Metek BPS Series User manual

M440077-01 Rev B www.programmablepower.com
BPS Series
AC Power Source
User Manual

2 programmablepower.com
User Manual
California Instruments - AC Power Source
AMETEK Programmable Power.
Models Covered in this manual:
BPS30-1
BPS30-3
BPS45-1
BPS45-3
BPS75-3
BPS90-3
BPS150-3
BPS180-3

AMETEK Programmable Power
BPS Series User Manual - M440077-01 Rev B 3
About AMETEK
AMETEK Programmable Power, Inc., a Division of AMETEK, Inc., is a global leader
in the design and manufacture of precision, programmable power supplies for R&D,
test and measurement, process control, power bus simulation and power
conditioning applications across diverse industrial segments. From bench top
supplies to rack-mounted industrial power subsystems, AMETEK Programmable
Power is the proud manufacturer of Elgar, Sorensen, California Instruments and
Power Ten brand power supplies.
AMETEK, Inc. is a leading global manufacturer of electronic instruments and
electromechanical devices with annualized sales of $3.3 billion. The Company has
over 11,000 colleagues working at more than 80 manufacturing facilities and more
than 80 sales and service centers in the United States and around the world.
Trademarks
AMETEK is a registered trademark of AMETEK, Inc. California Instruments is a
trademark owned by AMETEK, Inc. Other trademarks, registered trademarks, and
product names are the property of their respective owners and are used herein for
identification purposes only.
Notice of Copyright
BPS Series User Manual © 2013 – 2022 AMETEK Programmable Power, Inc. All
rights reserved.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, AMETEK PROGRAMMABLE
POWER, INC. (“AMETEK”):
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR
SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS
MANUALS OR OTHER DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES,
COSTS OR EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL
OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION.
THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’S RISK,
AND
(c) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN
ENGLISH, ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF
THE TRANSLATION, THE ACCURACY CANNOT BE GUARANTEED. APPROVED
AMETEK CONTENT IS CONTAINED WITH THE ENGLISH LANGUAGE VERSION,
WHICH IS POSTED AT WWW.POWERANDTEST.COM.
Document and Revision
Part Number M440077-01 February 2022, Revision B
Contact Information
Telephone: [phone] (toll free in North America)
858 450 0085 (direct)
Fax: [phone]

4 programmablepower.com
Email: sales[email protected]
service.[email protected]
Web: www.powerandtest.com

AMETEK Programmable Power
BPS Series User Manual - M440077-01 Rev B 5
This page is intentionally blank

6 programmablepower.com
Important Safety Instructions
Before applying power to the system, verify that your product is
configured properly for your application.
Only qualified personnel who deal with attendant hazards in power
supplies, are allowed to perform installation and servicing.
Ensure that the AC power line ground is connected properly to the Power
Rack input connector or chassis. Similarly, other power ground lines
including those to application and maintenance equipment must be
grounded properly for both personnel and equipment safety.
Always ensure that facility AC input power is de-energized prior to
connecting or disconnecting any cable.
In normal operation, the operator does not have access to hazardous
voltages within the chassis. However, depending on the user’s application
configuration, HIGH VOLTAGES HAZARDOUS TO HUMAN SAFETY may be
normally generated on the output terminals. The customer/user must
ensure that the output power lines are labeled properly as to the safety
hazards and that any inadvertent contact with hazardous voltages is
eliminated.
Guard against risks of electrical shock during open cover checks by not
touching any portion of the electrical circuits. Even when power is off,
capacitors may retain an electrical charge. Use safety glasses during open
cover checks to avoid personal injury by any sudden component failure.
Neither AMETEK Programmable Power Inc., San Diego, California, USA,
nor any of the subsidiary sales organizations can accept any responsibility
for personnel, material or inconsequential injury, loss or damage that
results from improper use of the equipment and accessories.

