Mercury 92-813054A2 User manual

© 2012 Mercury Marine QSD 2.0 Diesel Engine Inboard Models *8M0069748* 90-8M0069748 412
Declaration of Conformity—Mercury Diesel QSD Inboard
This inboard engine when installed in accordance to Mercury Marine’s instructions complies with the requirements of the
following directives by meeting the associated standards, as amended:
Recreational Craft Propulsion Engines with the Requirements of Directive 94/25/EC as amended by 2003/44/EC
Name of engine manufacturer: V M MOTORI, s.p.a.
Address: VIA FERRARESE, 29
Town: CENTO (FE) Post Code: 44042 Country: Italy
Name of Authorized Representative: Brunswick Marine in EMEA Inc.
Address: Parc Industriel de Petit‑Rechain
Town: Verviers Post Code: 4800 Country: Belgium
Name of Notified Body for exhaust emission assessment: T Ü V PRODUCT SERVICE Gmbh
Address: RIDLERSTRASSE, 65
Town: MÜNICH Post Code: 80339 Country: Germany ID Number: 0123
Conformity assessment module used for exhaust emissions: ☒ B+C ☐ B+D ☐ B+E ☐ B+F ☐ G☐ H
Other Community Directives applied: Electromagnetic Compatibility Directive 2004/108/EC
Description of Engines and Essential Requirements
Engine Type: Fuel Type: Combustion Cycle:
☒ Inboard engine ☒ Diesel ☒ 4 stroke
Identification of Engines Covered by this Declaration of Conformity
Name of engine model or engine
family:
Unique engine identification
number(s) or engine family code(s)
EC Type–examination certificate or
type‑approval certificate number
QSD 4.2L 350/320/270 MR706LX / MR706LH / MR706LS SB5 06 08 57278 006
QSD 2.8L 230/220/210/170 MR704LX / MR704LY / MR704LH /
MR704LS SB5 08 07 57278 008
QSD 2.0L 170/150/130/115 MR504LX / MR504LH / MR504LS /
MR504LB SB5 07 07 57278 007
Essential requirements Standards
Other
normative
document/
method
Technical
file
Please specify in more detail
(* = mandatory standard)
Annex I.B – Exhaust Emissions
B.1 engine identification ☐ ☐ ☒
B.2 exhaust emission
requirements ☒* ☐ ☐ *EN ISO 8178‑1:1996
B.3 durability ☐ ☐ ☒
B.4 owner’s manual ☒ ☐ ☐ ISO 8665:1995
Annex I.C – Noise Emissions see Declaration of Conformity of the craft in which the engine(s) has (have) been
installed

This declaration of conformity is issued under the sole responsibility of the manufacturer. I declare on behalf of the engine
manufacturer that the engine(s) will meet the exhaust emission requirements of Directive 94/25/EC as amended by Directive
2003/44/EC when installed in a recreational craft, in accordance with the engine manufacturer’s supplied instructions and that
this (these) engine(s) must not be put into service until the recreational craft into which it is (they are) to be installed has been
declared in conformity with the relevant provisions of the above mentioned Directives.
Name / function:
Mark Schwabero, President, Mercury
Marine
Signature and title:
Date and place of issue: April 20, 2012
Fond du Lac, Wisconsin, USA
Regulatory contact:
Regulations and Product Safety Department
Mercury Marine
W6250 W. Pioneer Road
Fond du Lac, WI 54936
USA
Identification Record
Please record the following information:
Engine Model and Horsepower Engine Serial Number
Transmission Model (Inboard) Gear Ratio Transmission Serial Number
Propeller Number Pitch Diameter
Hull Identification Number (HIN) Purchase Date
Boat Manufacturer Boat Model Length
Exhaust Gas Emissions Certification Number
The serial numbers are the manufacturer’s keys to numerous engineering details that apply to your Mercury Diesel power
package. When contacting Mercury Marine about service, always specify model and serial numbers.
Descriptions and specifications contained herein were in effect at the time this guide was approved for printing. Mercury
Marine, whose policies are based on continuous improvement, reserves the right to discontinue models at any time or to
change specifications or designs without notice and without incurring obligation.
Mercury Marine, Fond du Lac, Wisconsin, U.S.A. Printed in U.S.A.
Mercury, Mercury Marine, MerCruiser, Mercury MerCruiser, Mercury Racing, Mercury Precision Parts, Mercury Propellers,
Quicksilver, #1 On The Water, Alpha, Bravo, Bravo Two, Bravo Three, MerCathode, SmartCraft, Zero Effort, M with Waves
logo, Mercury with Waves logo, VesselView, and SmartCraft logo are all registered trademarks of Brunswick Corporation.
Mercury Product Protection logo is a registered service mark of Brunswick Corporation.
Welcome
You have selected one of the finest marine power packages available. It incorporates numerous design features to assure
operating ease and durability.
With proper care and maintenance, you will thoroughly enjoy using this product for many boating seasons. To ensure
maximum performance and carefree use, we ask that you thoroughly read this manual.
The Operation, Maintenance, and Warranty Manual contains specific instructions for using and maintaining your product. We
suggest that this manual remain with the product for ready reference whenever you are on the water.

