MERIDIAN SYSTEM REMOTE (MSR+)
USER GUIDE
G Series MSR 1 7/7/03, 3:16:20 pm

ii
Preface Preface
About this guide
This guide consists of the following chapters:
Introduction provides a general overview of the MSR+ and
explains how to install the batteries.
Using the MSR+ describes how to use the MSR+ to control your
Meridian equipment and other products.
Programming your MSR+ describes how to program the MSR+
to control other products.
Changing the source keycaps describes how to change the
MSR+ source keycaps to suit your other equipment.
Troubleshooting provides suggested solutions to problems that
may occur when using the MSR+.
Boothroyd|Stuart Meridian, Meridian, and MSR+ are registered
trademarks of Meridian Audio Ltd.
This guide was produced by Human-Computer Interface Ltd,
http://www.interface.co.uk/
Sales and service in the UK
Meridian Audio Ltd
Stonehill
Stukeley Meadows
Cambridgeshire
PE29 6EX
England
Tel [phone] Fax [phone]
Sales and service in the USA
Meridian America Inc
3800 Camp Creek Parkway
Building 2400
Suite 122
Atlanta
GA 30331
Tel [phone] Fax [phone]
World Wide Web http://www.meridian-audio.com/
Copyright © 2003 Meridian Audio Ltd
Part no: MSR+/1
G Series MSR ii 7/7/03, 3:16:23 pm

Introduction
1
About the MSR+
The MSR+ is an advanced remote control that provides a
comprehensive range of commands to allow you to control every
product in your Meridian system straight out of the box. You can
also program it to control your other equipment.
The MSR+ provides a total of 51 keys to give access to all the
most frequently used commands of your Meridian products, and
a Function (or shift) key for additional less frequently needed
operations.
Interchangeable Meridian source keys
For easy selection of sources the MSR+ provides 12 source keys
corresponding to the sources provided by the Meridian digital
surround controllers, preamplifiers, and integrated amplifiers.
The MSR+ is provided with a selection of alternative keycaps
for the source keys which you can use to match the particular
combination of units in your system. For example, if you own a
DVDR, you can change the keycaps to provide a DVDR key.
Control your other equipment
The MSR+ is pre-programmed to mimic the remote controls for
many popular audio and video products from other manufacturers,
and you can configure it to control up to nine other products
simply by entering the appropriate device code on the numeric
keypad. A complete list of the supported products is given at the
back of this manual.
Learning commands
Even if you own a product that is not supported by the device
library built in to the MSR+, it includes a learning mode which
allows it to learn up to 120 commands from other remote controls
and assign them to a key on the MSR+.
Backlight
For convenience the MSR+ keypad is backlit, so you can use it even
in low-light conditions. The backlight automatically turns on as
soon as you press a key in low light conditions.
The MSR+ will have a battery life of over six months under normal
conditions; slightly less if you use the backlight frequently.
Introduction
G Series MSR 1 7/7/03, 3:16:23 pm

2
Introduction
The MSR+ is supplied with four AA batteries, and these need to be
installed before you can use it.
Note: Dispose of used batteries thoughtfully.
•Press the tab and remove the battery cover on the back of the
MSR+:
•Make sure you observe the polarity of the batteries and the
polarity marks + and – inside the battery compartment.
•Insert the four AA batteries accordingly:
•Push the battery cover back into place.
Low battery indicator
The indicator normally lights up when you press a key. If it flashes
twice after releasing a key, this indicates that the battery is low.
Always replace all four batteries at the same time. Do not mix old
and new batteries.
Replace the batteries as soon as possible after the low battery
indicator appears, and after removing the old batteries replace the
new batteries within two minutes, or you risk losing any codes you
have programmed.
Installing the batteries
G Series MSR 2 7/7/03, 3:16:24 pm

Using
3
Using the MSR+
Using the MSR+ to control your Meridian equipment
The following diagram gives a summary of the MSR+ commands used for controlling Meridian products:
1
OpenOpen
AudioAudio
CD
1
4
7
FunctionFunction
RADIO
2
5
8
0
DVD
3
6
9
AUX DISC
Return
RecordRecord
TAPE
Enter
TV
Menu
SetupSetup
CABLE SAT VCR1
Store
SubtitleRepeat
Clear
DSP
Display Mute
VCR2 GAME OFF
PowerPower
BandBand AngleAngle OSDOSD
Top Me n u
##
PagePage
SlowSlow
PhasePhase
PagePage
A-BA-B
Top Menu
For controlling a
DVD player
Record/Band/
Angle/OSD
For controlling
DVD and other
sources
Store/Clear
For programming
tuner, CD player or
DSP presets
Display
Changes the
front-panel display
Indicator
Flashes when you
send a command -
includes sensor for
backlight
Volume keys/Mute
Change the
volume
OFF
Switches Meridian
equipment to
standby
Source keys
Select a source
Menu keys
For navigating
DVD menus or
editing DSP
parameters
Transport keys
For controlling a CD
player, DVD player,
or tuner
Function
Hold down to
select a secondary
function, shown in
blue on some keys
Number keys
For controlling a
CD player, DVD
player, or tuner
§2 Using 3 15/7/03, 11:04:13 am

4
Using
The MSR+ provides 12 source keys to allow you to select one of
the sources in your system.
To select a source
•Press the appropriate source key.
The indicator will flash once to indicate that the command has
been sent.
Your Meridian controller will select that source. In addition, the
MSR+ keys will change so that they control that source.
To use your MSR+ to control a source without selecting the source
on your Meridian system:
•Hold down Function and press the source key.
For example, to change the TV channel while listening to a CD
press Function TV, and then use the numeric keys to select the
channel.
To use the function options
The function options are shown in blue on each key.
•Hold down Function, in the lower left corner of the remote.
•Press the key corresponding to the function you want to select.
To control your other equipment
The nine source keys: AUX, DISC, TAPE, TV, CABLE, SAT, VCR1,
VCR2, and GAME can be programmed to control other equipment
in your system as described in
Programming your MSR+ , page 5.
The CD, RADIO, and DVD source keys are dedicated to controlling
Meridian products and cannot be changed.
The volume keys, Mute, and OFF also always control Meridian
products. To use these commands with other equipment hold down
Function with them.
To illuminate the MSR+ in low light conditions
•Press any key. Use Function to avoid sending a command.
The backlight will stay on for about five seconds.
Controlling sources
G Series MSR 4 7/7/03, 3:16:26 pm

