Merlin Premium+ E960M User manual

1. Programming - Merlin Security+ 2.0 door opener systems
The remote is preset for use with Merlin Security+ 2.0 systems, so for EVO door opener models with this code, simply program in the usual manner.
Refer to the WIRELESS PROGRAMMING section in your Opener Operating Manual.
NOTE: If you are unsure what code has been set previously, use the Security+ programming sequence on page 2.
1. Press & hold the button on the remote you wish to use.
2. Press & release the LEARN button on the opener.
3. Release the remote button when the opener light flashes. The code has been learnt and the next press of the remote button should activate the door.
E960M - Premium+ Remote
LED
ROLLER DOOR OPENERS
LEARN
BUTTON
LED
INDICATOR
SECTIONAL DOOR OPENERS
LEARN
BUTTON
LED
INDICATOR
Press and hold the
button on the
remote control you
wish to use. The
LED indicator on the
transmitter flashes
continuously.
Press and
immediately
release the
Learn button.
“click”
“click”
The opener
light flashes
or 2 clicks are
heard when
it has learnt
the code.
2 3
1
Initially: Locate the LEARN button on your
particular opener and identify the button on
the remote you wish to use. Do not select
a button already in use.
The Merlin Premium+ Remote can be used with both Merlin Security+
and Security+ 2.0 codes (dual function).
4 buttons are available and any button can be programmed with either code.
S P
1 2 3
123 2
LEARN
BUTTON
DN UP PS
123OR
LEARN
BUTTON
LED
INDICATOR
OR














©

2. Programming - Merlin Security+ door opener systems
3
2
4
1
4-BUTTON REMOTES
Press and hold the button down until the
garage door starts to move. The remote
will operate from up to 3 car lengths away
on typical installations. Installations and
conditions vary, contact an installing dealer
for more information.
HOW TO USE THE REMOTE
Additional buttons on the remote can
be programmed to operate up to 3
devices such as additional garage door
openers, light controls, gate operators
or access control systems.
To do this you will need to enter the unique REMOTE PROGRAMMING sequence:
1. Enter the programming MODE on the remote by pressing and holding the left and right buttons simultaneously for around 5 seconds (fig 1).
Release when the remote LED stays ON continuously.
2. Press & release the LEARN button on your garage door opener briefly (fig 2). Within 30 seconds, the remote can now be programmed.
3. Select the button on the remote you wish to program and press once (fig 3). If the opener light flashes, the code has been learnt and step 4
can be performed. If not, press the selected button again until the opener light flashes, indicating the code has been learnt. At this point, do not
press this button any more.
4. Now press any one of the OTHER 3 buttons of the remote (fig 4). This LOCKS IN the code to the button selected in step 3 and the remote LED
turns OFF.
5. The next press of the button should activate the door, if not repeat the process.
CR2032
Use a screwdriver
to open the case as
shown
Remove the old battery.
Dispose of old batteries
properly.
Insert replacement
batteries positive side
up. Replace the
batteries with only
CR2032 coin cell
batteries.
Replace cover.
ONE YEAR LIMITED WARRANTY
114A4819B
THE REMOTE CONTROL BATTERY
The lithium battery should produce power for up to 5 years.
If the battery is low, the remote control's LED will not flash
when the button is pressed. To replace battery :
professional
13
2
60s
120s
180s
O
–
MT600,MT800
MT1000
MR650,MR850
MRC950
MT3850
MT5580P
MR60, MR600
MR800
MT60/MT60P MJ3800,
MJ3800R
open
force
operate
learn delete
open
MR1000
MT230
NOTE: In the event you need to return a button to Security+ 2.0 code, repeat the programming sequence outlined above.
