1Introduction
1.1 Summarization
This IP-CAMERA (short for IP-CAM) is designed for high performance CCTV
solutions. It adopts state of the art video processing chips. It utilizes most advanced
technologies, such as video encoding and decoding technology, complies with the
TCP/IP protocol, SoC, etc to ensure this system more stable and reliable. This unit
consists of two parts: the IP-CAM device and central management software (short for
CMS). The CMS centralizes all devices together via internet or LAN and establishes a
sound surveillance system to realize unified management and remote operation to all
devices in one network.
This product is widely used in banks, telecommunication systems, electricity power
departments, law systems, factories, storehouses, uptowns, etc. In addition, it is also an
ideal choice for surveillance sites with middle or high risks.
1.2 Check Package Content
The pictures below are only for reference. Please make the object as the standard.
Accessories
Description
IP-CAMERA
The device without Lens
Quick Start Guide
The Brief instructions of the product
CD
CD-ROM with software and manual
Screws and Screwdriver
For installation
1.3 Connection
MIC: connect to MIC
DC12V: connect to power supply
LAN: network port (some models support PoE power supply)
Some models of this series support internal focusing. The steps are as follows:
www.merivasecurity.com
Page 2
IP CAMERA USER MUANUAL
Focus Zoom
Step 1: Remove the sun shade and lens case from the device as shown above.
Step 2: Loosen the screws of the lens for focusing. Then rotate the lens left or right to
adjust the focus.
Focus: Rotate left or right to adjust definition of the image.
Zoom: Rotate left or right to zoom in or out the image.
www.merivasecurity.com
Page 3
IP CAMERA USER MUANUAL
2Installation
2.1 Install IP-CAM to Ethernet Network
The connection of digital video server is show below.
Figure 2-1 Connection
Please connect the PC and IP-CAMERA in accordance with the above picture.
The connection steps are shown as below:
Step 1: Connect the monitor, microphone and network to the device.
Step 2: Connect the power supply.
Step 3: Install the device.
2.2 Install CMS
After the CDD IP-CAM connected to the Ethernet, user can remote monitoring and
managing the device by using client software or IE browser. This chapter is the client
software, which is the quick install guide of the CMS, the operation and monitor setting
details please refers to CMS user manual in CD.
Note: Before to install control center software in user’s computer, please make sure
all anti-virus software in the computer closed so that CMS can install correctly.
System requirement
Supported Operating System:
Operating system
Comments
Windows XP
Windows XP SP2 or most updated patch; Direct 9.0c or above
Windows Vista
Windows Vista; Direct 10. c
Window 7
Window 7 Ultimate
Windows 2003
Windows 2003 serve or Directx 9.0c or above
Windows 2000
Windows 2000 SP4 or Directx 9.0c or above
Computer hardware requirement
Please make sure the software running well and the computer is compatible ：
Recommended PC Specification –4 channels
www.merivasecurity.com
Page 4
IP CAMERA USER MUANUAL
Item
Specification
CPU
Intel Pentium 3.0 GHz orAMD 3000+
Memory
1GB
HDD
160GB
Recommended PC Specification -9 channels:
Item
Specification
CPU
Intel Core 2 Duo 1.8 GHz or AMD Dual core 3800+
Memory
1GB
HDD
250GB
Recommended PC Specification -16 channels:
Item
Specification
CPU
Intel Core 2 Duo 2.2 GHz or AMD Dual core 3800+
Memory
2GB
HDD
250GB
Notice:
The AMD chip hyper-3800+ and X64 series are not tested.
For real-time view at CIF, max 25 channels can be played concurrently.
For real-time view at D1, max 6 channels can be played concurrently.
Installation Process
It is recommended to disable the anti-virus software before the installation of CMS.
1. Run the „Setup.exe‟ from software CD. Then install CMS according to the prompts.
2. After you install this software, double click it to run if necessary.
3. Find the user manual of the control center system from programs. You can operate
this software according to the introduction of this user manual.
