Memorex MVDP1076 User manual

Before operating this product,
please read these instructions completely.
User’sGuide
7'' TFT DISPLAY PORTABLE DVD PLAYER
WITH REMOTE CONTROL
MVDP1076

Contents ..........................1
Important Safety Instructions.........2
Precautions .......................5
Power Sources.....................7
Rotating the Screen.................8
Location of Controls ................9
• Main Unit . . . . . . . . . . . . . . . . . . . . . . . . . 9
• Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
• Remote . . . . . . . . . . . . . . . . . . . . . . . . . 10
Remote Control ...................11
• Battery Installation . . . . . . . . . . . . . . . . . 11
• Effective Distance of the
Remote Control Transmitter. . . . . . . . . . 11
Connection .......................12
• Connecting the Unit to a TV Using the
A/V Cable. . . . . . . . . . . . . . . . . . . . . . . . 12
• Connecting the Unit to a Home
Theater System . . . . . . . . . . . . . . . . . . . 13
• Connecting the Unit to Another
Media Player . . . . . . . . . . . . . . . . . . . . . 15
About Discs ......................16
Setup Menu.......................18
• Language Setup Menu . . . . . . . . . . . . . 19
• Video Setup Menu . . . . . . . . . . . . . . . . . 20
•Audio Setup Menu . . . . . . . . . . . . . . . . . 20
• Reset Setup Menu. . . . . . . . . . . . . . . . . 21
Basic Operation ...................22
• Mute. . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
•RotateButton.....................22
• Headphone Jack(s) . . . . . . . . . . . . . . . . 22
•SourceButton....................22
• OSD Button . . . . . . . . . . . . . . . . . . . . . . 23
• LCD Button . . . . . . . . . . . . . . . . . . . . . . 23
• Volume. . . . . . . . . . . . . . . . . . . . . . . . . . 23
DVD Operation ....................24
• Playback of a DVD . . . . . . . . . . . . . . . . 24
• Skip . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
•Search..........................26
• Slow Motion . . . . . . . . . . . . . . . . . . . . . . 26
• Pause/Step . . . . . . . . . . . . . . . . . . . . . . 26
• Time Search . . . . . . . . . . . . . . . . . . . . . 26
• Title Search . . . . . . . . . . . . . . . . . . . . . . 26
•ChapterSearch...................26
• Bookmark. . . . . . . . . . . . . . . . . . . . . . . . 28
• Repeat Playback . . . . . . . . . . . . . . . . . . 29
• Repeat A-BPlayback...............29
• Audio Menu . . . . . . . . . . . . . . . . . . . . . . 30
• Subtitle Menu. . . . . . . . . . . . . . . . . . . . . 30
• DVD Menu . . . . . . . . . . . . . . . . . . . . . . . 30
• Title Menu . . . . . . . . . . . . . . . . . . . . . . . 30
• Zoom In . . . . . . . . . . . . . . . . . . . . . . . . . 31
• Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
• Programmed Playback . . . . . . . . . . . . . 32
CD Operation .....................33
• Playback of a CD. . . . . . . . . . . . . . . . . . 33
• Pause. . . . . . . . . . . . . . . . . . . . . . . . . . . 33
• Skip . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
• Search . . . . . . . . . . . . . . . . . . . . . . . . . . 34
• Track Time Search. . . . . . . . . . . . . . . . . 34
• Track Search . . . . . . . . . . . . . . . . . . . . . 34
• Disc Time Search . . . . . . . . . . . . . . . . . 35
• Track Search . . . . . . . . . . . . . . . . . . . . . 35
• Bookmark. . . . . . . . . . . . . . . . . . . . . . . . 35
• Selecting Tracks Using the
Number Buttons. . . . . . . . . . . . . . . . . . . 36
• Repeat Playback . . . . . . . . . . . . . . . . . . 36
• Repeat A-B Playback. . . . . . . . . . . . . . . 36
• Programmed Playback . . . . . . . . . . . . . 37
Picture CD Operation ..............38
Troubleshooting Guide .............39
Care and Maintenance..............41
Specifications.....................42
1
TABLE OF CONTENTS

2
SAFETY INSTRUCTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
THIS DIGITAL VIDEO DISC PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS OWNER’S
MANUAL CAREFULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT
REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION.
USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE
ENCLOSURE. VISIBLE LASER RADIATION MAY BE PRESENT WHEN THE ENCLOSURE
IS OPENED. DO NOT STARE INTO BEAM.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
WARNING:
TOREDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, AND ANNOYING
INTERFERENCE, USE THE RECOMMENDED ACCESSORIES ONLY.
DANGEROUS VOLTAGE:
The lightning flash with arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of uninsulated dangerous
voltage within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
ATTENTION:
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the appliance.

