrations of
substances which could be considered harmful to
the environment.
- Should you wish to dispose of the product once
its working life has ended, take it to an authorised
waste agent for the selective collection of waste
from electric and electronic appliances.