If you just want to user IP-tool, there is no necessary to install CMS software. You can
open the CD and find the IP-tool software and double click it to install.
www.merivasecurity.com
Page 5
IP CAMERA USER MUANUAL
3IE Remote Access
IP-Cam can be connected through LAN or WAN. Here only take IE browser (6.0)
for example. The details are as follows:
3.1 LAN
In LAN, there are two ways to access IP-Cam: 1. Access through IP-Tool; 2. Directly
access through IE browser.
3.1.1 Access through IP-Tool
Step 1: Make sure the PC and IP-Cam are connected to the LAN and the IP-Tool is
installed in the PC from the CD.
Step 2: Use IP-Tool to modify the network of IP-Cam. Then, double click the icon
on the desktop to run this software as shown below:
After starting IP-Tool, clicking the IP-Cam name in the list can display the detail
information of IP-Cam. If you cannot confirm which one is yours, please shut off the
electricity of the IP-Cam and then power on it. When shutting off the power, the device
information will disappear. When powering on, the device information will emerge. Well,
this device is the used device. Right click the device information and select “network
setup”. Then the network setup window will pop up as shown below:
www.merivasecurity.com
Page 6
IP CAMERA USER MUANUAL
For example, the network segment of this computer is 192.168.13.x under the local
config table. So, please modify the IP address, Gateway of IP-Cam which must be in the
same network segment with the computer. Modifying the network, you have to input the
password and click “OK” button to save the setting.
Note: The default user name is: admin. The default password is: 123456.
The new IP address of this device will display as follows after modification.
Step 3: Use the IP-Tool to login the IP-Cam.
Right-click the IP address and select “browse with IE” or double click the information
of this device. The IE browser will auto download the Active X control. If the IE
browser cannot download the Active X control, please refer to Q4 of Chapter 9. After
the completion of the installation of the Active X control, a login window will pop up.
Input User name and password and then click “OK” button to login.
Note: You can also use the modified IP address of the IP-Cam. Input the IP address in
the IE browser bar and then click “Enter” to access IP-Cam. The default user name is
admin. The default password is 123456.
www.merivasecurity.com
Page 7
IP CAMERA USER MUANUAL
3.1.2 DirectlyAccess through IE
The default network settings are as shown below:
IP address: 192.168.226.201
Subnet Mask: 255.255.255.0
Gateway: 192.168.226.1
HTTP: 80
Data port: 9008
The first time you used the IP-CAM, you should connect the device with the above
default settings. Here take the Windows XP OS for example to introduce the setting
steps.
Step 1: Manual setup the IP address of the PC, the network segment should be as same
as the default settings of IP-CAM. Right click “My Network Places” icon on the
desktopselect “properties” as shown in the left figure. Right click “Local Area
Connection” at the popup window and then select “property” as shown in the right
figure.
Select “Internet Protocol (TCP/IP)” in the “General” tabs, click “properties” in the next
window and then manual input network address information of the PC in the following
popup window.
Step 2: Open the IE Browser, input the default address of IP-CAM and confirm. This
will take you to the Active X control downloading interface. If IE browser can‟t
www.merivasecurity.com
Page 8
IP CAMERA USER MUANUAL
download Active X control, please refer to Q4 of chapter 9.
Step 3: After downloading Active X control, the login dialog box will pop up.
Step 4: Input user name and password in the login dialog box and click “OK” button to
enter into the live interface. You can manage and setup the IP-CAM in the IE client,
such as changing IP address, upgrading the software., etc.
3.2 WAN
Access through router or virtual server
Step1: Make sure the device is well connected in LAN. Then enter into System
ConfigurationNetwork configurationBasic configuration to setup the port number
as shown in Fig 3-1:
Step 2: Enter into System ConfigurationNetwork configurationIP configuration
interface to change IP address as shown in Fig 3-2:
Notice: The steps above should be saved after the change of the port and IP address.