3
SAFETY INSTRUCTIONS (CONT.)
FCC NOTICE:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Modifications not authorized by the manufacturer may void user’s authority to operate this
device.
FCC CAUTION:
To assure continued compliance, follow the attached installation instructions and use only
shielded cables when connecting to other devices. Also, any changes or modifications not
expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
ATTENTION:
POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE
DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISES ET POUSSER
JUSQU’AU FOND.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
LASER WARNING:
This unit employs a laser. Only qualified service personnel should attempt to service this
device due to possible eye injury.
SURGE PROTECTORS:
It is recommended to use a surge protector for AC connection. Lightning and power surges
ARE NOT covered under warranty for this product.

Dear Customer:
Selecting fine audio equipment such as the unit you’ve just purchased is only the start of
your musical enjoyment. Now it’s time to consider how you can maximize the fun and
excitement your equipment offers. This manufacturer and the Electronic Industries
Association’s Consumer Electronics Group want you to get the most out of your equipment
by playing it at a safe level. One that lets the sound come through loud and clear without
annoying blaring or distortion and, most importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of
sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard
against this by setting your equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.
Once you have established a comfortable sound level:
•Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future. After
all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often undetectable until it is too late, this manufacturer and
the Electronic Industries Association’s Consumer Electronics Group recommend you avoid
prolonged exposure to excessive noise. This list of sound levels is included for your protection.
Decibel
Level Example
30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
4
A
S
S
O
C
I
A
T
I
O
N
EST. 1924
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
EIA
We
LISTENING
For A Lifetime
Want You
SAFETY INSTRUCTIONS (CONT.)

5
PRECAUTIONS
NOTES ON HANDLING:
• When shipping the DVD player, always use the original shipping carton and
packing materials. For maximum protection, repack the unit as it was
originally packed at the factory.
• Do not use volatile liquids, such as insect spray, near the DVD player. Do not
leave rubber or plastic products in contact with the DVD player for a long
time. They will leave marks on the finish.
• The top and rear panels of the DVD player may become warm after a long
period of use. This is normal and not a malfunction.
• When the DVD player is not in use, be sure to remove the disc and turn off
the power.
• If you do not use the DVD player for a long period, the unit may not function
properly in the future. Turn on and use the DVD player occasionally.
NOTES ON LOCATING THE DVD PLAYER:
•When you place this DVD player near a TV, radio or VCR, the playback
picture may become poor and the sound may be distorted. In this case, move
the DVD player away from the TV, radio or VCR.
NOTES ON CLEANING:
Use a soft, dry cloth for cleaning.
•For stubborn dirt, soak the cloth in a weak detergent solution, wring well and
wipe. Use a dry cloth to wipe it dry. Do not use any type of solvent, such as
thinner or benzene, as they may damage the surface of the DVD player.
• If you use a chemical-saturated cloth to clean the unit, follow that product’s
instructions.
Warning: Cleaning and adjustment of lenses and/or other components of
playback mechanism should be performed by a qualified service technician.
CAUTION:
To reduce the risk of injury, only charge with supplied rechargeable Battery Pack;
other types of batteries may burst causing personal injury or damage.

6
PRECAUTIONS (CONTINUED)
TO OBTAIN A CLEAR PICTURE:
The DVD player is a high technology, precision device. If the optical pick-up lens
and disc drive parts are dirty or worn down, the picture quality becomes poor. To
obtain a clear picture, we recommend regular inspection and maintenance
(cleaning or parts replacement) every 1,000 hours of use depending on the
operating environment. For details, contact your nearest dealer.
NOTES ON MOISTURE CONDENSATION:
Moisture condensation damages the DVD player. Please read the following
carefully.
•Moisture condensation occurs, for example, when you pour a cold drink into a
glass on a warm day. Drops of water form on the outside of the glass. In the
same way, moisture may condense on the optical pick-up lens inside this unit,
one of the most crucial internal parts of the DVD player.
Moisture condensation occurs during the following cases:
•When you bring the DVD player directly from a cold place to a warm place.
• When you use the DVD player in a room where you just turned on the heater,
or a place where the cold wind from the air conditioner directly hits the unit.
• In summer, when you use the DVD player in a hot and humid place just after
you moved the unit from an air conditioned room.
• When you use the DVD player in a humid place.
Do not use the DVD player when moisture condensation may occur.
• If you use the DVD player in such a situation, it may damage discs and
internal parts. Remove the disc, insert the small end of the AC adapter into
the DC IN jack on the side of the unit and insert the other end into a
conveniently located AC outlet having 120 AC, 60 Hz, turn on the DVD player
and leave it “ON” for two or three hours. After two or three hours, the DVD
player will have warmed up and evaporated any moisture. Keep the DVD
player connected to the wall outlet and moisture condensation will seldom
occur.

