Metz Axio pro User manual

OPERATING INSTRUCTIONS
for LCD TV sets Axio pro, Linus, Caleo,
Primus, Sirius with Chassis 610
Metz - immer erstklassig.
610 47 2014.A1
09/44/30

2
1. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Connecting and switching on . . . . . . . . . . . . 5
2. Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3. The Remote Control . . . . . . . . . . . . . . . . . . . . . 8
4. Daily Operation. . . . . . . . . . . . . . . . . . . . . . . 14
5. Station selection. . . . . . . . . . . . . . . . . . . . . . . 15
. . . management of program position . . . . . . . 15
. . . via program table . . . . . . . . . . . . . . . . . . 15
6. User help (Information) . . . . . . . . . . . . . . . . . 16
7. Menu Control. . . . . . . . . . . . . . . . . . . . . . . . . 17
8. Teletext
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
9.
Selecting Operating Mode . . . . . . . . . . . . . . . 20
10.
AV Playback, . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
. . . automatic program change
. . . . . . . . . 21
10.1 . . . , VCR-function . . . . . . . . . . . . . . . . . . . . . 23
10.2 . . . , MPEG noise reduction . . . . . . . . . . . . . . 24
10.3 . . . , Picture profile adjustment . . . . . . . . . . . . 25
10.4 . . . , Picture Format . . . . . . . . . . . . . . . . . . . . 26
10.5 . . . , Noise reduction . . . . . . . . . . . . . . . . . . . 27
11. General Picture Settings . . . . . . . . . . . . . . . . . 28
. . . , Select power options . . . . . . . . . . . . . . 29
. . . , Configure picture profiles . . . . . . . . . . 31
. . . , Assign selected picture profile. . . . . . . 32
. . . , adjust border colour . . . . . . . . . . . . . . . . 33
. . . , setting zoom/panorama mode . . . . . . . . 34
11.1 . . . , Programs via TV-Menu . . . . . . . . . . . . . . 35
11.2 . . . , Programs via station table. . . . . . . . . . . . 36
12. General Sound Settings . . . . . . . . . . . . . . . . . 37
12.1 . . . , for Progr. via TV Menu . . . . . . . . . . . . . . 42
12.2 . . . , for Prog. via the Stat. Table . . . . . . . . . . . 44
12.3 . . . , Mute function. . . . . . . . . . . . . . . . . . . . . 45
12.4 . . . , HiFi-Amplifier, HiFi output . . . . . . . . . . . . 46
12.5 . . . , Sound via speaker/hi-fi surround. . . . 47
12.6 . . . , Overview. . . . . . . . . . . . . . . . . . . . . . . 48
12.7 . . . , connecting headphone . . . . . . . . . . . . . . 51
12.8 . . . , Sound 1, Sound 2 . . . . . . . . . . . . . . . . . 51
13. Automatic zoom . . . . . . . . . . . . . . . . . . . . . . 52
Foreword
Dear customer,
Thank you for selecting a Metz
LCD TV set.
We have equipped this TV set
with a menu system which uses
"file cards" and believe that this
will provide you with a user
interface that is easy to under-
stand.
If you have any problems, you can
press the key to display a
help function that will assist you in
setting up your TV set.
However, you should read at
least sections 1 to 8 of the Ope-
rating Instructions before putting
your new TV set into service.
TV sets with the type designa-
tion “HDTV” provide the possi-
bility of showing HDTV pro-
grammes.
In the box
• TV set
• Remote control RM16 for TV
sets without digital recorders,
or remote control RM17 for TV
sets with digital recorders.
• 2 AAA batteries
• Power cord
• Back panel cable cover
• Operating instructions
Your METZ-WERKE
Contents
HDTV
integriert