Introduction
For convenience the MSR+ provides three alternative programming
options to allow you to control ‘other products’; ie products from
other manufacturers:
•You can look up the manufacturer of the product you want to
control in the back of this manual, and specify the remote control
you want to mimic by entering a four digit device code on the
numeric keypad.
•You can specify the type of product you want to control, and then
search through the available remote controls until you find the
appropriate one that controls your product.
•You can learn each of the commands for the product from the
product’s own remote control.
Learning is the most flexible method but also the most time-
consuming. We recommend you start with one of the first two
procedures and then use learning to supplement them with any
other commands you want to add.
Dedicated (punch through) Meridian keys
Some keys on the MSR+ are dedicated to controlling your Meridian
system and cannot be reprogrammed for your other products:
Key Description
OFF Turns the Meridian system off.
Volume A, V, and Mute Control the Meridian system volume.
DSP Changes the preset on Meridian
surround controllers.
Function Menu A, V, <,
>, Function Store, and
Function Clear
Control the DSP menus on Meridian
surround controllers.
Function Display Changes the display of the Meridian
system.
You can program Function OFF, the Function volume keys,
the menu keys, Store, Clear, and Display to control your other
equipment.
Note: There is no danger of damaging your MSR+ by using these
procedures. A reset function is provided which will return your
MSR+ to the factory settings; see
Resetting the MSR +, page 10.
Programming
5
Programming your MSR+
G Series MSR 5 7/7/03, 3:16:26 pm

6
Programming Programming options
Specifying a device code
The simplest way to set up the MSR+ to control another product
is to enter the appropriate device code for the product. A complete
list of device codes for each of the supported products is given at
the back of this manual.
Entering a device code erases any learnt commands for that source
key.
To specify a device code
•Press the source key you want to use for the product; for
example, TAPE.
•Hold down 0and Mute simultaneously for two seconds until the
indicator flashes twice and stays lit.
•Enter the appropriate device code on the numeric keypad.
For example, if your tape deck is a Revox enter 0664.
If you entered a valid device code the indicator will turn off and
your MSR+ is ready to control the other product. If you entered an
incorrect code, or pressed an invalid key, the indicator will flash six
times and programming is abandoned.
For some products more than one device code is listed. Try each
of the alternative device codes in turn until you find the one that
controls your product.
To reset the source key to control Meridian products enter the
device code 8888.
Auto-programming
This procedure lets you step through the library of remote controls
in the MSR+ until you find the one that switches your product to
standby. This is likely to be the correct one for your product.
To auto-program
•Make sure your other product is switched on and out of standby.
•Press the source key you want to use for the product; for example
TV.
•Hold down 0and Mute simultaneously until the indicator flashes
twice and then stays lit.
G Series MSR 6 7/7/03, 3:16:27 pm

Programming
7
•Enter one of the following codes using the numeric keypad to
indicate the type of product you want to control.
The indicator should flash once each time you press a key, and then
flash twice and stay off when you have entered the code correctly:
Product type Code Product type Code
TV 1000 SAT/CABLE 6000
VCR 2000 LD 7000
TAPE/MD/CD-R 4000 DVD 8000
CD 5000 GAME 9000
For example, for a TV enter 1000.
•Point the MSR+ at the product you want to control, hold down
Function, and press OFF.
Each time you press Function OFF the MSR+ will step to the next
device in the library and send the corresponding Power off code to
the other product.
•As soon as the other product turns off, indicating that this is the
correct device, press the same source key again (eg TV) to store the
currently selected device.
•To step back through the device library if you overshoot press
Mute on the MSR+.
The indicator will flash twice to indicate that the operation has
succeeded, and the MSR+ is now ready to control your other
product.
Problems when programming automatically
If you reach the end of the device library without finding one that
switches off your product the indicator will flash six times.
•Press the source key again to resume the search from the beginning.
If the other product does not turn off, your product may not be
supported by the device library. In this case you will need to
program the MSR+ using your product’s own remote control as
described in
Learning commands , page 8.
Note: When stepping through the device library, you can use
the keys other than Function OFF on the MSR+ to test other
commands in the currently selected device.
G Series MSR 7 7/7/03, 3:16:27 pm

8
Programming
Learning commands
The third and most flexible way of programming the MSR+ is to
learn from your product’s own remote control. This allows you to
control products not supported by the device library, and gives you
the flexibility to assign any command to a chosen key.
The MSR+ can learn up to 120 commands. If you try to program
more than this the indicator will flash six times and the MSR+ exits
from learning mode.
You can also use learning to add commands additional to those
provided by the device library. Select the device code first, then
learn the additional commands.
Note: You cannot program the dedicated Meridian keys; see
Dedicated (punch through) Meridian keys , page 5. Also, you cannot
learn commands if the battery level is low. In these cases the
indicator will flash six times when you try to enter the learning
code.
To learn commands
•Press the source key you want to use for the product; for
example, TV.
•Hold down 0and Mute simultaneously for two seconds until the
indicator flashes twice and stays lit.
•Enter the learning code 0000 on the numeric keypad.
The indicator will flash twice and go off. The MSR+ is then ready to
learn commands.
•Aim the product’s remote control at the front of the MSR+, at a
distance of 5 to 8cm (2 to 3"):
5-8cm
(2-3")
G Series MSR 8 7/7/03, 3:16:28 pm