AC CONNECTION
Insert the small end of the AC adapter
into the DC IN jack (located on the
side of the unit) and connect the other
end to a wall outlet having 120V AC,
60 Hz.
AC Adapter, DC 9V Z
NOTES:
•Use the enclosed AC adapter for
this product only.
• Remove both the DC plug and the AC-IN plug to disconnect the AC adapter when
not using.
BATTERY PACK INSERTION/REMOVAL
Follow the diagram below to insert or remove the Battery Pack.
7
POWER SOURCES
TOREMOVE: Press the PUSH (Release)
button, then slide the Battery Pack out and
down.
TOINSERT: Align the tabs from the Battery
Pack into the holes on the bottom of the main
unit. Then, slide the Battery Pack into the
main unit until it clicks into place.
2
1

CHARGING THE BATTERY PACK
“Low Battery” will appear on the screen when the battery is low and needs
recharging. The battery can be charged while attached to the unit as follows:
With the Battery Pack attached, insert the small end of the AC adapter into the DC
IN jack on the side of the unit. Insert the other end (with the 2 blades) into a
conveniently-located AC outlet having 120V AC, 60Hz. The CHARGE indicator on
the battery will light red as the battery is charging and green when charging has
completed. Disconnect the AC adapter plugs when charging has finished.
NOTE:
• Fully charge the Battery Pack for 12 hours before using it for the first time. After
the initial charge, it should take approximately five hours to charge.
• A fully-charged Battery Pack can operate for about 2 hours.
To rotate the screen, twist in a clockwise direction up to
180 degrees as shown in Figure 1. It is suggested that the
screen remains in a perpendicular position while it is
being rotated to avoid scratching or damaging the surface
of the unit. To return the unit to its original position, rotate
the unit in a counter-clockwise direction.
If desired, when the screen is rotated to 180 degrees, you
can fold it over onto the body of the unit as shown in
Figure 2. To secure the screen onto the body of the unit,
tuck the tab on the top of the screen into the hole beneath
the Disc Compartment. To release, press the button next
to the hole.
8
POWER SOURCES (CONTINUED)
ROTATING THE SCREEN
Figure 1
Figure 2

1. Display
2. Alternate Navigation (√)Button
3. LCD Button
4. Left Speaker
5. Disc Compartment
6. SOURCE Button
7. AUDIO Button
8. SUBTITLE Button
9. Skip oButton
10. Search √√ Button
11. Right Speaker
12. Alternate Navigation (®)Button
13. ROTATE Button
14. POWER Button
15. SETUP Button
16. MENU Button
17. Play/Pause (®p)Button
18. Navigation (√,®,π,†)Buttons
19. ENTER Button
20. Power Indicator
21. Remote Sensor
22. Stop (■)Button
23. Screen Display Open Button
24. Search ®® Button
25. Disc Compartment Cover
OPEN Button
26. Skip nButton
9
LOCATION OF CONTROLS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
23
22
24
25
26
MAIN UNIT

10
LOCATION OF CONTROLS (CONTINUED)
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
SIDE
REMOTE
1. AUDIO (IN/OUT) Jack
2. Headphone 2 Jack
3. Headphone 1 Jack
4. VOLUME Control
5. PUSH (Release) Button
(Top of the Battery Pack)
6. Battery Pack
7. CHARGE Indicator
(Top of the Battery Pack)
8. VIDEO (IN/OUT) Jack
9. COAXIAL OUT Jack
10. DC IN Jack 9V z
1. MUTE Button
2. STANDBY Button
3. Number (0-9, 10+) Buttons
4. LCD Button
5. RETURN Button
6. TITLE Button
7. STEP Button
8. MENU Button
9. PAUSE (p)Button
10. PLAY (®)Button
11. Search ®® Button
12. Search √√ Button
13. REPEAT A-B Button
14. REPEATButton
15. SEARCH Button
16. OSD Button
17. SUBTITLE Button
18. AUDIO Button
19. ANGLE Button
20. CLEAR Button
21. PROG. Button
22. SETUP Button
23. ENTER Button
24. Navigation (√,®,π,†)Buttons
25. ZOOM Button
26. STOP (■) Button
27. SLOW Button
28. Skip (o) Button
29. Skip (n) Button
30. VOL - Button
31. VOL + Button
NOTE: Press the POWER button (on the main unit) to turn the unit
on; the Power indicator will light red. When the unit is on, if you
press the STANDBY button (on the remote), the unit will turn to the
Standby mode. To reduce the unit’s power consumption, press the
POWER button (on the main unit) to turn the unit off; the Power
indicator will turn off. Also, the STANDBY button is just for turning
the unit to Standby mode. Toturn the unit on or off, press the
POWER button (on the main unit).