3
Contents
14. Childlock . . . . . . . . . . . . . . . . . . . . .53
15. Timer Control . . . . . . . . . . . . . . . . .55
15.1 Setting the Time and Date . . . . . . . . .56
15.2 Recording Control . . . . . . . . . . . . . .57
16. Special Functions, . . . . . . . . . . . . . .59
. . . , Picture-in-Picture . . . . . . . . . . .59
. . . , Normal/Speech . . . . . . . . . . . .60
. . . , JPEG Photograph Display . . . . .61
. . . , viewing time shift mode . . . . . .64
. . . , Recording a progr. with a timer .66
. . . , Direct Recording (OTR) . . . . . . .68
. . . , Picture format . . . . . . . . . . . . .69
. . . , Picture position . . . . . . . . . . . .71
. . . , Audio language selections . . . .72
. . . , Select subtitle . . . . . . . . . . . . . .73
. . . , display subtitle . . . . . . . . . . . . .74
17. Programming the Function Keys . . . .75
18. EPG (Electronic Program Guide) . . . .76
18.1 Activating the EPG . . . . . . . . . . . . . .76
18.2 Collecting EPG Data . . . . . . . . . . . . .78
18.3 Using the EPG . . . . . . . . . . . . . . . . .80
. . ., selecting a program, . . . . . . . .81
. . . viewing, . . . . . . . . .81
. . . reminder . . . . . . . . .81
. . ., Program info (now showing..) . .82
. . ., recording a program . . . . . . . . .83
19. Setting the Country and Language . .84
20. Setting Stations, . . . . . . . . . . . . . . .85
. . . , reception mode . . . . . . . . . . . .85
20.1 . . . , TV-Standard . . . . . . . . . . . . . .86
. . . , Analogue -TV . . . . . . . . . . . . .87
. . . , Colour standard . . . . . . . . . . . .88
20.2 . . . DVB-T, Antenna suply voltage . . .89
. . . , automatic station search . . . . . .90
. . . , manual station search . . . . . . . .91
20.3 . . . DVB-C, automatic station search .92
. . . , manual search . . . . . . . . . . . . .93
20.4 Set-up satellite system, . . . . . . . . . . .94
. . . , Antenna system . . . . . . . . . . . .94
. . . , Unicable . . . . . . . . . . . . . . . . .95
. . . , LNB supply voltage . . . . . . . . . .96
. . . , DiSEqC System . . . . . . . . . . . .97
. . . , selecting Satellite . . . . . . . . . . .98
20.5 . . . DVB-S Search Settings . . . . . . . .99
. . . , automatic station search . . . . . .99
. . . , manual station search . . . . . . .100
20.6 . . . , Updating the Data . . . . . . . . .102
20.7 DVB-Prog.-Info, Signal quality . . . . .103
20.8 DVB-C and DVB-S Portal stations . .104
21. Station Logo . . . . . . . . . . . . . . . . .105
22. Sorting Stations . . . . . . . . . . . . . . .106
23. Initial Program Position . . . . . . . . .108
24. Display Configuration . . . . . . . . . .109
25. DVB Radio Mode . . . . . . . . . . . . . .110
26.
Operation without the Remote Control .110
27. Scope of Operation . . . . . . . . . . . .112
28. Cleaning the TV Set . . . . . . . . . . . .114
29. Connections to the Set . . . . . . . .115
. . . on the Front . . . . . . . . . . . . . . .115
. . . on the Rear . . . . . . . . . . . . . . .116
30. Registering AV Devices . . . . . . . . . .117
30.1 . . . , Data Logic . . . . . . . . . . . . . . .119
30.2 . . . , Setting the signal types RGB . .121
. . . ,
Setting the signal types DVI / HDMI 122
. . . , Setting the signal types YUV . .123
30.3
Connecting a Hifi Amplifier/AV Receiver 124
30.4 Removing AV Devices . . . . . . . . . . .126
31. Copying between AV Devices . . . . .127
32. Inserting/Removing CA Modules . .129
33. Connect PC . . . . . . . . . . . . . . . . . .130
33.1
Connect PC, sound from TV-speaker . . . .132
34. Glossary . . . . . . . . . . . . . . . . . . .133
35.
Problem, Possible cause, Remedy . .136
36. Upgrade Kits . . . . . . . . . . . . . . . . .139
37. Technical Data . . . . . . . . . . . . . . . .141
Battery disposal . . . . . . . . . . . . . . .145
Index . . . . . . . . . . . . . . . . . . . . . .146

