Freeman P50LSLW User manual

MODEL:P 50LSLW
SAVETHISMANUALFORFUTUREREFERENCE
WARNING:
FailuretofollowwarningscouldresultinDEATHORSERIOUSINJURY.
IMF500700AV08/14
HTTP://WWW.FREEMANTOOLS.COM
1-888-669-5672
PRIMEGLOBALPRODUCTS,INC.
HTTP://WWW.FREEMANTOOLS.COM
1-888-669-5672
PRIMEGLOBALPRODUCTS,INC.

Thewarningsand precautionsdiscussedinthemanualcannotcoverallpossibleconditionsand
situationsthatmayoccur. Itmustbeunderstood bytheuserthatcommon senseand caution are
factorswhichcannotbebuiltintothisproduct,butmustbesuppliedbytheuser.
WARNING:
GENERALSAFETYRULES
UNPACKING
FEATURES
OPERATION
MAINTENANCE
RECOMMENDEDHOOKUP
TROUBLESHOOTING
WEARINGPARTS
WARRANTIES
PREPARETHETOOL
LOADINGCLEATNAILS
LOADINGSTAPLES
CHANGETHEFOOTPLATE
SETTINGTHEAIRPRESSURE
OPERATINGTHETOOL
CLEARINGJAMS
P3
P5
P5
P6
P6
P6
P7
P7
P8
P8
P9
P
P10 11
P11
P12
SAVETHISMANUAL
Keepthismanualforthesafetywarnings,
precautions,operations,inspectionsand
maintenance.Keepthismanualandthe
receiptinasafeanddryplaceforfuture
reference.
Inthismanual,on the labels,packages andall otherinformation provided withthistool.The following
signalwordsandmeaningsareintendedtoexplainthelevelsofriskassociated withthistool.
Toavoidseriouspersonalinjury,donot
attempttousethisproductuntilyouread
thoroughlyandunderstandit
completely.Save thismanualand review
frequentlyforcontinuing safeoperation
andinstructing otherswho mayusethis
tool.
themanual
WARNING:
!
SYMBOLS SIGNAL MEANING
!
!
WARNING:
CAUTION:
CAUTION:
Indicates apotentiallyhazardous situation,which,ifnotavoided,
couldresultindeathorserious injury.
Indicates apotentiallyhazardous situation,which,ifnotavoided,
mayresultinminorormoderateinjury.
(Withoutsymbol)Indicates asituationthatmayresultin
propertydamage.
GENERALSAFETYRULES
WORKAREA
Keeptheworkareacleanandwelllighted.
Keepbystanders,children, and othersaway
whileoperatingthetool.
Cluttered benches and darkareasincreasethe
risksofaccidents.
Distractionscould
resultinimproperuseandcauseinjury.
Donotoperatethetool inexplosive
atmospheres,suchasin thepresenceof
flammableliquids,gases,ordust.
Avoidunintentionalmisfires.
The tool
createsasparkwhichmayigniteflammable
liquids,gasesordust.
Always use
cautiontoavoidaccidentallyfiring.Donot point
towardsyourselforanyonewhetheritcontains
fastenersornot.
CALIFORNIAPROPOSITION65
WARNING:
!
Whenusingtools,basicprecautions
shouldalwaysbefollowed, including the
following:
WARNING:
!
Thisproductoritspowercordmay
containchemicalsknowntotheState
ofCaliforniatocausecancerandbirth
defectsorotherreproductiveharm.
Washhandsafterhandling.
PERSONALSAFETY
Alwaysweareyeprotection.
Alwayswearhearingprotection whenusing
thetool.
Operatorand
othersintheworkarea shouldalwayswear
ANSI-approvedsafetygoggleswithside
shields. Eyeprotection isusedtoguardagainst
flyingfastenersanddebris,which may cause
severeeyeinjury.
Prolongedexposuretohighintensity
noisemaycausehearingloss.
Usesafetyequipment.Adustmask,non-skid
safetyshoesandahardhatmustbeused for
the applicableconditions.Wearafull face shield
ifyouareproducing metalfilingsorwoodchips.
Dressproperly.
Stay alert,watchwhatyouaredoingand
usecommonsensewhenoperating a
powertool.