11
REMOTE CONTROL
BATTERY INSTALLATION
BATTERY PRECAUTIONS
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated next to the battery
compartment. A reversed battery may cause damage to the device.
3. If the device is not to be used for a long period of time, remove the battery to prevent damage
or injury from possible battery leakage.
4. Do not try to recharge a battery not intended to be recharged; it can overheat and rupture.
(Follow battery manufacturer’s directions.)
1. Remove the Battery Compartment door
by sliding it downward.
2. Install a CR2025 battery, paying attention
to the polarity diagram in the battery
compartment (positive side up).
3. Replace the Battery Compartment door.
EFFECTIVE DISTANCE OF THE REMOTE CONTROL TRANSMITTER
NOTES:
•When there is an
obstacle between the
DVD and the transmitter,
the transmitter may not
operate.
•When direct sunlight, an
incandescent lamp,
fluorescent lamp or any
other strong light shines
on the Remote Sensor of
the DVD, the remote
operation may be
unstable.

12
CONNECTION
CONNECTING THE UNIT TO A TV USING THE A/V CABLE (INCLUDED)
NOTES FOR CONNECTING TO A TV:
• Set the TV’s TV/VIDEO button or switch to the VIDEO setting.
• When connecting the unit, refer to the owner’s manual of the TV, as well as this
manual.
• When connecting the unit to the TV, make sure the power is off and both units are
unplugged before making any connections.
• Connect the unit to your TV directly. If you connect the unit through a VCR, the
playback picture will be distorted because DVD video discs are copy protected.

13
CONNECTION (CONTINUED)
CONNECTING THE DVD TO A HOME THEATER SYSTEM (AUDIO JACK)
NOTES FOR CONNECTING TO A TV:
• Set the TV’s TV/VIDEO button or switch to the VIDEO setting.
• When connecting the unit,refer to the owner’s manuals for the TV and the audio
system, as well as this manual.
• When connecting, make sure the power is off and all units are unplugged before making
any connections.
• Connect the unit to your TV directly. If you connect the unit through a VCR, the playback
picture will be distorted because DVD video discs are copy protected.
Place the subwoofer, front, rear and center
speakers in locations as shown/described
here. After correctly positioning the
speakers, perform the Tone Test on the AV
Amplifier and adjust the Volume control(s)
until the desired sound is achieved. For best
results, sit in the viewing position and have
someone adjust the volumes for you; this will
enable you to set the optimal levels.
NOTE: The rear speakers can also be
located on the side wall facing the viewing
position and each other. Make sure the
viewing position is located between the two
speakers in this case. Experiment to find
optimal position.
1. Front Left Speaker
2. Television
3. Center Speaker–can be located on top or
below the television.
4. Sub-woofer–can be located anywhere in the
room.
5. Front Right Speaker
6. Viewing/Listening Position–The best
listening position is obtained by positioning the
chair, sofa, etc. in the middle of all the
speakers.
7. Rear Left Speaker
8. Rear Right Speaker
9. AV Amplifier w/Dolby Digital Decoder

14
CONNECTION (CONTINUED)
CONNECTING THE DVD TO A HOME THEATER SYSTEM (COAXIAL JACK)
NOTES FOR CONNECTING TO A TV:
•Set the TV’s TV/VIDEO button or switch to the VIDEO setting.
• When connecting the unit,refer to the owner’s manuals for the TV and the audio
system, as well as this manual.
• When connecting, make sure the power is off and all units are unplugged before making
any connections.
• Connect the unit to your TV directly. If you connect the unit through a VCR, the playback
picture will be distorted because DVD video discs are copy protected.
• Set the Digital Out on the Audio Setup menu to PCM, see page 20.
Place the subwoofer, front, rear and center
speakers in locations as shown/described
here. After correctly positioning the
speakers, perform the Tone Test on the AV
Amplifier and adjust the Volume control(s)
until the desired sound is achieved. For best
results, sit in the viewing position and have
someone adjust the volumes for you; this will
enable you to set the optimal levels.
NOTE: The rear speakers can also be
located on the side wall facing the viewing
position and each other. Make sure the
viewing position is located between the two
speakers in this case. Experiment to find
optimal position.
1. Front Left Speaker
2. Television
3. Center Speaker–can be located on top or
below the Television.
4. Sub-woofer–can be located anywhere in the
room.
5. Front Right Speaker
6. Viewing/Listening Position–The best
listening position is obtained by positioning the
chair, sofa, etc. in the middle of all the
speakers.
7. Rear Left Speaker
8. Rear Right Speaker
9. AV Amplifier w/Dolby Digital Decoder