Thank you for purchasing one of our Mercury Diesel products. We sincerely hope your boating will be pleasant!
Mercury Marine
Warranty Message
The product you have purchased comes with a limited warranty from Mercury Marine; the terms of the warranty are set forth
in the Warranty sections of this manual. The warranty statement contains a description of what is covered, what is not covered,
the duration of coverage, how to best obtain warranty coverage, important disclaimers and limitations of damages, and
other related information. Please review this important information.
Read This Manual Thoroughly
IMPORTANT: If you do not understand any portion of this manual, contact your dealer for a demonstration of actual starting
and operating procedures.
Notice
Throughout this publication, and on your power package, dangers, warnings, cautions, and notices, accompanied by the
International Hazard Symbol !, may be used to alert the installer and user to special instructions concerning a particular
service or operation that may be hazardous if performed incorrectly or carelessly. Observe them carefully.
These safety alerts alone cannot eliminate the hazards that they signal. Strict compliance with these special instructions while
performing the service, plus common sense operation, are major accident prevention measures.
! DANGER
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
! WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
! CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE
Indicates a situation which, if not avoided, could result in engine or major component failure.
IMPORTANT: Identifies information essential to the successful completion of the task.
NOTE: Indicates information that helps in the understanding of a particular step or action.
! WARNING
The operator (driver) is responsible for the correct and safe operation of the boat, the equipment aboard and the safety of all
occupants aboard. We strongly recommend that the operator read this Operation, Maintenance and Warranty Manual and
thoroughly understand the operational instructions for the power package and all related accessories before the boat is used.
! WARNING
The engine exhaust from this product contains chemicals known to the state of California to cause cancer, birth defects or
other reproductive harm.

90-8M0069748 eng APRIL 2012 Page i
TABLE OF CONTENTS
Section 1 - Warranty
Warranty Information................................................................. 2
Warranty Registration United States and Canada.............. 2
Warranty Registration—Outside the United States and
Canada............................................................................... 2
Warranty Policy–Diesel Models................................................. 2
High‑Output Recreational Use Worldwide Limited
Warranty............................................................................. 2
What is Covered............................................................. 2
Duration of Coverage..................................................... 2
High‑Output Rating......................................................... 3
Conditions That Must Be Met to Obtain Warranty
Coverage........................................................................ 3
What Mercury Marine Will Do......................................... 3
How to Obtain Warranty Coverage.................................3
Termination of Coverage................................................ 3
What Is Not Covered...................................................... 3
3‑Year Limited Warranty Against Corrosion–Diesel Models
(Recreational Use Only)..................................................... 4
What Is Covered............................................................. 4
Duration of Coverage..................................................... 4
Conditions That Must Be Met to Obtain Warranty
Coverage........................................................................ 4
What Mercury Will Do..................................................... 4
How to Obtain Warranty Coverage.................................5
What Is Not Covered...................................................... 5
Transfer of Warranty........................................................... 5
Section 2 - Getting to Know Your Power Package
Identification............................................................................... 8
Serial Number Decal........................................................... 8
Engine Data Label.............................................................. 8
Data Label Location............................................................ 9
Technodrive Transmissions................................................ 9
Features and Controls............................................................. 10
Audio Warning System..................................................... 10
Digital Throttle and Shift................................................... 10
Instrumentation................................................................. 10
VesselView................................................................... 10
SmartCraft Speedometer and Tachometer Digital
Gauges......................................................................... 11
System Link Digital Gauges......................................... 11
System Tachometer or Speedometer............................... 12
Switches........................................................................... 12
Emergency Stop Switch.................................................... 13
Lanyard Stop Switch......................................................... 14
Remote Controls............................................................... 15
Panel Mount Features.................................................. 15
Console Mount Features.............................................. 15
Engine Electrical System Overload Protection................. 16
Vessel Integration Panel (VIP) Overload Protection......... 17
Section 3 - On the Water
Safe Boating Suggestions........................................................ 20
Be Alert to Carbon Monoxide Poisoning........................... 21
Good Ventilation........................................................... 21
Poor Ventilation ........................................................... 21
Important Operation Information.............................................. 21
Launching......................................................................... 21
Duty Cycle Rating Requirements...................................... 21
High‑Output Rating........................................................... 22
Basic Boat Operation............................................................... 22
Operation Chart................................................................ 22
Freezing Temperature and Cold Weather Operation....... 22
Drain Plug and Bilge Pump............................................... 23
Starting, Shifting, and Stopping............................................... 23
Before Starting the Engine................................................ 23
Important Information – SmartStart................................... 24
Starting a Cold Engine...................................................... 24
Engine Warm Up.............................................................. 24
Starting a Warm Engine ................................................... 24
Shifting.............................................................................. 25
Engine Shut Down (Stopping).......................................... 25
Protecting People in the Water................................................ 25
While Boat is in Operation.................................................. 25
While the Boat is Stationary............................................... 25
High‑Speed and High‑Performance......................................... 26
Passenger Safety In Pontoon Boats And Deck Boats............. 26
Boats Having An Open Front Deck.................................... 26
Boats With Front‑Mounted, Raised Pedestal Fishing Seats
........................................................................................... 26
Wave and Wake Jumping........................................................ 26
Impact With Underwater Hazards............................................ 27
Conditions Affecting Operation................................................ 27
Weight Distribution (Passengers and Gear) Inside the
Boat.................................................................................. 27
Bottom of Boat.................................................................. 28
Elevation and Climate....................................................... 28
Propeller Selection............................................................ 28
Getting Started......................................................................... 28
Initial Break‑In Procedure................................................. 28
Engine Break‑In................................................................ 29
20‑Hour Break‑In Period...............................................29
After the 20‑Hour Break‑In Period................................ 29
End of First Season Checkup........................................... 29

