METREL EurotestCOMBO MI 3125 User manual

2
EurotestCOMBO
MI 3125
MI 3125 BT
Instruction manual
Version 2.3.2, Code no. 20 751 484
Source document version: Version 2.3, Code no. 20 751 484

3
Distributor:
Manufacturer:
METREL d.d.
Ljubljanska cesta 77
1354 Horjul
Slovenia
web site: http://www.metrel.si
e-mail: [email protected]
Mark on your equipment certifies that this equipment meets the requirements of the EU
(European Union) concerning safety and electromagnetic compatibility regulations
© 2019 METREL
The trade names Metrel, Smartec, Eurotest, Autosequence are trademarks registered or pending in
Europe and other countries.
No part of this publication may be reproduced or utilized in any form or by any means
without permission in writing from METREL.

MI 3125 / BT EurotestCOMBO Table of contents
4
Table of contents
1Preface ....................................................................................................................7
2Safety and operational considerations.................................................................8
2.1 Warnings and notes ..........................................................................................8
2.2 Battery and charging .......................................................................................11
2.2.1 New battery cells or cells unused for a longer period.............................................12
2.3 Standards applied ...........................................................................................13
3Instrument description.........................................................................................14
3.1 Front panel......................................................................................................14
3.2 Connector panel..............................................................................................16
3.3 Back side.........................................................................................................17
3.4 Display organization........................................................................................18
3.4.1 Terminal voltage monitor.......................................................................................18
3.4.2 Battery indication...................................................................................................18
3.4.3 Message field........................................................................................................18
3.4.4 Result field ............................................................................................................19
3.4.5 Sound warnings.....................................................................................................19
3.4.6 Help screens.........................................................................................................19
3.4.7 Backlight and contrast adjustments.......................................................................20
3.5 Instrument set and accessories.......................................................................21
3.5.1 Standard set MI 3125............................................................................................21
3.5.2 Standard set MI 3125 BT.......................................................................................21
3.5.3 Optional accessories.............................................................................................21
4Instrument operation............................................................................................22
4.1 Function selection ...........................................................................................22
4.2 Settings ...........................................................................................................23
4.2.1 Memory (model MI 3125 BT).................................................................................23
4.2.2 Language..............................................................................................................24
4.2.3 Date and time (model MI 3125 BT)........................................................................24
4.2.4 RCD testing...........................................................................................................24
4.2.5 Isc factor................................................................................................................26
4.2.6 Commander support..............................................................................................26
4.2.7 Initial settings ........................................................................................................27
5Measurements ......................................................................................................29
5.1 Voltage, frequency and phase sequence ........................................................29
5.2 Insulation resistance........................................................................................31
5.3 Resistance of earth connection and equipotential bonding .............................33
5.3.1 R LOWΩ, 200 mA resistance measurement..........................................................34
5.3.2 Continuous resistance measurement with low current...........................................35
5.3.3 Compensation of test leads resistance..................................................................36
5.4 Testing RCDs..................................................................................................37
5.4.1 Contact voltage (RCD Uc).....................................................................................38
5.4.2 Trip-out time (RCDt)..............................................................................................39
5.4.3 Trip-out current (RCD I).........................................................................................40
5.4.4 RCD Autotest ........................................................................................................41
5.5 Fault loop impedance and prospective fault current........................................44