Keepproperfootingandbalanceatalltimes.
Make surethehoseisfree ofobstructionsor
snags.
Donot wearlooseclothing or
jewelry.Containlonghair.Keep yourhair,
clothing,and gloves awayfrommoving parts.
Looseclothes,jewelry,orlonghaircan be
caughtinmovingparts.
Donotuse toolwhiletired orunder
the influence of drugs, alcohol, ormedication.A
momentofinattentionwhileoperatingthetool
maycauseserious injury.
Properfooting and balanceenablesbetter
controlofthetoolinunexpected situations.
Entangledorsnarledhosescan cause
loss ofbalance orfooting andmay become
damaged,resulting inpossibleinjury.
MODEL:PLSLW50
0302
MODEL:PLSLW50
HTTP://WWWFREEMANTOOLSCOM1-888-669-5672.. HTTP://WWWFREEMANTOOLSCOM1-888-669-5672..
INSTRUCTIONSPERTAININGTOARISKOF
FIRE,ELECTRICSHOCK,ORINJURYTO
PERSONS.

MODEL:PLSLW50 MODEL:PLSLW50
LOADINGTOOL
Donotloadthetool withfastenerswhen
anyoneoftheoperatingcontrolsis
activated.
Neverplaceahand oranypartofbodyin
fastenerdischargeareaoftool.
Neverpointtoolatanyone.
Thewarningsand precautionsdiscussed
abovecannotcoverall possible
conditionsandsituationsthatmay occur.
Itmustbeunderstoodbytheuserthat
commonsenseand caution arefactors
whichcannotbebuiltintothisproduct,
butmustbesuppliedbytheuser.
WARNING:
!
UNPACKING
Thistoolhasbeenshippedcompletely
assembled.
Makesurethatallitemslistedinthepacking
listareincluded.
Carefullyremovethetoolandany
accessoriesfromthebox.
Inspectthetoolcarefullytomakesureno
breakageordamageoccurredduring
shipping.
Donotdiscardthepackingmaterialuntilyou
havecarefullyinspectedandsatisfactorily
operatedthetool.
Ifanypartsaredamagedormissing,please
call1-888-669-5672.
PACKINGLIST
2In1flooring nailer
Colorbox
Mallet
Airconnector(Pre-installed)
Adjustmenttools
Lubrication oil
Anti-dustcap
5/8"otplate
Instructionmanual
(Pre-installed)
fo
FEATURES
SPECIFICATIONS
Operation pressure:
Nailscapacity:
Toolweight:
Airinlet:
Fasteners:
70-115psi
L:100pcs
U9
9.08lbs
1/4"NPT
:0pcs
FEATURES
REVOLUTIONARY2IN1DESIGN
NO-MARDESIGN
ANODIZEDALUMINUMMAGAZINE
DURABLECONSTRUCTION
AIRFILTER
MALLETINCLUDED
ForusewithStaples,L-Cleats.
Forlonglastingdurability.
Lightweightand durablyconstructed ofhigh-
strengthaluminumandheattreatedsteelparts.
Keepsinteriorcomponentsdebrisfree,
extendingtoollife.
Provides increasedprotectionfrommarring
whenworkingwithafinishedflooring surface.
Ifanypartsaremissingdonotoperate
thistool until themissing partsare
replaced.Failuretodosocould resultin
possibleseriouspersonalinjury.
WARNING:
!
Donotattempttomodifythistoolor
createaccessoriesnotrecommendedfor
usewiththistool. Anysuchalterationor
modificationismisuseandcouldresult
inhazardouscondition leadingto
possibleseriouspersonalinjury.
WARNING:
!
04 05
TOOLUSEANDCARE
Knowthistool.
Useonlyfastenersthatarerecommended
foryourmodels.
Checkformisalignmentorbinding of
movingparts,breakageofparts,andany
othercondition thatmay affectthetool's
operation.
Maintain toolswithcare.
Storetoolsoutofthereachofchildrenand
otheruntrainedpeople.
Checkoperationofthetoolbeforeuse.
Do notforcetool.
Useclampsoranotherpracticalway to
secureandsupport theworkpiecetoa
stableplatform.
Keep thetooland itshandledry,clean and
free fromoiland grease.
Donotusethetoolasahammer.
