Ezviz H6 User manual

1
Overview
1� Package Contents
Camera (x1) Power Adapter (x1)
Power Cable (x1) Drill Template (x1) Mounting Plate (x1)
Screw Kit (x1) Regulatory Information (x2) Quick Start Guide (x1)
The power adapter's appearance is subject to the actual one you have bought.
2� Basics
Front View
MIC
LED Indicator
Lens
Name Description
LED Indicator Solid Red: Camera starting up.
Slow-flashing Red: Network exception.
Fast-flashing Red: Camera exception (e.g. Micro SD card
error).
Solid Blue: Video being viewed in the EZVIZ app.
Slow-flashing Blue: Camera running properly.
Fast-flashing Blue: Camera ready for Wi-Fi connection.

2
Slide up the sphere
Micro SD Card Slot
Reset Button
Name Description
Micro SD Card
(sold separately)
Initialize the card in the EZVIZ app before using it.
Reset Button Hold for 4seconds to restart and set all parameters to default.
Back View Ethernet Port
Power Port (DC 5V/2A)
Speaker
Get the EZVIZ App
1. Connect your mobile phone to Wi-Fi (suggested).
2. Download and install the EZVIZ app by searching for “EZVIZ” in the App Store or Google PlayTM.
3. Launch the app and register an EZVIZ user account.
EZVIZ App
If you have already used the app, please make sure that it is the latest version. To find out if an update is available, go to the app store and
search for "EZVIZ".

3
Connect to the Internet
• Wired Connection: Connect the camera to a router. Refer to Option A.
• Wireless Connection: Connect the camera to Wi-Fi. Refer to Option B.
Option A: Wired Connection
1. Connect the power adapter cable to the camera’s power port.
2. Plug the power adapter into an electrical outlet.
The LED turning fast-flashing blue indicates that the camera is powered on and ready for network configuration.
3. Connect the camera to the LAN port of your router with the Ethernet cable (purchase separately).
The LED turning slow-flashing blue indicates that the camera is connected to the Internet.
Router
Power Cable
Outlet
4. Add your camera to EZVIZ.
-Log in to your account using the EZVIZ app.
-On the Home screen, tap “+” on the upper-right corner to go to the Scan QR Code interface.
-Scan the QR code on the Quick Start Guide cover or on the body of the camera.
Scan QR Code
-Follow the EZVIZ app wizard to add the camera to EZVIZ.

4
Option B: Wireless Connection
1. Connect the power adapter cable to the camera’s power port.
2. Plug the power adapter into an electrical outlet.
The LED turning fast-flashing blue indicates that the camera is powered on and ready for network configuration.
Outlet
Power Cable
3. Add camera to EZVIZ.
-Log in to your account using the EZVIZ app.
-On the Home screen, tap “+” on the upper-right corner to go to the Scan QR Code interface.
-Scan the QR code on the Quick Start Guide cover or on the body of the camera.
Scan QR Code
-Follow the EZVIZ app wizard to add the camera to EZVIZ.
Installation
1� Install the Micro SD Card (Optional)
-Rotate the sphere upwards until you see the card slot.
-Insert the Micro SD card (sold separately) into the card slot as shown in the gure below.
1
2

5
2� Install the Base
The camera can be placed horizontally or mounted on the ceiling. Here we take ceiling mounting as an example.
• Please install the device indoor as the device is not waterproof.
• Make sure the ceiling is strong enough to withstand three times the weight of the camera.
• Avoid positioning the camera in an area that gets a lot of light shining directly into the camera lens.
• Recommended mounting height: 3 meters above the ground.
-Place the drill template onto the surface you have chosen to mount the camera.
-(For cement wall/ceiling only) Drill screw holes according to the template, and insert three anchors.
-Use three metal screws to x the camera base.
Drill Template
Anchor
Metal Screw
3� Install the Camera
Mount the camera to the base, and turn it clockwise until it is fixed.

6
Operations on the EZVIZ App
The app interface may be different due to version update, and the interface of the app you installed on your phone shall
prevail.
1� Live View
When you launch the EZVIZ app, the device page displays as shown below.
You can view and listen to a live feed, take snapshots or recordings, and choose video definition as needed.
Swipe left and right across the screen to see more icons.
Icon Description
Share. Share your device with anyone you want.
Settings. View or change the device settings.
Popup. View the video displayed on top of another app you are using.
Snapshot. Take a snapshot.
Record. Manually start/stop recording.
PTZ . Rotate the camera to get broader field of view.
360° Picture. Tap to generate a 360 degree view picture.
Talk. Tap the icon, and then follow the on-screen instructions to talk to or
listen to people in front of the camera.
Privacy Mode. Enable to hide the screen display.
Definition. Select video resolution from Ultra HD, Full HD, Hi-Def or
Standard.
Multi-screen Live. Tap to select window layouts.

7
2� Settings
In the settings page, you can set the parameters of the device.
Parameter Description
Intelligent Detection You can select between different detection types for your device.
Notification You can manage the device message and EZVIZ APP notification.
Audio Settings You can set relevant audio parameters for your device.
Image Settings You can set relevant image parameters for your device.
Light Settings When disabled, the device indicator will be off.
PTZ Settings You can set parameters of PTZ for your device, like PTZ position calibration and 360° Picture here.
CloudPlay You can subscribe and manage the cloud storage.
Record List You can see micro SD card capacity, used space and free space here, and also you can enable or
disable cloud storage service here.
Security Settings You can encrypt your videos with encryption password and customize the privacy area.
Network Settings You can see the connection status.
Device Information You can see the device information here.
Share Device You can share the device to you family member or guest.
Restart the device Tap to restart the camera.
Delete Device Tap to delete the device from EZVIZ App.
For privacy protection, please remove SD card or other storage media(if any)when transferring the device to others.