MI 3125 / BT EurotestCOMBO Table of contents
5
5.6 Line impedance and prospective short-circuit current / Voltage drop..............46
5.6.1 Voltage drop..........................................................................................................48
5.7 Earth resistance ..............................................................................................50
5.8 PE test terminal...............................................................................................51
6Data handling (model MI 3125 BT) ......................................................................53
6.1 Memory organization.......................................................................................53
6.2 Data structure..................................................................................................53
6.3 Storing test results...........................................................................................55
6.4 Recalling test results.......................................................................................56
6.5 Clearing stored data........................................................................................57
6.5.1 Clearing complete memory content.......................................................................57
6.5.2 Clearing measurement(s) in selected location.......................................................57
6.5.3 Clearing individual measurements.........................................................................58
6.5.4 Renaming installation structure elements (upload from PC) ..................................59
6.5.5 Renaming installation structure elements with serial barcode reader or RFID reader
59
6.6 Communication (model MI 3125 BT)...............................................................61
6.6.1 USB and RS232 communication...........................................................................61
6.6.2 Bluetooth communication......................................................................................62
7Upgrading the instrument....................................................................................63
8Maintenance..........................................................................................................64
8.1 Fuse replacement............................................................................................64
8.2 Cleaning..........................................................................................................64
8.3 Periodic calibration..........................................................................................64
8.4 Service ............................................................................................................64
9Technical specifications......................................................................................65
9.1 Insulation resistance........................................................................................65
9.2 Continuity ........................................................................................................66
9.2.1 Resistance R LOW  .............................................................................................66
9.2.2 Resistance CONTINUITY......................................................................................66
9.3 RCD testing.....................................................................................................66
9.3.1 General data .........................................................................................................66
9.3.2 Contact voltage RCD-Uc.......................................................................................67
9.3.3 Trip-out time..........................................................................................................67
9.3.4 Trip-out current......................................................................................................68
9.4 Fault loop impedance and prospective fault current........................................68
9.4.1 No disconnecting device or FUSE selected...........................................................68
9.4.2 RCD selected........................................................................................................69
9.5 Line impedance and prospective short-circuit current / Voltage drop..............69
9.6 Resistance to earth .........................................................................................70
9.7 Voltage, frequency, and phase rotation...........................................................70
9.7.1 Phase rotation.......................................................................................................70
9.7.2 Voltage..................................................................................................................71
9.7.3 Frequency.............................................................................................................71
9.7.4 Online terminal voltage monitor.............................................................................71
9.8 General data....................................................................................................71
AAppendix A - Fuse table.......................................................................................73
A.1 Fuse table - IPSC............................................................................................73

MI 3125 / BT EurotestCOMBO Table of contents
6
A.2 Fuse table –Impedances at 230 V a.c. (AS/NZS 3017)..................................76
BAppendix B - Accessories for specific measurements.....................................77
CAppendix C –Country notes ...............................................................................78
C.1 List of country modifications............................................................................78
C.2 Modification issues..........................................................................................78
C.2.1 HUN modification –gR fuse types.....................................................................78
C.2.2 AT modification - G type RCD............................................................................79
C.2.3 NO, DK, SW modification –IT supply system....................................................80
C.2.4 AUS / NZ modification –Fuse types according to AS/NZS 3017 .......................81
DAppendix D - IT supply systems .........................................................................84
D.1 Standard references........................................................................................84
D.2 Fundamentals..................................................................................................84
D.3 Measurement guides.......................................................................................84
EAppendix E –Commanders (A 1314, A 1401).....................................................87
E.1 Warnings related to safety.............................................................................87
E.2 Battery.................................................................................................................87
E.3 Description of commanders.................................................................................87
E.4 Operation of commanders ...................................................................................88

MI 3125 / BT EurotestCOMBO Preface
7
1 Preface
Congratulations on your purchase of the Eurotest instrument and its accessories from
METREL. The instrument was designed on a basis of rich experience, acquired through
many years of dealing with electric installation test equipment.
The Eurotest instrument is professional, multifunctional, hand-held test instrument
intended to perform all the measurements required in order for a total inspection of
electrical installations in buildings. The following measurements and tests can be
performed:
Voltage and frequency,
Continuity tests,
Insulation resistance tests,
Earthing resistance tests,
RCD testing,
Fault loop / RCD trip-lock impedance measurements,
Line impedance / Voltage drop,
Phase sequence.
The graphic display with backlight offers easy reading of results, indications,
measurement parameters and messages. Two LED Pass/Fail indicators are placed at
the sides of the LCD.
The operation of the instrument is designed to be as simple and clear as possible and
no special training (except for the reading this instruction manual) is required in order to
begin using the instrument.
In order for operator to be familiar enough with performing measurements in general
and their typical applications it is advisable to read Metrel handbook Guide for testing
and verification of low voltage installations.
The model MI 3125 BT has inbuilt Bluetooth interface for easy communication with PC
and Android devices.
The instrument is equipped with the entire necessary accessory for comfortable testing.
Note:
For some national specific instrument implementations some details in the below
description can differ from the actual instrument implementation. Check the national
specific notes in Appendix C or ask your local dealer.

