DESCRIPTION
This manual covers cabinets with electrical ratings of: 120V, 60 Hz, 900W
INSTRUCTIONS FOR USE
METRO®TC90 SERIES INSULATED
TRANSPORT CABINET (TC90S/TC90B)
TABLE OF CONTENTS
Safety Information & Symbols ...................................... 2
Identifying your Cabinet................................................2
Part Numbering.............................................................2
Installation and setup....................................................3
Features — all models.................................................. 3
Operating Instructions ..................................................4
Cleaning instructions ....................................................5
Care and Maintenance ................................................. 5
Service and Replacement Parts................................... 6
Wiring Schematics ......................................................10
Warranty ......................................................................11
Metro Heated Cabinets are for
Hot Food Holding applications only.

TC90 SERIES INSULATED TRANSPORT CABINET — INSTRUCTIONS FOR USE
2
www.metro.com
L01-144
REV K 04/22
SAFETY INFORMATION
WARNING: Follow all food safety guidelines. Pre-heat the cabinet to the desired temperature before placing hot cooked
food into the cabinet. Food must be at the appropriate temperature before being placed into cabinet. Use a
food probe to check internal food temperature - the cabinet temperature is not necessarily the internal food
temperature.
WARNING: Only factory-approved service agents should attempt to service, repair or replace electrical components,
wiring or power cord.
WARNING: This cabinet is for hot food holding applications only.
WARNING: Unplug the cabinet before cleaning or servicing. Do not wash the cabinet with a water jet or high pressure
water, do not hose wash/spray interior.
WARNING: Allow the unit to cool before cleaning, as the interior of the cabinet may be hot enough to burn.
WARNING: Food Service Equipment must be electrically grounded. Failure to ground Food Service Equipment may
result in serious injury or death from electrical malfunction.
CAUTION: Never steam clean. Severe damage or electrical hazard could result.
CAUTION: Water dripping onto the oor from open doors can be a slip hazard.
For future reference, note the serial and model number found on the data plate of the cabinet here:
Serial number ________________________________
PART NUMBERING
IDENTIFYING YOUR CABINET
!
HAZARDOUS
VOLTAGE!
Disconnec tpower
beforeservicingor
cleaning.
TC90S OR B
Cabinet Series Steam Pans
Bun Pans

TC90 SERIES INSULATED TRANSPORT CABINET — INSTRUCTIONS FOR USE
3
www.metro.com
L01-144
REV K 04/22
INSTALLATION AND SETUP
1. Check the packaging and cabinet for shipping damage after unloading the unit, and after removing all the packaging.
2. The receiver of this product is responsible for filing freight damage claims. This equipment must be opened immediately
for inspection. All visible damage must be reported to the freight company within 48 hours and must be noted on freight
bill at the time of delivery.
3. Concealed damage is your responsibility — you must advise the carrier of any loss or damage within 15 days after
receipt of the cabinet. If there is damage, retain the original packaging for inspectors.
4. Any protective covers (plastic or paper sheet) must also be removed before turning the cabinet on.
FEATURES — ALL MODELS
In order to utilize your new cabinet to its full potential; take a minute to identify the following features that have been provided
for your convenience.
• Cabinet is shipped in one carton.
• Temperature range is 120°F to 180°F.
• Analog type thermometer to allow temperature monitoring when unit is disconnected from power source.
• 15 amp service.
• 3 - 300 watt heating elements.
• Totally insulated with high temp rigid board fiberglass insulation.
• Kick latch for “hands-off” opening.
• Magnetic door latch.
• Adjustable hinges and strike.
• Removable slide racks.
• Stainless steel internal liner.
• Closed loop thermal break to reduce heat transfer.
• Outside shell brushed aluminum.
• Non-marking 5" neoprene casters (two with brakes).
• Side mounted lift handles.
• Adjustable door mounted vent.

