Mesa 4I60 User manual

.*9-*73*9.39*7+&(*2&3:&1
VERSION 1.1
Copyright 2000 by MESA ELECTRONICS Richmond, CA. Printed in the United States of
America. All rights reserved. This document and the data disclosed herein is not to be reproduced,
used, disclosed in whole or in part to anyone without the written permission of MESA
ELECTRONICS.
MesaElectronics
4175LakesideDrive,Suite#100
Richmond,CA94806-1950
Tel [phone] - Fax [phone]
E-Mail: [e-mail] - Website: www.mesanet.com

4I60 USER’S MANUAL

TABLE OF CONTENTS
HANDLING PRECAUTIONS
Handlingprecautions 4..................................................................
INTRODUCTION
General 5................................................................................
HARDWARE CONFIGURATION
General 6................................................................................
Default configuration 6..................................................................
PC/104-PLUS 6.........................................................................
PCI slot select 8.........................................................................
INTERFACE CONNECTORS
100/10BaseTconnector 9...............................................................
AUIconnector 9.........................................................................
Externaltransceiveroption 9............................................................
MIIconnector 9.........................................................................
LEDconnector 9........................................................................
AUIconnectorpinout 10.................................................................
LEDconnector pinout 10................................................................
INSTALLATION
General 11...............................................................................
PC/104-PLUS 11........................................................................
Power 11.................................................................................
REFERENCE INFORMATION
Specifications 12.........................................................................
Warranty 13..............................................................................
Schematicdiagrams 14...................................................................
4I60 USER’S MANUAL

HANDLING PRECAUTIONS
4I60 USER’S MANUAL
Page 4
STATICELECTRICITY
The CMOS integrated circuits on the 4I60 can be damaged by exposure to electrostatic
discharges. The following precautions should be taken whenhandling the 4I60 to prevent possible
damage.
A.Leavethe4I60initsantistaticbaguntilneeded.
B.Allwork shouldbeperformedat anantistaticworkstation.
C.Groundequipmentintowhich4I60willbeinstalled.
D.Groundhandlingpersonnelwithconductivebracelet through1 megohmresistor to ground.
E.Avoidwearingsyntheticfabrics,particularlyNylon.

INTRODUCTION
GENERAL
The 4I60 is a high performance PCI 100BaseT Ethernet card in a PC/104-PLUS form factor.
PC/104-PLUS is a new embedded system card format that adds a stackable PCI connector to the
PC/104standard.
The 4I60 is a bus mastering PCI Ethernet card using the Digital Semiconductor 21143 Ethernet
chip. Thebusmasteringarchitecture ofthe21143 minimizes CPUinvolvement inpacket transmission
and reception. The large receive and transmit FIFOs permit efficient operation even with high
system latencies. The 21143 chip was chosen for its high performance, advanced feature set, and
widerangeofavailabledrivers.
The 4I60 supports full autonegotiation for automatic selection of all twisted media types. Full
duplex operation is supported on 100BaseT and 10BaseT modes. The 4I60 is a universal type
PC/104-PLUS card and will work with 3.3V and 5V bus systems. Only 5V power is required by the
4I60 (+12V is usedonlyfor theAUI connector) Unused circuitryispowered down whennot needed,
includingthe oncard DC-DCconverter. The 100BaseT interface ofthe PHY ispowered down when
using10BaseT.
All options are software selectable except the PCI slot number. A MII compatible connector is
available for use with other media types. A socket for a 32 pin boot ROM of up to 256K bytes is
provided. 5V flash ROMs, can be used, simplifying software upgrades. Various 4I60 options are
available including a lower cost and lower power 10BaseT only model. A low cost external panel
mount transceiveroptionisavailablefor10Base2(BNC) operation.
Page 5
4I60 USER’S MANUAL

