Merlin CM128 User manual

2. Programming - Merlin Security+ 2.0 door opener systems
The remote is preset for use with Merlin Security+ 2.0 systems, so for EVO door opener models with this code, simply program in the usual manner.
Refer to the WIRELESS PROGRAMMING section in your Opener Operating Manual.
NOTE: If you are unsure what code has been set previously,
use the Security+ programming sequence on page 2.
1. Press & hold the button on the remote you wish to use.
2. Press & release the LEARN button on the opener.
3. Release the remote button when the opener light flashes.
The code has been learnt and the next press of the remote
button should activate the door.
E148M - Four Button Wireless
Wall Mount Remote Control
Press and hold the
button on the remote
control you wish to use.
The LED indicator on
the transmitter flashes
continuously.
Press and
immediately release
the Learn button.
“click”
“click”
2 3
1
Initially: Locate the LEARN button on your particular opener and identify the button on
the remote you wish to use. Do not select a button already in use.
The Merlin Four Button Wireless Wall Mount Remote Control can be used with both Merlin Security+ and Security+ 2.0 codes (dual function).
4 buttons are available and any button can be programmed with either code.
S P
1 2 3
123 2
LEARN
BUTTON
ROLLER DOOR OPENER
LEARN
BUTTON
LED
INDICATOR
SECTIONAL DOOR
OPENER
LEARN
BUTTON
LED
INDICATOR
DN UP PS
123
LEARN
BUTTON
LED
INDICATOR
OR
The opener light flashes
or 2 clicks are heard
when it has learnt the code
• The battery is hazardous.
• Keep new and used batteries away from children.
• Do not ingest battery. Chemical burn hazard.
• If the coin cell battery is swallowed or placed inside any part
of the body, it can cause severe or fatal injuries in 2 hours or less.
• If the battery compartment does not close securely, stop using the product and
keep away from children.
• If you think batteries might have been swallowed or placed inside any part of the body,
call the 24-hour Poisons Information Centre on 13 11 26 in Australia, or the 24-hour
National Poisons Centre on 0800 764 766 in New Zealand, or seek immediate medical
attention.
• Dispose of used coin/button cell batteries immediately and safely. Flat batteries can still
be dangerous.

• Carefully pry open the E148M and locate the two screws for mounting.
• Attach to the wall using the two screws provided. If mounting to a plaster wall, wall plugs may be required.
NOTE: Do not over tighten screws.
• Replace the front cover plate.
Disconnect power to the opener before installing this accessory to prevent accidental activation.
Locate minimum 1.5m above the floor.
1. Installation
OR

3. Programming - Merlin Security+ door opener systems
3
2
4
1
4-BUTTON REMOTES
Press and hold the button down until the
garage door starts to move. The remote
will operate from up to 3 car lengths away
on typical installations. Installations and
conditions vary, contact an installing dealer
for more information.
HOW TO USE THE REMOTE
Additional buttons on the remote can
be programmed to operate up to 3
devices such as additional garage door
openers, light controls, gate operators
or access control systems.
To do this you will need to enter the unique REMOTE PROGRAMMING sequence:
1. Enter the programming MODE on the remote by pressing and holding the left and right buttons simultaneously for around 5 seconds (fig 1).
Release when the remote LED stays ON continuously.
2. Press & release the LEARN button on your garage door opener briefly (fig 2). Within 30 seconds, the remote can now be programmed.
3. Select the button on the remote you wish to program and press once (fig 3). If the opener light flashes, the code has been learnt and step 4
can be performed. If not, press the selected button again until the opener light flashes, indicating the code has been learnt. At this point, do not
press this button any more.
4. Now press any one of the OTHER 3 buttons of the remote (fig 4). This LOCKS IN the code to the button selected in step 3 and the remote LED
turns OFF.
5. The next press of the button should activate the door, if not repeat the process.
CR2032
Use a screwdriver or
similar to pry open
the case as
shown
Remove the old battery.
Dispose of old batteries
properly.
Insert replacement
batteries positive side
up. Replace the
batteries with only
CR2032 coin cell
batteries.
Replace cover.
ONE YEAR LIMITED WARRANTY
114A5473B
THE REMOTE CONTROL BATTERY
The lithium battery should produce power for up to 3 years.
If the battery is low, the remote control's LED will not flash
when the button is pressed. To replace battery :
Chambrain Austraia PtLimitd Chambrain NwZaand (Chambrain), thmanufacturr of Mrin®automac
garagdoor opnrs, warrants to thoriginaconsumr purchasr of this product that it is fr from dfct in matrias
andor workmanship for a priod of 1 ar from thdatof purchas
Chambrain is commid to manufacturing and supping high quaitgoodsAs part of this commitmnt, wsk to
providriab srvicand support for our goods and arpasd to providou, thoriginapurchasr, with this
Chambrain Limitd Warrant
Thbnts givn to ou undr this Chambrain Limitd Warrantarin addion to anrights and rmdis that ou ma
havundr Austraian or Nw Zaand consumr protcon awsOur goods comwith guarants that cannot b
xcudd undr thAustraian Consumr Law, or Nw Zaand Consumr Guarants Act 1993You arntd to a
rpacmnt or rfund for a major faiurand for compnsaon for anothr rasonab forsab oss or damag You
araso ntd to havfor compnsaon for anothr rasonab forsab oss or damag You araso ntd to
havthgoods rpaird or rpacd if thgoods faito bof accptab quaitand thfaiurdos not amount to a major
faiur
NOTE: In the event you need to return a button to Security+ 2.0 code, repeat the programming sequence outlined above.