TC90 SERIES INSULATED TRANSPORT CABINET — INSTRUCTIONS FOR USE
4
www.metro.com
L01-144
REV K 04/22
OPERATING INSTRUCTIONS
A. SLIDE RACKS
The slide racks provided with your cabinet are nickel chrome-plated to insure years of corrosion-free service. The
racks are already in place when the cabinet is shipped to you. They can be removed for cleaning by first lifting up on
the rack and then swinging the bottom towards the center of the cabinet.
The slide spacing is 25/8" to accommodate lip loaded pans for TC90S; bottom loaded pans for TC90B.
The following pans may be used:
9 pans — 12" x 20" x 21/4" (TC90S)
9 pans — 12" x 20" x 25/8" (TC90S)
9 pans — 18" x 26" x 1" (TC90B)
B. CABINET START-UP
1. A nine-foot, three-wire grounded lead cord is supplied fi xed to the cabinet. The cord cannot be separated from
the cabinet.
NOTE: Before operating your cabinet be sure to unwrap the lead cord completely from bracket.
CAUTION: With the POWER switch OFF, plug the lead cord into a standard grounded 15-amp, 125-VAC receptacle.
2. Set the thermostat dial to setting 10 = HIGH.
3. Snap the POWER switch to ON. The red POWER light will now glow as will the yellow indicator light indicating that
power is on and that the heating elements are activated and heating up.
4. Allow the cabinet to PREHEAT FOR APPROXIMATELY 45 MINUTES. After that time, the thermostat can be lowered
to a setting of 6 or 7. In a room of average temperature (72°F), this should provide 150°F to 170°F. Adjustments to
the temperature may be made as necessary.
NOTE: The POWER (red) light will glow as soon as the POWER switch is switched ON and will continue to glow
until switched OFF. The yellow indicator light will go on and off as the thermostat cycles. If the yellow light is not
illuminated, this indicates that the cabinet has achieved the preset TEMPERATURE level, NOT that the unit has been
switched OFF.
It is not necessary at the end of the operating day to disrupt the temperature setting in order to turn the unit OFF. By
switching the POWER switch to OFF, the unit is no longer operating.
By switching the POWER switch to ON when resuming operations, the cabinet will attain the preset level.

TC90 SERIES INSULATED TRANSPORT CABINET — INSTRUCTIONS FOR USE
5
www.metro.com
L01-144
REV K 04/22
CLEANING INSTRUCTIONS
Before proceeding with any CLEANING activity strictly follow “Safety Information” on page
2 of this manual.
ALL MODELS
Your TC90 series cabinet has been listed by the National Sanitation Foundation (NSF) which means that it has been
designed and constructed in a way that promotes a sanitary condition, i.e. sanitary materials and easy cleanability. To
maintain a sanitary condition and obtain the best cabinet performance, Metro strongly suggests that the cabinet be
thoroughly cleaned on an adequate regular basis — daily if necessary.
A. REMOVAL OF INTERIOR COMPONENTS FOR CLEANING
All interior components are removable, without tools, for thorough, unobstructed cleaning.
1. Turn off master switch and disconnect the unit from its power source.
2. If necessary, the door may be removed by simply lifting it from its cabinet-mounted hinges. Do not place the door
against an object that may scratch the door or damage the gasket.
3. The slide racks may be removed by lifting them from their respective brackets.
4. After cleaning, simply reverse the above steps to reassemble the cabinet.
B. SPECIFIC CLEANING INSTRUCTIONS
Do not immerse the cabinet when cleaning. Instead, use a damp cloth and a drying towel. BE SURE TO
THOROUGHLY DRY THE UNIT BEFORE RETURNING IT TO USE.
C. GENERAL CLEANING INSTRUCTIONS
1. LIGHT SOIL: If routine (daily) cleaning is practiced, a mild soap and warm water should be suffi cient to keep the
unit clean.
2. HEAVIER SOIL: If cleaning has been postponed, solvent or emulsion type cleaners that can be applied with bare
hands will give excellent results. Such cleaners are available under various brand names and detergent suppliers
can recommend materials appropriate for use on natural and epoxycoated aluminum and stainless steel interior
liner.
NOTE: For every cleaning method, best results are always obtained when the cleaner and technique are matched to the
soil conditions involved. To ensure using the proper cleaner for natural and epoxy-coated aluminum and stainless steel,
contact your detergent representative.
CARE AND MAINTENANCE
Before proceeding with any CLEANING activity strictly follow “Safety Information” on page
2 of this manual.
A. CABINET MAINTENANCE—ALL MODELS
Your TC90 series cabinet has been designed to require very little maintenance. With normal use, cleaning is the only
form of maintenance that need be done on a regular basis. Keeping the casters free of dirt build-up will go a long
way in prolonging their life.
If your cabinet is rolled over rough surfaces or transported over-the-road, the various threaded fasteners, i.e., screws
and nuts, should be periodically inspected and tightened if necessary, particularly the transport latch, hinge and
caster fasteners.
B. CONTROL PANEL MAINTENANCE
The control panel of your cabinet has also been designed to require very little maintenance. With normal use,
cleaning is the only form of maintenance that need be done on a regular basis. No maintenance is required on the
electrical components.