4
• Take care that no bright artificial light
or sunshine falls directly on the screen.
This could cause reflections which have
a negative effect on the brilliance of
the picture.
• The best viewing distance is five times
the screen diagonal, i.e.
- Approx. 2 m (6.3 ft) for 26" screens
- Approx. 2.4 m (7.6 ft) for 32" screens
- Approx. 2.8 m (9 ft) for 37" screens
- Approxi. 3.2 m (10.3 ft) for 42" screens
- Approxi. 3.5 m (10.3 ft) for 47" screens
- Approxi. 4.2 m (10.3 ft) for 55" screens
• The antenna cable and any other com-
ponents (such as a video recorder)
connected between the antenna socket
in the wall and the TV set must comply
with the European standard
EN 60966-2-4.
• The antenna cable used for connecting
the TV set must have a screening atte-
nuation of at least 75 dB.
• The use of non-approved cables will
invalidate the operating permission for
the TV set.
1. Installation
• Only use Metz bases as a stand for the
LCD TV.
• Use the Metz wall bracket (item no.
604 99 0286.A3) or a suitable Omni-
Mount wall bracket to hang the LCD TV
on the wall.
• Smoking at the installation location of
the LCD TV can lead to nicotine and
soot deposits behind the panel glass
and thus to an impairment of the ima-
ge quality. Such deposits can only be
removed by a specialist. In extreme
cases the panel may be damaged
permanently, which may require to
replacing the panel. The cleaning and /
or the replacement of the panel is not
covered by warranty claims.
This TV set is exclusively designed for the
reception and replay of picture and
sound signals.
The TV set is designed for dry rooms
(living rooms and offices).
The room climate should be in a range
from +5°C to +35°C with 75% air humi-
dity.
The TV set must not be used in rooms
with higher air humidity (e.g. bathroom,
sauna, etc.).
The TV set must not be used in rooms
with a high concentration of dust (e.g. a
workshop).
If, as an exception, you operate the TV
set outdoors, then please make sure that
it is protected against moisture (rain,
water spray, dew).
1.1 Proper use

Axio pro
5
1.2 Connecting and switching on
Power connector
Connect the TV set to the wall socket with
the supplied power cord.
Antenna connector
Connect the TV set to the antenna socket with an
antenna cable.
Switching on
Switch on the TV set with the main switch.
from below
Linus
Sirius
On the side
from below
Primus, at the right side
Power connection,
back panel
DVB-S antenna
connector
DVB-C/T antenna
connector

6
1.2 Connecting and switching on
The TV set is now in standby mode and
the red standby indicator lights.
After about 25 seconds, the TV set swit-
ches to program position 1 or to the pro-
grammed initial program position (see
page 108).
If you press no further keys on the remote
control a window requesting that you do
so is displayed after about 10 minutes. If
you do not do this, the TV set switches
back to the standby state.
Switching on from the
Stand-by
Use the numeric keys to select any de-
sired program position. Pressing the
or TV key selects program position
1 or, if it is programmed, the initial pro-
gram position (see page 108.
Switching off
Press the key to switch the TV set to
standby mode. If you do not intend to use
the TV set for a longer period switch it off
with the main power switch.
2. Safety notes
• Always place the monitor on a solid,
stable surface.
• If a cold TV set is moved to a warm
room, always allow any condensation
on the screen to evaporate before swit-
ching it on.
• The TV set is intended for use in a dry
room. If, in exceptional circumstances,
you use it outdoors, take care that is
protected against moisture (rain, splas-
hed water, dew).
• Do not expose TV set to dripping or
splashes (e.g. rain)!
• TV sets need adequate ventilation.
Never cover the openings on the rear of
the set with curtains, doilies, newspa-
pers, etc.
Also take care that the slits in the bot-
tom of the case are freely accessible so
that the intake of the cooling air is not
hindered.
• If you place the TV set in a wall unit
leave sufficient space on all sides for
the circulation of cooling air.
• Do not place the TV set close to a radi-
ator, since this would effect adequate
cooling.