MI 3125 / BT EurotestCOMBO Safety and operational considerations
8
2 Safety and operational considerations
2.1 Warnings and notes
In order to maintain the highest level of operator safety while carrying out various tests
and measurements, Metrel recommends keeping your Eurotest instruments in good
condition and undamaged. When using the instrument, consider the following general
warnings:
The symbol on the instrument means »Read the Instruction manual
with special care for safe operation«. The symbol requires an action!
If the test equipment is used in a manner not specified in this user manual,
the protection provided by the equipment could be impaired!
Read this user manual carefully, otherwise the use of the instrument may
be dangerous for the operator, the instrument or for the equipment under
test!
Do not use the instrument or any of the accessories if any damage is
noticed!
If a fuse blows in the instrument, follow the instructions in this manual in
order to replace it!
Consider all generally known precautions in order to avoid risk of electric
shock while dealing with hazardous voltages!
Do not use the instrument in supply systems with voltages higher than
550 V!
Service intervention or adjustment is only allowed to be carried out by a
competent authorized personnel!
Use only standard or optional test accessories supplied by your
distributor!
Consider that protection category of some accessories is lower than of the
instrument. Test tips and Tip commander have removable caps. If they are
removed the protection falls to CAT II. Check markings on accessories!
(cap off, 18 mm tip)…CAT II up to 1000 V
(cap on, 4 mm tip)… CAT II 1000 V / CAT III 600 V / CAT IV 300 V
The instrument comes supplied with rechargeable Ni-Cd or Ni-MH battery
cells. The cells should only be replaced with the same type as defined on
the battery compartment label or as described in this manual. Do not use
standard alkaline battery cells while the power supply adapter is
connected, otherwise they may explode!
Hazardous voltages exist inside the instrument. Disconnect all test leads,
remove the power supply cable and switch off the instrument before
removing the battery compartment cover.
All normal safety precautions must be taken in order to avoid risk of
electric shock while working on electrical installations!

MI 3125 / BT EurotestCOMBO Safety and operational considerations
9
Warnings related to measurement functions:
Insulation resistance
Insulation resistance measurement should only be performed on de-energized
objects!
Do not touch the test object during the measurement or before it is fully
discharged! Risk of electric shock!
When an insulation resistance measurement has been performed on a capacitive
object, automatic discharge may not be done immediately! The warning message
and the actual voltage is displayed during discharge until voltage drops below
10 V.
Do not connect test terminals to external voltage higher than 600 V (AC or DC) in
order not to damage the test instrument!
Continuity functions
Continuity measurements should only be performed on de-energized objects!
Parallel impedances or transient currents may influence test results.
Testing PE terminal
If phase voltage is detected on the tested PE terminal, stop all measurements
immediately and ensure the cause of the fault is eliminated before proceeding
with any activity!
Notes related to measurement functions:
General
The indicator means that the selected measurement cannot be performed
because of irregular conditions on input terminals.
Insulation resistance, continuity functions and earth resistance measurements
can only be performed on de-energized objects.
PASS / FAIL indication is enabled when limit is set. Apply appropriate limit value
for evaluation of measurement results.
In the case that only two of the three wires are connected to the electrical
installation under test, only voltage indication between these two wires is valid.
Insulation resistance
If voltages of higher than 10 V (AC or DC) is detected between test terminals, the
insulation resistance measurement will not be performed. If voltages of higher
than 10 V (AC or DC) is detected between test terminals, the insulation
resistance measurement will not be performed.
The instrument automatically discharge tested object after finished
measurement.
A double click of TEST key starts a continuous measurement.

MI 3125 / BT EurotestCOMBO Safety and operational considerations
10
Continuity functions
If voltages of higher than 10 V (AC or DC) is detected between test terminals, the
continuity resistance test will not be performed.
Before performing a continuity measurement, where necessary, compensate test
lead resistance.
RCD functions
Parameters set in one function are also kept for other RCD functions!
The measurement of contact voltage does not normally trip an RCD. However,
the trip limit of the RCD may be exceeded as a result of leakage current flowing
to the PE protective conductor or a capacitive connection between L and PE
conductors.
The RCD trip-lock sub-function (function selector switch in LOOP position) takes
longer to complete but offers much better accuracy of fault loop resistance (in
comparison to the RLsub-result in Contact voltage function).
RCD trip-out time and RCD trip-out current measurements will only be performed
if the contact voltage in the pre-test at nominal differential current is lower than
the set contact voltage limit!
The autotest sequence (RCD AUTO function) stops when trip-out time is out of
allowable time period.
Z-LOOP
The low limit prospective short-circuit current value depends on fuse type, fuse
current rating, fuse trip-out time and impedance scaling factor.
The specified accuracy of tested parameters is valid only if the mains voltage is
stable during the measurement.
The measuring accuracy and immunity against noise are higher if parameter in
Zs rcd is set to standard “Std”.
Fault loop impedance measurements will trip an RCD.
The measurement of fault loop impedance using trip-lock function does not
normally trip an RCD. However, the trip limit may be exceeded as a result of
leakage current flowing to the PE protective conductor or a capacitive connection
between L and PE conductors. In this case setting parameter in measuring
function Zs rcd to “Low” can help.
Z-LINE / VOLTAGE DROP
In case of measurement of ZLine-Line with the instrument test leads PE and N
connected together the instrument will display a warning of dangerous PE
voltage. The measurement will be performed anyway.
Specified accuracy of tested parameters is valid only if mains voltage is stable
during the measurement.
L and N test terminals are reversed automatically according to detected terminal
voltage (except in UK version).