Programming
9
•Press and release the key on the MSR+ that you want to use for
a particular command.
The indicator will light up to show that the MSR+ is waiting to
receive the code for that command.
•Press and hold down the corresponding key on the product’s
remote control to transmit the command.
When the command has been received and learnt correctly the
indicator will flash twice and turn off. If there was a problem
learning the command the indicator will flash six times.
•Press the MSR+ key followed by the product’s remote control key
to learn each of the command keys you want to use.
When you have finished learning commands from the third-party
remote control:
•Press the source key again, eg TV.
The LED indicator will flash once and go off.
Alternatively if you leave the MSR+ without pressing a key for
more than 20 seconds the LED indicator will flash six times and the
MSR+ exits from learning mode, remembering any keys you have
programmed up to that point.
To learn dual signals
Some manufacturers use a sequence of two different remote
control signals to operate their equipment. To learn the commands
for these manufacturers you need to program each key twice so the
MSR+ can store each of the two signals used for the command.
•Program the key using the standard procedure described above
until the indicator flashes twice and turns off indicating that the
first code has been learnt correctly.
•Press and release the same key on the MSR+ again so the
indicator lights up again.
•Press and hold the same key on the product’s remote control
until the indicator flashes twice and turns off.
Both signals have now been learnt successfully and assigned to the
MSR+ key.
G Series MSR 9 7/7/03, 3:16:29 pm

10
Programming
•Repeat the dual-learning procedure for any other keys you want
to program.
•Press the source key again to store the settings.
Resetting the MSR+
You can reset the MSR+ to the programmed state it was in when
you first received it.
Warning: This will erase any devices or learned commands you
have programmed.
•Hold down 0and Mute simultaneously until the indicator flashes
twice and stays on.
•Enter the code 9990 on the numeric keypad.
The indicator will turn off, and all sources are reset to their default
Meridian codes.
Note: You can reset an individual source by specifying device code
8888; see
Specifying a device code , page 6
G Series MSR 10 7/7/03, 3:16:29 pm

Keycaps
11
Changing the source keycaps
Introduction
The MSR+ is supplied with 12 standard source keycaps,
corresponding to the 12 standard sources on the Meridian
preamplifiers and controllers. Some additional keycaps are supplied
with the MSR+ and you can substitute these for the standard
keycaps to suit the particular combination of products in your
system.
To change the keycaps
•Undo the four screws at the back of the MSR+ using a #1
Pozidriv screwdriver:
•Carefully lift the front cover off the MSR+. (1)
The top row of keycaps (except OFF) can then be removed. (2)
(1)
(2)
The remaining keycaps are held in position and cannot be changed.
•Replace the keycaps in the required order, taking care to orient
them correctly.
•Refit the front panel of the MSR+ by replacing the four screws.
Take care not to overtighten the screws, or you may damage the
threads.
G Series MSR 11 7/7/03, 3:16:30 pm

12
Troubleshooting Troubleshooting
The indicator flashes twice after pressing any key
The battery level is low. Replace the batteries as soon as possible
for a new set of four AA type batteries; see
Installing the batteries ,
page 2.
The LED indicator flashes six times when attempting to
program the MSR+
This indicates that the current operation you are performing was
unsuccessful. For more information read the instructions for the
appropriate programming procedure.
When I press the source key for one of my other products,
my Meridian controller selects a different source
Hold down Function while pressing the source key. This changes
the MSR+ to the correct device for your other product without
transmitting the source command to the Meridian system.
How do I control my television sound and power?
The volume Aand V, Mute, and OFF keys are dedicated to
controlling the Meridian system even when the source key is
programmed for another manufacturer’s product. To control the
television volume or power hold down Function when using the
volume or OFF keys.
I can’t change the television volume after changing the
Meridian volume
You control the volume of another product with the Function
volume keys. To send a Function key combination immediately
after the ordinary key you need to release and press the key again.
I can’t find the manufacturer of my product in the device
code list
Try auto-programming; see
Auto-programming , page 6. If this fails
try learning commands from your product’s remote control; see
Learning commands , page 8.
Commands do not work reliably with my product
Try dual-signal learning; see
To Learn dual signals , page 9.
I can’t learn successfully from my product’s remote control
If none of the programming methods succeed it may be that you
have one of a small number of products that uses non-standard
remote control signals not supported by the MSR+.
The indicator light does not light up when I press key
Try removing and refitting the batteries. If this does not work
replace the batteries with new ones; see
Installing the batteries ,
page 2.
G Series MSR 12 7/7/03, 3:16:31 pm

13
Typical commands provided for each type of product
Description TV VCR TAPE, MD, CD-R
CD, LD
SAT, CTV DVD, GAME
00/10 0/10 0/10 0/10 0/10 TOP MENU -/--, 11 VIDEO PLUS -/--, 11 PPV TOP MENU (DVD)
-/-- (GAME)
ENTER SELECT SELECT SELECT ENTER UP UU UU DOWN DD DD LEFT LL LL RIGHT RR RR RETURN EXIT EXIT BACK RETURN MENU MENU MENU MENU MENU RED RED RED RED GREEN GREEN GREEN GREEN YELLOW YELLOW YELLOW YELLOW BLUE BLUE BLUE BLUE ˘>> FF FF FF ¯<< REW REW REW PLAY PLAY PLAY PLAY PLAY STOP STOP STOP STOP STOP ]CH+ CH+ SKIP + CH+ SKIP + [CH- CH- SKIP - CH- SKIP - REPEAT LAST CHANNEL LAST CHANNEL REPEAT LAST CHANNEL REPEAT SUBTITLE TEXT ON TEXT ON SUBTITLE PAUSE PAUSE PAUSE PAUSE PAUSE
STORE STORE PROGRAM FAVOURITE CLEAR CLEAR CLEAR DISPLAY GUIDE CLOCK DISPLAY GUIDE DISPLAY
Function keys Description TV VCR TAPE, MD, CD-R
CD, LD
SAT, CTV DVD, GAME
POWER POWER POWER POWER POWER POWER #-/--, 11 INTERACTIVE -/--, 11 Fn+ENTER SP/LP Fn+RETURN RESET COUNTER RESET SETUP INDEX INDEX SETUP SETUP RECORD RECORD RECORD (TAPE/
MD/CDR)
RECORD
BAND ANTENN A/B TV/VCR ANGLE FORMAT 16 9 FORMAT 16 9 OSD INFO COUNTER INFO SLOW Fn+¯ AUDIO AUDIO FRAME FWD SOUND AUDIO OPEN EJECT EJECT EJECT Page ]PAGE+ SLOW+ DIR A (TAPE Only) PAGE+ DISC SKIP
Page [PAGE- SLOW- DIR B (TAPE Only) PAGE-
A-B INPUT INPUT INPUT A-B Fn+SUBTITLE TEXT MIX TEXT MIX TITLE Fn+DSP PHASE Fn+MUTE MUTE Fn+VOLUME AVOL+ Fn+VOLUME VVOL-
G Series MSR 13 7/7/03, 3:16:32 pm