Page ii 90-8M0069748 eng APRIL 2012
Section 4 - Specifications
Fuel Requirements................................................................. 32
Recommended Fuels............................................................. 32
Diesel Fuel in Cold Weather................................................... 32
Coolant (Antifreeze)................................................................33
Engine Oil............................................................................... 33
Engine Specifications............................................................. 34
Fluid Specifications.................................................................34
Engine............................................................................. 34
QSD 2.0...................................................................... 34
Transmission................................................................... 35
Approved Paints..................................................................... 35
Section 5 - Maintenance
Owner and Operator Responsibilities..................................... 38
Dealer Responsibilities........................................................... 38
Maintenance........................................................................... 38
Do‑It‑Yourself Maintenance Suggestions............................... 38
General Inspection................................................................. 38
Engine Cover.......................................................................... 39
Removal.......................................................................... 39
Cleaning.......................................................................... 39
Inspection........................................................................ 39
Installation....................................................................... 39
Maintenance Schedule........................................................... 39
Routine Maintenance...................................................... 39
Scheduled Maintenance.................................................. 40
Maintenance Log............................................................. 41
Engine Oil............................................................................... 43
Oil Level—Overfilled........................................................ 43
Checking......................................................................... 43
Filling............................................................................... 44
Changing Oil and Filter.................................................... 45
TM 345 Technodrive Transmission Fluid............................... 47
Checking......................................................................... 47
Filling............................................................................... 48
Changing......................................................................... 48
TM 485‑A Technodrive Transmission Fluid............................ 50
Check Fluid..................................................................... 50
Add Fluid......................................................................... 51
Change Fluid................................................................... 51
Engine Coolant....................................................................... 53
Checking......................................................................... 53
Filling............................................................................... 54
Changing......................................................................... 55
Air Filter.................................................................................. 55
Removal.......................................................................... 55
Inspection........................................................................ 56
Installation....................................................................... 56
Water‑Separating Fuel Filter.................................................. 57
Draining........................................................................... 57
Replacing........................................................................ 58
Filling............................................................................... 60
Fuel System............................................................................61
Priming............................................................................ 61
Filling (Bleeding).............................................................. 61
Fuel Tank Cleaning and Flushing.................................... 62
Seawater System................................................................... 62
Draining the Seawater System........................................ 62
Checking the Seawater Pickups...................................... 64
Cleaning the Seawater Strainer...................................... 64
Engine Seawater Pump Inspection................................. 66
Replacing the Engine Coolant................................................ 66
Draining the Closed‑Cooling System.............................. 66
Filling the Closed Cooling System................................... 67
Corrosion Protection............................................................... 68
General Information.........................................................68
Engine Corrosion Protection Components...................... 68
Removal...................................................................... 68
Cleaning and Inspection............................................. 69
Installation................................................................... 69
Antifouling Paint.............................................................. 70
Lubrication.............................................................................. 70
Throttle Cable.................................................................. 70
Shift Cable....................................................................... 71
Serpentine Belt Inspection......................................................71
Battery.................................................................................... 72
Battery Precautions for Multiple Engines.......................... 72
Section 6 - Storage
Cold Weather (Freezing Temperature), Seasonal Storage, and
Extended Storage................................................................... 76
Cold Weather (Freezing Temperature) Storage.............. 76
Preparing Your Power Package for Seasonal or Extended
Storage............................................................................ 77
Seasonal Storage............................................................ 77
Extended Storage Instructions........................................ 78
Battery............................................................................. 78
Recommissioning................................................................... 78
Section 7 - Troubleshooting
Diagnosing Electronically Controlled Fuel System Problems. 82 Troubleshooting Charts.......................................................... 82