Donotusethetool ifitleaksairordoesnot
functionproperly.
Readmanualcarefully,learn
itsapplications andlimitations,as well asthe
specificpotentialhazardsrelatedtothistool.
Donotuse thewrong
fastenersorloadthefastenersincorrectly.
If damaged,havethe toolserviced
beforeusing.Many accidentsarecausedby
poorlymaintainedtools. Keeptoolclean.A
properlymaintained tool,reduces therisk of
binding and iseasiertocontrol.
Toolsaredangerous
inthe handsofuntrainedusers.
Usethecorrecttoolforyour
application.Thecorrecttoolwilldo thejob better
andsaferattherateforwhichitisdesigned.
Holdingatoolbyhandor
againstthebodyisunstableand mayleadto
lossofcontrol.
Always use aclean
clothwhen cleaning.Neveruse brake fluids,
gasoline,petroleum-based products,orany
strongsolventstocleanyourtool.
Neverusethistool in amannerthatcould
causeafastenertobedirectedtoward
anythingotherthantheworkpiece.
Alwayscarrythetoolbythehandle.Never
carrythetoolbytheairhose.
Donotoperatethetool ifitdoesnotcontain
alegiblewarninglabel.
TOOLSERVICE
Useonlyaccessoriesthatareidentifiedby
themanufacturerforthespecifictoolmodel.
Useofunauthorizedpartsorfailureto
followmaintenanceinstructionsmay create
ariskofinjury.
Useonlythelubricantssuppliedwiththe
toolorspecifiedbythemanufacturer.
Toolservicemustbeperformedonlyby
qualifiedrepairpersonnel.
OPERATION
Donotdrive fastenersnearedgeofmaterial.
The workpiecemay splitcausing the fasteneror
ricochet,injuring you orpeoplearound.
Neverengageinhorseplay.
Donotdrive fastenersontop ofother
fastenersorwiththetool atan overlysteep
angleasthismaycausedeflection of
fastenerswhichcouldcauseinjury.
Donotactuatethetoolunless you intendto
driveafastenerintotheworkpiece.
Alwayshandlethetoolwithcare:
◆Respectthetoolasaworkingimplement.
◆
◆Keepothersasafedistance fromthetool
whiletoolisinoperation asaccidental
actuation may occur,possiblycausinginjury.
AIRSUPPLYANDCONNECTIONS
Theconnectoronthetoolmustnothold
pressurewhenairsupplyisdisconnected.
Donotuseoxygen,combustiblegasesor
bottledgassesasapowersourceforthistool.
Explosionmayoccur,causinginjuryordeath.
If
anincorrectfittingisused,thetoolcan remain
charged withairafterdisconnectingand thus will
beabletodriveafastenerevenaftertheairlineis
disconnected,possiblycausinginjury.
Donotconnectwithanaircompressor
whichcanpotentiallyexceed200Psi.
Alwaysdisconnectairsource:
Astoolmayburst,possiblycausinginjury.
CompatibleWithGenericBrandsOf15.5Ga
Staples&16Ga.L-Cleats.
Beforeunloadingormaking adjustments.
Whenmaintainingthe tool.
Whenclearingajam.
Whentouching thesafetyyoke.
Whentoolisnotinuse.
Whenmovingtoadifferentworkarea.
Suchprecautionarymeasures reduce theriskof
injurytopersons.
HTTP://WWWFREEMANTOOLSCOM1-888-669-5672.. HTTP://WWWFREEMANTOOLSCOM1-888-669-5672..
(15.5Ga.Staples)
38mm
45mm
50mm
1-1/2"
1-3/4"
2"
38mm
45mm
50mm
1-1/2"
1-3/4"
2"
(16Ga.Lcleats)
12.7mm(1/2")
7.5mm(3/10")

MODEL:PLSLW50 MODEL:PLSLW50
06 07
HTTP://WWWFREEMANTOOLSCOM1-888-669-5672.. HTTP://WWWFREEMANTOOLSCOM1-888-669-5672..
Useonlythosefastenersrecommended
forusewiththistool.Fastenersnot
identifiedforusewiththistoolbythetool
manufacturerareabletoresultinariskof
injurytopersonsortooldamagewhen
usedinthistool.
