Meridian Bioscience BreathID Smart User manual

MLD01039 REV-01
Note: To load more pairs of bags, repeat steps 1 and 2. A batch can be run with 1 to 4 tests loaded, but the
pairs must be loaded in order, starting with Pair #1.
2.
1.
●Scan the barcode of the Gray Post Ingestion Breath Sample Bag.
●On the top panel of the device, insert the Gray Post Ingestion Breath Sample Bag into the lower port for Pair #1.
If the matching LED is lit green, the bag was inserted correctly and the image of the bag on the screen will
change to gray with the barcode number listed below.
●Ensure both LEDs are lit after properly inserting the bags in their corresponding sample ports on top panel of
the device.
●Make sure instrument status is “Ready” before loading a batch.
●On the screen, a flashing cursor on Pair #1 indicates the first patient sample is ready to be scanned.
●Scan the barcode of the Blue Baseline Breath Sample Bag.
●On the top panel of the device, insert the Blue Baseline Breath Sample Bag into the upper port for
Pair #1.
●If the matching LED is lit green, the bag was inserted correctly and the image of the bag on the screen will
change to blue with the barcode number listed below.

MLD01039 REV-01
3.
●Press Start
●The Status changes to “Running” and the barcodes become hidden. Pair #1 is analyzed first and an indicator
spins until the batch is completed.
●After Pair #1 is analyzed, the result is displayed, and Pair #2 analysis begins. The remaining pairs of bags are
analyzed the same way.
4.
●To print control barcode labels, press the barcode printer icon at the bottom left corner of the screen before
pressing Continue.
●Choose the tests you want to use as controls and place one label on each bag. Be sure the labels correspond
with the correct test according to the pair number.
●Replace the bag caps and store for future use as controls.
●After the last pair has been analyzed the screen will display “Remove bags and press Continue”. Once this is
completed, the system will automatically prepare for the next batch.
