Metro DataVac INSULATION ARMOUR PLUS C5 4 Series User manual

INSTRUCTIONS FOR USE
C5 4 SERIES INSULATION ARMOUR™ PLUS
HOT OR COLD FOOD TRANSPORT CABINETS
© 2016 InterMetro Industries Corporation, Wilkes-Barre, PA 18705
L01-607 Rev. A 05/2016
INSTRUCTIONS FOR USE
C5 4 SERIES INSULATION ARMOUR™ PLUS TRANSPORT CABINETS
TABLE OF CONTENTS
Safety Information ..........................................................2
Identify Your Cabinet ......................................................2
Product Details ...............................................................3
Installation and Setup .....................................................3
Reversing the Door Hinging ...........................................5
Care and Maintenance ................................................... 8
Replacement Parts.........................................................8
Warranty .......................................................................10

2
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
SAFETY INFORMATION
This cabinet is designed for hot and cold food holding applications.
C5 4 Series transport cabinet (Polymer Insulation Armour panels on the sides,
top and rear) must not be placed next to char boilers. Allow 18" (46cm) between
Insulation Armour and any cooking equipment. Do not allow hot kitchen
equipment whose surfaces exceed 200° F (90° C) to touch the panels.
IDENTIFYING YOUR CABINET
For future reference, note the serial and model number found on the data plate of the cabinet here:
Model number _________________________________________________
Serial number _________________________________________________
Date the cabinet was put into service _______________________________
Fill out and return the warranty card located at the back of this manual.
Part Numbering
C5 4 9 S U
-
N A
CABINET NAME
CABINET HEIGHT
9 = FULL
8 = 5/6
5 = 1/2 NON-POWERED
MATERIAL
S = STAINLESS STEEL
SLIDES
U = UNIVERSAL WIRE SLIDE
L = FIXED LIP LOAD
CABINET
SERIES
ACCESSORIES
(IF APPLICABLE)

3
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
PRODUCT DETAILS
INSTALLATION AND SETUP
1. Check the packaging and cabinet for shipping damage after unloading the unit, and after removing all
the packaging.
2. The receiver of this product is responsible for filing freight damage claims. This equipment must be
opened immediately for inspection. All visible damage must be reported to the freight company within
48 hours and must be noted on freight bill at the time of delivery.
3. Concealed damage is your responsibility — you must advise the carrier of any loss or damage within
15 days after receipt of the cabinet. If there is damage, retain the original packaging for inspectors.
4. Remove all packaging material from inside as well as outside of the unit.
Armour Panel
(Left-Right-Back)
Door Handle
Door
(2) Brake Casters
Slides
(2) Swivel Casters Upright
Armour Panel
(Top)
(FULL HEIGHT CABINET SHOWN)

4
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
Slide Installation
Slide Position to Maximize Universal Slide Pan Capacity when Slides are Spaced on 3" Centers
Fixed Lip Load Slide Configurations
NOTE: Full and half height fixed lip load slides have two slots on the uprights, always use lower slot (LS)
to install on rack hanger.
For additional pairs of wire slides, order C5-USLIDEPR-C for Chrome or C5-USLIDEPR-S for Stainless Steel.
To order individual universal uprights only, see item #13.
Complete set of universal slides and
uprights for full height cabinet
Part No. RPC54-9-URACK
17 Levels
Complete set of universal slides and
uprights for 5/6 height cabinet
Part No. RPC54-8-URACK
14 Levels
Complete set of universal slides
and uprights for 1/2 height cabinet
Part No. RPC54-5-URACK
8 Levels
13
12
Complete set of lip load slides
for full height cabinet
Part No. RPC54-9-LRACK
Complete set of lip load slides
for 5/6 height cabinet
Part No. RPC54-8-LRACK
Complete set of lip load slides
for 1/2 height cabinet
Part No. RPC54-5-LRACK
LS
LS
LS
LS
LS
LS
LS
LS
11
The universal rack uprights or lip load
slides have been installed at the factory.
If removed for cleaning, reinstall by
hanging them on the rack hangers on
the side walls of the cabinet.