14
Device codes
TV
Brand Name Device Code
AIWA 3881
AKAI 0061, 0101, 0231, 1051, 1211, 1421, 1461, 1601, 1701,
1781, 2821, 3541, 3551
ALBA 1101, 1191, 2141, 2921
AMSTRAD 1161, 1351, 2971, 3521
ARC EN CIEL 0541
ARCAM 0541, 0731
ARCHER 3591
ARISTONA 0721
ARTHUR MARTIN 0431, 1461
ASTRA 1351
ATANTIC 0731
ATLANTIC 0731
AUDIOSONIC 1041, 1181, 1351, 3461
AUTOVOX 0091, 0341, 0461, 0471, 0571, 0751, 0881, 0931, 0951,
1251, 1281, 3511, 3591
BAIRD 0971, 1211
BANG & OLUFSEN 0951
BLAUPUNKT 0221, 0231, 0241, 0251, 0451, 0711, 1981, 1991, 2001,
2011, 2021, 2041, 2261, 2271
BRANDT 0541, 0621, 0701, 0861, 1631
BUSH 0431, 1101, 1191, 1461, 1551, 1911, 1931, 3461
BUSH (UK) 0461, 1391, 1441
CARVER 2601
CITIZEN 0761, 2841, 2851, 3381, 3391, 3401, 3421, 3431,
3551, 3561
CONTINENTAL EDISON 0541, 0621, 0861
CRAIG 1031, 2741, 3511
CROSLEY 0021, 0471, 0911, 0951, 1261, 1781, 1981, 2031, 2051
CROWN 2231, 3401, 3511
CURTIS MATHES 2651, 2851, 3391, 3401, 3441, 3551
DACUS 3801, 3821
DAEWOO 0101, 1341, 1351, 2301, 2781, 2791, 2821, 3211, 3401,
3461, 3491, 3561, 3601, 3921, 3941, 3951, 3961
DANSAI 0101, 3461
DECCA 0271, 0551, 0571, 0891, 0971, 1501, 2761, 3461
DECCA (UK) 0271, 0551, 0571, 0971, 1491
DEGRAAF 0431, 1211
DUAL 0091, 0571, 1441, 1461, 1881
DUAL-TEC 0571, 1351, 1451, 1891
DYNATRON 0101
ELECTROHOME 3401
EMERSON 0911, 0951, 0991, 1031, 1121, 1161, 2511, 2531, 2561,
2571, 2581, 2591, 2611, 3281, 3291, 3301, 3311, 3321,
3331, 3341, 3361, 3381, 3401, 3441, 3471, 3491, 3511,
3521, 3531
ETRON 1781, 2821
FERGUSON 0281, 0361, 0521, 0621, 0751, 0831, 0851, 1001, 1041,
1221, 1301, 1771, 1791, 2061, 2091, 2121, 3461
FIDELITY 0431, 0731, 2061
FIDELITY (UK) 0531, 0561, 1741, 2061
FINLANDIA 0431, 2101
FINLUX 0021, 0261, 0471, 0491, 0751, 0781, 0841, 0951, 1271,
1281, 1781, 1841, 1871, 1901, 1931, 2241, 3461
FISHER 0021, 0091, 0141, 0481, 0571, 0771, 0791, 0901, 0911,
0951, 1781, 1871, 2661, 3271, 3441
FRONTECH 0431, 1041, 1781
FUJITSU 1121, 3531
FUNAI 0381, 0661, 1031, 1041, 1121, 3511, 3531, 3901, 3911
FUNJI 3701
FUTURETECH 1031, 3511
GE 2621, 2651, 2691, 3221, 3231, 3241, 3251, 3261, 3281,
3331, 3501
GEC 0431, 0971, 1141, 2101, 2761, 3461
GEC (UK) 0031, 0081, 0551, 0571, 0971, 1141, 1391
GEMINI 2881
GENEXXA 0431, 1191, 2921
GOLDSTAR 0561, 0571, 0731, 0761, 1231, 1331, 1351, 1391,
1451, 1461, 2841, 2901, 3331, 3401, 3431, 3461, 3491,
3551, 3581
GOODMANS 0141, 0971, 1231, 1461, 2081
GRANADA 0141, 0431, 0471, 0551, 0571, 0971, 0981, 1211, 1781,
2101, 3461
GRANADA (UK) 0081, 0141, 0431, 0471, 0551, 0571, 0921, 1171, 1361,
1391, 1461
GRUNDIG 0221, 0231, 0451, 0471, 0681, 0711, 1241, 1811, 1831,
1921, 1931, 3991, 4001, 4011, 4021, 4031, 4041, 4051,
4061, 4071, 4081, 4091
H/K 3211
HINARI 0071, 0141, 0431, 1121, 1211, 1351, 1461, 1781, 1801,
3461, 3531
HITACHI 0001, 0011, 0031, 0081, 0141, 0291, 0321, 0331, 0431,
0571, 0601, 0671, 1141, 1391, 1431, 1631, 1641, 1651,
1671, 1681, 1691, 1701, 1751, 1781, 1841, 2101, 2121,
2671, 2841, 3161, 3171, 3181, 3191, 3201, 3341, 3401,
3431, 3761
INGERSOL 1351
INTERFUNK 0031, 0041, 0061, 0121, 0181, 0431, 0471, 0951, 1461,
1601, 1631, 1781, 2011, 3461
ITT 0031, 0041, 0051, 0061, 0071, 0081, 0181, 0401, 0431,
0471, 1101, 1151, 1211, 1341, 1431, 1461, 1551, 1731,
1781, 1871, 2111, 2171, 3101
ITT-NOKIA 0031, 0041, 0051, 0061, 0071, 0081, 0181, 0401, 0431,
0471, 1101, 1151, 1211, 1341, 1431, 1461, 1551, 1731,
1781, 1871, 2111, 2171
JBL 2601
JENSEN 2801
JVC 0071, 0691, 1291, 1411, 1421, 1551, 1601, 2751, 2771,
3131, 3141, 3151, 3311, 3611, 3621, 3631
KARCHER 0561, 0571, 0811, 0961, 1181, 1351, 1391, 1841
KENWOOD 2851, 3491, 3551
G Series MSR 14 7/7/03, 3:16:34 pm

