Metabo HPT NV 65AN Instruction Manual

Instruction and safety manual
Manuel d’instructions et de sécurité
Instrucciones y manual de seguridad
Model
Modèle
Modelo NV 65AN • NV 65AN(S) Nailer
Cloueur
Clavador
NV65AN
(contact actuation model)
NV65AN(S)
(single sequential actuation model)
DANGER
Improper use of this Nailer can result in death or serious injury!
This Manual contains important information about product safety.
Read and understand this Manual before operating the Nailer.
Never allow anyone who has not reviewed this manual to use the tool.
This manual should be stored in safe place.
DANGER
Une utilisation incorrecte et sans respecter la sécurité de ce cloueur risque d’entraîner la
mort ou des blessures graves !
Ce manuel renferme des instructions importantes sur la sécurité de l’outil.
Lire et bien assimiler ce manuel avant d’utiliser le cloueur.
Cet outil ne doit jamais être utilisé par une personne n’ayant pas pris connaissance du manuel.
Ce mode d’emploi doit être conservé dans un endroit sûr.
PELIGRO
¡La utilización inadecuada e insegura de este clavador puede resultar en lesiones serias o
en la muerte!
Este manual contiene información importante sobre la seguridad del producto.
Lea y entienda este manual antes de utilizar el martillo neumático.
La herramienta no deberá utilizarse sin haber leído previamente este manual.
Este manual debe ser guardado en un lugar seguro.
000BookNV65ANUS.indb1000BookNV65ANUS.indb1 2018/05/089:24:172018/05/089:24:17

English Page Page
Français Page Page
Español Página Página
CONTENTS
TABLE DES MATIÈRES
ÍNDICE
IMPORTANT SAFETY INFORMATION ....................3
DEFINITIONS OF SIGNAL WORDS.........................3
EXPLANATION OF THE NAILING ACTION
OF THE metabo HPT NAILER.............................3
SAFETY
IMPORTANT SAFETY INSTRUCTIONS -
FOR USING NAILERS.........................................4
RESPONSIBILITIES OF EMPLOYER, TOOL
OWNER AND TOOL OPERATOR.......................8
FUNCTIONAL DESCRIPTION
NAME OF PARTS .....................................................9
SPECIFICATIONS................................................... 10
NAIL SELECTION ................................................... 10
ACCESSORIES....................................................... 10
STANDARD ACCESSORIES............................. 10
OPTIONAL ACCESSORIES.............................. 11
OPERATING INSTRUCTIONS
APPLICATIONS ...................................................... 11
BEFORE OPERATION............................................ 11
WORKING ENVIRONMENT.............................. 11
AIR SUPPLY ...................................................... 11
LUBRICATION................................................... 12
COLD WEATHER CARE ................................... 12
TESTING THE NAILER ..................................... 12
ADJUSTING AIR PRESSURE........................... 14
LOADING NAILS ............................................... 14
NAILER OPERATION ............................................. 15
METHODS OF OPERATION ............................. 16
CHANGING THE EXHAUST DIRECTION......... 18
MAINTENANCE
MAINTENANCE AND INSPECTION ...................... 19
SERVICE AND REPAIRS........................................20
PARTS LIST ............................................................62
INFORMATION IMPORTANTE DE SÉCURITÉ......22
DEFINITION DES MOTS DE SIGNALISATION......22
EXPLICATION DE L’ACTION DE CLOUAGE DU
CLOUEUR metabo HPT ....................................22
SECURITE
CONSIGNES DE SÉCURITÉ IMPORTANTES POUR
L’UTILISATION DU CLOUEUR..........................23
RESPONSABILITÉS DE L’EMPLOYEUR,
DU PROPRIÉTAIRE DE L’OUTIL ET DE
L’OPÉRATEUR DE L’OUTIL...............................27
DESCRIPTION FONCTIONNELLE
NOM DES PIECES..................................................28
SPECIFICATIONS...................................................29
SELECTION DES CLOUS ......................................29
ACCESSOIRES.......................................................29
ACCESSOIRES STANDARD.............................29
ACCESSOIRES EN OPTION ............................30
INSTRUCTIONS D’OPÉRATION
APPLICATIONS ......................................................30
AVANT L’UTILISATION ...........................................30
ENVIRONNEMENT DE TRAVAIL......................30
ALIMENTATION D’AIR.......................................30
GRAISSAGE...................................................... 31
ENTRETIEN PAR TEMPS FROID ..................... 31
ESSAI DU CLOUEUR........................................31
RÉGLAGE DE LA PRESSION D’AIR.................33
CHARGEMENT DES CLOUS............................33
UTILISATION DU CLOUEUR.................................. 35
MÉTHODES D’UTILISATION............................36
CHANGEMENT DU SENS D’ECHAPPEMENT ...38
ENTRETIEN
ENTRETIEN ET INSPECTION................................38
ENTRETIEN ET REPARATIONS ............................40
LISTE DES PIÈCES ................................................62
INFORMACIÓN IMPORTANTE SOBRE
SEGURIDAD......................................................42
DEFINICIÓN DE LAS PALABRAS CLAVE .............42
EXPLICACIÓN LA ACCIÓN DE CLAVADO DEL
CLAVADOR metabo HPT..................................42
SEGURIDAD
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
PARA LA UTILIZACIÓN DEL CLAVADOR........43
RESPONSABILIDADES DEL EMPLEADOR, EL
PROPIETARIO DE LA HERRAMIENTA Y EL
OPERADOR DE LA HERRAMIENTA................ 47
DESCRIPCIÓN FUNCIONAL
NOMENCLATURA..................................................48
ESPECIFICACIONES .............................................49
SELECCIÓN DE CLAVOS ......................................49
ACCESORIOS ........................................................49
ACCESORIOS ESTÁNDAR...............................49
ACCESORIOS OPCIONALES...........................50
INSTRUCCIONES DE OPERACIÓN
APLICACIONES......................................................50
ANTES DE LA OPERACIÓN...................................50
ENTORNO DE TRABAJO .................................50
SUMINISTRO DE AIRE .....................................50
LUBRICACIÓN .................................................. 51
CUIDADOS PARA CLIMAS FRÍOS ................... 51
PRUEBA DEL CLAVADOR................................52
AJUSTE DE LA PRESIÓN DE AIRE..................53
CARGA DE CLAVOS.........................................53
OPERACIÓN DEL CLAVADOR ..............................55
MÉTODOS DE OPERACIÓN ............................56
CAMBIO DEL SENTIDO DEL AIRE DE ESCAPE ...58
MANTENIMIENTO
MANTENIMIENTO E INSPECCIÓN .......................58
SERVICIO Y REPARACIONES...............................60
LISTA DE PIEZAS ..................................................62
000BookNV65ANUS.indb2000BookNV65ANUS.indb2 2018/05/089:24:172018/05/089:24:17