5
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
REVERSING THE DOOR HINGING
NOTE: Retain all hardware as these are used during door reversal.
The door on your cabinet can be reversed to accommodate a right- or left-hand opening. To reverse, follow the
instructions listed below:
D
Lift the Complete
Door Assembly from Bottom Hinge
and set it aside for Re-installation.
4 Series
INSULATION ARMOUR P l u s
TM
4 Series
I N S U L A T I O N A R M O U R P l u s
TM
CA B
Door Plate — Top
4 Series
INSULATION A R M O U R P l u s
TM
CAUTION: Do not damage the door gasket and
carefully set the door aside.
E-1
E-2
Bottom Hinge
Top Hinge

6
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
E-3
NOTE:
Install hinges on
opposite side
F-1
Remove latch
strike plate
from left side.
F-2
Install latch
strike plate on
the right side.
4 Series
IN S U L AT I O N A R M O UR P l u s
TM
I
4 Series
INSULATION ARMOUR Plus
TM
G
Door
Handle
NOTE:
Keep these pair of
fasteners (2x) for
re-installation.
Door Plate
— Bottom
Cabinet with Door
Handle on Left
Side and Hinged
on Right Side
4 Series
I N S U L A T I O N A R M O U R P l u s
TM
H
Fastener
on Bottom
Rotate the door 180° about
vertical axis and note the
position of fasteners.

7
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
4 Series
I N S U L A T I O N A R M O U R Plus
TM
Door Handle on Right
Side of the Cabinet
J
Install Door
Assembly on
Bottom Hinge
K
L
M N
THIS STEP COMPLETES
REVERSING THE
DOOR HINGING
NOTE: Order replacement door label with part #RPC05-1200.

8
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
CARE AND MAINTENANCE
Before proceeding with any maintenance activity strictly follow
“Safety Information” on page 2 of this manual.
Cleaning The Cabinet
WARNING: Do not wash the cabinet with a water jet or high pressure water.
CAUTION: To clean the cabinet, wipe with a damp cloth and dry with a towel. Use only cleaning agents
approved for stainless steel.
CAUTION: Do not use cleaners with chlorides or phosphates as they may cause damage to stainless steel.
1. Use cleaners in proper concentrations. Follow the manufacturer’s directiowns for the cleaning product
used. The floor of the cabinet may be hosed out with low pressure water. After using any cleaning products,
thoroughly rinse all surfaces to remove residue.
2. Use a damp cloth or sponge. Mild soap suitable for stainless steel is acceptable. Dry with a clean towel.
Wipe up spills as soon as possible and regularly clean the cabinet to avoid staining and difficult to clean
conditions.
Regularly inspect the casters. Tighten loose fasteners and replace worn or
damaged parts with new InterMetro approved parts. Replace worn or damaged
casters immediately.
Armour Panel Cleaning
Use soft cloth, mild soap water solution to clean lightly-soiled surfaces. Then wipe dry with a clean, soft cloth.
For heavily-soiled areas, use a soft brush and solvent or emulsion-based cleaner. Always ensure the cleaner
is recommended for use on plastics and follow any special instructions from the manufacturer.
C5 4 SERIES TRANSPORT CABINET REPLACEMENT PARTS
Item#
Replacement
Part No. Description Item#
Replacement
Part No. Description
1 RPC06-1130A Full Height Door Gasket 9 RPC53-HGRKIT Replacement Rack Hanger Kit
RPC06-1130B 5/6 Height Door Gasket 10 RPC54-9-URACK Full Height Universal Slide Assembly – 2 pair
RPC06-1130C 1/2 Height and Dutch Door Gasket RPC54-8-URACK 5/6 Height Universal Slide Assembly — 1 pair
2RPC54-9SFS-DOOR Solid Full Height Door Assembly RPC54-5-URACK 1/2 Height Universal Slide Assembly – 1 pair
RPC54-8SFS-DOOR Solid 5/6 Height Door Assembly 11 RPC54-9-LRACK Full Height Lip Load Slide Assembly — 2 pair
RPC54-9SDS-BDOOR Solid 1/2 Height Door Assembly RPC54-8-LRACK 5/6 Height Lip Load Slide Assembly — 1 pair
3RPC14-118A Door Latch Flush Handle RPC54-5-LRACK 1/2 Height Lip Load Slide Assembly — 1 pair
4 RPC54-BOTHINGEASY Bottom Hinge Assembly 12 C5-USLIDEPR-C Chrome Wire Slide — 1 pair
5 RPC54-TOPHINGEASY Top Hinge Assembly C5-USLIDEPR-S Stainless Steel Wire Slide — 1 pair
6 B5DN 5" Swivel Caster 13 RPC54-9-UNIVUP Individual Full Height and
1/2 Height Universal Upright
B5DNB 5" Swivel, Brake Caster RPC54-8-UNIVUP Individual 5/6 Height Universal Upright
RPQC02-247 6" Swivel Caster 14 RPC54-TRVL Travel Latch
RPQC02-248 6" Swivel, Brake Caster 15 C5-SHELF-S Wire Shelf (Used with Universal Uprights)
6A B5DNR 5" Rigid Caster 16 RPC05-1200 Door Label
7 RPC54-8-REDPNLF
RPC54-9-REDPNLF
Armour Panel with Screws
(FOR PANEL
IDENTIFICATION SEE CHART)
8 RPC54N-REDTOPF Armour Top Panel
ARMOUR SIDE PANEL IDENTIFICATION
Height Top Panel Bottom Panel
Full Height RPC54-9-REDPNLF RPC54-9-REDPNLF
5/6 Height RPC54-8-REDPNLF RPC54-9-REDPNLF
1/2 Height — RPC54-9-REDPNLF