15
KONKA 2391
LOEWE 3461
LOEWE OPTA 0121, 0131, 0551, 0581, 0951
LOWEWE 0801
LUXMAN 0761, 2841, 3431
LUXMAN STEREO
TUNER
0761
LUXOR 0001, 0061, 0181, 0331, 0411, 0431, 0441, 0471, 0571,
0641, 1211, 1231, 1391, 1431, 1721, 1731, 1781
LXI 2601, 3111, 3231, 3331, 3441
MAGNADYNE 0021, 0061, 0261, 0551, 0611, 0741, 0911, 0951,
1451, 1781
MAGNAVOX 2601, 2831, 2881, 2891, 2901, 2911, 3071, 3081, 3091,
3101, 3121, 3151, 3421, 3551
MARANTZ 0101, 2601, 2711, 2851, 3461, 3551
MATSUI 0061, 0431, 0571, 0661, 0971, 1011, 1101, 1131, 1161,
1351, 1391, 1491, 1501, 2761, 2821, 3461
MCMICHAEL 1141
MEDION 2281, 2291, 2301, 2311, 2331, 2341, 2351, 2361, 2371,
2381, 2401, 2411, 2451, 2461, 2471
MEGATRON 3181, 3331, 3591
MEI 3471
MEMOREX 1351, 2821, 3061, 3331, 3431, 3441, 3451, 3981
MGA 1091, 2851, 3051, 3061, 3331, 3491, 3551
MISTRAL 2061
MITSUBISHI 0141, 0201, 0231, 0631, 1051, 1061, 1091, 1481,
1501, 1551, 2711, 2811, 3051, 3061, 3151, 3331, 3491,
3541, 3791
MONTGOMERY 3531
MOTOROLA 3501, 3571
MULTITECH 0261, 0551, 0571, 0611, 0901, 1181, 1351, 3511
NAD 1201, 3041, 3111, 3331
NEC 0141, 1521, 1531, 1541, 2731, 2841, 2851, 3151, 3431,
3491, 3551, 3731, 3971
NOKIA 0031, 0041, 0051, 0061, 0071, 0081, 0181, 0401, 0431,
0471, 1101, 1151, 1211, 1341, 1431, 1461, 1551, 1731,
1781, 1871, 2111, 2171, 2191, 2481
NORDMENDE 0031, 0291, 0321, 0431, 0501, 0511, 0541, 0931, 1001,
1421, 1601, 1621, 1631, 1701, 1751, 2321
OPTIMUS 3041
OPTONICA 3031, 3571
ORION 0061, 0381, 0661, 0821, 1071, 1101, 1111, 1161, 1321,
1351, 1491, 1501, 1781, 2151, 2161, 3301, 3461
PANASONIC 0031, 0201, 0211, 0431, 0671, 1171, 1561, 1761, 2251,
2431, 2601, 2681, 2741, 3221, 3501, 3721, 3781, 3831
PANORAMIC 2131
PATHE MARCONI 0541
PATHE’ CINEMA (F) 0421, 0561, 1451, 1471, 1771
PHILCO 0021, 0471, 0781, 0901, 0911, 0951, 1261, 1441, 1451,
1561, 1981, 2031, 2051, 2851, 3071, 3081, 3091, 3101,
3121, 3421, 3491, 3551
PHILIPS 0101, 0351, 0561, 0591, 0651, 0721, 0731, 0911, 0951,
1141, 1821, 2061, 2071, 2171, 2181, 2201, 2421, 2601,
2891, 3461
PIONEER 0291, 0431, 1201, 1631, 3001, 3041, 3341, 3741
PRIMA 0431
PROSCAN 3231
PROTECH 0611, 1041, 1781, 3461
PROTON 2991, 3331, 3401, 3481, 3591
QUASAR 2741, 3221, 3501
RADIO SHACK 3031, 3401, 3491, 3511, 3581
RANK 0461, 1931
RCA 2551, 2631, 2641, 2671, 2901, 2981, 3021, 3231, 3241,
3341, 3491
REALISTIC 3031, 3331, 3401, 3431, 3441, 3491, 3511, 3551, 3581
REDIFFUSION 0431, 0631, 1461, 1781, 2111
REDIFFUSION (UK) 0061, 0081, 0921
ROTEL 0151
RUNCO 3351, 3551
SABA 0291, 0321, 0411, 0431, 0501, 0511, 0541, 0551, 0621,
0701, 0871, 0911, 0941, 0951, 1001, 1601, 1621, 1631,
1701, 1751, 2321
SAISHO 0431, 0571, 1021, 1101, 1161, 1351, 1481, 1491, 1501,
2821, 3521
SAMPO 2851, 3401, 3481, 3551, 3581
SAMSUNG 0101, 0571, 0811, 0901, 0971, 1041, 1231, 1351, 1801,
2821, 2831, 2841, 2851, 3331, 3391, 3401, 3431, 3461,
3491, 3551, 3581, 3861
SANYO 0141, 0151, 0391, 0571, 0771, 0791, 0901, 0911, 0971,
0981, 1151, 1211, 1501, 1551, 1841, 1871, 2241, 2661,
2721, 2761, 3151, 3271, 3371, 3441, 3641, 3661, 3671
SCOTT 1031, 1121, 3301, 3331, 3401, 3491, 3511, 3531
SEARS 2601, 2651, 2661, 2841, 2971, 3011, 3111, 3231, 3271,
3331, 3431, 3441, 3531
SELECO 0071, 0101, 0341, 0401, 0431, 0881, 1711, 1851,
1881, 1891
SHARP 0141, 0151, 0191, 1571, 1591, 2951, 2961, 3031, 3151,
3371, 3401, 3571, 3651, 3681
SIEMENS 0151, 0221, 0231, 0431, 0711, 1801, 1981, 1991, 2001,
2011, 2021, 2041, 2261, 2271
SINGER 0021, 0261, 0911, 0951
SONY 0141, 0171, 0991, 1491, 1501, 2441, 2861, 2941, 3151,
3311, 3411, 3691, 3841
SOUNDESIGN 1031, 3331, 3421, 3511, 3531
SYMPHONIC 2971
SYLVANIA 2601, 2851, 2931, 3071, 3081, 3091, 3101, 3121,
3421, 3551
TANDBERG 0161, 0321, 0581, 0911, 1281, 1581, 1601, 1861
TANDY 0191, 0431, 1191, 1371, 2761, 2921, 3571
TATUNG 0271, 0551, 0571, 0891, 0971, 1491, 1501, 2761, 3461,
3501, 3591
TECHNICS 1171, 3221
TEKNIKA 1031, 1091, 1121, 2601, 2841, 3061, 3391, 3401, 3421,
3431, 3451, 3491, 3511, 3531, 3561, 3981
TELEAVIA 0541, 0621, 0701, 1631
G Series MSR 15 7/7/03, 3:16:35 pm