3
English
IMPORTANT SAFETY INFORMATION
Read and understand tool labels and all of the operating instructions, safety precautions and warnings
in this manual before operating or maintaining this Nailer.
Failure to follow warnings could result in DEATH or SERIOUS INJURY
Most accidents that result from the operation and maintenance of Nailers are caused by the failure to observe basic
safety rules or precautions. An accident can often be avoided by recognizing a potentially hazardous situation before it
occurs, and by observing appropriate safety procedures.
Basic safety precautions are outlined in the “SAFETY” section of this Manual and in the sections which contain the
operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by DANGERS and WARNINGS
on the Nailer and in this Manual.
NEVER use this Nailer for applications other than those specified in this Manual.
DEFINITIONS OF SIGNAL WORDS
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury, or
may cause machine damage.
NOTE emphasizes essential information.
EXPLANATION OF THE NAILING ACTION OF THE metabo HPT NAILER
○ SINGLE SEQUENTIAL ACTUATION MECHANISM:
First, press the push lever against the wood; next, pull the trigger to drive the fastener.
After nailing once, nailing will not be possible again until the Trigger is released and pressed again.
○ CONTACT ACTUATION MECHANISM:
First, press the push lever against the wood; next, pull the trigger to drive the fastener.
First, pull the trigger; next, press the push lever against the wood to drive the fastener.
If the Trigger is held back, a nail will be driven each time the Push Lever is pressed against the wood.
000BookNV65ANUS.indb3000BookNV65ANUS.indb3 2018/05/089:24:172018/05/089:24:17

4
English
SAFETY
IMPORTANT SAFETY INSTRUCTIONS - FOR USING NAILERS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
● General
To reduce the risks of electric shock, fire, and injury to persons, READ ALL THE INSTRUCTIONS BEFORE
USING THE TOOL.
DANGER
1. OPERATORS AND OTHERS IN WORK AREA
MUST WEAR EYE PROTECTION (SAFETY
GLASSES WITH SIDE SHIELDS).
When operating the Nailer, always wear
safety glasses with side shields, and
make sure others in work area wear
safety glasses, too.
Safety glasses must conform to the
requirements of American National
Standards Institute, ANSI Z87.1 and
provide protection against flying particles
both from the front and side.
Ordinary eyeglasses do not provide
adequate protection.
The employer must enforce the use of
safety glasses by the Nailer operator and
others in work area.
WARNING
3. NEVER POINT TOOL AT YOURSELF OR OTHERS
IN WORK AREA.
Always assume that the Nailer contains
fasteners.
Never point the Nailer toward yourself or
others, whether it contains fasteners or
not.
If fasteners are mistakenly driven, it can
lead to severe injuries.
Never engage in horseplay with the
Nailer.
Respect the Nailer as a working
implement.
2. NEVER USE REACTIVE GASES OR OTHER
BOTTLED GASES. EXPLOSION MAY OCCUR.
Never use reactive gases such as
oxygen, combustible gases or any other
bottled gases as a power source for the
Nailer.
Use of the above gases is dangerous, as
the Nailer will explode.
Use only clean, dry, regulated
compressed air.
4. DO NOT PLACE FINGER ON TRIGGER AND KEEP
FINGERS AWAY FROM TRIGGER WHEN NOT
DRIVING FASTENERS TO AVOID ACCIDENTAL
DISCHARGE.
Never carry the Nailer with finger on Trigger since
you could drive a fastener unintentionally and injure
yourself or someone else.
Always carry the Nailer by the handle only.
5. KNOW AND UNDERSTAND WHAT TRIGGER
SYSTEM YOU ARE USING.
Read and understand section titled “METHODS OF
OPERATION.” (pages 16 – 18)
6. DO NOT MAKE CONTACT WITH SAFETY
TIP (PUSH LEVER) WHEN NOT DRIVING
FASTENERS.
000BookNV65ANUS.indb4000BookNV65ANUS.indb4 2018/05/089:24:182018/05/089:24:18