HARDWARE CONFIGURATION
GENERAL
The4I60has onlyone hardwareconfiguration options,thePCI slot number.ThePCI slot number
option is selected with shorting jumpers placed on three pin headers. In the following discussions,
when the words "up", "down" are used it is assumed that the 4I60 card is oriented with its ISA bus
connectorsJ1andJ2at thebottomedgeofthecard(nearest thepersondoingthe configuration).
InthispositiontheMESA4I60textat thetopofthecardisrightsideup.
DEFAULT CONFIGURATION
The4I60cardisconfiguredinthefollowingmannerwhenshippedfromthefactory.
FUNCTION DEFAULT JUMPER POSITION
PCI SLOTSELECT SLOT W3/W4 DOWN,DOWN
PC/104-PLUS
The 4I60 is a PC/104-PLUS, PCI only card. This means that even though the PC/104 ISA
connector are present, the ISA signals are not used at all on the 4I60. The 4I60 will only work on
PC/104-PLUSCPUs!
Page 6
4I60 USER’S MANUAL

HARDWARE CONFIGURATION
DEFAULT JUMPER SETTINGS
CONNECTOR LOCATIONS
Page 7
4I60 USER’S MANUAL

HARDWARE CONFIGURATION
PCI SLOT SELECT
The onlyhardware selectable option on the 4I60 is the PCI slot number. This isthe equivalent to
choosing the motherboard slot a standard PCI card is installed into. The slot number also determines
the PCI interrupt line driven bythe 4I60. Jumpers W3 and W4 determine the PCI slot number: Each
card in the PC/104-PLUS stack must have a different slot number selected. Some PC/104-PLUS
CPUs do not haveall4 slots available for PC/104-PLUS add-incards. Notethat PCI DMAchannel2
isshared byslots 3 and 4. Since the4I60 is a busmaster card it cannot be used in slot 3 if another bus
master cardisinstalled inslot 4and vice versa.
SLOT DMA PCI INT W3 W4
1 REQ0/GNT0 A DOWN DOWN
2 REQ1/GNT1 B DOWN UP
3 REQ2/GNT2 C UP DOWN
4 REQ2/GNT2 D UP UP
Page 8
4I60 USER’S MANUAL

INTERFACE CONNECTORS
100/10BASET CONNECTOR
The 4I60 may has a 8 pin modular telephone type jack for use with 100/10BaseT twisted pair
networks. This connector is marked P4. When twisted pair networks are used, a 100BaseT or 10
BaseT hubmust besupplied. You cannot ingeneralsimplyconnect fromoneinterface cardto another
when twisted pair cable is used.
AUI CONNECTOR
An AUI connector (P3) is provided for connecting to external 10 MBPS transceivers. This
connector is a 16 pin header. Whena flat cable with a female header at one end, and a female D-SUB
connector at the other end is plugged onto the 16 pin header, the D-SUB pinout matches the AUI
standard pinout. This flat cable is availablefrom MESA. Ifyou makeyour own cable, note that pin 16
of the flat cable is not used. The flat cable should be less than one foot long, as it is not a good
impedance match to the 78 Ohmtwisted pair transceiver cables. 12V power on the AUI connector is
directly connected to the PC/104 bus 12V system power. Selection of the AUI interface is a driver
option.
EXTERNAL 10BASE2 TRANSCEIVER OPTION
The 4I60isavailable with a low cost external10Base2 transceiver option.This panelmount BNC
transceiverallowssimpleexternalaccesstothe10Base2connectorwithoutdependingonthePC/104
stack location. This transceiver connects to the 4I60’s AUI connector with a 20 pinflat cable and gets
its isolated power from the 4I60’sDC-DC converter (P5). This flat cable must be 1 foot or shorter in
length . When installing the flat cable, make sure that the pin one mark on the cable is aligned with the
whitedotonconnectorP3. SelectionoftheBNCinterfaceisa driveroption.
MII CONNECTOR
A 44 pin 2MM connector is provided for connection to a MII paddle board. This connection
allows alternate high speed physical media interfaces to be attached to the 4I60. The paddle board
adapter is availablefromMESA.
LED CONNECTOR
P1isaconnectorforexternalstatusLEDs.Itisonlyfunctionalonthestandard4I60(notthe4I60-
10).
Page 9
4I60 USER’S MANUAL