8
EZVIZ Connect
1� Use Amazon Alexa
These instructions will enable you to control your EZVIZ devices with Amazon Alexa. If you run into any difficulties during the
process, please refer to Troubleshooting.
Before you start, make sure that:
1. EZVIZ devices are connected to the EZVIZ app.
2. In the EZVIZ app, turn off the "Image Encryption" in the Device Settings page.
3. You have an Alexa-enabled device (i.e Echo Spot, Echo-Show, All-new Echo-Show, Fire TV (all generations), Fire TV stick
(second generation only), or Fire TV Edition smart TVs).
4. The Amazon Alexa app is already installed on your smart device, and you have created an account.
To Control EZVIZ devices with Amazon Alexa:
1. Open the Alexa app and select "Skills and Games" from the menu.
2. On the Skills and Games screen, search for "EZVIZ", and you will nd "EZVIZ" skills.
3. Select your EZVIZ device's skill, then tap ENABLE TO USE.
4. Enter your EZVIZ username and password, and tap Sign in.
5. Tap the Authorize button to authorize Alexa to access your EZVIZ account, so that Alexa can control your EZVIZ devices.
6. You will see "EZVIZ has been successfully linked", then tap DISCOVER DEVICES to allow Alexa to discover all your EZVIZ
devices.
7. Go back to Alexa app menu and select "Devices", and under devices you will see all your EZVIZ devices.
Voice Command
Discover a new smart device via the "Smart Home" menu in the Alexa app or the Alexa Voice Control function.
Once the device is found, you can control it with your voice. Speak simple commands to Alexa.
Your device's name for example: "show xxxx camera," can be modified in the EZVIZ app. Every time you change the name of the device, you
will need to discover the device again to update the name.
Troubleshooting
What do I do if Alexa fails to discover my device?
Check if there are any Internet connecting problems.
Try to reboot the smart device and re-discover the device on Alexa.
Why does the device's status show "Ofine" on Alexa?
Your wireless connection might have been disconnected. Reboot the smart device and re-discover on Alexa.
Internet access on your router could be unavailable. Check if your router is connected to the Internet and try again.
For details about countries that support the using of Amazon Alexa, see its official website.
2� Use Google Assistant
With the Google Assistant, you can activate your EZVIZ device and watch live by speaking Google Assistant voice commands.
The following devices and apps are required:
1. A functional EZVIZ app.
2. In the EZVIZ app, turn off the "Image Encryption" and turn on the "Audio" in the Device Settings page.
3. A TV with functional Chromecast connecting to it.
4. The Google Assistant app on your phone.
To get started, follow the steps below:
1. Set up the EZVIZ device and make sure it works properly on the app.
2. Download the Google Home app from the App Store or Google Play StoreTM and log into your Google account.
3. On the Myhome screen, tap “+” on the upper-left corner, and select "Set up device" from the menu list to go to the Set up
interface.
4. Tap Works with Google, and search for "EZVIZ", where you will nd "EZVIZ" skills.

9
5. Enter your EZVIZ username and password, and tap Sign in.
6. Tap the Authorize button to authorize Google to access your EZVIZ account, so that Google can control your EZVIZ devices.
7. Tap Return to app.
8. Follow the above steps to complete the authorization. When synchronization is completed, EZVIZ service will be listed under
your list of services. To see a list of compatible devices under your EZVIZ account, tap on the EZVIZ service icon.
9. Now try some commands. Use the name of the camera that you created when you set up the system.
Users can manage devices as a single entity or in a group. Adding devices to a room allows users to control a group of devices
at the same time using one command.
See the link for more information:
https://support.google.com/googlehome/answer/7029485?co=GENIE.Platform%3DAndroid&hl=en
FAQ
Q:
A:
If the camera is oine, will the video recording be continued?
If the camera is powered on but disconnect to the Internet, then video recording on micro SD card will continue but cloud
recording will stop. If the camera is powered off, both video recordings will stop.
Q:
A:
Why the alarm is triggered when nobody in the image?
Try to set the alarm sensitivity lower. Please notice that vehicle and animals are also the trigger source.
Q:
A:
What if I forget my password?
Please go to the EZVIZ app > login page, tap on “Forgot password?” > Enter your account’s email address or phone number.
(Send)> Input the verification code > Reset your password.
Q:
A:
Why can't I receive my verication code?
1. If you registered the account via email, please check your junk mail.
If still haven't received the verification code, you might have email filter/block restricting this email, please check with
your email provider.
2. If you registered an account via mobile number, please conrm whether your mobile can receive SMS short codes or not.
3. If you still haven't received the verication code, please provide your number, your country, time of request to the support
center at [email protected] or contact your regional support team.
Q:
A:
How to solve Wi-Fi conguration failed?
Please check the following settings:
1. Ensure that your mobile phone is connected to the Wi-Fi and the Wi-Fi network is working properly.
2. Check the network condition:
• Make sure your network has no firewall or other limits.
• Ensure the router can distribute IP address to your device or disable the static IP setting (DHCP is enabled by default on
all EZVIZ devices).
3. Reset your camera; ensure that your device is in ready mode or Wi-Fi conguration mode > then use the EZVIZ app for
device Wi-Fi conguration.
For additional information about the device, please refer to www.ezviz.com/eu.