7
2. Safety notes
• Do not place burning candles or
vessels containing liquids (vases, etc.)
on top of the TV set, since any hot wax
or water dripping into the set could
cause serious damage to the electronic
components and could also jeopardise
the electrical safety of the set.
• Lightning can damage electrical equip-
ment. A lightning flash entering the
power cable or the aerial cable can
damage the TV set even if it is swit-
ched off. You should therefore discon-
nect the power cable and aerial cable
from their outlets or from the TV set in
the case of a thunderstorm.
• The monitor may be opened and
repaired only by a qualified person.
CAUTION! HIGH VOLTAGES CAN KILL !
If repairs should be necessary, consult
your local dealer.
• Always switch off the TV set before
cleaning it.
• Do not hold the remote control directly
in front of your eyes and press a but-
ton. The remote control emits infrared
radiation!
• Do not place rechargeable batteries in
the battery compartment of the remote
control. Use only two 1.5 V dry batte-
ries of the type LR03/AM4/AAA
(Micro).
• The TV set is intended only for the
reception and reproduction of picture
and sound signals.
• The TV set may be operated only from
a mains voltage of 230-240V VAC,
50 Hz. Australia: 240 VAC.
• Do not demage the power cord or plugs.
In the event of repair or maintenance the
power cord must be able to be easily dis-
connected.
• Lay the power cord so that there are
no objects resting on it and no-one
can trip over it!
• Do not display still images, logos, 4:3
pictures with stripes etc. over an exten-
ded period. These still images can
result in marks on the screen.
• Lay the power cable so that nothing
stands on it and no-one can trip over
it.
• Keep candles and open flames away
from this product at all times to prevent
fire spreading.
• Grime and dust deposits can accumu-
late behind the front panel glass of the
LCD TV set without a visible source
being present. These grime and dust
deposits are also known as „fogging“
or „magic dust“. There are scattered
instances of this phenomenon, but
especially during the warm-up period
and after renovation work or in new
constructions. Various factors can cau-
se the above mentioned phenomenons,
see also reports on the Internet.
In such cases cleaning or replacement
of the panel is excluded from the gua-
rantee, since it does not involve a set
defect, but rather an external influen-
ce.

8
3. The Remote Control
The RM 16 is included with all TV sets
delivered without digital recorders.
The RM 17 remote control is included
with all TV sets delivered with digital
recorders.

9
3. The Remote Control
Do not insert rechargeable batteries in
the battery compartment of the remote
control.
Use only two dry batteries of the type
LR03/ AM4/AAA 1.5V.
The batteries that are used must not be
exposed to excessive heat such as
sunshine, fire or the like.
The remote control sends commands to the TV set
by means of an infrared signal. You must point it
towards the TV set when using it. Note that the
remote control may interfere with the operation of
other devices which use infrared signals (such as
infrared headphones).
Sunlight falling directly on the TV set may interfere
with the operation of the remote control, since the TV
set cannot detect the infrared signals from the remote
control under these conditions. The TV set must be
switched on with the main power switch before it can
be controlled with the remote control.
i

10
3.1 The Remote Control (RM 16)
ON at program position 1 or at the pro-
grammed start program position.
OFF, enter stand-by setting.
Call “Information“.
Back to table of contents in “Information“.
In TV mode: Start time shift
When set to Play: Still picture/Pause
Hold down when set to Play: Slow motion
Switch to TV -> Radio1) / Radio1) -> TV
Function keys
Press briefly: for factory programming
Hold down: display of the special functions selection
Select AV device
Select picture settings
In TV menu: Adjust the settings for “pictu-
re and sound”
Select sound settings
In TV menu: Adjust the settings “AV devi-
ces”
Select program table,
In the TV menu: Adjust the settings “Pro-
gram table” or station features
Display date, time info on program
In the TV menu: Adjust the settings “Time
settings”
In video text: Scroll by markers
When set to time shift: Display playback
position
In the TV menu: Adjust the settings “Con-
figuration“
In video text: Set or delete marker
Mark TV program for recording in EPG
V+ volume + / In the menu: Change value
+P Progr. + / In the menu: Change value
V– volume – / In the menu: Change value
–P Progr. – / In the menu: Change value
TIMESHIFT

11
3.1 The Remote Control (RM 16)
Note:
In the following sections of these operating
instructions the term + – Key is used. This refers
to the value adjustment within the TV menu with
V+ / +P or V– /–P.
Cursor control key
Confirmation key
In the menu: Save
Mute/sound stop
Back to last program
In the menu: Delete
Exit menu without saving any changes that
have been made
Select video text
In video text: Scroll by markers
Select the electronic program guide
Select the TV menu.
In the menu: Return to main menu point

12
3.2 The Remote Control (RM 17)
ON at program position 1 or at the pro-
grammed start program position.
OFF, shut down digital recorder & switch
to stand-by setting.
Switch to Metz-TV
Switch to DVD
Switch to STB (Set Top Box)
Switch to AUX (audio devices)
When set to Play: Rewind
When set to time shift: Skip backwards
20 seconds
Open archive / in archive: Play
When set to Play: Fast forward
When set to time shift: Skip forwards one
minute
Start direct recording / EPG direct recor-
ding
In TV mode: Start time shift /
when set to Play: Still picture/Pause
When set to Play: hold down: Slow
motion.
Stop (when set to Play: Return to archive /
when set to time shift: Switch to “Live”)
Select “Information” / In “Information”
back to table of contents
Picture in picture on/off
Switch to TV -> Radio / Radio -> TV
PVR stop and back to TV picture
Function keys
Press briefly: for factory programming
Hold down:
display of the special functions selection.
Select AV device
Select picture settings
In TV menu: Adjust the settings “picture
and sound”
In “File Manager“: Switch from USB stick
to digital recorder
AUX
STB
DVD
TV
ARCHIV
TIMESHIFT