5
English
SAFETY — Continued
WARNING
When using tools, basic precautions should always be followed, Including the following:
1. Work area
(1) Keep the work area clean and well lighted.
Cluttered benches and dark areas increase the risks
of electric shock, fire, and injury to persons.
(2) Do not operate the Nailer in explosive
atmospheres, such as in the presence of
flammable liquids, gases, or combustible dust.
The Nailer is able to create sparks resulting in the
ignition of the dust or fumes.
(3) Keep bystanders, children, and visitors away
while operating the Nailer. Distractions are able to
result in the loss of control of the Nailer.
2. Personal safety
(1) Stay alert. Focus on your work and use common
sense when working with the Nailer. Do not use
the Nailer while tired, after having consumed
drugs or alcohol, or while under the influence of
medication.
A moment of inattention while operating the Nailer
increases the risk of injury to persons.
(2) Dress properly. Do not wear loose clothing or
jewelry. Contain long hair. Keep hair, clothing,
and gloves away from moving parts.
Loose clothes, jewelry, or long hair increases the
risk of injury to persons as a result of being caught in
moving parts.
(3) Avoid unintentional starting. Be sure the switch
is offbefore connecting to the air supply. Do
not carry the Nailer with your finger on the switch or
connect the Nailer to the air supply with the switch on.
(4)
WARNING
– Disconnect the Nailer from
the air source before making adjustments, doing
Nailer maintenance, clearing jams, touching
the Push Lever, when not in use, leaving work
area, leaving the Nailer outside of the operator's
supervision or control, loading, or unloading the
Nailer, handing it to another person, elevating,
lowering or otherwise moving the Nailer to a new
location. Never attempt to clear a jam or repair the
Nailer unless you have disconnected air hose from
the Nailer and removed all remaining fasteners from
the Nailer. The Nailer should never be left unattended
since people who are not familiar with the Nailer
might handle it and injure the themselves.
Such precautionary measures reduce the risk of
injury to persons.
(5) Do not overreach. Keep proper footing and
balance at all times. Proper footing and balance
enables better control of the Nailer in unexpected
situations.
(6) Use safety equipment. A dust mask, non-skid
safety shoes and a hard hat must be used for the
applicable conditions.
(7)
WARNING
– Risk of hearing loss. Wear
hearing protection.
Hearing protection shall have a Noise Reduction
Rating (NRR) determined in accordance with US
Environmental Protection Agency rules that is
appropriate for noise exposure.
(8) Always wear head protection.
Always wear head protection to protect your
head from flying objects.
(9) Do not attach the hose or Nailer to your body.
Attach the hose to the structure to reduce the risk of
loss of balance if the hose shifts.
(10)
WARNING
– Drive Nails into proper work
surface only. Do not drive nail into other nails. This
is able to cause the fastener to be deflected and hit
someone, or cause the Nailer to react and result in a
risk of injury to persons.
3. Nailer use and care
(1) Use clamps or another practical way to secure
and support the workpiece to a stable platform.
Holding the work by hand or against the body is
unstable and is able to lead to loss of control.
(2) Do not force the Nailer. Use the correct Nailer for
the application. The correct Nailer will do the job
better and safer at the rate for which the Nailer is
designed.
(3) Do not use the Nailer if the switch does not
turn the Nailer on or off. Any Nailer that cannot be
controlled with the switch is dangerous and must be
repaired.
Never use Nailer which is defective or operating
abnormally. If the Nailer appears to be operating
unusually, making strange noises, or otherwise
appears defective, stop using it immediately and
arrange for repairs by a metabo HPT authorized
service center.
000BookNV65ANUS.indb5000BookNV65ANUS.indb5 2018/05/089:24:182018/05/089:24:18

6
English
(4) Disconnect the Nailer from the air source before
making any adjustments, changing accessories,
or storing the Nailer. Such preventive safety
measures reduce the risk of starting the Nailer
unintentionally.
(5) Store the Nailer when it is idle out of reach of
children and other untrained persons. A Nailer is
dangerous in the hands of untrained users.
(6) Maintain the Nailer with care. Keep the
Nailer Clean and lubricated for better and safer
performance.
(7) Check for misalignment or binding of moving
parts, breakage of parts, and any other condition
that may affect the Nailer's operation.
If damaged, have the Nailer serviced before using.
Because of high air pressure in the Nailer, cracks in
the surface are dangerous. To avoid this, do not drop
the Nailer or strike the Nailer against hard surfaces;
and do not scratch or engrave signs on the Nailer.
Many accidents are caused by poorly maintained
Nailers. There is a risk of bursting if the Nailer is
damaged.
(8) Do not use the Nailer that is not in proper
working order. Tags and physical segregation
shall be used for control.
(9) Use only accessories that are identified by
metabo HPT for the specific Nailer. Use of an
accessory not intended for use with the specific
Nailer , increases the risk of injury to persons.
(10)Use only those fasteners listed in the
Accessories section of this manual. Fasteners not
identified for use with this Nailer by metabo HPT are
able to result in a risk of injury to persons or Nailer
damage when used in this Nailer.
4. Service
(1) Tool service must be performed only by qualified
repair personnel.
(2) When servicing a Nailer, use only identical
replacement parts. Use only authorized parts.
(3) Use only the lubricants supplied with the Nailer
or specified by metabo HPT.
5. Air source
(1) Never connect to an air source that is capable
of exceeding 200 psi (13.7 bar 14 kgf/cm2) if a
regulator fails.
Over pressurizing the Nailer is able to result in
bursting, abnormal operation, breakage of the Nailer
or serious injury to persons.
DO NOT EXCEED 120 psi (8.3 bar 8.5 kgf/cm2).
Use only clean, dry, regulated compressed air at the
rated pressure or within the rated pressure range as
marked on the Nailer.
Always verify prior to using the Nailer that the air
source has been adjusted to the rated air pressure or
within the rated air-pressure range.
(2) Never use reactive gases such as oxygen,
carbon dioxide, combustible gases or any
bottled gas as an air source for the Nailer. Such
gases are capable of explosion and serious injury to
persons.
6. Others
(1) Be careful of double fire and being hit by the
Nailer due to spring back (“recoil”).
After driving a nail, the Nailer may recoil causing it to
move away from the work surface.
To reduce risk of injury always manage recoil by:
1) always maintaining control of the Nailer.
2) allowing recoil to move the Nailer away from work
surface.
3) not resisting recoil such that the Nailer will be
forced back into the work surface. In “CONTACT
ACTUATION MECHANISM”, if push lever is
allowed to re-contact work surface before the
trigger is released, an unintended discharge of a
nail will occur. In order to avoid this undesirable
double fire,
○ Intermittent operation (Trigger fire)
1 Pull the trigger rapidly and firmly.
2 Release the trigger QUICKLY.
SAFETY — Continued
WARNING
000BookNV65ANUS.indb6000BookNV65ANUS.indb6 2018/05/089:24:182018/05/089:24:18