AMETEK Programmable Power
BPS Series User Manual - M440077-01 Rev B 7
Safety Symbols

8 programmablepower.com
Product Family: BPS Series AC Power Source
Warranty Period: 1 Year
WARRANTY TERMS
AMETEK Programmable Power, Inc. (“AMETEK”), provides this written warranty
covering the Product stated above, and if the Buyer discovers and notifies AMETEK
in writing of any defect in material or workmanship within the applicable warranty
period stated above, then AMETEK may, at its option: repair or replace the
Product; or issue a credit note for the defective Product; or provide the Buyer with
replacement parts for the Product.
The Buyer will, at its expense, return the defective Product or parts thereof to
AMETEK in accordance with the return procedure specified below. AMETEK will, at
its expense, deliver the repaired or replaced Product or parts to the Buyer. Any
warranty of AMETEK will not apply if the Buyer is in default under the Purchase
Order Agreement or where the Product or any part thereof:
is damaged by misuse, accident, negligence or failure to maintain the same as
specified or required by AMETEK;
is damaged by modifications, alterations or attachments thereto which are not
authorized by AMETEK;
is installed or operated contrary to the instructions of AMETEK;
is opened, modified or disassembled in any way without AMETEK’s consent; or
is used in combination with items, articles or materials not authorized by AMETEK.
The Buyer may not assert any claim that the Products are not in conformity with
any warranty until the Buyer has made all payments to AMETEK provided for in the
Purchase Order Agreement.
PRODUCT RETURN PROCEDURE
Request a Return Material Authorization (RMA) number from the repair facility
(must be done in the country in which it was purchased):
In the USA, contact the AMETEK Repair Department prior to the return of the
product to AMETEK for repair:
Telephone: [phone], ext. 2295 or ext. 2463 (toll free North America)
858-450-0085, ext. 2295 or ext. 2463 (direct)
Outside the United States, contact the nearest Authorized Service Center (ASC). A
full listing can be found either through your local distributor or our website,
www.powerandtest.com, by clicking Support and going to the Service Centers tab.
When requesting an RMA, have the following information ready:
•Model number
•Serial number
•Description of the problem
NOTE:Unauthorized returns will not be accepted and will be returned at the
shipper’s expense.

AMETEK Programmable Power
BPS Series User Manual - M440077-01 Rev B 9
NOTE:A returned product found upon inspection by AMETEK, to be in specification
is subject to an evaluation fee and applicable freight charges.

10 programmablepower.com
Table of Contents
1. Introduction .................................................................................... 19
1.1 General Description......................................................................... 19
1.2 Manual Organization and Format ....................................................... 19
2. Specifications .................................................................................. 20
2.1 Electrical ....................................................................................... 20
2.1.1 Input.................................................................................................................20
2.1.2 Output ..............................................................................................................21
2.1.3 AC Measurements...............................................................................................24
2.1.4 System Specification ...........................................................................................24
2.1.5 Unit Protection ...................................................................................................26
2.1.6 Mechanical.........................................................................................................27
2.2 Environmental................................................................................ 28
2.3 Regulatory..................................................................................... 28
2.4 Front Panel Controls........................................................................ 28
2.4.1 Special Features and Options ...............................................................................30
2.4.2 -HV Option Specifications.....................................................................................31
2.4.3 -LF Option Specifications .....................................................................................33
2.5 Supplemental Specifications ............................................................. 33
2.5.1 Output ..............................................................................................................33
2.5.2 Acoustic Noise Levels .......................................................................................... 33
3. Unpacking and Installation – BPS30 and BPS45 Models. ................. 34
3.1 Unpacking ..................................................................................... 34
3.2 Power Requirements ....................................................................... 34
3.3 Mechanical Installation .................................................................... 35
3.4 AC Input Connections and Wiring ...................................................... 35
3.5 AC On/Off Circuit Breaker on BPS Series front panel............................. 42
3.6 Output Connections......................................................................... 44
3.6.1 Output Wiring.....................................................................................................44
3.6.2 Output Terminal Blocks ....................................................................................... 46
3.6.3 BPS30-1, BPS45-1 -1 ø mode Output Wiring Diagram ...........................................47
3.6.4 BPS30-3, BPS45-3 3ø mode Output Wiring Diagram..............................................49
4. Unpacking and Installation – BPS75 thru BPS180 Models................ 51