WARNING:
!
Thetoolmayfirewhen itfirstconnected
totheairsource.Alwaysconnectthetool
totheairsourcebeforeloading fasteners
topreventinjuryfromunintendedcycling.
Alwaysmakesurethetool'smagazineis
emptyatthebeginningofeachwork
session, beforeconnecting toanair
source.
WARNING:
!
OPERATION
The toolisshipped withtheArmpart detached
fromtheMainbodypart. (A)
PREPARETHETOOL
SettheArm(A)againstthe Handle.
Wrench-tightentheNuts(B)untiltheArm(A)and
Handle (C)aresecuredandtheArmislocked
againstHandle. (A) (C)
Followtheseinstructionstopreparethetoolfor
using.
1.
2.
Nut(B)
Hex. Bolt
Arm(A)
Handle (C)
Prepared
Flooring Nailer
LOADINGLCLEATNAILS
Connectthetooltotheairsource.
Pressdownon the Latch Button(F).Pullthe
Magazine Cover(D)backtothe end ofthe
magazine.
Place fullclipofdesired fastenersintomagazine
fromthe side.Upto100cleatnailscan be
loaded intomagazine.Benoted that, when
loading the Lcleatnails,the side withtheLhead
shouldbe inthe leftoftheMagazine Pusher(E).
PushtheMagazine Cover(D)forwarduntil
Magazine Pusher(E)popsup.
1.
2.
3.
4.
LCleatHead
Direction
MagazinePusher
(E)
Magazine
Cover
(D)
LOADINGSTAPLES
Connectthetooltotheairsupply.
Pressdownthe LatchButton(F),the pull the
Magazine Cover(D)back totheend ofthe
magazine.
Place afull clipof1/2"crownstaplesinthe
magazine fromthe top.Upto90 staplescan be
loadedintomagazine.
Pushthe MagazineCover(D)forwarduntil the
Magazine Pusher(E)popsup.
1.
2.
3.
4.
Loadstaples
fromthetop
CHANGETHEFOOTPLATE
The toolisequipped withafactorypre-installed
3/4"FootPlate(G).And an additionaluninstalled
5/8"footplate.Tochangethe plate:
Disconnectthetoolfrom theairsource.
Emptythe magazinecompletely.
Firethe toolintoapiece ofscrapwood to
ensurethereisno compressed airorfasteners
leftinthe tool.
Setthe toolon itsside toexpose thefour
Screws(H).
Removethe fourScrews(H),then,removethe
footplate.
Align the fourscrewholesinthereplacement
footplatewiththe fourthreadedmounting
holes.
Using the fourscrewsyou removedjustnow,
securethe replacementfootplatetothe tool.
Ensurethe correctFootPlateisinstalled by
firingintoascrappieceofflooringandchecking
forproperfastenerplacement.
Disconnectthetool fromtheairsource
wheneverchangingthefootplate.
Make surethereisnofastenerin the
magazinebeforechangingthefootplate.
WARNING:
!
⒈
⒉
⒊
⒋
⒌
⒍
⒎
⒏
Screws(E)
Footplate(D)
The amountofairpressurerequired depends
on the sizeofthe fastenersand theworkpiece
material.
Begintestingthe depthofdrive bydrivingatest
nailintothe sametypeofworkpiecematerial
usedfortheactualjob.
Driveatest fastenerwiththe airpressureset at
90-95psi.
Raise orlowertheairpressuretofindthelowest
setting thatwill performthe job withconsistent
results.
SETTINGTHEAIRPRESSURE
Ifanypartsaremissing, do notoperate
thistool untilthemissing partsare
replaced. Beforeusing thistool,make
surethearmpartand themainbodypart
arescrewedtogethertightly.Failuretodo
socouldresultin possibleserious
personalinjury.
WARNING:
!
LatchButton(F)
Magazine
cover
(D)
LatchButton(F)
Magazine
pusher
(E)
⒈
⒉
⒊
⒋

08 09
OPERATINGTHETOOL
Extremecaution mustbeused whenever
thistool isconnectedtoanairresource.If
thetoolisdropped, oriftheHammerCap
(I)isaccidentallystruck, thenthetoolwill
fireafastener,potentiallycausing
SERIOUSPERSONALINJURY.