7
English
○ Continuous operation (Push lever fire)
1 Do not press the Nailer against the wood with
excessive force.
2 Separate the Nailer from the wood as it recoils
after nailing.
4) keeping face and body parts away from the Nailer.
(2) Never use NON relieving coupler on Nailer. If a
non relieving coupler is used on the Nailer, the Nailer
can remain charged with air after disconnecting
and thus will be able to drive a fastener even after
disconnecting. The Nailer and air hose must have a
hose coupling such that all pressure is removed from
the Nailer when the coupling joint is disconnected.
(3) Check Push Lever before use. Make sure the
Push Lever operates properly, and is not inoperable,
disconnected, or altered. (The Push Lever may be
called “Safety”.) Never use the Nailer unless the Push
Lever is operating properly, otherwise the Nailer
could drive a fastener unexpectedly. Do not tamper
with or remove the Push Lever, or otherwise cause
the Push Lever to become inoperable.
(4) Keep all screws and covers tightly in place. Keep
all screws and covers tightly mounted.
Check their condition periodically. Never use the
Nailer if parts are missing or damaged.
(5) Do not load fasteners with Trigger or Push Lever
depressed. When loading fasteners into the Nailer
or when connecting the air hose,
1) do not depress the Trigger;
2) do not depress the Push Lever; and
3) keep the Nailer pointed downward.
(6) Keep hands and body away from firing head
during use. Never place your hands or feet closer
than 8 inches (200 mm) from the firing head. A
serious injury can result if the fasteners are deflected
by the workpiece, or are driven away from the point of
entry.
(7) When working close to an edge of a workpiece
or at steep angles, or driving fasteners into
thin workpiece use care to minimize chipping,
splitting or splintering, or free flight, ricochet or
piercing of fasteners, which may cause injury.
(8) Never drive fasteners from both sides of a wall
at the same time. The fasteners can be driven into
and through the wall and hit a person on the opposite
side.
(9) Use extra caution when driving the Nailer into
existing walls or other blind areas to prevent
contact with hidden objects or persons on other
side (eg., wires, pipes).
(10)Check for live wires. Avoid the risk of severe
electrical shock by checking for live electrical wires
that may be hidden by walls, floors or ceilings. Turn
offthe breaker switch to ensure there are no live
wires.
(11) Do not lift, pull or lower the Nailer by the hose.
(12)Do not disconnect air hose from Nailer with
finger on Trigger. The Nailer can fire when re-
connected to An air supply.
(13) Handle Nailer correctly. Operate the Nailer
according to this Manual. Never allow the Nailer to
be operated by children, individuals unfamiliar with its
operation or unauthorized personnel.
(14) Never use Nailer for applications other than
those specified in this manual.
(15) Never modify or alter a Nailer. Doing so may cause
it to malfunction and personal injuries may result.
(16) Do not remove Dust Cover. Fragments of wire
collating fasteners can fly out.
(17) Close Nail Guide and do not open it during
operation. If driving fasteners with the Nail Guide
open, the fasteners can be driven away from the
workpiece.
SAFETY — Continued
WARNING
000BookNV65ANUS.indb7000BookNV65ANUS.indb7 2018/05/089:24:182018/05/089:24:18

8
English
RESPONSIBILITIES OF EMPLOYER, TOOL OWNER AND TOOL OPERATOR
1. Ensure that this MANUAL is available to operators
and personnel performing maintenance.
2. Train the operator in the safe use of the Nailer as
described in this MANUAL.
3. Ensure that only persons who have read and
understand this MANUAL operate the Nailer.
4. Ensure that Nailers are used only when operators and
others in work area are wearing EYE PROTECTION,
and other appropriate personal protective equipment
such as HEAD, HEARING, FOOT PROTECTION.
5. Enforce the use of EYE PROTECTION by operators
and others in work area.
6. Ensure that Nailers are kept in safe working order as
described in this MANUAL.
7. Maintain Nailers properly.
8. Ensure that only qualified personnel shall repair
Nailers.
9. Ensure that Nailers that require repair are removed
from service and that tags and physical segregation
are used as a means of control.
SAVE THIS MANUAL AND
KEEP IT AVAILABLE FOR OTHERS!
SAFETY — Continued
000BookNV65ANUS.indb8000BookNV65ANUS.indb8 2018/05/089:24:182018/05/089:24:18

9
English
FUNCTIONAL DESCRIPTION
NOTE: The information contained in this Manual is designed to assist you in the safe operation of the Nailer.
Some illustrations in this Manual may show details or attachments that differ from those on your own Nailer.
NAME OF PARTS
Nose
Piston
Piston O-ring
Exhaust Cover
Driver Blade
Nail Stopper
Outlet (Firing Head)
Body Trigger
Cap
Magazine Cover
Nail Holder
Magazine Assembly
Dust Cover
Air Plug
Knob
Push Lever
Magazine
NOSE PART
Nail Guide
Feeder
Feed Piston
Feed Spring
000BookNV65ANUS.indb9000BookNV65ANUS.indb9 2018/05/089:24:182018/05/089:24:18