AMETEK Programmable Power
BPS Series User Manual - M440077-01 Rev B 11
4.1 Unpacking......................................................................................51
4.2 Power Requirements........................................................................51
4.3 Mechanical Installation.....................................................................53
4.4 AC Input Connections and Wiring.......................................................54
4.5 AC On/Off Circuit Breaker on BPS Series front panel. ............................59
4.6 Output Connections .........................................................................61
4.6.1 Output Wiring.....................................................................................................61
4.6.2 Output Terminal Blocks ....................................................................................... 63
4.6.3 Output Wiring Diagram........................................................................................ 65
4.6.4 BPS150-3 or BPS180-3 Parallel Output Wiring Diagram ...........................................66
4.6.5 Multi-Chassis Output Connections .........................................................................68
4.7 Connectors - Rear Panel ...................................................................69
4.7.1 System Interface ................................................................................................69
4.7.2 Analog Input Connector.......................................................................................71
4.7.3 BNC Connectors.................................................................................................. 73
4.7.4 External Sense Connector ....................................................................................73
4.7.5 RS232C Serial Interface Connector .......................................................................73
4.7.6 USB Interface.....................................................................................................75
4.7.7 LAN Interface – RJ45........................................................................................... 76
4.8 Multiple Cabinet Power Up/Down Procedures .......................................78
4.8.1 Power Up Procedure............................................................................................ 78
4.8.2 Power Down Procedure........................................................................................78
4.10 Basic Initial Functional Test ............................................................79
4.11 Remote Inhibit / Remote Shutdown .................................................81
5. Front Panel Operation ...................................................................... 83
5.1 Tour of the Front Panel ....................................................................83
5.1.1 Front Panel Controls and Indicators.......................................................................83
5.1.2 System On/Off Circuit Breaker..............................................................................83
5.1.3 Status Indicator Lights ........................................................................................84
5.1.4 The Shuttle Knob................................................................................................85
5.1.5 FUNCTION Keypad ..............................................................................................86
5.1.6 DECIMAL KEYPAD ...............................................................................................88
5.1.7 LCD Display ....................................................................................................... 89

12 programmablepower.com
5.2 Menu Structure .............................................................................. 91
5.2.1 MAIN Menus.......................................................................................................91
5.2.2 Overview of Menu 1 ............................................................................................94
5.2.3 Overview of Menu 2 and 3 ................................................................................... 95
5.2.4 PROGRAM Menu..................................................................................................96
5.2.5 MEASUREMENTS Screens.....................................................................................99
5.2.6 TRANSIENTS Menu ........................................................................................... 102
5.2.7 SETUP REGISTERS Menu ................................................................................... 113
5.2.8 UTILITY Menus ................................................................................................. 114
5.2.9 MEASUREMENT CAL FACTORS Menu.................................................................... 126
5.2.10 OUTPUT CAL FACTORS Menu........................................................................... 127
5.3 Output Programming..................................................................... 128
5.3.1 Set the Output ................................................................................................. 128
5.3.2 Slewing Output Values with the Knob in IMMEDIATE Mode ..................................... 128
5.3.3 Change Output Values with the Knob in SET Mode ................................................ 129
5.3.4 Change Output Values with the shuttle knob from the MEASUREMENT 1 screen........ 129
5.4 Standard Measurements ................................................................ 130
5.4.1 Standard Controller Measurements ..................................................................... 130
5.4.2 Controller Measurements ................................................................................... 131
5.4.3 Accuracy Considerations .................................................................................... 133
5.4.4 Triggering Measurements................................................................................... 133
5.5Transient Programming ................................................................. 139
5.5.1 Introduction ..................................................................................................... 139
5.5.2 Using Transient Modes....................................................................................... 139
5.5.3 Step Transients ................................................................................................ 139
5.5.4 Pulse Transients ............................................................................................... 141
5.5.5 List Transients.................................................................................................. 142
5.5.6 Programming Slew Rates ................................................................................... 145
5.5.7 Transient Execution........................................................................................... 145
5.5.8 Saving Transient List Programs........................................................................... 145
6. Principle of Operation .................................................................... 147
6.1 General....................................................................................... 147
6.2 Overall Description........................................................................ 148
6.3 Controller Assembly ...................................................................... 150