INTERFACE CONNECTORS
AUI CONNECTOR PINOUT:
PIN FUNCTION PIN FUNCTION
1 GND 2 CD-
3CD+4 TX-
5 TX+ 6 GND
7 GND 8 RX-
9 RX+ 10 +12V
11 GND 12 GND
13 NC 14 NC
15 GND 16 NC
LED CONNECTOR PINOUT:
PIN FUNCTION PIN FUNCTION
1 GND 2 GND
3 /SPDLED 4 GND
5 /ACTLED 6 GND
7 /LNKLED 8 GND
9 VCC 10 VCC
Page 10
4I60 USER’S MANUAL

INSTALLATION
GENERAL
When the 4I60 has been properlyconfigured for its application, it can be inserted into a PC/104-
PLUS stack. The standoffs should then be tightened to secure the 4I60 in its place. When the 4I60 is
securedinthestacktheI/Oconnectorscanbepluggedinfromtheside.
PC/104-PLUS
Again, the 4I60 is a PC/104-PLUS, PCI onlycard. This means that even though the PC/104 ISA
connector are present, the ISA signals are not used at all on the 4I60. The 4I60 will only work on
PC/104-PLUSCPUs!
POWER
The 4I60 gets all of its power from system +5V. +12V power will be required if an external
transceiver is used on the AUI connector. This does not apply to the MESA MAU 10Base2 interface
which gets its power from a DC-DC converter on the 4I60 card. The 4I60 can be used with 5V and
3.3VPCIbusCPUcards.Thisvoltageselectionisautomatic.
Page 11
4I60 USER’S MANUAL

REFERENCE INFORMATION
SPECIFICATIONS
MIN MAX UNIT NOTES
POWERSUPPLY
Voltage 4.5 5.5 V
4I60Supplycurrent ---- 350 mA BNC off
4I60Supplycurrent ---- 400 mA BNC on
4I60-10Supplycurrent ---- 100 mA BNCoff
4I60-10Supplycurrent ---- 250 mA BNCon
ENVIRONMENTAL:
Operatingtemperaturerange
-Iversion -40 +85 oC
-Cversion 0 +70
oC
Relativehumidity 0 90 Percent
Non-condensing
Page 12
4I60 USER’S MANUAL

REFERENCE INFORMATION
WARRANTY
Mesa Electronics warrants the products it manufactures to be free effects in material and
workmanship under normal use and service for the period of 2 years from date of purchase. This
warranty shall not apply to products which have been subject to misuse, neglect, accident, or
abnormalconditionsofoperation.
In the event of failure of a product covered by this warranty, Mesa Electronics, will repair any
product returned to Mesa Electronics within 2 years of original purchase, provided the warrantor’s
examination discloses to its satisfaction that the product was defective. The warrantor may at its
option,replacetheproduct inlieuofrepair.
Withregardto anyproduct returnedwithin2yearsofpurchase, said repairsor replacementwillbe
made without charge. If the failure has been caused by misuse, neglect, accident, or abnormal
conditions ofoperation, repairs will be billed at a nominalcost.
THE FOREGOING WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED. INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTY OF MERCHANTABILITY, FITNESS, OR ADEQUACY FOR ANY
PARTICULAR PURPOSE OR USE. MESA ELECTRONICS SHALL NOT BE LIABLE FOR
ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER IN
CONTRACT, TORT,OR OTHERWISE.
Ifanyfailureoccurs,thefollowingstepsshouldbetaken:
1. Notify Mesa Electronics, giving full details of the difficulty. On receipt of this information,
service data, or shipping instructions willbe forwarded to you.
2. On receipt of the shipping instructions, forward the product, in its original protective
packaging, transportation prepaid to Mesa Electronics. Repairs willbe made at Mesa Electronics and
theproductreturnedtransportationprepaid.
Page 13
4I60 USER’S MANUAL

REFERENCE INFORMATION
SCHEMATICS
Page 14
