Metra Electronics CS-1X4HDMSPL4 User manual

5.0 Panel Description
HDMI™ Splitter lx4 Support 4K@60Hz
I -)o o -- ~ a -·J
,1
-------
-~-----
-------
1
-------
-------
-------
--------
1
-------
-------
_,.
---
l
I
I
6.0 Connection and Operation
ll Connect the HDMI input source and output devices into the HDMI Splitter.
2 Insert the DC connector of SV power supply into the splitter and then connect the AC. connector
of the power supply into the wall outlet .
3) Turn on the power.
Attention: Insert/ Extract cable gently.
6.1 Connection Diagra
Siu-ray DVD
m '
~
.[)
I 'l'l'l'I'
HDMI Cable
I l1l1l11,1
(l HOMI Cable
IIII I [)
HDMI table
,.
I i'11111t1
HDMI table
I•
1l1l1l1l1
[)
I•
HDMI Cable
I•
111111111
~17
I•
1!1!1!1!i
HDTV HDTV
Note: The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
Ale7ra-..
HOME THEATER GROUP
866.839.9187
460 Walker Street, HollyHIii, Fl 32117
www .MetraHomeTheater.com
-3-
HOME THEATER GROUP
CS-1X4HDMISPL4
USER MANUAL
Table of Contents
1.0 Introduction..................................................................................01
2.0 Feature..........................................................................................01
3.0 Specification .•............................................................................... 02
4.0 Package Content............................................................................02
5.0 Panel Description ........................................................................... 03
6.0 Connection and Operation .............................................................03

HDMI"' Splitter lx4 Support 4K@60Hz
HDMI™ Splitter 1x4 Support 4K@60Hz
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this
manual for future reference.
1.0 Introduction
The HDMI"' 4K splitter lx4 lets you share four HDMI™ displays or projectors with an
HDMl"'-enabled audio/ video source device. With support for Ultra HD (4K@60Hz) the HDMI"'
splitter ensures astonishing picture quality, four times the resolution of HD 1080p@60 Hz. The 4K
splitter is also backward compatible with previous HDMI"' revisions, supporting 1080p/ 720p
HDMI"' video resolution devices. Even if you don't require 4K video today, the HDMI"' 4K Splitter
lx4 ensures you'll be ready to take advantage of tomorrow's display technology.
2.0 Feature
*Support full 30 video format
*Support high resolution up to 4K@60Hz YUV 4:4:4
*Support HDCP 2.2 and HDCP 1.4
* Support High Dynamic Range (HDR) video
• Support highest data transfer rate up to 6.0Gbps per channel {18Gbps all channels)
*TMDS clock can be up to 600MHz
*Support 12bit per channel {36bit all channels) deep color
* Support uncompressed audio such as LPCM
*Support compressed audio such as DTS, Dolby Digital(including DTS-HD Master Audio"' and
Dolby TrueHD)
Note: Dolby is a trademark of Dolby Laboratories.
-1-
HDMI"' Splitter lx4 Support 4K@60Hz
3.0 Specification
Input Signal HDMISignal
Output Signal HDMISignal
Vertical Frequency Range 50/60Hz
Video Amplifier Bandwidth 6.0Gbps/600MHz per channel
lnterlaced(S0&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p,4K
Limited Warranty 1
Year Parts and Labor
Operating Temperature 0°c
to 10°c I 32°F to 1ss°F
Storage Humidity
5% to 90% RH (no condensation)
Power Supply SVDC@2A
Power Consumption (Max)
SW
Splitter Unit Cert FCC, CE, RoHS
Power Supply Cert CE, FCC, RoHS
Power Adapter Standard US, EU, UK, AUS Standard etc.
User Manual English Version
Note: Specification is subject to change without notice.
4.0 Package Content
1) Main Unit
2) SV DC Power Supply
3) User Manual
-2-

HDMI® SPLITTER
HDMI® SPLITTER
www.MetraHomeTheater.com
1-866-839-9187 | 386-257-1186
SALES 866-839-9187
• HDMI splitter with 1 input and 4 outputs
• Connect up to 4 HDMI displays to a single HDMI source.
• Supports HDMI 2.0 and HDCP 2.2 (and earlier versions)
• Supports 1080p, 3D, 4K/60Hz 4:4:4 up to 18Gbps
• Supports all HDR formats