10
English
SPECIFICATIONS
Operating pressure 80 – 120 psi (5.4 – 8.3 bar 5.5 – 8.5 kgf/cm2)
Dimensions
Length × Height × Width 12" × 12-7/16" × 5-13/64" (305 mm × 316 mm × 132 mm)
Weight 5.9 lbs (2.7 kg)
Nail capacity 200 – 300 nails (1 coil)
Air consumption .049 ft3/cycle at 100 psi
(1.4 ltr/cycle at 6.9 bar)
(1.4 ltr/cycle at 7 kgf/cm2)
Air inlet 3/8 NPT Thread
NAIL SELECTION
WARNING
● Be sure to use only the genuine metabo HPT nails for the NV65AN. The use of any other nails can result in
tool malfunction and/or nail breakdown, leading to serious injuries.
Only nails shown in the Table below can be driven with this Nailer.
Wire-collated coil nails
Min. Max.
.080"
(2.0 mm)
1-1/2" (38 mm)
.189"
(4.8 mm)
.099"
(2.5 mm)
2-1/2" (65 mm)
.236"
(6 mm)
ACCESSORIES
WARNING
● Accessories other than those shown below can lead to malfunction and resulting injuries.
STANDARD ACCESSORIES
1
2
NV65AN, NV65AN(S)
1 Eye protection ..........................................................1
NV65AN
2 Sequential actuation trigger kit.................................1
000BookNV65ANUS.indb10000BookNV65ANUS.indb10 2018/05/089:24:182018/05/089:24:18

11
English
OPTIONAL ACCESSORIES ... sold separately
○ Pneumatic Tool Lubricant
.8 oz. (25 cc) oil feeder (Code No. 877153)
4 oz. (120 cc) oil feeder (Code No. 874042)
1 quart (1 ltr) can (Code No. 876212)
NOTE: Accessories are subject to change without any
obligation on the part of metabo HPT.
OPERATING INSTRUCTIONS
APPLICATIONS
○ Making wooden palettes, drums, and export wooden
boxes.
○ Packing operations in manufacturing plants, and
other types of packing and crating work in general.
○ Construction wooden work such as floor and wall
framing, roof decking, subflooring.
○ Mobile and modular home construction.
BEFORE OPERATION
Read section titled “SAFETY” (pages 4 – 8).
Make sure of the followings before operation.
WORKING ENVIRONMENT
WARNING
● No flammable gas, liquid or other flammable
objects at worksite.
● Clear the area of children or unauthorized
personnel.
AIR SUPPLY
DANGER
● NEVER use reactive gases or
other bottled gases.
Explosion may occur.
WARNING
● Never connect Nailer to pressure
which potentially exceeds 200 psi
(13.7 bar 14 kgf/cm2) if a regulator fails.
● Never use non relieving coupler on Nailer.
1. Power source
○ Use only clean, dry, regulated compressed air as a
power source for this Nailer.
○ Air compressors used to supply compressed air to
this Nailer must comply with the requirements of
the latest version of ANSI Standard B 19.3 “Safety
Standard For Compressors For Process Industries.”
○ Moisture or oil in the air compressor may accelerate
wear and corrosion in the Nailer.
Drain daily.
2. Filter-Regulator-Lubricator
○ Use a regulator with a pressure range of 0 – 120 psi
(0 – 8.3 bar 0 – 8.5 kgf/cm2).
○ Filter-regulator-lubricator units supply an optimum
condition for the Nailer and extend the Nailer life.
These units should always be used.
Filter ............The filter removes moisture and dirt
mixed in compressed air.
Drain daily unless fitted with an
automatic drain.
Keep the filter clean by regular
maintenance.
Regulator ......The regulator controls the operating
pressure for safe operation of the Nailer.
Inspect the regulator before operation to
be sure it operates properly.
Lubricator ....The lubricator supplies an oil mist to the
Nailer.
Inspect the lubricator before operation
to be sure the supply of lubricant is
adequate.
Use metabo HPT pneumatic tool
lubricant.
000BookNV65ANUS.indb11000BookNV65ANUS.indb11 2018/05/089:24:182018/05/089:24:18

12
English
○ Filter-regulator-lubricator units should always be
used.
Keep the lubricator filled with metabo HPT pneumatic
tool lubricant.
○ If a lubricator is not available, supply 5 – 10 drops of
metabo HPT pneumatic tool lubricant into the air plug
on the Nailer twice a day.
COLD WEATHER CARE
○
Do not store the Nailer in a cold weather environment.
Keep the Nailer in a warm area until beginning the
work.
○ If the Nailer is already cold, bring it in a warm area
and allow the Nailer to warm up before use.
1 Reduce the air pressure to 80 psi (5.4 bar
5.5 kgf/cm2).
2 Remove all nails from the Nailer.
3 Connect the air hose and free-fire (blank-fire) the
Nailer.
The lowered air pressure will be enough to free-
fire the Nailer.
Slow speed operation tends to warm up the
moving part.
CAUTION
● Do not free-fire the Nailer at high pressure.
TESTING THE NAILER
DANGER
● Operators and others in work
area MUST wear safety
glasses with side shields
which conforms to ANSI Z87.1
specifications.
Ordinary eyeglasses do not
provide adequate protection.
WARNING
● Never use Nailer unless push lever is
operating properly.
Before actually beginning the nailing work, test the Nailer
by using the checklist below. Conduct the tests in the
following order.
If abnormal operation occurs, stop using the Nailer
and contact a metabo HPT authorized service center
immediately.
(1) DISCONNECT AIR HOSE FROM NAILER.
REMOVE ALL NAILS FROM NAILER.
Nailer Side
Filter
Lubricator
Compressor Side
Regulator
3. Air hose
Compressed air supply hoses shall have a minimum
working pressure rating equal to or greater than the
pressure from the power source if a regulator fails, or
150 psi (10.4 bar 10.6 kgf/cm2), whichever is greater.
4. Air consumption
Using the Air consumption table and the Air
compressor size formula, find a correct compressor
size.
Air consumption table
Operating pressure psi (bar)
(kgf/cm2)
80
(5.5)
(5.6)
90
(6.2)
(6.3)
100
(6.9)
(7)
Air consumption ft3/cycle
(Itr/cycle) .039 (1.1) .042 (1.2) .049 (1.4)
Air compressor size formula
Amount of air required
=number of Nailers
× average nails driven each minute per Nailer
× air consumption at given air pressure
× safety factor (always 1.2)
Example: 2 Nailers operating at 100 psi driving 30
nails per minute
Amount of air required
=2 × 30 × .049 (1.4) × 1.2
=3.5 CFM (ft3/min) (101 ltr/min)
After making the calculations as shown above, you
should find a compressor providing 3.5 CFM of air
that is required.
LUBRICATION
It is important that the Nailer be properly lubricated.
Without proper lubrication, the Nailer will not work
properly and parts will wear prematurely.
○ Use metabo HPT pneumatic tool lubricant.
Do not use detergent oil or additives. These lubricants
will harm the O-rings and other rubber parts. This will
cause the Nailer to malfunction.
000BookNV65ANUS.indb12000BookNV65ANUS.indb12 2018/05/089:24:182018/05/089:24:18

