Meowant SELF-CLEANING CAT LITTER BOX User manual

SELF-CLEANING
CAT LITTER
BOX
User Manual
Made In China
suppo@meowanthome.com
Questions or Concerns
Model: MW-LB01
MANUFACTURER
Shenzhen Guiyang Network Technology Co., Ltd
ADDRESS
1404K3, East Block, Shengtang Commercial Building,
Futian District, Shenzhen, China
Rev_1.0_EN

CONTENT
01 01-03
IMPORTANT
SAFETY
INSTRUCTIONS
02 04-05
EXPLORING
CAT LITTER
BOX
03 06-10
USING
CAT LITTER
BOX
04 11-13
CARE
AND
CLEANING
05 14-15
TROUBLE-
SHOOTING
GUIDE
06 16
WARRANTY
AND
SERVICE

IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
AND SAVE FOR FUTURE REFERENCE
Cat or kitten must
weigh at least 3lbs
and age 4 months
or more to safely
use the litter box.
> 3 lbs.
DO NOT place on
carpet. Place on a
rm, level suace
with a little space
around.
DO NOT drag when
moving the litter
box. Move by lifting
the base with both
hands.
DO NOT rinse or
immerse the base
in water or other
liquid.
When using an electrical appliance, especially when children are present, basic safety precautions
should always be followed, including the following:
•This appliance is not intended for use by persons (including children) with reduced physical, senso or mental capabilities, or lack
of experience and knowledge, unless they have been given supeision or instruction concerning the use of the appliance by
person responsible for their safety.
•Close attention is necessa when used by or near children. Children should be supeised to ensure that they do not play with, in
or around the appliance. Keep the appliance and all accessories out of reach of children.
•Use the appliance only for intended household purposes as described in this User Manual.
INTENDED USE
•DO NOT operate the appliance if it has a damaged power cord or plug, or if it is malfunctioning or has been damaged in any
manner.
•DO NOT use an external power supply other than the one provided with the appliance. Use only the provided power adapter.
•DO NOT immerse the power adapter or the base in water or other liquid or allow moisture to come into contact with these pas.
•If the supply cord is damaged, it must be replaced by the manufacturer, its seice agent or similarly qualied persons in order to
avoid a hazard.
•Always unplug when not in use, before putting on or taking o pas and before cleaning, maintenance or seicing.
ELECTRICITY SAFETY
•Always place the litter box on a rm, level suace. Avoid soft, uneven, or unstable ooring, which may aect the ability of the unit
to detect your cat. If using litter mats or rugs, place in front of the unit. Do not place mats paially or completely under the unit.
•Keep indoors in a cool, d location. Reduce exposure to high temperature and humidity.
•DO NOT sit on or place anything on top of the litter box.
•DO NOT put anything in the unit other than clumping litter or litter beads and cstals that are small enough to pass through the
screen.
•DO NOT allow pets to chew on or swallow any pas. Cover or hide the power cord with care to prevent pets from biting.
•DO NOT open the top cover while the litter box is rotating.
•DO NOT attempt to disassemble, repair, modify or replace any pa of the appliance. No user seiceable pas inside. All seicing
should be peormed by qualied personnel only.
•Dispose of all packaging materials properly. Keep away from children and pets.
RELATED TO USE
01 02
•Always wash hands thoroughly after removing the waste. Pregnant women and those with suppressed immune systems should
note that a parasite sometimes found in cat feces could cause toxoplasmosis. Exercise cation and consult with a physician before
handling the litter box.
•How often you will need to replace the waste bags depends on the number and size of your cats. We recommend to replace
eve 3 to 5 days to avoid bacteria growth.

•Always place the litter box on a rm, level suace. Avoid soft, uneven, or unstable ooring, which may aect the ability of the unit
to detect your cat. If using litter mats or rugs, place in front of the unit. Do not place mats paially or completely under the unit.
•Keep indoors in a cool, d location. Reduce exposure to high temperature and humidity.
•DO NOT sit on or place anything on top of the litter box.
•DO NOT put anything in the unit other than clumping litter or litter beads and cstals that are small enough to pass through the
screen.
•DO NOT allow pets to chew on or swallow any pas. Cover or hide the power cord with care to prevent pets from biting.
•DO NOT open the top cover while the litter box is rotating.
•DO NOT attempt to disassemble, repair, modify or replace any pa of the appliance. No user seiceable pas inside. All seicing
should be peormed by qualied personnel only.
•Dispose of all packaging materials properly. Keep away from children and pets.
03 04
•Always wash hands thoroughly after removing the waste. Pregnant women and those with suppressed immune systems should
note that a parasite sometimes found in cat feces could cause toxoplasmosis. Exercise cation and consult with a physician before
handling the litter box.
•How often you will need to replace the waste bags depends on the number and size of your cats. We recommend to replace
eve 3 to 5 days to avoid bacteria growth.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
Specications
Input
Rated Power
For Cat
Waste Bin Capacity
Toileting Space
Max Weight Capacity
Applicable Litter
DC 5V 2A
10W
Weight > 3lbs / Age > 4 months
3.7gal / 14L
21.1gal / 80L
5.5lbs / 2.5kg
All clumping cat litter
(bentonite mineral, mixed and tofu cat litter (length < 0.5in))
EXPLORING CAT LITTER BOX
Check if all accessories are included.
Contact us via email:
suppo@meowanthome.com
if there is any pa missing or damaged.
Waste Container
Cover
Cat Exit / Ent
Litter Filter
Screen
MAX Fill Line
LED Display
Snap Lock
Other Accessories
•Waste Bags (20 pack)
•Power Adapter x 1
•Rubber Band x 3 (1 pre-installed)
•User Manual x 1
•Quick Sta Guide x 1
Deodorization
Cover
Waste Container
Drum
Drum Suppo
Weight Sensor
Control Buttons
Cat Litter Mat
Base
Drum Handle
Power Po