16
TELEFUNKEN 0291, 0301, 0311, 0521, 0701, 1001, 1311, 1421, 1601,
1611, 1621, 1631, 1791, 1941, 1951, 1961, 1971, 1981,
2031, 2051, 2211, 2321
TELETECH 1351, 2821
THOMSON 0321, 0461, 0501, 0541, 0601, 0621, 0701, 0861, 1101,
1401, 1421, 1601, 1621, 1631, 1701, 1751, 2221
THORN 0711, 0831, 1871, 2031, 2051, 2061
THORN-FERGUSON 0281, 0361, 0521, 0621, 0751, 0831, 0851, 1001, 1041,
1221, 1301, 1771, 1791, 2061
TOSHIBA 0141, 0371, 0461, 1081, 1131, 1511, 1551, 1661, 1931,
2491, 2501, 2871, 3011, 3111, 3151, 3391, 3441, 3711
TRISTAR 2061
ULTRAVOX 0021, 0261, 0561, 0911, 0951, 1781
VICTOR 1291, 1421, 3141
VIDTECH 3331, 3491
VIDIKRON 2601, 2701
VORTEC 0101, 0621
WARDS 2601, 2851, 2941, 3031, 3071, 3081, 3091, 3101, 3241,
3251, 3261, 3331, 3431, 3451, 3491, 3531, 3551, 3981
WEGA 0141, 0951, 1781
WEGA COLOR 0911
WHITE
WESTINGHOUSE
0101, 0261, 0421, 0561, 0731, 1261, 1381
YAMAHA 2851, 3491, 3551
ZANUSSI 0071, 0101, 0341, 0401, 0431, 0881, 1711, 1851,
1881, 1891
ZENITH 2521, 2541, 3351, 3451, 3981
VCR
Brand Name Device Code
A TANDY 2022
AIWA 0042, 0352, 0432, 1152, 2112
AKAI 0042, 0422, 0492, 0582, 0612, 0642, 0652, 0762, 0912,
1412, 2062, 2072, 2082, 2092
ALBA 0002, 0112, 0282, 0332, 0342, 0972
AMSTRAD 0322, 0432, 0452, 2112
AUDIOSONIC 0002
AUDIOVOX 2032
BAIRD 0042, 0282, 0492
BANG & OLUFSEN 0042
BLAUPUNKT 0062, 0092, 0252, 0462, 0672, 0992, 1532
BUSH 0002, 0282, 0332, 0342, 0512, 0972, 1972
BUSH (UK) 0812
CAPEHART 0112
CANON 1982, 2052
CROWN 0112, 0282, 0622
CURTIS MATHES 1782, 1942, 2052
DAEWOO 0112, 0282, 0622, 1922, 1932, 2102
DANSAI 0012
DECCA 0042, 0052, 0432, 0942
DECCA (UK) 0052
DEGRAAF 0052, 0132, 0432, 0532, 0602
DUAL 0042, 0632
EMERSON 0012, 0162, 0202, 0432, 0512, 0522, 1232, 1292, 1302,
1312, 1322, 1332, 1342, 1352, 1372, 1822, 1832, 1842,
1852, 1862, 1872, 1882, 1892, 1902, 1992, 2002, 2012,
2032, 2072, 2112, 2192
FERGUSON 0042, 0712, 0722, 0852, 0902, 1002, 1012, 1032
FIDELITY 0432
FINLANDIA 0052, 0532
FINLUX 0012, 0042, 0052, 0082, 0262, 0382, 0432, 0462, 0492,
0532, 0572, 0602, 0912, 1162, 2112
FISHER 0162, 0482, 0532, 0542, 0572, 0592, 1802, 1812,
1962, 2022
FRONTECH 0112
FUNAI 0432, 2112
GBC 0002
GE 1782, 1942, 2052
GEC (UK) 0022, 0052
GO VIDEO 1762, 1772
GOLDSTAR 0012, 0122, 0812, 0952, 1242, 1752, 2032
GOODMANS 0002, 0072, 0282, 0432, 0502
GOODMANS (UK) 0002
GRANADA 0052, 0132, 0532, 0572, 1162
GRANADA (UK) 0052, 0092, 0462, 0602, 0812, 0822
GRUNDIG 0052, 0062, 0092, 0232, 0252, 0262, 0752, 0802
HARMAN/KARDON 0122, 0922, 1752, 2202
HINARI 0002, 0202, 0412, 0442, 0522, 1972
HITACHI 0042, 0172, 0292, 0432, 0602, 0662, 0812, 1012, 1262,
1682, 1692, 1702, 1712, 1722, 2112
INGERSOL 0442
INTERFUNK 0022, 0052
ITT 0022, 0032, 0042, 0072, 0292, 0492, 0532, 0572,
0762, 2062
ITT-NOKIA 0022, 0032, 0042, 0072, 0292, 0492, 0532, 0572, 0762
JENSEN 0042
JVC 0042, 0102, 0142, 0272, 0742, 0762, 0782, 0902, 1362,
1642, 1652, 1662, 1672
KARCHER 0052, 0072, 0812
KENDO 0492
KENWOOD 0042, 0142, 0572, 1362, 1662, 1732, 1752, 2022
KLH 1972
LOEWE OPTA 0052, 0092, 0152
LUXOR 0492, 0572, 0812, 2062
LXI 1182, 2032
MAGNADYNE 0052
MAGNAVOX 1162, 1602, 1612, 1622, 1632, 2052
MARANTZ 0012, 0052, 0092, 0122, 0502, 1162, 1362, 1752, 2052
MATSUI 0012, 0442, 0512, 0522, 0812, 0972, 1842
MATSUSHITA 2052
MEDION 1082, 1102, 1112
MEI 1382, 2052
G Series MSR 16 7/7/03, 3:16:36 pm