13
English
□ ALL SCREWS MUST BE TIGHTENED.
If any screws are loose, tighten them.
□ THE PUSH LEVER AND TRIGGER MUST MOVE
SMOOTHLY.
Push Lever
Trigger
Do not connect
air hose
(2) Adjust the air pressure to 70 psi (4.9 bar 5 kgf/cm2).
Connect the air hose.
(3) REMOVE ALL NAILS FROM NAILER.
Do not push or rest Push Lever against any surface or
Switching device will not turn.
CONTACT ACTUATION MECHANISM
Identified by: BLACK TRIGGER
(1) With the Nailer offthe wood, pull the Trigger.
Next, depress the Push Lever against the wood.
□THE NAILER MUST OPERATE.
(2) Next, depress the Push Lever against the workpiece.
Now pull the Trigger.
□THE NAILER MUST OPERATE.
(3) If no abnormal operation is observed, you may load
nails in the Nailer.
Drive nails into the workpiece that is the same type to
be used in the actual application.
□ THE NAILER MUST OPERATE PROPERLY.
SINGLE SEQUENTIAL ACTUATION
MECHANISM
Identified by: RED TRIGGER
(1) Remove the finger from the trigger and press the
push lever against the wood.
□ THE NAILER MUST NOT OPERATE.
Do not pull Trigger
Depress
Push Lever
(2) Separate the push lever from the wood.
Next, point the nailer downward, pull the trigger and
then wait in that position for 5 seconds or longer.
□ THE NAILER MUST NOT OPERATE.
000BookNV65ANUS.indb13000BookNV65ANUS.indb13 2018/05/089:24:182018/05/089:24:18

14
English
Knob
Nail guide Magazine cover
(2) Adjust the position of the plate according to the nail
length.
The nail will not feed smoothly if the plate is not
correctly adjusted.
Magazine Nail holder
Magazine cover
NOTE: Before loading nails in the magazine, adjust
the plate. If the magazine cover is forcibly
closed without adjusting the plate correctly,
the nail holder may be damaged.
1 Slide in vertical direction possible.
Lift or lower the nail holder to accept different
length nails.
2 Adjust the plate to the nail length reference points
on the magazine cover and turn the nail holder 45
degrees.
Nail holder
Magazine
2
1
11/2"
13/4"
2 21/4"
21/2"
Pull Trigger
(3) First pull the Trigger.
Next, depress the Push Lever against the wood.
□ THE NAILER MUST NOT OPERATE.
(4) Without touching the Trigger, depress the Push Lever
against the wood.
Next, pull the Trigger.
□THE NAILER MUST OPERATE.
ADJUSTING AIR PRESSURE
WARNING
● Do not exceed
120 psi (8.3 bar
8.5 kgf/cm2).
Adjust the air pressure at recommended operating
pressure 80 – 120 psi (5.4 – 8.3 bar 5.5 – 8.5 kgf/cm2)
according to the length of nails and the hardness of
workpiece.
The correct air pressure is the lowest pressure which will
do the job. Using the Nailer at a higher than required air
pressure unnecessarily over stresses the Nailer.
LOADING NAILS
WARNING
● When loading nails into Nailer,
1) do not pull trigger;
2) do not depress push lever; and
3) keep Nailer pointed downward.
(1) Grip the nail guide and knob with finger.
Press the knob down and swing the nail guide open.
And open the magazine cover.
000BookNV65ANUS.indb14000BookNV65ANUS.indb14 2018/05/089:24:192018/05/089:24:19