AMETEK Programmable Power
BPS Series User Manual - M440077-01 Rev B 13
6.3.1 CPU Controller.................................................................................................. 150
6.3.2 Keyboard / Display Board .................................................................................. 150
6.3.3 GPIB / RS232 or GPIB / RS232 / USB / LAN IO Board............................................ 150
6.4 System Interface Board..................................................................154
6.5 Current / Voltage Sensor Board .......................................................154
6.6 Low Voltage Power Supply ..............................................................154
6.7 Power Module ...............................................................................155
6.7.1 PFC Input Power Converter ................................................................................ 157
6.7.2 Modulator Board ............................................................................................... 157
6.7.3 Amplifier Boards ............................................................................................... 158
6.7.4 Filter Boards .................................................................................................... 159
6.7.5 Fan Supply Board ............................................................................................. 159
6.7.6 Output Snubber Board....................................................................................... 159
7. Calibration ..................................................................................... 161
7.1 Recommended Calibration Equipment...............................................161
7.2 Front Panel Calibration Screens .......................................................162
7.3 Routine Measurement Calibration.....................................................164
7.3.1 Measurement Cal - AC....................................................................................... 167
7.3.2 Measurement Calibration Summary..................................................................... 167
7.4 Routine Output Calibration..............................................................168
7.4.1 Output Cal ....................................................................................................... 170
7.4.2 Three Phase Mode............................................................................................. 171
7.4.3 Phase Angle Calibration ..................................................................................... 171
7.4.4 Output Calibration Summary .............................................................................. 172
7.5 Non-Routine Calibration .................................................................173
7.5.1Power Source Gain Adjustment........................................................................... 173
8. Service........................................................................................... 175
8.1 Cleaning ......................................................................................175
8.2 General .......................................................................................175
8.3 Basic operation .............................................................................175
8.3.1 Excessive Output Voltage................................................................................... 175
8.3.2 Poor Output Voltage Regulation .......................................................................... 176
8.3.3 Overload Light is On.......................................................................................... 177
8.3.4 Distorted Output............................................................................................... 177

14 programmablepower.com
8.3.5 Unit Shuts Down after 1-2 Seconds..................................................................... 177
8.3.6 No Output and No Lights on Front Panel .............................................................. 177
8.3.7 No Output But Front Panel controller is active....................................................... 178
8.4 Advanced Troubleshooting.............................................................. 179
8.4.1 Switch Off Unit ................................................................................................. 179
8.4.2 Removing Covers.............................................................................................. 179
8.4.3 Initial Inspection............................................................................................... 179
8.4.4 Fuse Check ...................................................................................................... 179
8.4.5 Power-on Troubleshooting Using the LED’s........................................................... 180
8.4.6 Other No Output Conditions ............................................................................... 181
8.5 Factory Assistance ........................................................................ 182
8.6 Fuses.......................................................................................... 183
8.7 Firmware Updates......................................................................... 184
8.7.1 Requirements................................................................................................... 184
8.7.2 Download Instructions....................................................................................... 184
8.7.3 Flash download Messages .................................................................................. 187
9. Top Assembly Replaceable Parts – BSP30 and BPS45 Models ........ 188
10. Top Assembly Replaceable Parts – BPS75 thru BPS180 Models. .... 194
11. Options .......................................................................................... 198
11.1 Introduction .............................................................................. 198
11.1.1 Option -HV: Additional AC Voltage Range ......................................................... 198
11.1.2 Option –ES: Emergency Stop Push Button ........................................................ 198
12. Error Messages .............................................................................. 200