90-8M0069748 eng APRIL 2012 Page iii
Starter Motor Will Not Crank Engine, or Cranks Slow...... 82
Engine Will Not Start, or Is Hard to Start.......................... 82
Engine Runs Rough, Misses, or Backfires....................... 82
Poor Performance............................................................. 83
Incorrect Engine Temperature.......................................... 83
Low Engine Oil Pressure.................................................. 83
Battery Will Not Charge.................................................... 83
Remote Control Operates Hard, Binds, Has Excessive
Free‑play, or Makes Unusual Sounds.............................. 84
Section 8 - Customer Assistance Information
Owner Service Assistance....................................................... 86
Local Repair Service.......................................................... 86
Service Away From Home..................................................86
Stolen Power Package....................................................... 86
Attention Required After Submersion................................. 86
Replacement Service Parts................................................ 86
Parts and Accessories Inquiries......................................... 86
Resolving a Problem.......................................................... 86
Customer Service Literature.................................................... 87
English Language.............................................................. 87
Other Languages................................................................87
Andre sprog........................................................................ 87
Andere talen....................................................................... 87
Muut kielet.......................................................................... 87
Autres langues................................................................... 87
Andere Sprachen............................................................... 87
Altre lingue......................................................................... 87
Andre språk........................................................................ 87
Outros Idiomas................................................................... 87
Otros idiomas..................................................................... 88
Andra språk........................................................................ 88
Allej glþssej........................................................................ 88
Ordering Literature................................................................... 88
United States and Canada................................................. 88
Outside the United States and Canada.............................. 88

Page iv 90-8M0069748 eng APRIL 2012

Section 1 - Warranty
90-8M0069748 eng APRIL 2012 Page 1
Section 1 - Warranty
Table of Contents
Warranty Information.............................................................. 2
Warranty Registration United States and Canada........... 2
Warranty Registration—Outside the United States and
Canada............................................................................ 2
Warranty Policy–Diesel Models.............................................. 2
High‑Output Recreational Use Worldwide Limited
Warranty.......................................................................... 2
What is Covered ...................................................... 2
Duration of Coverage .............................................. 2
High‑Output Rating .................................................. 3
Conditions That Must Be Met to Obtain Warranty
Coverage ................................................................. 3
What Mercury Marine Will Do .................................. 3
How to Obtain Warranty Coverage ......................... 3
Termination of Coverage ......................................... 3
What Is Not Covered ............................................... 3
3‑Year Limited Warranty Against Corrosion–Diesel
Models (Recreational Use Only)...................................... 4
What Is Covered ...................................................... 4
Duration of Coverage .............................................. 4
Conditions That Must Be Met to Obtain Warranty
Coverage ................................................................. 4
What Mercury Will Do .............................................. 4
How to Obtain Warranty Coverage ......................... 5
What Is Not Covered ............................................... 5
Transfer of Warranty........................................................ 5
1

Section 1 - Warranty
Page 2 90-8M0069748 eng APRIL 2012
Warranty Information
Warranty Registration United States and Canada
1. To be eligible for warranty coverage, the product must be registered with Mercury Marine. At the time of sale, the dealer
should complete the warranty registration and immediately submit it to Mercury Marine via MercNET, E‑mail, or mail. Upon
receipt of this warranty registration, Mercury Marine will record the registration.
2. Warranty coverage is not effective until your product is registered with Mercury Marine.
3. You may change your address at any time, including at time of warranty claim, by calling Mercury Marine or sending a
letter or fax with your name, old address, new address, and engine serial number to Mercury Marine’s Warranty
Registration Department. Your dealer can also process this change of information.
Mercury Marine
Attn: Warranty Registration Department
W6250 Pioneer Road
P.O. Box 1939
Fond du Lac, WI 54936-1939
920-929-5054
Fax [phone]
NOTE: Registration lists must be maintained by Mercury Marine and any dealer on marine products sold in the United
States, should a safety recall notification under the Federal Safety Act be required.
Warranty Registration—Outside the United States and Canada
1. It is important that your selling dealer fills out the Warranty Registration Card completely and mails it to the distributor or
Marine Power Service Center responsible for administering the warranty registration and claim program for your area.
2. The Warranty Registration Card identifies your name and address, product model and serial numbers, date of sale, type of
use and the selling distributor's and dealer's code number, name and address. The distributor or dealer also certifies that
you are the original purchaser and user of the product.
3. A copy of the Warranty Registration Card, designated as the Purchaser's Copy, must be given to you immediately after the
card has been completely filled out by the selling distributor or dealer. This card represents your factory registration
identification, and should be retained by you for future use when required. Should you ever require warranty service on this
product, your dealer may ask you for the Warranty Registration Card to verify date of purchase and to use the information
on the card to prepare the warranty claim forms.
4. In some countries, the Marine Power Service Center will issue you a permanent (plastic) Warranty Registration Card within
30 days after receiving the Factory Copy of the Warranty Registration Card from your distributor or dealer. If you receive a
plastic Warranty Registration Card, you may discard the Purchaser's Copy that you received from the distributor or dealer
when you purchased the product. Ask your distributor or dealer if this plastic card program applies to you.
5. For further information concerning the Warranty Registration Card and its relationship to Warranty Claim processing, refer
to the International Warranty. See Table of Contents.
IMPORTANT: Registration lists must be maintained by the factory and dealer in some countries by law. It is our desire to have
ALL products registered at the factory should it ever be necessary to contact you. Make sure your Mercury Marine distributor or
Mercury Marine authorized dealer fills out the warranty registration card immediately and sends the factory copy to the Marine
Power International Service Center for your area.
Warranty Policy–Diesel Models
High‑Output Recreational Use Worldwide Limited Warranty
What is Covered
Mercury Marine warrants each new engine/drive package (Product) to be free of defects in material and workmanship during
the period described following.
Duration of Coverage
The warranty period begins on the date the product is first sold to a recreational‑use retail purchaser or the date on which the
product is first put into service, whichever occurs first. This Limited Warranty provides coverage for two (2) years or 1000 hours
of use, whichever occurs first. Commercial use of the product voids the warranty. Commercial use includes any work or
employment related use of the product, or any use of the product which generates income during any part of the warranty
period, even if the product is only occasionally used for such purposes. The repair or replacement of parts, or the performance
of service under this warranty does not extend the term of this warranty beyond its original expiration date. Unexpired warranty
coverage can be transferred from one recreational use customer to a subsequent recreational use customer upon proper
re‑registration of the product.