WARNING:
!
Keepyourfeetoffthetool.
WARNING:
!
Beforeusing thetoolonafloor,testthe
tool onascrap pieceofwood. Adjustthe
drivingdepthbyprovidingmoreorless
airpressure.Neverexceed1PSI.15
WARNING:
!
MODEL:PLSLW50 MODEL:PLSLW50
HTTP://WWWFREEMANTOOLSCOM1-888-669-5672.. HTTP://WWWFREEMANTOOLSCOM1-888-669-5672..
HammerCap(I)
Arm(A)
Attachthe tooltotheairsource.Startyour
compressorandcheck the pressure,making
sureitissetbetween 70-115psi.Donotexceed
the maximum120psi
HoldtheArm(A)securelyandpressFoot
Plate(G)totheworksurface.Makesurethe
plateisoverthefastenertargetposition.
Pressdownhardsothatthe FootPlate(G)is
firmlycontacting the worksurface.Then,using
the malletpacketwiththe tool,strikethe
HammerCap(I)firmlytodrivethe fastenerinto
worksurface.Liftthetoolofftheworksurface.
Repeatthisprocess untilthe jobiscompleted.
When finished, makesuretostorethetoolina
clean, dry, safelocationout of reach of children
andotherunauthorizedpeople.
1.
2.
3.
4.
CLEARINGJAMS
Occasionally,fastenersmay become jammedin
the firingmechanism ofthetool,makingthe tool
inoperable.Toremove ajammed fastener,follow
the steps below:
Makesurethereisnofastenerinthe
magazinebeforeclearingajam.
WARNING:
!
1.
2.
3.
4.
5.
6.
7.
8.
9.
Disconnectthe toolfromairsource.
Emptythe magazine.Makesureallfasteners
areremoved.
Trytofirethe toolintoapieceof scrap woodor
flooring tomakesurethat it'sincapableoffiring
anyfasteners.
Setthe toolon itssidetoexposethe Nose
Bolts(J).
RemoveNoseBolts(J)andDriverGuide(K)to
expose thejammedfastener.
Removejammed fastener,using plierora
screwdriverifrequired.
ReplacetheDriverGuide(K)andNoseBolts(J).
Reconnecttooltothe airsource,then reloadthe
toolwithfasteners.
Pressthe Drive Guide (K)againstapiece of
wood,and testfirethefastenersseveraltimesto
checkforproperoperation.If the toolisproperly
firing,you maycontinueusing thetool.Ifthe tool
failstoperformproperly,immediately
discontinueuse and havethe toolrepaired by a
qualifiedservicetechnician.
DriverGuide(K)
Hex. Bolts(J)
Animproperlyfunctioningtoolmustnot
beused.Donotactuatethetoolunless
thetoolisplacedfirmlyagainstthework
piece.
WARNING:
!
MAINTENANCE
Anytimeinspection,maintenance,and
cleaningaredone:
Disconnectthetoolfromtheair
Emptythemagazinecompletely.
source.
WARNING:
!
Eachtoolispackedwithananti-dustcapon the air
connector, checkit afterunpacking. Keep the anti-
dustcaptocovertheairconnectorwhenthe toolis
notinusetopreventdebrisfromentering thetool.
ANTI-DUST
Lubricatetoolonlywithspecified
lubricants.
CAUTION:
LUBRICATION
Frequent,butnotexcessive, lubrication isrequired
forbestperformance.Oilforthetooladdedthrough
the airline connectionaddwilllubricatetheinternal
parts.Donotdetergentoil oradditives as these
lubricantswillcauseacceleratedweartothe seals
andbumpersinthe tool,resultinginpoortool
performance andfrequenttoolmaintenance.
Disconnectthe airsupplyfromthe tooltoadd
lubricant.
⒈
Turnthetoolsotheairinletisfacingup.Place
2-3drops ofpneumaticfasteningtooloilintoair
inlet.Donotusedetergentoils,oiladditives,or
air-tooloilsas theselubricantswillcause
accelerated weartothe sealsand bumpersin
the tool,resulting inpoortoolperformanceand
frequenttoolmaintenance.
2.
Afteraddingoil,run toolbriefly.Wipe offany
excessoilfromthe cap exhaust.
3.