AMETEK Programmable Power
BPS Series User Manual - M440077-01 Rev B 15
List of Figures
Figure 2-1: Sample BPS90 Voltage / Current Rating Chart, -HV Option – Max.
Rating. ....................................................................................................32
Figure 2-2: Sample BPS90 Voltage / Current Rating Chart, -HV Option – Derated.
..............................................................................................................32
Figure 3-1: The BPS30 or BPS45 Power Source..............................................35
Figure 3-2: Location of BPS30 and BPS45 AC Input and Chassis Ground Connection
..............................................................................................................37
Figure 3-3: BPS30 and BPS45 Series AC Input Connection Diagram (Rear view) .39
Figure 3-4: BPS30 or BSP45 Rear Panel........................................................43
Figure 3-5: External sense cable shield connection to chassis ground ................45
Figure 3-6: Location of BPS30 and BPS45 Output Terminals (Front view) ...........47
Figure 3-7: BPS30-1 / BPS45-1 Output Wiring (Rear view) ..............................48
Figure 3-8: BPS30-3 / BPS45-3 Output Wiring (Rear view) ..............................50
Figure 4-1: BPS75/BPS90 Power Source Photo...............................................52
Figure 4-2: Location of BPS75 and BPS90 AC Input and Chassis Ground Connection
..............................................................................................................55
Figure 4-3: BPS75-3 or BPS90-3 AC Input Connection Diagram (Rear view) .......57
Figure 4-4: BPS75-3 or BPS90-3 Rear Panel – External Sense connector location.
..............................................................................................................60
Figure 4-5: External sense cable shield connection to chassis ground ................61
Figure 4-6: Location of Output Terminals (Rear view) .....................................64
Figure 4-7: BPS75-3 or BPS90-3 Output Wiring (Rear panel view) ....................65
Figure 4-8: BPS150-3 or BPS180-3 - 2 Chassis Output Wiring (Rear view) ........67
Figure 4-9: Ship kit Terminal Block dimensions ..............................................69
Figure 4-10: USB Connector pin orientation...................................................75
Figure 4-11 LAN Connector.........................................................................76
Figure 4-12: Functional Test Setup. .............................................................81
Figure 5-1: Shuttle Knob............................................................................85
Figure 5-2: FUNCTION Keypad ...................................................................86
Figure 5-3: Entering Values from the Decimal Keypad.....................................88
Figure 5-4: Cursor UP Key Movement...........................................................88
Figure 5-5: Cursor DOWN key Movement......................................................89
Figure 5-6: Main Menu 1 Screen..................................................................90
Figure 5-7: Menu 1 through 3 .....................................................................91
Figure 5-8: PROGRAM Menu .......................................................................96
Figure 5-9: MEASUREMENTS Screen, Single Phase and Three Phase Modes ........99
Figure 5-10: TRANSIENTS Menu................................................................102

16 programmablepower.com
Figure 5-11: VOLTAGE SURGE/SAG SETUP Screen ....................................... 103
Figure 5-12: VOLTAGE SWEEP/STEP SETUP Screen...................................... 106
Figure 5-13: FREQUENCY SWEEP/STEP SETUP Screen .................................. 108
Figure 5-14 VOLTAGE/FREQUENCY SWEEP/STEP SETUP Screen .................... 110
Figure 5-15:START/VIEW TRANSIENT SEQUENCE Screen.............................. 111
Figure 5-16: SETUP REGISTERS Menu ....................................................... 113
Figure 5-17: UTILITY Menus..................................................................... 114
Figure 5-18: GPIB/RS232 SETUP Menu ...................................................... 118
Figure 5-19: VOLTAGE/CURRENT CONTROL SETUP Menu .............................. 120
Figure 5-20: INITIAL SETUP Menus ........................................................... 122
Figure 5-21: LIMIT SETUP Menu ............................................................... 124
Figure 5-22: CONFIGURATION SETUP Menus .............................................. 125
Figure 5-23: MEASUREMENT CAL FACTORS Menu. ....................................... 126
Figure 5-24: OUTPUT CAL FACTORS Menu (Series II only) ............................ 127
Figure 5-25: SET VOLT Trigger Source Acquisition ....................................... 135
Figure 5-26: Positive Trigger Delay (Post Trigger Data)................................. 137
Figure 5-27: Negative Trigger Delay (Pre-Trigger Data) ................................ 138
Figure 5-28: Pulse Transients ................................................................... 141
Figure 5-29: List Transients ..................................................................... 142
Figure 5-30: START/VIEW TRANSIENT SEQUENCE Menu ............................... 145
Figure 6-1: BPS Series Functional Block Diagram......................................... 148
Figure 6-2: BPS90 Series Detailed Block Diagram ........................................ 152
Figure 6-3: Power Module Detailed Block Diagram ....................................... 153
Figure 6-4: Power Module Layout .............................................................. 156
Figure 6-5: Amplifier Board Layout ............................................................ 158
Figure 7-1: Sample Voltage Calibration Setup BPS75 or BPS90 (Rear view) ..... 163
Figure 7-2: Sample BPS 90 Current Measurement Calibration Setup (Rear view)
........................................................................................................... 165
Figure 7-3: DC offset AC filter................................................................... 169