15
English
(3) Place the nail coil into the magazine.
Uncoil enough nails to reach the driving hole.
Magazine
Nail holder
Nails
(4)
1 Uncoil enough nails to reach the driving hole.
2 Insert the first nail into the driving hole and the
second nail between the two pawls of the feeder.
3 Fit the nail heads in the guide slot.
Nail Guide
First nail
1
4
2
Feeder
Guide surface
Driving hole Guide slot
1
4
2
3
2
4
Pulling the nails to the right, swing the nail guide
closed.
(5) Close the magazine cover first and swing the nail
guide closed.
(6) Lock the knob correctly.
Magazine cover
Nail guide
Knob
NOTE: Be careful not to deform the collated wires and
not to disengage the nails with the guide surface.
Otherwise, the nail guide will not close correctly.
NAILER OPERATION
Read section titled “SAFETY” (pages 4 – 8).
DANGER
● Operators and others in work
area MUST wear safety
glasses with side shields
which conforms to ANSI Z87.1
specifications.
Ordinary eyeglasses do not
provide adequate protection.
WARNING
● Only person who have read
and understand this
MANUAL should operate the
Nailer.
● NEVER point tool at yourself
or others in work area.
● Keep fingers AWAY from trigger when not
driving nails to avoid accidental discharge.
● Know and understand what trigger system
you are using.
Please read and understand “Methods of
Operation” below.
● Before starting work, check the types of
operation to drive nails.
● Never place your hands or body closer than 8
inches (200 mm) from firing head when using.
● Do not drive nails into other nails; nails can
ricochet and hurt someone.
● Do not actuate Nailer unless Nailer is placed
firmly against the workpiece.
● In order to avoid double fire or unwanted
ejection of a nail due to bouncing of the
Nailer,
1) do not push Nailer on workpiece with
strong force;
2) take Nailer away from workpiece using
recoil;
3) release trigger quickly when performing
trigger fire.
● When working close to an edge of a workpiece
or at steep angles, or driving fasteners into
thin workpiece use care to minimize chipping,
splitting or splintering, or free flight, ricochet or
piercing of fasteners, which may cause injury.
000BookNV65ANUS.indb15000BookNV65ANUS.indb15 2018/05/089:24:192018/05/089:24:19

16
English
● Never drive nails from both sides of a wall
at the same time. Nails can be driven into
and through the wall and hit a person on the
opposite side.
● Never use Nailer which is defective or
operating abnormally.
● Do not use Nailer as hammer.
● Disconnect air hose from Nailer when:
1) it is not in use;
2) leaving work area;
3) elevating, lowering or otherwise moving it
to another location;
4) handing it to another person;
5) performing any maintenance or repairs;
6) clearing a jam;
7) Nailer is outside of the operator's
supervision or control;
8) removing nails from the magazine; and
9) turning the top cover.
There are two types of operation to drive nails with this
Nailer.
Use CONTACT ACTUATION MECHANISM or SINGLE
SEQUENTIAL ACTUATION MECHANISM in accordance
with the work to be performed.
Explanation of the various nailing operations
○ CONTACT ACTUATION MECHANISM: First, press
the push lever against the wood; next, pull the trigger
to drive the nail. Or,
pull the trigger; next, press the push lever against the
wood to drive the nail.
If the trigger is held back, a nail will be driven each
time the push lever is pressed against the wood.
NV65AN is shipped with CONTACT ACTUATION KIT.
When switching from CONTACT ACTUATION KIT
TO SEQUENTIAL ACTUATION KIT, replace to
SEQUENTIAL ACTUATION KIT.
Punch Contact actuation
trigger kit
Sequential actuation trigger kit
Spiral Pin
○ SINGLE SEQUENTIAL ACTUATION MECHANISM:
First, press the push lever against the wood; next,
pull the trigger to drive the nail.
After nailing once, nailing will not be possible again
until the trigger is released and pressed again.
METHODS OF OPERATION
This Nailer is equipped with the push lever and does
not operate unless the push lever is depressed (upward
position).
There are three methods of operation to drive nails with
this Nailer.
They are:
1. Intermittent operation (Trigger fire):
CONTACT ACTUATION MECHANISM, SINGLE
SEQUENTAL ACTUATION MECHNISM
2. Continuous operation (Push lever fire):
CONTACT ACTUATION MECHANISM
3. Single sequential operation (Trigger fire):
SINGLE SEQUENTIAL ACTUATION MECHANISM
(1) Intermittent operation (Trigger fire)
WARNING
● To avoid double firing or accidental firing due
to recoil.
1) Pull the trigger rapidly and firmly.
1 Position the nail outlet on the workpiece with
finger offthe trigger.
2 Depress the push lever firmly until it is completely
depressed.
3 Pull the trigger to drive a nail.
4 Remove finger from the trigger.
To continue nailing in a separate location, move the nailer
along the wood, repeating steps
1 – 4 as required.
Push Lever
2
3
Trigger
000BookNV65ANUS.indb16000BookNV65ANUS.indb16 2018/05/089:24:192018/05/089:24:19

17
English
WARNING
● A nail will fire each time the trigger is
depressed as long as the push lever remains
depressed.
(2) Continuous operation (Push lever fire)
Using CONTACT ACTUATION MECHANISM
WARNING
● To avoid double firing or accidental firing due
to recoil.
1) Do not press the nailer against the wood with
excessive force.
2) Separate the nailer from the wood as it
recoils after nailing.
1 Pull the trigger with the Nailer offthe workpiece.
2 Depress the push lever against the workpiece to
drive a nail.
3 Move the Nailer along the workpiece with a
bouncing motion.
Each depression of the push lever will drive a nail.
As soon as the desired number of nails have been
driven, remove finger from the trigger.
Previously pull
the trigger
1
3
(3) Single sequential operation (Trigger fire)
WARNING
● To avoid double firing or accidental firing due
to recoil.
1) Pull the trigger rapidly and firmly.
1 Position the nail outlet on the workpiece with
finger offthe trigger.
2 Depress the push lever firmly until it is completely
depressed.
3 Pull the trigger to drive a nail.
4 Remove finger from the trigger.
To continue nailing in a separate location, move the nailer
along the wood, repeating steps 1 – 4 as required.
Push Lever
2
3
Trigger
WARNING
● Keep your finger offthe trigger except during
fastening operation, because serious injury
could result if the push lever accidentally
contacts you or others in work area.
● Keep hands and body away from the
discharge area. This metabo HPT nailer may
bounce from the recoil of driving a fastener
and unwanted subsequent fastener may be
driven, possibly causing injury.
● Some types of loaded nails can spark out of
the muzzle during a nail driving operation.
Exercise caution!
The SINGLE SEQUENTIAL ACTUATION MECHANISM
is for use where precision fastener placement is desired.
The SINGLE SEQUENTIAL ACTUATION MECHANISM
may reduce the possibility of bodily injury to you or others
in the work area compared to the CONTACT ACTUATION
MECHANISM. This is because it is less likely to drive
an unwanted nail if you keep the trigger pulled and
accidentally bump the push lever against yourself or
others.
The SINGLE SEQUENTIAL ACTUATION MECHANISM
may also reduce the speed of operation compared
to the CONTACT ACTUATION MECHANISM. The
SINGLE SEQUENTIAL ACTUATION MECHANISM is
recommended to inexperienced users.
NOTE:
● If all warnings and instructions are followed,
safe operation is possible with two systems:
CONTACT ACTUATION MECHANISM and SINGLE
SEQUENTIAL ACTUATION MECHANISM.
000BookNV65ANUS.indb17000BookNV65ANUS.indb17 2018/05/089:24:192018/05/089:24:19