MI 3125 / BT EurotestCOMBO Safety and operational considerations
11
2.2 Battery and charging
The instrument uses six AA size alkaline or rechargeable Ni-Cd or Ni-MH battery cells.
Nominal operating time is declared for cells with nominal capacity of 2100 mAh.
Battery condition is always displayed in the lower right display part.
In case the battery is too weak the instrument indicates this as shown in figure 2.1. This
indication appears for a few seconds and then the instrument turns itself off.
Figure 2.1: Discharged battery indication
The battery is charged whenever the power supply adapter is connected to the
instrument. The power supply socket polarity is shown in figure 2.2.Internal circuit
controls charging and assures maximum battery lifetime.
+
-
Figure 2.2: Power supply socket polarity
The instrument automatically recognizes the connected power supply adapter and
begins charging.
Symbols:
Indication of battery charging
Figure 2.3: Charging indication
When connected to an installation, the instruments battery compartment can
contain hazardous voltage inside! When replacing battery cells or before
opening the battery/fuse compartment cover, disconnect any measuring
accessory connected to the instrument and turn off the instrument,
Ensure that the battery cells are inserted correctly otherwise the instrument will
not operate and the batteries could be discharged.
If the instrument is not to be used for a long period of time, remove all batteries
from the battery compartment.
Alkaline or rechargeable Ni-Cd or Ni-MH batteries (size AA) can be used. Metrel
recommends only using rechargeable batteries with a capacity of 2100 mAh or
above.
Do not recharge alkaline battery cells!
Use only power supply adapter delivered from the manufacturer or distributor of
the test equipment to avoid possible fire or electric shock!

MI 3125 / BT EurotestCOMBO Safety and operational considerations
12
2.2.1 New battery cells or cells unused for a longer period
Unpredictable chemical processes can occur during the charging of new battery cells or
cells that have been left unused for a longer period (more than 3 months). Ni-MH and
Ni-Cd cells can be subjected to these chemical effects (sometimes called the memory
effect). As a result the instrument operation time can be significantly reduced during the
initial charging/discharging cycles of the batteries.
In this situation, Metrel recommend the following procedure to improve the battery
lifetime:
Procedure
Notes
Completely charge the battery.
At least 14 h with in-built charger.
Completely discharge the battery.
This can be performed by using the
instrument normally until the instrument is
fully discharged.
Repeat the charge / discharge cycle
at least 2-4 times.
Four cycles are recommended in order to
restore the batteries to their normal
capacity.
Notes:
The charger in the instrument is a pack cell charger. This means that the battery
cells are connected in series during the charging. The battery cells have to be
equivalent (same charge condition, same type and age).
One different battery cell can cause an improper charging and incorrect
discharging during normal usage of the entire battery pack (it results in heating of
the battery pack, significantly decreased operation time, reversed polarity of
defective cell,…).
If no improvement is achieved after several charge / discharge cycles, then each
battery cell should be checked (by comparing battery voltages, testing them in a
cell charger, etc). It is very likely that only some of the battery cells are
deteriorated.
The effects described above should not be confused with the normal decrease of
battery capacity over time. Battery also loses some capacity when it is repeatedly
charged / discharged. Actual decreasing of capacity, versus number of charging
cycles, depends on battery type. This information is provided in the technical
specification from battery manufacturer.