05 06
Control & Display
Manual
Clean
Spread
Flat
Press MODE button until “Manual clean”
displayed, then press OK button to sta cleaning
the waste litter.
Press MODE button until “Smooth litter” displayed,
then press OK button to sta spreading the litter
at.
Empty
Litter
Press MODE button until “Empty litter” displayed,
then press OK button to sta emptying all litter.
Reset Press MODE button until “Reset” displayed, then
press OK button to restore to facto settings.
Wi-Fi
Setup
Press MODE button until “WIFI” displayed, then
press OK button twice to bring the litter box into
paring mode.
USING CAT LITTER BOX
Getting Staed
•Remove all protective tapes and foam pads before use.
•Make sure that the drum is properly installed onto the base before plugging into an outlet.
•Make sure that the waste bag is properly installed and the waste container cover is locked before use.
1
Locate the litter box
indoors on a rm, level
suace with little space
around. Place the mat
in front of the litter box.
2 3 4
Check to make sure that
the rotating shaft is
properly inseed into the
slot of the drum suppo.
Plug in. The drum auto
rotates a full circle with
“Resetting” on display.
Wait for it to return to
Home position (“Used 0
times” on display).
Pinch the snap lock
inward to open the
waste container cover.
Do not touch
any walls 1
2

07 08
5
Take a rubber band
and slip it over the rim
of waste bag. Simply
arrange the waste bag.
6 7 8
Attach the waste bag to
cover the opening and
x onto the frame with
the rubber band. Pinch
the snap lock inward to
lock the cover.
Add clumping litter
below the MAX ll line
when spread at. Do not
oveill.
Wait 2min after adding
litter. Press MODE button
until “Smooth litter”
displayed, then press OK
button to spread the
litter at.
To help your cat transition to the new litter box:
•Location is Key. Place the litter box in the same location as the old one, or leave the old one nearby for a sho period of time
(at least during transition).
•Keep the Old Box. Do not throw out the old box. Put the new one in its designated spot and stop cleaning out the old one.
•Use Recognizable Scents. Add a scoop of litter from the old litter box to provide a familiar scent for your cat.
Introducing New Litter Box to Your Cat
Wi-Fi Setup
•Make sure that your sma device is connected to a secure 2.4GHz network and Bluetooth is enabled.
Allow access to your Location during connection.
•Make sure that the drum is at the Home position before connecting.
•You can use the litter box with control buttons only or download APP for more customizable options.
•The litter box can only be linked to one account. You can press MODE button until Reset displayed to
reset and follow the below steps to pair it with another device.
1 2 3
Download and install NOTTY
Sma Pet app, then sign up for
an account.
Press MODE button until “WIFI”
displayed, then press OK button
twice to bring it into paring
mode.
Open app, tap .
2.4GHz
MODE
Smooth
litter
OK
MODE
Smooth
litter
OK
MODE
WIFI
OK
MODE
WIFI
OK

09 10
4 5 6
Select the device to be added. Tap
Sta and follow the on-screen
instructions.
Select a 2.4GHz Wi-Fi and enter
password.
Wait until successfully connected
and go to Homepage.
Using with APP
Device Settings
Scheduled Clean
(Clean at scheduled time)
Auto Clean
(Auto clean once cat leaves)
Soft Cat Poop Mode
(Bu then clean 15min after cat leaves)
Empty All Litter
Spread Litter Flat
Manual Clean
Slide to check daily records
or cat information
1
2
Cat Litter Box