AMETEK Programmable Power
BPS Series User Manual - M440077-01 Rev B 17
List of Tables
Table 3-1: Suggested Input Wiring Sizes for each BPS Cabinet * ......................40
Table 3-2: Suggested Output Wiring Sizes *..................................................45
Table 3-3: Output Terminal connections. ......................................................46
Table 4-1: Suggested Input Wiring Sizes for each RS Cabinet * ........................58
Table 4-2: Suggested Output Wiring Sizes*...................................................62
Table 4-3: Output Terminal connections. ......................................................63
Table 4-4: System Interface Connectors .......................................................71
Table 4-5: Analog Interface Connector .........................................................72
Table 4-6: BNC Connectors.........................................................................73
Table 4-7: External Sense Connector ...........................................................73
Table 4-8: RS232 Connector pin out – BPS Series with RS232 and USB. ............74
Table 4-9: USB Connector pin out................................................................75
Table 4-10: RJ45 LAN Connector pin out.......................................................77
Table 4-11: Remote Inhibit Mode Settings ....................................................82
Table 7-1: Sample BPS45/90/180 Calibration Load Resistance and Power Values
............................................................................................................166
Table 7-2: Measurement Calibration Table - ................................................167
Table 7-3: Output Calibration Table – BPS Series .........................................172
Table 8-1: Basic Symptoms ......................................................................175
Table 8-2: BPS75 and BPS90 Fuse Ratings ..................................................183
Table 8-3: Flash Download Messages .........................................................187
Table 9-1: BPS 30 and BPS45 - Replaceable Parts and Fuses .........................188
Table 10-1: BPS75/BPS90, BPS150 and BPS180 - Replaceable Parts & Fuses.... 194
Table 12-1: Error Messages ......................................................................207

18 programmablepower.com
This page is intentionally blank

AMETEK Programmable Power
BPS Series User Manual - M440077-01 Rev B 19
1. Introduction
This instruction manual contains information on the installation,
operation, calibration, and maintenance for the California Instruments
BPS Series power sources with the programmable controller.
1.1 General Description
The BPS Series AC power source systems are high efficiency, floor
standing AC bulk power sources that provide a precise output with low
distortion.
Available voltage ranges are 150 Vac, 300 Vac and 400 Vac for the
standard unit.
When equipped with the -333 option, the voltage ranges are: 166 Vac,
333 Vac and 400 Vac.
Output voltage options, such as the -333 option, allow testing of high
voltage 480VAC L-L products at 120% of nominal as required by IEEE
1547 (Table 1) “Interconnection system response to abnormal voltages”.
All BPS models provide interface features such as a standard RS232C,
USB, IEEE-488 interfaces and an available LAN option.
The BPS Series units are contained in a floor standing enclosure on
casters. This allows the units to be moved around more easily.
Read the installation instructions carefully before attempting to install and
operate the BPS Series power systems. If you have any questions or
concerns, please contact the factory prior to applying power to the
system.
1.2 Manual Organization and Format
All user documentation for California Instruments power sources is
provided on CDROM in electronic format. (Adobe Portable Document
Format) The required Adobe PDF viewer is available for download from
the www.adobe.com website. This manual may be printed for personal
use if a hardcopy is desired. To request a hardcopy from AMETEK
Programmable Power, contact customer service at
[e-mail] . There will be a charge for providing printed
manuals.
This manual contains sections on installation, normal use, maintenance,
and calibration. If the BPS system is equipped with a GPIB, RS232C, USB
or LAN interface, refer to the BPS Programming manual for information on
using the remote control interfaces and command syntax. The
programming manual is provided on the same CDROM as this user
manual.