17
MEMOREX 0012, 0132, 0432, 0482, 0532, 0572, 1392, 1402, 1592,
1632, 1732, 1962, 2022, 2032, 2042, 2052, 2112
METZ 0062, 0092, 0932
MGA 0912, 1882, 2072
MGA TECHNOLOGY 2042
MINOLTA 0172, 0602, 1712, 1722
MITSUBISHI 0052, 0062, 0142, 0912, 0922, 1572, 1582, 1662, 1882,
2072, 2202
MOTOROLA 1592, 2052
NATIONAL 0462
NEC 0042, 0122, 0142, 1282, 1362, 1432, 1542, 1552,
1662, 1752
NOKIA 0022, 0032, 0042, 0072, 0292, 0492, 0532, 0572,
0762, 1092
NORDMENDE 0042, 0102, 0142, 0192, 0222, 0242, 0392, 0402, 0632,
0732, 0742, 0762, 0782, 0792, 0832, 0842, 0872
OLYMPUS 0462, 1532, 2052
OPTIMUS 1562, 1592, 2032
OPTONICA 0132, 0502
ORION 0162, 0202, 0312, 0442, 0512, 0522, 0982, 1372, 1842,
1862, 1892
PANASONIC 0022, 0212, 0462, 0672, 0992, 1042, 1052, 1122, 1172,
1212, 1252, 1382, 1502, 1512, 1522, 1532, 2052
PHILCO 1162, 2052
PHILIPS 0052, 0082, 0092, 0152, 0182, 0362, 0372, 0382, 0472,
0502, 1022, 1162, 1422, 1612, 2052
PIONEER 0052, 0142, 0372, 0472, 1562, 1662
PROSCAN 2122, 2132, 2142, 2152, 2162, 2172, 2182
PYE 0052, 0152
QUASAR 1512, 1522, 2052
RADIO SHACK 2032, 2112
RCA 1272, 1512, 1522, 1602, 1712, 1722, 1782, 1942, 2062
REALISTIC 0012, 0072, 0132, 0432, 0482, 0502, 0532, 0572, 1592,
1732, 1802, 1962, 2022, 2032, 2042, 2052, 2112
RICOH 0952, 1482, 1492
SABA 0042, 0142, 0192, 0222, 0242, 0392, 0632, 0732, 0742,
0762, 0772, 0782, 0792, 0872
SAISHO 0162, 0202, 0292, 0442, 0512, 0522, 0972, 1372, 1702,
1842, 1852, 1862, 1892
SAMSUNG 0052, 0072, 0622, 0652, 1132, 1372, 1452, 2042, 2082
SANSUI 0042, 0142, 1432, 1662, 1952
SANYO 0482, 0532, 0562, 0572, 1402, 1732, 1962, 2022, 2042
SEARS 1442, 1712, 1722, 1732, 1802, 1812, 1962, 2022,
2032, 2052
SELECO 0042
SHARP 0132, 0502, 0702, 1592
SIEMENS 0062, 0092, 0252, 0572
SONY 0432, 0552, 0682, 0692, 0942, 0952, 0962, 1062, 1072,
1192, 1462, 1482, 1492, 1792, 1912, 2052
SYLVANIA 0432, 0912, 1162, 1612, 1622, 1882, 2052, 2112
SYMPHONIC 0432, 0912, 2112
TANDBERG 0062, 0162, 0522, 0932
TANDY 2112
TATUNG 0042, 0052, 0432, 0922
TEAC 0042, 0432, 2112
TECHNICS 0462, 2052
TEKNIKA 0012, 0432, 2032, 2052, 2112
TELEFUNKEN 0042, 0192, 0632, 0732, 0742, 0762, 0782, 0882, 0892
THOMSON 0042, 0102, 0142, 0192, 0402, 0632, 0762
THORN 0042, 0902
THORN-FERGUSON 0042, 0222, 0302, 0712, 0722, 0742, 0762, 0852, 0862,
0872, 0902
TOSHIBA 0042, 0622, 0912, 1222, 1442, 1472, 1742, 1802,
1832, 1882
TRIUMPH 0922
ULTRAVOX 0032
VECTOR RESEARCH 0122, 1362, 1552, 1752
VICTOR 0042, 0102, 0142, 1662, 1672
WHITE
WESTINGHOUSE
0032
YAMAHA 0042, 1142, 1362, 1752
ZENITH 1202, 1492, 1632, 1792
CD
Brand Name Device Code
ACCUPHASE 0295
ACOUSTIC RESEARCH 2855
ADC 0825, 1875, 1915
ADCOM 0745, 0975, 2015, 2065, 2665
AIWA 1065, 1185, 1195, 1645, 1765, 1785, 2095, 2605,
2685, 2705
AKAI 0115, 0125, 0685, 0695, 0705, 0895, 1115, 2005
ARCAM 1725
ARCAM-ROTEL 0155
AUDIO-TECHNICA 0795, 2285
CALIFORNIA AUDIO
LAB
1035, 1905
CARVER 0785, 1365, 2085, 2785
CYRUS-ROTEL 0195
DENON 0045, 0915, 1005, 1515, 1665, 1675, 2075, 2535, 2545
DUAL 0965
EMERSON 0975, 1235, 1565, 2015, 2125, 2755
FISHER 0105, 0555, 0565, 0785, 1125, 1135, 1935, 2295,
2585, 2655
GENEXXA 0485, 0785, 0815, 0835, 0955, 1215, 1235, 1295, 1305,
1435, 1495, 1565, 1605, 1695, 2105, 2125, 2755
GOLDSTAR 0515, 1145, 1155, 1505, 2785
GRUNDIG 0165
HARMAN KARDON 0305, 0475, 0525, 1095, 1105, 1115, 1945, 2005,
2235, 2645
HITACHI 0065, 0545, 0645, 0905, 0965, 0975, 1175, 1465,
2015, 2255
ITT-NOKIA 0175
JVC 0365, 0375, 0435, 0535, 0545, 2115
G Series MSR 17 7/7/03, 3:16:37 pm

