Memphis SBT4 User manual

SBT4
Bluetooth Controller With AUX Input
Marine Grade Construction
MA MEDIA ACCESSORY
BLUETOOTH
SBT4
USB
STREAM/CHARGE
AUX
INPUT
ROTARY DIAL WITH
RGB SOURCE INDICATOR
BLUETOOTH
CONTROLLER

Features
• Rotary knob for easy and intuitive volume control
• RGB LED knob indicates source selection
• Inputs include Bluetooth, AUX, USB flash drive play
• USB charging compatibility
• Water and element resistant
• 2.6V output
• Flush surface mount or bar mount
SBT4 BLUETOOTH CONTROLLER
Memphis Audio built a 50 year legacy in the audio industry by engineering the highest quality
products to produce the best possible listening experience for our fans and loyal supporters. To fully
appreciate our products we recommend taking the time to read and follow the instructions in this
manual. As always, we recommend all the installations and services to be performed by an
authorized Memphis Audio dealer.
For optimal performance, Memphis recommends using only Memphis Connection
accessories. Outfitting your system with properly sized Memphis Connection wire and
accessories will dramatically boost your listening experience and increase the durability of
your Memphis Audio products.
Combine with our Memphis Xtreme Speakers and ultra-compact amplifiers for the perfect
rugged go-anywhere audio solution!
Memphis Audio’s SBT4 Bluetooth streaming accessories allow you to wirelessly connect to any
Bluetooth device providing a complete Bluetooth solution wherever you need it. To keep this piece
as bulletproof as possible, we sealed the unit making it waterproof in the event of submersion and
resistant to the elements.
Ready to turn it up? Read this first!

Track
Up
Track
Up
Track
Up
Track
Down
Power/
Mode
Play/
Pause
Vol.
Up/
Down
Bluetooth functions are typically depicted by a Bluetooth symbol. Look for the Bluetooth
symbol on your device when attempting to enable Bluetooth functionality.
Before starting, confirm your Bluetooth device is capable of streaming A2DP Bluetooth signals and
that the Bluetooth is ENABLED on the device. Typically that function is available by entering the
settings menu, then finding the ‘Bluetooth” controls on your device.
Operation:
Long press and hold the power button for 2 seconds. The unit will turn on and the buttons will
illuminate blue. The BT LED will flash rapidly when the unit is powered on. When the SBT4 is
successfully paired, the BT indicator will then be lit blue continuously and will no longer be flashing.
Make sure your phone is in ‘Pairing’ or ‘Discoverable’ mode. Within a few seconds you should see
‘SBT4’ appear on your device’s Bluetooth menu. Selecting ‘SBT4’ will authorize your device to
connect with the SBT4.
Once the SBT4 is connected, be certain the volume on your phone is set at a reasonably high level
(at least 3/4 of max volume). Adjusting the volume of the system can be done on the SBT4 once
your device is paired.
Press and hold the power button for 2 seconds to turn off the unit.
Control Functions:
The controls will allow you to perform the following functions: track up, track down, volume up,
volume down, play/pause in Bluetooth mode.
Changing Source:
After the power is on, short pressing the power button will change between the sources:
Bluetooth > Aux > USB. The related indicator will illuminate showing which selection is active.
Identifying source modes: BLUE LED indicates Bluetooth source.
GREEN LED indicates Aux source.
PURPLE LED indicates USB source.
Pairing Instructions
Button Functions

SBT4 BLUETOOTH CONTROLLER
Bluetooth, Aux, and USB Charging Inputs
3
Warranty
Should your SBT4 require service, please consult with the dealer from which it was purchased, or
contact Memphis Audio customer service: 800-489-2300, or send an email to
[e-mail]. Do not attempt to return your accessory directly to us
without first calling for a Return Authorization number. Units received without an accompanying
Return Authorization number will be returned unopened. Additionally, you must include a copy
of your purchase receipt from an authorized dealer for consideration of in-warranty service;
otherwise, repair charges will apply. Units received without a receipt will be held for 30 days
allowing us time to contact you and obtain a copy of the receipt.
USB Charging/MP3 Flash Drive Play
REMOTE TURN ON

4
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment must be installed and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide a separation distance of at least
20cm from all persons.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Caution!
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