15
CONNECTION (CONTINUED)
CONNECTING THE UNIT TO ANOTHER MEDIA PLAYER
(To view the image/hear the sound from an external unit):
NOTES FOR CONNECTING:
•When connecting the unit, refer to the owner’s manual(s) of the external unit(s),
as well as this manual.
• When connecting the unit, make sure the power is off and all units are unplugged
before making any connections.
• Press the POWER button (on the main unit) to turn on the unit and press the
SOURCE button (on the main unit) to select AV Input.

16
ABOUT DISCS
PLAYABLE DISCS:
The following discs can be played back on this DVD player:
The region number for this DVD Player is:
See the following page for information regarding region numbers.
DISC TYPES:
DVD
Data on most DVDs is divided into sections
called “titles” and then into subsections called
“chapters”, each of which is given a title or
chapter number. Some features of this DVD
player will not operate with some DVD discs
as they are preset. If a function you selected
does not run as desired, refer to the manual
accompanying the DVD disc.
AUDIO CD
Data on an audio CD is divided into sections
called “tracks”, each of which is given a track
number.
IMPORTANT:
It is important that you read the manual that accompanies the DVD disc, as there are
features that are on the DVD player that cannot be used with certain DVDs. There are also
extra features on the DVD disc that are different for each DVD disc, so they are not
explained in this owner’s manual.

Notes on Copyright:
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public
and rent copyrighted material without permission. DVD video discs are copy
protected, and any recordings made from these discs will be distorted. This product
incorporates copyright protection technology that is protected by method claims of
certain U.S. patents and other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation, and is intended for home and other
limited viewing uses only, unless otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
Region Management Information:
This DVD Player is designed and manufactured to respond to the Region
Management Information that is recorded on a DVD disc. If the Region number
described on the DVD disc does not correspond to the Region number of this DVD
player, this DVD player cannot play that disc. You may not be able to play back
some DVD video discs on this player if they were purchased from outside your
geographic area or made for business purposes. When you try to play back an
unauthorized disc, "Wrong Region" appears on the TV screen.
17
ABOUT DISCS (CONTINUED)

The Setup Menu lets you customize the DVD player by allowing you to select
various language preferences, set video/audio settings, adjust what type of
television screen you have and more.
Use the following instructions to navigate and change the options as described on
the upcoming pages.
1. Without a disc inserted and with the
disc compartment cover closed, press
the SETUP button 1to enter the Setup
Menu.
2. Select one of the Setup icons at the
top of the screen using the Navigation
(√,®) buttons 2,then press the
ENTER button 3to select it.
3. Use the Navigation (π,†) buttons 2to
select one of the Setup options, then
press the ENTER button 3to select it.
4. Use the Navigation (π,†) buttons 2to
change the desired setting, then press
the ENTER button 3to make the
change.
5. Exit by pressing the SETUP button 1
again.
NOTE:
• To turn on the unit, press the POWER button (on the main unit); the Power
indicator will light. To turn off the unit, press the POWER button (on the main
unit); the Power indicator will turn off.
• You can also press the RETURN button (on the remote) to exit the Setup menu.
18
SETUP MENU
1
23

19
SETUP MENU (CONTINUED)
Select the desired language (ENGLISH,
FRENCH, SPANISH) for the On-Screen
display to display text. Note that the DVD
must have the language included in order to
display it.
1
Select the language the Subtitle (OSD) will
be in (ENGLISH, FRENCH, SPANISH,
AUTO, OFF). The DVD must be recorded in
the selected language, otherwise the default
language of the DVD will be shown. Select
OFF to select without any language
showing on the TV screen.
1
LANGUAGE SETUP MENU:
Press the SETUP button to enter the menu, select LANGUAGE using the Navigation (√,®)
buttons, then press the ENTER button to select it. Select/change the Setup option as described
on page 18.
OSD LANGUAGE SUBTITLE
Select the language the DVD will be played
back in (ENGLISH, FRENCH, SPANISH).
The DVD must be recorded in the selected
language, otherwise the default language of
the DVD will be played.
1
Select the language the DVD MENU will be
in (ENGLISH, FRENCH, SPANISH). The
DVD’s MENU must be made in the selected
language, otherwise the default language of
the DVD will be shown.
1
AUDIO DVD MENU