13
3.2 The Remote Control (RM 17)
Select sound settings
In TV menu: Adjust the settings “AV devices”.
In “File Manager“: Mark file / Remove
marking.
Select program table in the TV menu:
Select “Program table” or station features.
In the PVR archive: Sort recordings accor-
ding to complete, partial & unseen.
Display date, time info on program.
In the TV menu: Select “Time settings”.
In video text: Scroll by markers.
When set to playback / time shift: Display
playback position.
In the PVR archive: Show recording accor-
ding to the category.
In the TV menu: Adjust the settings “Confi-
guration“.
In video text: Set or delete marker.
In the PVR archive: Sort the recordings
from A-Z.
In EPG : Mark TV program for recording.
V+ volume + / In the menu: Change value.
+P Progr. + / In the menu: Change value.
V– volume – / In the menu: Change value.
–P Progr. – / In the menu: Change value.
Cursor control key.
Confirmation key / In the menu: Save.
Mute / sound stop.
Back to last program.
Back to last program.
Exit menu without saving any changes that
have been made to save.
Select video text.
In video text: Scroll by marks.
Select the electronic program guide.
Select the TV menu.
In the menu: Return to main menu point.

14
4. Daily Operation
Changing picture settings
The picture settings can be accessed with the blue
button . The settings box with the individual
functions (see picture) appears on the bottom left
of the screen.
Select the desired function with the cursor key and
adjust it with the V– /V+ key.
The individual picture characteristics can also be
saved as default values for all programs. See
Chapter 11 for this.
Volume settings
Use the V– /V+ key to change the volume .
Changing the sound settings
The sound settings can be accessed with the yel-
low button . The settings box with the indivi-
dual functions (see picture) appears on the bottom
left of the screen.
Select the desired function with the cursor key and
adjust it with the V– /V+ key.
The individual sound characteristics can also be
saved as default values for all programs.
See Chapter 12 for this.
The settings that are made here are only tem-
porary and are not saved. If the TV set is swit-
ched to stand-by mode or switched off, all set-
tings will be reset to the preset default values.
Contrast
Brightness 50%
Profil
Brightness
Profil Standard
Colour impr.
Profil
Colour impr. harmoniously
MPEG noise reduct.
Noise reduct.
Sharpness 7
Colour intensity
Colour intensity
Contrast 70%
Brightness
Opening the menu
Sound mode
Volume 38%
Tone settings
Sound mode
Headph.Vol.
Speakers
Speakers
Sound mode on
Volume
Headph.Vol.
Speakers on
Sound mode
i

15
The program table can be called up with the white key
in the TV or radio mode.
• Programs can be selected with the
cursor key or numeric keys in the
table displayed. It is possible to skip
to the next or last 15 programs with
the cursor control key. You can
display the program selected with the
key .
• A key pad is displayed as a result of
repeated pressing of the white key
. The station table can be ordered
alphanumerically with the correspon-
ding key.
• All HD stations saved in the station table are displayed by pressing the blue key
. By renewed pressing of the blue key all stations are once again
displayed in the station table.
• By selection with the cursor control key of another station and pressing the green
key , you can see the short information of the station on the program and the
start and end times (only DVB stations, not analogue stations).
• By using the joker character % you can look for text characters inside the station
name. For example, enter “%FER” and all station names are listed in which the
character string “FER” occurs, e.g. “hr-fernsehen”, “SWR Fernsehen”.
5. Station Selection
5. Station Selection via program table
Station selection and management of
program positions
The TV set can store the settings for up to
2000 TV stations and 2000 radio stations
in so-called program positions. You can
select any of these program positions with
the numeric keys, with the oval rocker key
“P+/P-“ or from the station table.
If you use the numeric keys for station
selection, the first digit you enter is nor-
mally the “thousands“ digit. If less than
1000 program positions are occupied, it
automatically becomes the “hundreds“
digit.
If less than ten program positions are
occupied, the first digit you enter automa-
tically becomes the “units“ digit.
After pressing any numeric key, you have
three seconds to press further numeric
keys
10 Kabel 1
9 Nord 3
8RTL
7 PRO 7
6 Nord 3
5 PRO 7
4SAT1
3 Bayern 3
2 ZDF
1 ARD
56 Hessen 3
55 SW-BW
Select with ...
or .
Confirm with .
show
HD- stations
Short info prog.
 %  ABC  DEF
 GHI  JKL  MNO
 PQRS  TUV  WXYZ
OK
Pr
Pr
2 x

