Mesa WS-600A User manual

Do not dispose this product as unsorted municipal
waste. Collection of such waste separately for special
treatment is necessary.
WS-600A

6×25
4×15
STEP6
STEP7
Dear Guest,
Thank you very much for purchasing our sanitary ware. To
enable you to use this product safely and effectively, please
read this installation and operation manual carefully before
use.
1.Please ensure that the product installed reliable electric leakage
protection device, the power plug contains earth line, and make sure
it is reliable earth line. Check the protect system of leakage
protection each time before use.
2.Do not turn on water pump, heat pump or air bubble pump without
water.
3.Before turn on water pump, check if the water level over jets 10 to
20 mm or not, make sure regular usage of water pump otherwise it
will be destroy because of water leakage.
4.People with Hypertension symptom, after drink or heart disease are
not allowed to use the bathtub. Children have a bath must under
adult's guidance.
5.During use please noticed that don't blocked the jets and avoiding
the air adjustment valve overflowing. Also keep the bathtub clean
and don't let it blocked by hair or mess.
6.During use, please firstly adjust the water temperature or it will be
burned.
7.The bathtub is designed with ergonomic, rise and fall changes are
quite big so during usage pay more attention of be slipped.
8.Please shut down the system when not to use.
AC220V(±10%) 50/60HZ 0.1~0.2Mpa 3KW 1.5KW 0.2KW
CAUTIONS: Heat pump and air bubble pump is required by customers.
CAUTIONS
1HP
TECHNIQUE PARAMETER
Voltage Frequency Water
Volatge
Power of
steam
generator
Power of
water pump
Power of
heat pump
Power of
air pump
01 06

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1.rooflamp
2.top shower
3.speak
4.decorated lamp
5.moveable shower
6.shower moveable rail
7.function shift switch
8.cold/hot water switch
9.function shift switch
10.waist-shaped board
11.ozone
12.roof
13.exhaust fan
14.mirror
15.room body
16.temperature sensor
17.controp panel
18.noozle
19.noozle
20.foot massage
21.steam out
22.bottom bathtub
STEP3
STEP4
STEP5
05 02
CONSTRUCTION SKETCH

Top shower
Movable
shower head
Water fall
Foot
massage
Steam
generator
Nozzle
Nozzle Nozzle
Nozzle
Switch
valve
Cold/hot
water switch
Hot water connection
(red pipe)
Cold water connection
(red pipe)
Switch
valve
STEP1
STEP2
INSTALLATION SKETCH
1
2
3
4
5
6
7
8
9
1、water pump switch
2、air regulator
3、bottonlamp
4、water suction
5、water jet
6、draining switch
7、waterfall
8、drainage
9、air bubble jet
SIZE:1400X1400X2200mm
1400
1400
2200
540
1250
1800
100
400
200
200
900
The socket
of power and
the socket
of telephone
Cold
water
pipe
Hot
water
pipe
Drain
400
200
The socket
of bottom
bathtub
INSTALLATION PROCESS
03 04
As the“ ”“ ”from the picture,please make the connection according to the serial number v1,v2,etc.
Drawing of water connection