TC90 SERIES INSULATED TRANSPORT CABINET — INSTRUCTIONS FOR USE
6
www.metro.com
L01-144
REV K 04/22
REPLACEMENT PARTS AND PROCEDURES
A. CABINET
1. Refer to TC90S/TC90B Series Cabinet Replacement Parts Diagram to identify the part(s) to be replaced.
8
CONTROL PANEL
HEAT ELEMENT COVER
LIFT HANDLE
OUTER WRAPPER
CHASSIS
9A
9
2
6
3
7
4
5
1
CABINET REPLACEMENT PARTS LIST
Item No. Part No. Description
1 RPC13-112 Heating Element
2 B5DN Caster — Without Brake
3 B5DNB Caster — With Brake
4 RPC06-222 Thermometer Bulb Clamp
5 RPC06-221 Thermostat Bulb Clamp
6 RPC06-323 Vertical Thermal Break
RPC06-324 Hoz. Thermal Break TC90S
RPC06-324A Hoz. Thermal Break TC90B
7 RPTC90S-RACK Slide Rack TC90S
RPTC90B-RACK Slide Rack TC90B
8 RPC06-189 Star Bushing
9 RPC13-112 Cabinet Hinge
9A RPF07-050A Door Hinge Pin

TC90 SERIES INSULATED TRANSPORT CABINET — INSTRUCTIONS FOR USE
7
www.metro.com
L01-144
REV K 04/22
TC90S/ TC90B Series Cabinet Replacement Parts Diagram
REPLACEMENT PARTS LIST
Item No. Part No. Description
10 RPCT90S-300G Complete Door Assembly (TC90S)
RPCT90B-300G Complete Door Assembly (TC90B)
11 RPC06-325 Door Gasket (TC90S)
RPC06-325A Door Gasket (TC90B)
12 RPTC90S-3400 Strike Plate
13 RPC11-206 Door Vent Assembly
14 RPHINGE-4001 Door Hinge
12
14
13
11
INNER DOOR PANEL
OUTER DOOR PANEL

TC90 SERIES INSULATED TRANSPORT CABINET — INSTRUCTIONS FOR USE
8
www.metro.com
L01-144
REV K 04/22
TC90S/TC90B Control Panel Replacement Parts Diagram
5
9
3
2
2
1
11 12
13
10
14
6
8
7
4

TC90 SERIES INSULATED TRANSPORT CABINET — INSTRUCTIONS FOR USE
9
www.metro.com
L01-144
REV K 04/22
REPLACEMENT PARTS LIST
Item No. Part No. Description
1 RPC13-375 Power Switch
2 RPC13-246 Indicator Lights (Red)
RPC13-245 Indicator Lights (Yellow)
3 RPC06-313 Termostat Knob
4 RPC13-096 Terminal Block
5 RPC13-109 Thermometer
6 RPC13-113 Thermostat
7 RPC13-108 Power Cord
8 RPC13-110 Strain Relief
9 RPC09-028 Transport Latch
10 RPC09-027 Kick Latch
11 RPC14-041 Magnetic Door Latch
12 RPC10-013 Kick Latch Spring
13 RPF07-040 Cotter Pin
14 RPF05-017 Clevis Pin

TC90 SERIES INSULATED TRANSPORT CABINET — INSTRUCTIONS FOR USE
10
www.metro.com
L01-144
REV K 04/22
WIRING SCHEMATIC
BULB
TEMP. INDICATOR LIGHT (YELLOW)
WHITE
HEATING ELEMENT #1
HEATING ELEMENT #2
HEATING ELEMENT #3
RED
RED
THERMOSTAT
POWER INDICATOR LIGHT
POWER SWITCH
BLACK
TO GROUND SCREW ON CABINET
GREEN TO GROUND SCREW ON EXTRUSION
POWER CORD
WHITE
WHITE
WHITE
RED
TERMINAL BLOCK

TC90 SERIES INSULATED TRANSPORT CABINET — INSTRUCTIONS FOR USE
11
www.metro.com
L01-144
REV K 04/22
®
04/2022
For online warranty registration, please go to www.metro.com/service-support/thermal-cabinets to register electronically

© 2022 InterMetro Industries Corporation, Wilkes-Barre, PA 18705
L01-144 REV K 04/22