16
During the design of this TV set, we have made
every effort to make it as easy a possible for you
to use it and we hope that you will enjoy familiari-
sing yourself with your new TV set.
With the “Information“ menu, the TV set is able to
answer the many questions which may come up
during installation and setup.
To display this menu, simply press the key
for the table of contents.
The “Information“ menu (user help)
In the table of contents or the index, you
can select the item of interest with the cursor
control key.
Use the cursor-right key to scroll for-
wards through the contents or index ...
Use the cursor-left key to scroll back-
wards through the contents or index ...
Use the cursor-up key to select the last
underlined item ...
Use the cursor-down key to select the
menu lines...
... and then press the key to display
the explanation of the selected item.
You can select any underlined word in the table of
contents, the index or the explanation of a selec-
ted item with the cursor. Pressing the key
then displays the explanation for this word.
You can also scroll forwards and backwards
through previously displayed pages with the aid
of the red and green keys.
6. User Help (Information)Opening the Info
Information
Contents
Index
Station selection
Picture settings
Sound settings
AV playback
Recording facilities:
- Timer recording
- Direct recording
- AV copying
Teletext
Function keys
DVB radio mode
Electronic Program Guide (EPG)
Select the underlined text with the cursor..
: further information : table of contents
Visited pages:  back  forward
INFO




17
With the “TV menu“, we provide you with an
assistant to help you find your way through the
many possible settings of the TV set.
Don't be afraid to change any
settings in the various menus.
No changes will be saved
unless you press the key
to confirm them. If you are not
sure whether you want to keep
a changed setting, you can
exit from the menu at any
time, without saving any
changes, by pressing the
key.
Within the TV menu, you can
return to the previous main menu
item at any time by pressing the
key. If you are not sure
what a menu item does, press the
key for more information.
In order to return to the menu, press the
key twice.
You can open each of the five main sections of the menu
with the key of the corresponding colour. The “card file“
which is then displayed is subdivided into Subjects (on
the left) and Sections (on the right), and you can select
these by moving the red, triangular cursor with the oval
cursor control key or with the numeric keys.
When you press the key, the current setting
for the selected item is shown in the “Setting win-
dow“ below the card file and can be adjusted
with the V– /V+ key.
You can save the new setting by pressing the
key, which also returns you to the list of sections. If
you do not want to save the new setting, press the
key to return to the corresponding main
menu item or press the key to close the menu.
You can delete any incorrect inputs with the
key.
7. Menu Control Opening the menu
* The number of subjects and sections
depends on the selected scope of operation.
Depending on the configuration of the TV
set, the various menu items may be display-
ed in a different order and numbered diffe-
rently.
Picture profile selection
Zoom/Panorama
Noise reduction
Picture sharpness
Colour impr.
Colour intensity
Power options
Contrast
Brightness
Picture profile adjustment
Sound set,.prog.posn
Sound settings, gen.
Pict.set.,prog.posn.
Picture settings, gen.
Picture-Volume
Setting window
Related numeric keys
Cursor Section*Subject*
MENU
EXIT