Section 1 - Warranty
90-8M0069748 eng APRIL 2012 Page 3
High-Output Rating
A High‑Output Rating applies to variable load applications where full power is limited to one (1) hour out of every eight (8)
hours of operation. Reduced power operation (the 7 hours out of 8 hours in which the engine is not operated at full power) must
be at or below cruise speed. Cruise speed is dependant on the engine's maximum engine rated speed (RPM):
Full Power Engine Rated Speed (RPM) Cruise Speed
Reduction from Engine Rated Speed (RPM)
3500–4500 RPM 400 RPM
This rating is for pleasure (non–commercial) applications that operate 500 hours or fewer per year.
Conditions That Must Be Met to Obtain Warranty Coverage
Warranty coverage is available only to retail customers that purchase from a Dealer authorized by Mercury Marine to distribute
the product in the country in which the sale occurred, and then only after the Mercury Marine specified pre‑delivery inspection
process is completed and documented. Warranty coverage becomes available upon proper registration of the product by the
authorized dealer. Inaccurate warranty registration information regarding recreational use, or subsequent change of use from
recreational to commercial (unless properly re‑registered) may void the warranty at the sole discretion of Mercury Marine.
Routine maintenance outlined in the Operation, Maintenance, & Warranty Manual must be timely performed in order to obtain
warranty coverage. Mercury Marine reserves the right to make any warranty coverage contingent upon proof of proper
maintenance.
What Mercury Marine Will Do
Mercury Marine’s sole and exclusive obligation under this warranty is limited to, at our option, repairing a defective part,
replacing such part or parts with new or Mercury Marine certified re‑manufactured parts, or refunding the purchase price of the
Mercury Marine product. Mercury Marine reserves the right to improve or modify products from time to time without assuming
an obligation to modify products previously manufactured.
How to Obtain Warranty Coverage
Warranty claims must be made through a Mercury Marine authorized repair facility. The customer must provide Mercury Marine
with a reasonable opportunity to repair and reasonable access to the product for warranty service. The purchaser shall not,
unless requested by Mercury Marine, ship the product or parts of the product directly to Mercury Marine.
Termination of Coverage
Warranty coverage may be terminated for used product obtained in any of the following ways:
• Repossession from a retail customer
• Purchase at auction
• Purchase from a salvage yard
• Purchase from an insurance company that obtained the product as a result of an insurance claim
• Inaccurate warranty registration information
What Is Not Covered
This limited warranty does not cover the following:
• Routine maintenance items
• Adjustments
• Normal wear and tear
• Damage caused by abuse
• Abnormal use
• Use of a propeller or gear ratio that does not allow the engine to run in its recommended RPM range (see the Operation,
Maintenance & Warranty manual)
• Operation of the product in a manner inconsistent with the recommended operation and duty cycle section of the
Operation, Maintenance & Warranty manual
• Neglect
• Accident
• Submersion
• Improper installation (proper installation specifications and techniques are set forth in the installation instructions for the
product)
• Improper service