Fig 3-1 Port setup Fig 3-2 IP setup
Step 3: Enter into the router‟s management interface through IE browser and forward
the IP address and port of IP-CAM in the “virtual server”. The name depends on the
router. Please refer to Fig 3-3:
Fig 3-3 Router setup
Step 4: Open the IE browser and input its WAN IP and http port to access. The
following steps are as same as “Step 2, 3 and 4” of Chapter 3.1.2 in LAN.
www.merivasecurity.com
Page 9
IP CAMERA USER MUANUAL
4Remote Preview
4.1 The Remote Preview Interface
Fig 4-1 Remote Preview
When motion detection alarm is triggered, the people icon turns red.
Click icon to zoom in the preview image to suitable size. Drag the cursor on
the enlarged image to view suitable preview area. Click icon to zoom out the
enlarged image. Click icon to full-screen the live image.
Clicking icon will appear a save path window and the record file can save on
your PC.
Note: On Window 7 and Window Vista, user can not record or snap pictures until UAC
function is disabled. Please refer to following steps: Start—Control panel—User
accounts—Change user account control settings in which user needs to drag the scale to
Always notify end and then click “OK” button to save.
4.2 Record Playback
Click icon and refer to Fig 4-2:
1
People icon
2
Fix size
3
Zoom in
4
Zoom in
5
Zoom out
6
Full screen
7
Start record
8
Playback
9
Snap
10
Enable audio
www.merivasecurity.com
Page 10
IP CAMERA USER MUANUAL
Fig 4-2 record playback interface
After selecting the record date, the record files will be displayed in the record file list
box. User can double click a
certain record file to playback or check a certain file. Then click Play button to do
playback.
4.3 Right-click Function
Clicking right mouse will appear a pull-down list as below:
Stream: There are two options.
Turn off the live: Click this item will close present live
preview.
Enable audio: Enable remote audio transmission. Users can
hear the audio from the IP-CAM.
Full screen: The live preview picture will full-screen display.
Double click or click right mouse to return to the previous
interface. Fig 4-3 Right key sub-menu
Online user: Display user‟s list connect to the device.
System information: Display the device information: device name, firmware version,
software build date, kernel version and hardware version.
4.4 Snap Pictures
1. Select the picture number, and then click “Snap” icon as shown in the Fig
4-4:
2. User can snap multiple pictures. Select the picture number from Frame pull down
list box, such as 3, and check “Title” and “Time” to show capture title and time on the
snap pictures simultaneously. Refer to Fig 4-5:
3. Click “Browse” to set saving path; Click “Save” to save pictures to HDD on the
computer; Click “Printer setup” to set the printer and print the snap pictures; drag the
www.merivasecurity.com
Page 11
IP CAMERA USER MUANUAL
scroll bar to view all snapped pictures.
Fig 4-4 Single Snap
Fig 4-5 Multi-picture Snap
www.merivasecurity.com
Page 12
IP CAMERA USER MUANUAL
5Remote Live Surveillance
Functions of remote configurations include: System Configuration, Video Configuration,
Alarm Configuration, Network Configuration and Advanced Configuration. User should
firstly select the menu on the left, and then setup the relative parameters. When a user
setup parameters of a certain device, other users can not setup this device.
5.1 System Configuration
The “System configuration” includes two submenus: Basic Information and Date &
Time.
5.1.1 Basic Information
In the “Basic Information interface, user can setup the device name and also can check
the relative information of the server
Setting steps:
1. Clicking the "Config" icon will appear the menu list.
2. Clicking the “Basic Information "will pop up a window as shown in Fig 5-1:
3. Input the name of the device in the "Device name" text box.
4. Press the "Save" button to save the settings.
Fig 5-1 Basic Information Config
Please refer to the following table for parameters and instructions of server basic
configuration.