18
KARCHER 0465
KENWOOD 0025, 0055, 0145, 0205, 0555, 0635, 0655, 0665, 0675,
0885, 1305, 1435, 1495, 1565, 1605, 1695, 1895, 1935,
2185, 2315, 2405, 2415, 2425, 2435, 2555
LINN 0155, 1725
LUXMAN 0245, 0255, 0755, 0765, 1245, 1255, 1475, 1775
LUXOR 0175, 1745, 1755
MAGNAVOX 1715, 1725, 1995, 2025, 2365, 2615
MARANTZ 0155, 0165, 0505, 0625, 1225, 1285, 1355, 1445, 1725,
1805, 2025, 2045, 2165, 2455, 2865
MATSUSHITA 1055, 1525
MCINTOSH 2155, 2735
MEDION 0075, 1825, 1835, 1845
MEMOREX 0485, 0975, 1215, 1225, 1235, 1565, 2015, 2035, 2045,
2105, 2125, 2755
MICROMAXX 1845
MISSION 0155, 1725, 2025
MITSUBISHI 1085, 1165, 1965, 2215
NAD 0135, 0235, 0265, 0275, 0285, 0325, 0715, 0725, 1265,
1275, 1885, 2335, 2385, 2395
NAKAMICHI 0595, 0605, 1485, 1955, 2205, 2265
NEC 0385, 0495, 0735, 0745, 2065, 2565, 2625
ONKYO 0845, 1335, 1375, 1405, 1455, 1985, 2225, 2245,
2475, 2795
OPTIMUS 2035, 2055, 2295, 2325, 2505, 2515, 2525, 2555, 2595
PANASONIC 1015, 1035, 1535, 1545, 1905, 2485, 2745, 2775
PENNY 2565
PHILIPS 0155, 0165, 0185, 1715, 1725, 1995, 2025
PIONEER 0095, 0315, 0405, 0415, 0425, 0485, 0815, 0995, 1795,
2105, 2595, 2695
PROTON 0865, 1725, 2025, 2825
QUASAR 1035, 1905
RCA 2015, 2575, 2765
REALISTIC 0785, 0975, 1215, 1225, 1235, 1495, 2015, 2035, 2045,
2125, 2295, 2505
REVOX 2815
ROTEL 1725, 2025
SABA 0965
SAMSUNG 2845
SANSUI 0395, 0925, 0935, 0945, 1205, 1565, 1725, 2025, 2345,
2635, 2675, 2755
SANYO 0585, 0785, 0805, 0875, 1975, 2295, 2355, 2445
SCOTT 1235, 1565, 2125, 2755
SEARS 2145
SHARP 0025, 0035, 0985, 1075, 1225, 1555, 1655, 1685, 1695,
1705, 2045, 2375, 2555, 2715, 2725
SHERWOOD 1225, 1395, 2045
SIEMENS 1045
SONY 0325, 0335, 0345, 0355, 0825, 1575, 1585, 1595, 1605,
1615, 1625, 1635, 1915, 2525
SYLVANIA 1725, 2025
SYMPHONIC 2135
TANDBERG 1735
TANDY 2105
TCM 1815, 1845
TEAC 0215, 0225, 1225, 1315, 1325, 1345, 1385, 1415, 1425,
2045, 2135, 2175, 2275, 2465, 2495, 2875
TECHNICS 0445, 0455, 1025, 1035, 1545, 1905, 2745
TELEFUNKEN 0965
THETA DIGITAL 1715
THOMSON 0965
THOMSON (E) 2255
TOSHIBA 0715, 0725, 1885, 2385
VECTOR RESEARCH 0515, 0825, 1915, 2785
VICTOR 0535, 2115
YAMAHA 0005, 0015, 0085, 0325, 0575, 0615, 0775, 0795, 0855,
1685, 1855, 1865, 1925, 2195, 2285, 2305, 2715
Cable
Brand Name Device Code
ARCHER 0966, 1046
CABLEVISION 0986
FRANCE TELECOM 0746
GE 0946, 0956
GEC 0776
GEC CABLE SYSTEM 0986
JERROLD 0766
JERROLD 400L 1366
JERROLD 450L 1356
JERROLD 550 1346
JERROLD OSD CATV 1336
JERROLD SPRUCER 1176
MAGNAVOX/PHILIPS 1156, 1166
MEMOREX 1126
NSC 0796
OAK 0936
OAK SIGMA 450 1286
OAK SIGMA 550 1276
PANASONIC TZ
120/130
1216
PANASONIC TZ
170/180
1186
PANASONIC TZ140 1206
PANASONIC TZ150/
160
1196
PARAGON 1126
PHILIPS 0746, 0896, 1006, 1056, 1066, 1076, 1086, 1096
PIONEER 0006, 0886, 0916
PIONEER BR50 1486
PIONEER BR60/70/
80/81/82
1386
PIONEER BR90 1296
G Series MSR 18 7/7/03, 3:16:38 pm