Section 1 - Warranty
Page 4 90-8M0069748 eng APRIL 2012
• Use of an accessory or part that was not manufactured or sold by Mercury Marine and that damages the Mercury product
• Jet pump impellers and liners
• Operation with fuels, oils, or lubricants that are not suitable for use with the product (see the Operation, Maintenance &
Warranty manual)
• Alteration or removal of parts
• Water entering the engine through the fuel intake, air intake, or exhaust system or damage to the product from insufficient
cooling water caused by blockage of the cooling system by a foreign body
• Running the engine out of water
• Mounting the engine too high on the transom
• Operating the boat with the engine over trimmed
Use of the product for racing or other competitive activity, or operating with a racing‑type lower unit at any point, even by a
previous owner of the product, voids the warranty. Expenses related to haul‑out, launch, towing, storage, telephone, rental,
inconvenience, slip fees, insurance coverage, loan payments, loss of time, loss of income, or any other type of incidental or
consequential damages are not covered by this warranty. Also, expenses associated with the removal or replacement of boat
partitions or other material in order to gain access to the product are not covered by this warranty. No individual or entity,
including Mercury Marine authorized dealers, has been given authority by Mercury Marine to make any affirmation,
representation, or warranty regarding the product, other than those contained in this limited warranty. If such affirmation,
representation, or warranty is made, it shall not be enforceable against Mercury Marine.
DISCLAIMERS AND LIMITATIONS
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
EXPRESSLY DISCLAIMED. TO THE EXTENT THAT THEY CANNOT BE DISCLAIMED, THE IMPLIED WARRANTIES
ARE LIMITED IN DURATION TO THE LIFE OF THE EXPRESS WARRANTY. INCIDENTAL AND CONSEQUENTIAL
DAMAGES ARE EXCLUDED FROM COVERAGE UNDER THIS WARRANTY. SOME STATES/COUNTRIES DO NOT
ALLOW FOR THE DISCLAIMERS, LIMITATIONS AND EXCLUSIONS IDENTIFIED ABOVE. AS A RESULT, THEY MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
LEGAL RIGHTS WHICH VARY FROM STATE TO STATE AND COUNTRY TO COUNTRY.
3‑Year Limited Warranty Against Corrosion–Diesel Models (Recreational Use Only)
What Is Covered
Mercury Marine warrants that each new recreational use engine/drive package (Product) will not be rendered inoperative as a
direct result of corrosion for the period of time described in the following:
Duration of Coverage
This limited corrosion warranty provides coverage for three (3) years from either the date the product is first sold, or the date on
which the product is first put into service, whichever occurs first. The repair and replacement of parts, or the performance of
service under this warranty does not extend the life of this warranty beyond its original expiration date. Unexpired warranty
coverage can be transferred to subsequent (non‑commercial use) purchaser upon proper re‑registration of the product.
Warranty coverage may be terminated for used product repossessed from a retail customer, purchased at auction, from a
salvage yard, or from an insurance company that obtained the product as a result of an insurance claim.
Conditions That Must Be Met to Obtain Warranty Coverage
Warranty coverage is available only to retail customers that purchase from a dealer authorized by Mercury Marine to distribute
the product in the country in which the sale occurred, and then only after the Mercury Marine specified pre‑delivery inspection
process is completed and documented. Warranty coverage becomes available upon proper registration of the product by the
authorized dealer. Corrosion prevention devices specified in the Operation, Maintenance & Warranty manual must be in use on
the boat, and routine maintenance outlined in the Operation, Maintenance & Warranty manual must be timely performed
(including without limitation the replacement of sacrificial anodes, use of specified lubricants, and touch‑up of nicks and
scratches) in order to maintain warranty coverage. Mercury Marine reserves the right to make warranty coverage contingent
upon proof of proper maintenance.
What Mercury Will Do
Mercury's sole and exclusive obligation under this warranty is limited to, at our option, repairing a corroded part, replacing such
part or parts with new or Mercury Marine certified re‑manufactured parts, or refunding the purchase price of the Mercury
product. Mercury reserves the right to improve or modify products from time to time without assuming an obligation to modify
products previously manufactured.