18
English
● Always handle nails and package carefully. If nails
are dropped, collating wire may be broken.
● After nailing:
1) disconnect air hose from the Nailer;
2) remove all nails from the Nailer;
3) supply 5 – 10 drops of metabo HPT pneumatic
tool lubricant into the air plug on the Nailer; and
4) open the petcock on the air compressor tank to
drain any moisture.
CHANGING THE EXHAUST DIRECTION
WARNING
● When changing the exhaust direction, be
sure to remove your finger from the trigger
and disconnect the air hose from the nailer.
The direction of the exhaust vent can be changed by
turning the top cover.
Top Cover
Exhaust Vent
000BookNV65ANUS.indb18000BookNV65ANUS.indb18 2018/05/089:24:192018/05/089:24:19

19
English
MAINTENANCE
NOTE: The information contained in this Manual is designed to assist you in the safe maintenance of the Nailer.
Some illustrations in this Manual may show details or attachments that differ from those on your own Nailer.
MAINTENANCE AND INSPECTION
Read section titled “SAFETY” (pages 4 – 8).
WARNING
● Disconnect air hose and remove all nails
from Nailer when:
1) doing maintenance and inspection; and
2) clearing a jam.
1. Clearing a jam
Remove a jammed nail in the following order:
1 DISCONNECT AIR HOSE.
2 Open the nail guide.
3 Insert a rod into the outlet.
Tap the rod with a hammer.
Hammer
Rod
Outlet
Disconnect
air hose
1
4
Remove the jammed nail with a slotted screw
driver.
Nail Slotted Screw Driver
5 Cut the deformed collated wire with nippers.
Correct the deformation.
6 In case of frequent jam, contact a metabo HPT
authorized service center.
2. Inspecting the push lever
1 DISCONNECT AIR HOSE.
2 Clean the push lever sliding part.
Lubricate it with metabo HPT pneumatic tool
lubricant.
Lubricate
Disconnect
air hose
1
3. Inspecting the feeders
1 DISCONNECT AIR HOSE.
2 Clean the knob sliding part.
Lubricate it with metabo HPT pneumatic tool
lubricant.
Nail
Guide
Knob
Push Lever
Disconnect
air hose
1
3
Open the nail guide and remove dust.
Lubricate the sliding groove of the feeder and
shafts.
000BookNV65ANUS.indb19000BookNV65ANUS.indb19 2018/05/089:24:192018/05/089:24:19

20
English
Nail Guide
Nail Stopper
Feeder Feeder Shaft
Feed Piston
4 Lubricate the feeding surfaces of the nose and
the nail guide after cleaning.
This promotes smooth operation and prevents
rust.
CAUTION
●
Check that the nail stopper slides smoothly by
pushing them with finger.
If not smooth, nails can be driven at an irregular
angle and hurt someone.
4. Inspecting the magazine
1 DISCONNECT AIR HOSE.
2 Clean the magazine. Remove dust or wooden tips
which may have accumulated in the magazine.
5. Storing
○ When not in use for an extended period, apply a
thin coat of the lubricant to the steel parts to avoid
rust.
○ Do not store the Nailer in a cold weather
environment.
Keep the Nailer in a warm area.
○ When not in use, the Nailer should be stored in a
warm and dry place.
Keep out of reach children.
6. WARNING LABEL
Do not use the Nailer with missing or damaged
WARNING LABEL.
A new WARNING LABEL is available from a
metabo HPT authorized service center.
Warning
Label
7. Maintenance chart (See page 21)
8. Operator troubleshooting (See page 21)
9. Service parts list
CAUTION
●
Repair, modification and inspection of
metabo HPT Power Tools must be carried out by
a metabo HPT Authorized Service Center.
This Parts List will be helpful if presented
with the tool to the metabo HPT Authorized
Service Center when requesting repair or other
maintenance. In the operation and maintenance
of power tools, the safety regulations and
standards prescribed in each country must be
observed.
MODIFICATIONS:
metabo HPT Power Tools are constantly being improved
and modified to incorporate the latest technological
advancements.
Accordingly, some parts may be changed without prior
notice.
SERVICE AND REPAIRS
WARNING
● Only service personnel trained by
metabo HPT, distributor or employer shall
repair the Nailer.
● Use only parts supplied or recommended by
metabo HPT for repair.
All quality Nailers will eventually require servicing or
replacement of parts because of wear from normal use.
NOTE: Specifications are subject to change without any
obligation on the part of metabo HPT.
000BookNV65ANUS.indb20000BookNV65ANUS.indb20 2018/05/089:24:202018/05/089:24:20