11 12
CARE AND CLEANING
Replacing Waste Bag
•How often you will need to replace the waste bag depends on the number and size of your cats. We
recommend to replace eve 3 to 5 days to avoid bacteria growth.
•This bag is not a toy. Keep it out of the reach of babies and small children. Do not use the bag in cribs,
children's beds, prams, pushchairs or anywhere in the vicinity of children.
1
Pinch the snap lock
inward to open the
waste container cover.
2 3 4
Carefully remove the
rubber band and take the
waste bag out. Gather
the edges and dispose.
Slip the rubber band over
the rim of the new waste
bag. Simply arrange the
waste bag.
Attach the waste bag to
cover the opening and x
onto the frame with the
rubber band. Pinch the
snap lock inward to lock
the cover.
Emptying and Cleaning
•Always make sure the waste bag is empty before emptying all litter.
•How often you will need to clean depends on your personal preference and your cat's behavior. We
recommend cleaning the inside eve one to three months.
•Always d all pas thoroughly before reassembling for next use.
1
Open the waste container
and dispose of the litter.
Replace with a new waste
bag. Make sure that the
deodorization cover is
not stuck.
2 3 4
Press MODE button until
“Empty litter” displayed,
then press OK button to
sta emptying all litter.
Wait until the empty cycle
is done. Carefully take the
waste bag out and
dispose.
Unplug the litter box.
Hold to take out the
drum.
10s
MODE
OK
Empty
litter
MODE
Empty
litter
OK

13 14
5
Disassemble the lter
screen and inside mat
from the drum if desired.
Rinse clean each pa.
Air d thoroughly
before reassembling.
67 8
Wipe clean the base with
a soft, slightly damp cloth.
Do not rinse or immerse in
water.
Place the drum back on the
base, making sure that the
rotating shaft is properly
inseed into the slot of the
drum suppo.
Install the waste bag
and set up as instructed
in section "Getting
Staed".
TROUBLESHOOTING GUIDE
The troubleshooting guide addresses the most common problems. If problems persist, feel free to
contact the Customer Suppo via email: suppo@meowanthome.com
Problem Solution
Fail to connect the litter box.
•Make sure that your mobile is connected to a secure 2.4GHz Wi-Fi network and
Bluetooth is enabled Allow access to your Location during connection..
•Make sure that your mobile and litter box are connected to the same Wi-Fi
network.
•Make sure that you have entered a correct Wi-Fi password and the litter box is
under strong Wi-Fi signal.
•Check if the litter box is linked to another device. Press MODE button until Reset
displayed to reset or have the device unbound on app.
•Check if a 5GHz frequency is used. T a Personal Hotspot, or change 5GHz to
2.4GHz to connect your mobile. Consult the router supplier for detailed instruction
on router conguration.
Drum does not rotate or
stops rotating suddenly.
•Disconnect from the power supply and remove the drum to check if there is any
foreign object stuck at the gear of the base.
•Make sure the drum is installed properly on the base. Reconnect it to the power
supply and t again.
•The drum stops rotating automatically when cat / weight is detected. It will resume
rotating after the cat exists, or the weight is removed.
1
2

15 16
The waste cannot be
cleaned.
Check if the deodorization cover is blocked by the waste bag, cat litter or waste.
Open the waste container cover and remove any foreign objects.
Can my family members and
I connect to the litter box at
the same time?
Yes, you can. But to protect your privacy, the litter box can only be linked to one
account. You can share with your family members on app.
I cannot weigh my cat.
•Disconnect from the power supply and check if the litter box is placed on a
rm and level suace with the four weight sensors at the same level.
•Empty all litter. Press MODE button until “Reset” displayed, then press OK
button to reset weight sensors and t again.
Can I use the litter box
without APP?
Yes, you can use the litter box with control button only or download APP for more
customizable options.
How to get the new waste
bags?
For the new waste bags, search for MeoWant waste bags on Amazon or contact
our Customer Suppo via email: suppo@meowanthome.com.
WARRANTY AND SERVICE
Thank you for choosing MeoWant Self-Cleaning Cat Litter Box. This product is covered with MeoWant
product and labor warranty for 12 months from the date of its original purchase.
The warranty will not apply in cases of:
-Accident, misuse, or repairs peormed by unauthorized personnel.
-Any unit that has been tampered with or used for commercial purpose.
-Normal wear and tear of wearable pas.
-Use of force, damage caused by external inuences.
-Damage caused by non-obseance of the User Manual, e.g. connection to an unsuitable mains supply or non-compliance with the
instructions.
-Paially or completely dismantled appliances.
-Defects caused by or resulting from damages from repairs, seice, or alteration to the product or any of its pas that have been
peormed by a repair person not authorized.
We can only provide after sales seice for products that are sold by MeoWant or MeoWant authorized retailers and distributors.
If you have purchased your unit from a dierent place, please contact your seller for return and warranty issues.
* Please have your order ID ready before contacting Customer Suppo via email: suppo@meowanthome.com

82
81
FCC Compliance
This device complies with Pa 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)this device may not cause harmful inteerence, and
(2)this device must accept any inteerence received, including inteerence that may cause undesired operation.
Warning: Changes or modications not expressly approved by the pay responsible for compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Pa 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful inteerence in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful inteerence to radio communications. However, there is no guarantee that inteerence will not occur in a paicu-
lar installation. If this equipment does cause harmful inteerence to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to t to correct the inteerence by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set foh for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the radiator & your body.