Section 1 - Warranty
90-8M0069748 eng APRIL 2012 Page 5
How to Obtain Warranty Coverage
The customer must provide Mercury with a reasonable opportunity to repair, and reasonable access to the product for warranty
service. Warranty claims shall be made by delivering the product for inspection to a Mercury dealer authorized to service the
product. If purchaser cannot deliver the product to such a dealer, written notice must be given to Mercury. We will then arrange
for the inspection and any covered repair. Purchaser in that case shall pay for all related transportation charges and/or travel
time. If the service provided is not covered by this warranty, purchaser shall pay for all related labor and material, and any other
expenses associated with that service. Purchaser shall not, unless requested by Mercury, ship the product or parts of the
product directly to Mercury. Proof of registered ownership must be presented to the dealer at the time warranty service is
requested in order to obtain coverage.
What Is Not Covered
This limited warranty does not cover electrical system corrosion; corrosion resulting from damage, corrosion which causes
purely cosmetic damage, abuse or improper service; corrosion to accessories, instruments, steering systems; damage due to
marine growth; product sold with less than a one year limited product warranty; replacement parts (parts purchased by the
Customer); products used in a commercial application. Commercial use is defined as any work or employment related use of
the product, or any use of the product which generates income, for any part of warranty period, even if the product is only
occasionally used for such purposes.
DISCLAIMERS AND LIMITATIONS
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
EXPRESSLY DISCLAIMED. TO THE EXTENT THAT THEY CANNOT BE DISCLAIMED, THE IMPLIED WARRANTIES
ARE LIMITED IN DURATION TO THE LIFE OF THE EXPRESS WARRANTY. INCIDENTAL AND CONSEQUENTIAL
DAMAGES ARE EXCLUDED FROM COVERAGE UNDER THIS WARRANTY. SOME STATES/COUNTRIES DO NOT
ALLOW FOR THE DISCLAIMERS, LIMITATIONS AND EXCLUSIONS IDENTIFIED ABOVE. AS A RESULT, THEY MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
LEGAL RIGHTS WHICH VARY FROM STATE TO STATE AND COUNTRY TO COUNTRY.
Transfer of Warranty
The limited warranty is transferable to a subsequent purchaser, but only for the remainder of the unused portion of the limited
warranty. This will not apply to products used for commercial applications.
To transfer the warranty to the subsequent owner, send or fax a copy of the bill of sale or purchase agreement, new owner’s
name, address and engine serial number to Mercury Marine’s Warranty Registration Department. In the United States and
Canada, mail to:
Mercury Marine
Attn: Warranty Registration Department
W6250 W. Pioneer Road
P.O. Box 1939
Fond du Lac, WI 54936-1939
920-929-5054
Fax [phone]
Upon processing the transfer of warranty, Mercury Marine will send registration verification to the new owner of the product by
mail.
There is no charge for this service.
For products purchased outside the United States and Canada, contact the distributor in your country, or the Marine Power
Service Center closest to you.

Section 1 - Warranty
Notes:
Page 6 90-8M0069748 eng APRIL 2012

Section 2 - Getting to Know Your Power Package
90-8M0069748 eng APRIL 2012 Page 7
Section 2 - Getting to Know Your Power Package
Table of Contents
Identification........................................................................... 8
Serial Number Decal........................................................8
Engine Data Label........................................................... 8
Data Label Location......................................................... 9
Technodrive Transmissions............................................. 9
Features and Controls.......................................................... 10
Audio Warning System.................................................. 10
Digital Throttle and Shift................................................ 10
Instrumentation.............................................................. 10
VesselView ............................................................ 10
SmartCraft Speedometer and Tachometer Digital
Gauges .................................................................. 11
System Link Digital Gauges .................................. 11
System Tachometer or Speedometer............................ 12
Switches........................................................................ 12
Emergency Stop Switch.................................................13
Lanyard Stop Switch...................................................... 14
Remote Controls............................................................ 15
Panel Mount Features ........................................... 15
Console Mount Features ....................................... 15
Engine Electrical System Overload Protection.............. 16
Vessel Integration Panel (VIP) Overload Protection...... 17
2

Section 2 - Getting to Know Your Power Package
Page 8 90-8M0069748 eng APRIL 2012
Identification
The serial numbers are the manufacturer's keys to numerous engineering details that apply to your Mercury Marine power
package. When contacting Mercury Marine about service, always specify model and serial numbers.
Serial Number Decal
The serial number decal is located on the engine and indicates the engine's serial number, transom serial number, drive serial
number, and the fill cap color codes for engine fluids.
25986
Serial number decal
Engine Data Label
A tamper‑resistant engine data label is affixed to the engine at the time of manufacture. It contains important information. Note
that the engine data label will not affect the fit, function, or performance of the engine and neither boatbuilders nor dealers may
remove the engine data label or the engine component it is affixed to before sale. If modifications are necessary or the engine
data label is damaged, contact Mercury Marine about the availability of a replacement.
The owner or operator is not to modify the engine in any manner that would alter the horsepower or allow exhaust gas emission
levels to exceed their predetermined factory specifications.
Example QSD engine data label
a - CE logo
b - Engine weight
c - Engine power rating
d - Maximum engine speed (RPM)
e - Engine serial number
f - Abbreviated engine description
50489
a
b
c
d
ef
c
b

Section 2 - Getting to Know Your Power Package
90-8M0069748 eng APRIL 2012 Page 9
Data Label Location
The engine data label is located on the front of the engine as shown below.
a - Serial number and part
number label, with bar codes
b - Engine data label
Technodrive Transmissions
The transmission identification plate indicates gear ratio, serial number, and model.
27943
Technodrive TM 345 identification plate
24657
Technodrive TM 485-A identification plate
a
b50480