MI 3125 / BT EurotestCOMBO Safety and operational considerations
13
2.3 Standards applied
The Eurotest instruments are manufactured and tested in accordance with the following
regulations:
Electromagnetic compatibility (EMC)
EN 61326
Electrical equipment for measurement, control and laboratory use –
EMC requirements
Class B (Hand-held equipment used in controlled EM environments)
Safety (LVD)
EN 61010-1
Safety requirements for electrical equipment for measurement, control
and laboratory use –Part 1: General requirements
EN 61010-031
Safety requirements for hand-held probe assemblies for electrical
measurement and test
EN 61010-2-030
Safety requirements for electrical equipment for measurement,
control, and laboratory use - Part 2-030: Particular requirements for
testing and measuring circuits.
Functionality
EN 61557
Electrical safety in low voltage distribution systems up to 1000 VAC
and 1500 VAC –Equipment for testing, measuring or monitoring of
protective measures
Part 1: General requirements
Part 2: Insulation resistance
Part 3: Loop resistance
Part 4: Resistance of earth connection and equipotential bonding
Part 5: Resistance to earth
Part 6: Residual current devices (RCDs) in TT and TN systems
Part 7: Phase sequence
Part 10: Combined measuring equipment
Other reference standards for testing RCDs
EN 61008
Residual current operated circuit-breakers without integral overcurrent
protection for household and similar uses
EN 61009
Residual current operated circuit-breakers with integral overcurrent
protection for household and similar uses
EN 60364-4-41
Electrical installations of buildings Part 4-41 Protection for safety –
protection against electric shock
IEC 60364-5-52
Low-voltage electrical installations –Part 5-52: Selection and erection
of electrical equipment –Wiring systems
BS 7671
IEE Wiring Regulations (17th edition)
AS / NZ 3760
In-service safety inspection and testing of electrical equipment
Note about EN and IEC standards:
Text of this manual contains references to European standards. All standards of
EN 6XXXX (e.g. EN 61010) series are equivalent to IEC standards with the same
number (e.g. IEC 61010) and differ only in amended parts required by European
harmonization procedure.

MI 3125 / BT EurotestCOMBO Instrument description
14
3 Instrument description
3.1 Front panel
2
3
4
5
6
78
9
10
111
12
Figure 3.1: Front panel (picture of MI 3125 BT)
Legend:
* Model MI 3125 BT
** Model MI 3125
1
LCD
128 x 64 dots matrix display with backlight.
2
TEST
TEST
Starts measurements.
Acts also as the PE touching electrode.
3
UP
Modifies selected parameter.
4
DOWN
5*
MEM
Store / recall / clear tests in memory of instrument.
5**
CAL
Calibrates test leads in Continuity functions.
Starts ZREF measurement in Voltage drop sub-function.
6
Function selectors
Selects test function.
7
Backlight,
Contrast
Changes backlight level and contrast.
8
ON / OFF
Switches the instrument power on or off.
The instrument automatically turns off 15 minutes after the
last key was pressed.

MI 3125 / BT EurotestCOMBO Instrument description
15
9*
HELP / CAL
Accesses help menus.
In RCD Auto toggles between top and bottom parts of results
field.
Calibrates test leads in Continuity functions.
Starts ZREF measurement in Voltage drop sub-function.
9**
HELP
Accesses help menus.
In RCD Auto toggles between top and bottom parts of results
field.
10
TAB
Selects the parameters in selected function.
11
PASS
Green indicator
Indicates PASS/ FAIL of result.
12
FAIL
Red indicator

MI 3125 / BT EurotestCOMBO Instrument description
16
3.2 Connector panel
Figure 3.2: Connector panel (picture of MI 3125 BT)
Legend:
* Model MI 3125 BT
** Model MI 3125
1
Test connector
Measuring inputs / outputs
2
Protection cover
3
Charger socket
4*
USB connector
Communication with PC USB (1.1) port.
5*
PS/2 connector
Communication with PC serial port and connection to optional
accessories.
5**
PS/2 connector
Serial port for upgrading the instrument.
Warnings!
Maximum allowed voltage between any test terminal and ground is 600 V!
Maximum allowed voltage between test terminals is 600 V!
Maximum short-term voltage of external power supply adapter is 14 V!