Parameter
Meaning
Software version
The software of the device
Software build date
The software build date of the device
Kernel version
The kernel version of the device
Hardware version
The hardware version of the device
Mac Address
MAC address of device
Maximum number of user
Support max 4 users to access
Device name
Name of the device.
www.merivasecurity.com
Page 13
IP CAMERA USER MUANUAL
5.1.2 Date & Time Configuration
Setting steps:
1. Enter into "System Configuration" “Date & Time”. Refer to Fig 5-2:
2. Select “Modify Time " to self-define time. Choose "Time Zone" according to user‟s
location.
3. Set DST as required.
4. User can setup time by select the “Synchronize with NTP Server”.
5. Press the "Save" button to save the settings.
Fig 5-2 Date &Time Config
5.2 Video Configuration
Camera Configuration includes four submenus: Camera Configuration, Video Stream,
Time Stamp and Video Mask.
5.2.1 Camera Configuration
Setting steps:
1. Enter into "Video Configuration ""Camera" interface as shown in Fig 5-3:
Fig 5-3 Basic Configuration
www.merivasecurity.com
Page 14
IP CAMERA USER MUANUAL
2. User can adjust Brightness, Contrast, Hue and saturation of the picture.
3. Select white balance mode.
4. Sharpen, denoise , white balance, frequency, CVBS format and Day-Night mode are
adjustable.
5. User also can enable the image mirror and image overturn function.
6. Press the "Save" button to save the settings.
5.2.2 Video Stream
1. Enter into "Video configuration""Video Stream" to see a interface as shown in
Fig 5-4:
Fig 5-4 Video Stream
2. Select the resolution of the single frame image at the "Resolution" pull down list.
3. Select the quantity of video per second at the "Frame rate" pull down list.
4. Select the data stream type at the "Bit rate type" pull down list.
5. Set the video quality at the "Video quality" pull down list.
6. Select alarm picture size.
7. Press the "Save" button to save the settings.
5.2.3 Time Stamp
Enter into "Video configuration""Time Stamp" to display the interface as shown in
Fig 5-5:
Fig 5-5 Time Stamp
1. Select Date Format to show in the live image.
2. Set time stamp. If time stamp is enabled, the live pictures with the time stamp will
display. There are four positions of time stamp can be set. Top left, top right, bottom
left and bottom right.
3. Press the "Save" button to save the settings.
www.merivasecurity.com
Page 15
IP CAMERA USER MUANUAL
5.2.4 Video Mask
You can set 4 mask area at most.
Fig 5-6 Video Mask
Enable the mask, select color and transparent of the mask area and then drag the mouse
to set the mask area. This will take you see a gridding area. After that, click “Save”
button to save the settings. Then you will see a mask area on the live image.
5.3 Alarm Configuration
Alarm configuration includes three submenus: Motion Detection Area, Motion
Detection Trigger and Motion Detection Schedule.
5.3.1 Motion DetectionArea
1. Enter into “Alarm configuration""Motion Detection Area" to see a interface shown
as Fig 5-7:
2. Move the "Sensitivity" scroll bar to setup the motion trace sensitivity.
3. Check "Add”, press the "Ctrl" button and move mouse to select the motion detection
area; Select “Erase” and move the mouse to clear all motion detection area.
4. Press the "Save" button to save the settings.
www.merivasecurity.com
Page 16
IP CAMERA USER MUANUAL
Fig 5-7 Motion Detection Area
5.3.2 Motion Detection Trigger
1. Enter into “Alarm Configuration""Motion Detection Trigger" to display a
interface as shown in Fig 5-8:
2. Check "Enable alarm" check box. Then all functions under this interface will be
activated.
4. Trigger Email: Check “Attach picture” and select email addresses in the “Receival
email address” text box(Email address shall be set first in the Mail config
interface).Then the triggered snap pictures will be sent into those address. User also can
define the subject and content of the email.
5. Trigger FTP: Check “Uploading picture”. Then the triggered snap pictures will be
sent into FTP server address.
Note: Please refer to FTP configuration chapter for more details.
6. Press the "Save" button to save the settings.
Fig 5-8 Motion Alarm Trigger
www.merivasecurity.com
Table of contents