20 programmablepower.com
2. Specifications
Specifications shown are valid over an ambient temperature range of 25 ±5°C and apply after a 30
minute warm-up time. Unless otherwise noted, all specifications are per phase for sine wave output
into a resistive load. For three phase configurations or mode of operation, all specifications are for Line
to Neutral (L-N) and phase angle specifications are valid under balanced load conditions only.
2.1 Electrical
2.1.1 Input
Parameter
BPS3 0
BPS4 5
BPS7 5
BPS9 0
BPS150
BPS180
Line Voltage:
(3 phase, 3 wire +
ground (PE))
208 VLL±10% / 230 VLL±10% / 380 VLL±10% / 400 VLL±10% /480 VLL±10% / 600 VLL±10%
Li n e VA: 3 7 KVA 5 3 KVA 8 8 KVA 106 KVA 176KVA 212 KVA
Line Current:
116 ARMS @187 VLL
105 ARMS @207 VLL
62 ARMS @ 3 42 VLL
60 ARMS @360 VLL
50 ARMS @432 VLL
40 ARMS @ 540 VLL
175 ARMS @187 VLL
157 ARMS @207 VLL
95 ARMS @342 VLL
90 ARMS @360 VLL
75 ARMS @432 VLL
60 ARMS @540 VLL
292 ARMS @187 VLL
261 ARMS @207 VLL
154 ARMS @342 VLL
150 ARMS @360 VLL
125 ARMS @432 VLL
99 ARMS @540 VLL
350 ARMS @187 VLL
314 ARMS @207 VLL
177 ARMS @342 VLL
180 ARMS @360 VLL
150 ARMS @432 VLL
112 ARMS @540 VLL
Each BPS150
chassis
requires its
o wn AC s e r vi c e .
To t a l Li n e
currents are
2 x BP S75
Each BPS180
chassis
requires its
o wn AC s e r vi c e .
To t a l Li n e
currents are
2 x BPS90
Line Frequency:
47-63 Hz
Efficiency:
85 %(typical) depending on input line and load
P owe r Fa c t o r :
0.95 (typical) / 0.99 at full power.
Inrush Current:
230 Apk @208 VLL
220 Apk @230 VLL
130 Apk @380 VLL
132 Apk @400 VLL
110 Apk @480 VLL
88 Apk @230 VLL
230 Apk @208 VLL
220 Apk @230 VLL
130 Apk @380 VLL
132 Apk @400 VLL
110 Apk @480 VLL
88 Apk @600 VLL
460 Apk @208 VLL
440 Ap k @ 230 VLL
277 Apk @380 VLL
264 Apk @400 VLL
220 Apk @480 VLL
176 Apk @360 VLL
460 Apk @208 VLL
440Apk @230 VLL
277Ap k @ 380 VLL
264Apk @400 VLL
220Apk @480 VLL
176Ap k @ 600 VLL
Each BPS150
chassis
requires its
o wn AC s e r vi c e .
Total Peak
currents are
2 x BPS75
Each BPS180
chassis
requires its
o wn AC s e r vi c e .
Total Peak
currents are
2 x BPS90
Ho ld -Up Time :
> 10 mS
Isolation Voltage:
2200 VACinput to output, 1350 VACinput to chassis