MI 3125 / BT EurotestCOMBO Instrument description
17
3.3 Back side
Figure 3.3: Back side
Legend:
1
Side belt
2
Battery compartment cover
3
Fixing screw for battery compartment cover
4
Back panel information label
5
Holder for inclined position of the instrument
6
Magnet for fixing instrument close to tested item (optional)
Figure 3.4: Battery compartment
Legend:
1
Battery cells
Size AA, alkaline or rechargeable NiMH / NiCd
2
Serial number label
3
Fuse
M 0.315 A, 250 V

MI 3125 / BT EurotestCOMBO Instrument description
18
3.4 Display organization
Figure 3.5: Typical function
display
Function name
Result field
Test parameter field
Message field
Terminal voltage
monitor
Battery indication
3.4.1 Terminal voltage monitor
The terminal voltage monitor displays on-line the voltages on the test terminals and
information about active test terminals.
Online voltages are displayed together with test terminal indication. All
three test terminals are used for selected measurement.
Online voltages are displayed together with test terminal indication. L
and N test terminals are used for selected measurement.
L and PE are active test terminals; N terminal should also be connected
for correct input voltage condition.
3.4.2 Battery indication
The indication indicates the charge condition of battery and connection of external
charger.
Battery capacity indication.
Low battery.
Battery is too weak to guarantee correct result. Replace or
recharge the battery cells.
Recharging in progress (if power supply adapter is connected).
3.4.3 Message field
In the message field warnings and messages are displayed.
Measurement is running, consider displayed warnings.
Conditions on the input terminals allow starting the measurement;
consider other displayed warnings and messages.
Conditions on the input terminals do not allow starting the
measurement, consider displayed warnings and messages.

MI 3125 / BT EurotestCOMBO Instrument description
19
RCD tripped-out during the measurement (in RCD functions).
Instrument is overheated. The measurement is prohibited until the
temperature decreases under the allowed limit.
Result(s) can be stored. (model MI 3125 BT)
High electrical noise was detected during measurement. Results may
be impaired.
L and N are changed.
Warning! High voltage is applied to the test terminals.
Warning! Dangerous voltage on the PE terminal! Stop the activity
immediately and eliminate the fault / connection problem before
proceeding with any activity!
Test leads resistance in Continuity measurement is not compensated.
Test leads resistance in Continuity measurement is compensated.
High resistance to earth of test probes. Results may be impaired.
Fuse F1 is broken.
3.4.4 Result field
Measurement result is inside pre-set limits (PASS).
Measurement result is out of pre-set limits (FAIL).
Measurement is aborted. Consider displayed warnings and messages.
3.4.5 Sound warnings
Continuous sound
Warning! Dangerous voltage on the PE terminal is detected.
3.4.6 Help screens
HELP
Opens help screen.
Help menus are available in all functions. The Help menu contains schematic diagrams
for illustrating how to properly connect the instrument to electric installation. After
selecting the measurement you want to perform, press the HELP key in order to view
the associated Help menu.
Keys in help menu:
UP / DOWN
Selects next / previous help screen.
HELP
Scrolls through help screens.
Function selectors / TEST
Exits help menu.

MI 3125 / BT EurotestCOMBO Instrument description
20
Figure 3.6: Examples of help screens
3.4.7 Backlight and contrast adjustments
With the BACKLIGHT key backlight and contrast can be adjusted.
Click
Toggles backlight intensity level.
Keep pressed for 1 s
Locks high intensity backlight level until power is turned off or the
key is pressed again.
Keep pressed for 2 s
Bargraph for LCD contrast adjustment is displayed.
Figure 3.7: Contrast adjustment menu
Keys for contrast adjustment:
DOWN
Reduces contrast.
UP
Increases contrast.
TEST
Accepts new contrast.
Function selectors
Exits without changes.

MI 3125 / BT EurotestCOMBO Instrument description
21
3.5 Instrument set and accessories
3.5.1 Standard set MI 3125
Instrument
Short instruction manual
Calibration Certificate
Mains measuring cable
Test lead.,3 x 1.5 m
Test probe, 3 pcs
Crocodile clip, 3 pcs
Set of NiMH battery cells
Power supply adapter
CD with instruction manual, and “Guide for testing and verification of low voltage
installations” handbook
Set of carrying straps
3.5.2 Standard set MI 3125 BT
Instrument
Short instruction manual
Calibration Certificate
Mains measuring cable
Test lead, 3 x 1.5 m
Test probe, 3 pcs
Crocodile clip, 3 pcs
Set of NiMH battery cells
Power supply adapter
CD with instruction manual, and “Guide for testing and verification of low voltage
installations” handbook and PC software EuroLink PRO
Set of carrying straps
RS232 - PS/2 cable
USB cable
3.5.3 Optional accessories
See the attached sheet for a list of optional accessories that are available on request
from your distributor.