9
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
C5 4 Series Transport Cabinet Replacement Parts Diagram
3
2
4
1
13
12 6
6
7
5
7
7
9
14
15
6A
11 10
Brake (x2)
Swivel (x2)
7
NOTE:
For armour panel
identification, see
chart on page 8.
8
4 Series
INSULAT I O N A R M O U R Plus
TM
16
NOTE:
For slide identification,
see page 4.

10
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
®
04/2016

11
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
CUSTOMER INFORMATION
1. Which one of the following best describes
your establishment?
a. Full-Service Restaurant
b. Banquet Hall
c. Hotel/Motel
d. Hospital/Nursing Home
e. College/University
f. School
g. Employee Feeding
h. Other
WARRANTY INFORMATION:
Cabinet Model No.
Date Purchased
Customer Name
Address
Phone No.
2. Please indicate the two product benefits / features
that
were of major interest to you.
a.
b.
c.
d.
g.
Other
FOLD HERE — DO NOT DETACH
3. Main factor that led to your decision to
pur chase this product?
a. Product operating and functional features
b. Overall quality
c. Price
d. Availability
e. Other
4. Three sources that led to the purchase of
his product — in the order of their impact
(1 — being most impact; 3 — being least impact).
a. Trade Journal Ad
b Trade Show
c. Sales Call
d. Direct Mail
e. Previous Purchase
f. Other
For warranty coverage please fill out this card and
return it to Metro, or go to www.metro.com/heatedcabinetsupport
and select Online Warranty Registration to register electronically.
Thank you for purchasing a Metro C5 4 Series Cabinet. We are certain you will be
more than satisfied with its quality and performance. Please fill in the warranty
information space below so we may register your warranty. Also, so that we may learn
more about our customers and hopefully be of continued service in the future,
please take a moment to fill in the customer information space below.
Thank you
Superior Temperature Retention
Pan Capacity
Built-in Handles & Full Body Bumper
Easy-to-clean Stainless Steel
e. Holds Multiple Pan Sizes
f. Easy Access Door Latch

12
C5 4 Series Insulation Armour™ Plus
Hot or Cold Food Transport Cabinets
L01-607
L01-607 Rev. A 05/2016
US/Can: 1.800.992.1776
Corporate Headquarters (US): 1.570.825.2741
For Inquiries Outside of the U.S. and Canada, Visit www.metro.com/contactus
www.metro.com
FOLD HERE — DO NOT DETACH
STAPLE HERE
STAPLE HERE
POSTAGE WILL BE PAID BY
INTERMETRO INDUSTRIES CORPORATION
ATTN: CUSTOMER SERVICE
P O BOX A
WILKES-BARRE PA 18705-9968
STAPLE HERE
BUSINESS REPLY MAIL
FIRST-CLASS PERMIT NO. 121 WILKES-BARRE, PA
NO POSTAGE
NECESSARY
IF MAILED
IN THE
UNITED STATES