Section 2 - Getting to Know Your Power Package
Page 10 90-8M0069748 eng APRIL 2012
Features and Controls
Audio Warning System
Your power package is equipped with an audio warning system. The audio warning system monitors critical components and
informs the operator when a malfunction has occurred. The warning system is not capable of protecting the power package
from damage caused by a malfunction.
When an electronic control system detects a recordable malfunction, the audio warning system will sound to alert the operator.
The duration and type of horn sound depend upon the nature of the fault condition. In the case of any horn sounding, the user
should refer to the helm displays to understand the specific situation.
For the operator to view the fault code of the malfunction indicated and any recommended actions, the power package must be
equipped with a gauge package that supports the warning system and can display fault codes.
The following instruments have screens that display fault codes:
• VesselView
• SmartCraft System Tachometer
• SmartCraft System Speedometer
NOTICE
The sound from an audio warning horn indicates that a critical fault malfunction has occurred. Operating a power package
with a critical fault can damage components. If the audio warning horn emits a sound, do not continue operations unless
avoiding a hazardous situation.
If the audio warning sounds, stop the engine immediately if you are not in a hazardous situation. Investigate the cause and
correct it, if possible. If you cannot determine the cause, consult an authorized repair facility.
Digital Throttle and Shift
Digital Throttle and Shift (DTS) operating instructions are provided in a separate manual. Refer to Mercury Diesel's SmartCraft
and DTS Operator's Manual.
Instrumentation
VesselView
Your power package may be connected to a SmartCraft VesselView display. The interactive VesselView display continuously
reports real‑time information about speed, performance, engine fault codes, fuel status, water temperature and depth, and
other operating data. When VesselView detects a problem with any connected system, it displays an alarm message to the
boat operator.
27198
VesselView
VesselView may also be connected to other vessel systems such as GPS, generators, and cabin environmental controls. This
vessel integration allows the operator to monitor and control a wide range of vessel systems from a single display.
Refer to your VesselView operations manual for detailed instructions on how to operate this display.

Section 2 - Getting to Know Your Power Package
90-8M0069748 eng APRIL 2012 Page 11
SmartCraft Speedometer and Tachometer Digital Gauges
The SmartCraft instrument package, if equipped, augments the information provided by VesselView. The instrument package
may display:
• Engine RPM
• Boat speed
• Coolant temperature
• Oil pressure
• Battery voltage
• Fuel consumption
• Engine operating hours
SmartCraft tachometer and speedometer
a - Tachometer
b - Speedometer
c - LCD display
The SmartCraft instrument package also aids in identifying the fault codes associated with the engine audio warning system.
The SmartCraft instrument package displays critical engine alarm data and other potential problems on its LCD display.
For basic operation information on the SmartCraft instrument package and for details on the warning functions monitored by the
system, refer to the manual provided with your gauge package.
System Link Digital Gauges
Some instrumentation packages include gauges that augment the information provided by VesselView and the SmartCraft
tachometer and speedometer. The owner and operator should be familiar with all the instruments and their functions on the
boat. Because of the large variety of instrumentation and manufacturers, have your boat dealer explain the gauges and normal
readings that appear on your boat.
The following types of digital gauges may be included with your power package.
a
b
c
d
37925
System Link digital gauges
Item Gauge Indicates
a Oil pressure gauge Engine oil pressure
b Voltmeter Battery voltage
c Water temperature gauge Engine operating temperature
d Fuel gauge Quantity of fuel in tank
a
b
c
c50400

Section 2 - Getting to Know Your Power Package
Page 12 90-8M0069748 eng APRIL 2012
System Tachometer or Speedometer
The LCD on the system tachometer, if equipped, displays active fault codes. To indicate an active fault code is present, the
following screen appears on the tachometer display.
MODE
RPM x 1000
0
2
34
5
6
7
1
RESET
TROLL
+
TROLL
-
ENGINE
[DFLT] [SKIP] [SAVE]
CHECK
25991
Typical system tachometer fault code display
After pressing "MODE," a blinking "AL" also appears in the upper right corner of each menu on the digital display screen to
signify an active fault. A major fault is also accompanied by an audio warning.
To view the active faults, press "MODE" until you reach the total engine hours screen. In the event of an active fault code, total
engine hours are displayed for 30 seconds after key‑on. After 30 seconds, the digital display screen outputs the active fault
codes in 3‑second intervals.
The following is a list of faults displayed by the Smart Tachometer that also activate an audio warning.
Smart Tach Display Warning Indication
"LOW OIL PRESS" The oil pressure has dropped below the critical engine protection limit.
"OVERHEAT" The engine coolant temperature has risen above the engine protection limit.
"WATER IN FUEL" The WIF sensor detects water in the fuel filter housing.
"FAULT THROTTLE" The throttle sensor is registering a fault.
"FAULT BATTERY" The ECM battery voltage is out of range.
"CHECK ENGINE" This code corresponds to a number of different engine related faults. Refer to your Mercury Diesel
authorized repair facility.
Switches
Four‑Position Key Switch
38160
•"OFF" ‑ In the "OFF" position, all electrical circuits are off. The engine will not operate
with the key switch in the "OFF" position.
•"ACC" ‑ In the "ACC" position, any accessories connected to the electrical circuits can
be operated. The engine will not operate with the key switch in the "ACC" position.
•"ON" ‑ In the "ON" position, all electrical circuits and instrumentation receive power. The
engine can be started with an optional start‑stop switch.
•"START" ‑ Turn the key to the start position and release to start the engine.
NOTE: The key can only be removed with the key switch in the "OFF" position.