18
Teletext is an additional service provided free of
charge by many TV stations. It is an “electronic
magazine“ through which you can browse in
various ways.
Opening Teletext:
• Press the “TEXT“ key. If the selected
station offers “TOP-Text“, a “card
file“ is displayed (see the picture on
the left).
If “TOP-Text“ is not available, Teletext
page 100 is displayed (see the pictu-
re below).
• In the TOP-Text card file, you can
select the desired cards with the cur-
sor control key or with the numeric
keys.
• Press the key to open the selec-
ted card.
Controlling Teletext with pages
displayed:
Blue key – next subject.
Yellow key – next section.
White key – next page.
After pressing the coloured pre-selec-
tion key, you can step through the sub-
jects, sections or pages with the cursor
control key or with the numeric keys.
If you wish to select a specific page,
enter its page number on the numeric
keys.
If sub-pages exist for the selected page,
the page numbers are displayed in black. In the
example shown here, there are five sub-pages.
You can step through these sub-pages with the
cursor control key.
8. TeletextOpening the menu
Page number
i
Gehörlose
Börse
Service
BR-Intern
Hörfunk
Fernsehen
Sport
Bayern
Schlagzeilen
Übersicht
Impressum
A-Z
100
100 ProSieben Datum Uhrzeit
100
Kartenlegen
Live
Gratis
09.56 talk talk talk. . . . . . . . . . . . . . . . . . . . . . 334
10.56 S.O.S.Style & Home. . . . . . . . . . . . . . . . 335
Aktuelle Meldungen. . . . . . . . . . . . . . . . . . . . . . . 112
Computer Wurm . . . . . . . . . . . . . . . . . . . . . . . . . 113
TED: Brauchen wir Schutz ? . . . . . . . . . . . . . . . . . 123
Weitere Meldungen. . . . . . . . . . . . . . . . . . . . . . . 135
458
00 01 02 03 04 05 06 07 08 09
Sub-pages
TEXT

19
Double font size
You can double the size of the font used
for Teletext pages with the key.
Pressing this key once displays an enlar-
ged picture of the upper third of the
page. Pressing it a second and third time
displays the centre and lower thirds of
the page. Pressing a fourth time displays
the entire page again.
Riddle key (display hidden text)
Function key is programmed in
the factory to display hidden text, such
as the answers to riddles.
Back to the last index page
You can return directly to the last index
page you have displayed by pressing
the numeric key .
Stop page scrolling
The II key or the “OK“ key can be used
to stop the automatic scrolling executed
by some pages, and to enable this
again.
Page selection with the cursor
Press the key to stop page scrol-
ling. The cursor is now positioned at
the top left corner of the page and you
can use the cursor control key    
to position it anywhere on the displayed
page. This function is useful on index
pages (such as pages 100, 200, etc.) in
order to select a page you want to see.
After positioning the cursor on the des-
ired page number, press the key to
display its contents.
Setting marks in Teletext 6)
As a user of Teletext, you will probably
want to visit certain pages (such as stock-
market news, news pages or the weather
forecast) regularly.
In order to find these pages quickly, you
can set marks to suit your personal requi-
rements.
To do this, open a page for which you
want to set a mark.
• Press the red key for “Set“ to place
a mark on this page. The number of the
mark you have just set is displayed
above the window containing the num-
ber of the Teletext page. In the case of
multiple pages, the mark is always set
and displayed for the currently display-
ed sub-page.
Up to 10 marks can be set for each
program position.
Scrolling through marked
Teletext pages 6)
With the Teletext window open, you can
step sequentially through the marked
pages with the green key.
An even easier method is by pressing the
key while the TV program is dis-
played. Each time you press this key, the
next marked page is displayed. After the
last marked page, the TV picture is dis-
played again.
☞
8. Teletext
6) Not possible with an external receiver !

20
Displaying all Teletext marks 6)
If you have set marks for a program
position, you can display an overview of
these marks by pressing the key.
The displayed list shows where the marks
are set. Press again to hide the
list.
You can select the individual marks in
the list with the numeric keys.
Clearing Teletext marks 6)
Open the Teletext page whose mark is to
be deleted and press the red key
“Delete“ to delete the mark.
Subtitles in Teletext
Your TV set is capable of displaying sub-
titles. When a program for which subtit-
les exist starts, the TV station displays a
box showing the Teletext page on which
these can be found.
• Press the key to open Teletext.
• If this is a “TOP-Text“ station, the card
file is displayed. Press the key
and open any available page.
• Use the numeric keys to enter the num-
ber of the page containing the subtit-
les.
Split-Screen
In Teletxt mode, the TV-Programm win-
dow in the upper left corner can be
enlarged to half of your screen by pres-
sing the “TV“ button.
If you press “TV“ button again, it will be
used to the orginal size.
8. Teletext
6) Not possible with an external receiver !
9. Selecting operating mode
You can switch the TV set between its various ope-
rating modes with the keys and .
You can also switch from standby mode to the
desired operating mode with these keys.
= TV mode /DVB Radio mode 1)
= TV mode with input from AV devices
(e.g. video tape recorder, DVD player,
etc.)
1) Possible only in DVB mode
6)
Not possible with a set top box
TV/R
0/AV
