Meyer Sound Control Electronics Unit MPS-3 User manual

Note 2:
“A” weighted noise input, speaker driven by 125 W (8 ohm rating for MPS-
305, 16 ohm rating for MPS-355) mono power amplifier.
MPS Series 3
MPS-305 Reinforcement Loudspeaker MPS-355 Reinforcement Loudspeaker
Designed for sound reinforcement applications requiring
absolute minimum size, the ultra-compact MPS-305 deliv-
ers full-range performance with very low distortion. The
loudspeaker comprises a single 5-inch low-frequency cone
driver and 2 by 5 inch horn-loaded piezoelectric high-fre-
quency element.
Suitable for a wide range of applications from music
playback and delay fill systems to stage monitoring, the
MPS-355 features outstanding low-frequency response.
It␣comprises two 5-inch low-frequency cone drivers and a
2␣by␣5␣inch horn-loaded piezoelectric high-frequency ele-
ment.
Frequency Response1
Maximum SPL2
Continuous
Peak
HF Distribution Pattern
Driver Complement
Low-Frequency
High-Frequency
Cabinet Impedance
Enclosure
Type
Finish
Connector
Grill
Mounting Points
Physical Dimensions
Weight
Frequency Response1
Maximum SPL2
Continuous
Peak
HF Distribution Pattern
Driver Complement
Low-Frequency
High-Frequency
Cabinet Impedance
Enclosure
Type
Finish
Connector
Grill
Mounting Points
Physical Dimensions
Weight
70 Hz to 20 kHz ±4 dB
102 dB
112 dB
80°horizontal by 60°vertical
MS-5 5-inch cone driver
2"x5" horn-loaded piezoelectric
8 ohms
0.17 cu. ft. acoustic suspension
Black textured
XLR (A-3) or Neutrik SpeakOn™
Metal screen with black cloth
3⁄8"-16 nut plates
6 3⁄4" W x 10 1⁄2" H x 7" D
6.6 lbs (3 kg)
60 Hz to 20 kHz ±4 dB
108 dB
118 dB
80°horizontal by 60°vertical
(2) MS-5 5-inch cone driver
2"x5" horn-loaded piezoelectric
16 ohms
0.31 cu. ft. vented
Black textured
XLR (A-3) or Neutrik SpeakOn™
Metal screen with black cloth
3⁄8"-16 nut plates
6 3⁄4" W x 18 " H x 7" D
11 lbs (5 kg)
Note 1:
Measured at 1 meter on axis, pink noise input, in third-octave bands with
half-space loading.

™
MPS-3 Control Electronics Unit
Input Type
Output Type
Maximum Input/Output Level1
Unbalanced
Balanced
Hum and Noise2
Driver Protection Circuitry
Indicators
Sense/Limit
Power
Controls
Connectors
Balanced Input/Output
Sense
Power
Physical Dimensions
Weight
Active balanced, 24k ohms
Push-pull, 200 ohms output Z
>+16 dBu
>+22 dBu
<-85 dBV
RMS and peak limiters
Bicolor (grn/red) LEDs
Green LED
Output Levels. Power, Stereo/
Mono and Lo Cut switches
3-pin XLR (A-3) type
Banana jacks
120/240V AC, 50/60 Hz, 15 watts
19" W x 1 3/4" H x 7 3/4" D
7 lbs (3.1 kg)
MPS Series 3 loudspeakers are designed to operate with
the MPS-3 Control Electronics Unit. A two-channel unit op-
erating at line level, the MPS-3 is the final component in
the signal chain before the power amplifier.
Optimized for Series 3 loudspeakers and aligned at the
factory, the MPS-3 comprises frequency and phase response
alignment circuitry, and Meyer Sound’s SpeakerSense™
driver protection circuitry, with both peak and RMS signal
limiting. Complementary phase equalization in the MPS-3
gives the Series 3 loudspeakers flat frequency response with
outstanding phase characteristics.
SpeakerSense protects the Series 3 drivers from damage
due to overheating under continuous high power condi-
tions. Through a Sense connection to the power amplifier
outputs, this unique circuit continuously monitors the
power applied to the loudspeaker, and limits the signal out-
put when the safe operating limits of the loudspeaker are
exceeded. Until the onset of overload, the SpeakerSense cir-
cuit has no effect on the signal.
MPS-305 Architect’s and Engineer’s Specifications
ing) amplifier shall meet the following performance crite-
ria: Frequency response, 60 Hz to 20 kHz ±4␣dB measured
in half space at 1 meter on axis with pink noise at
1
⁄ 3 octave
resolution; output of 108 dB SPL measured at 1 meter on
axis with peaks of 118 dB SPL when driven with “A”-
weighted noise. Distribution pattern, 80°H by 60°V.
Speaker enclosure dimensions shall be 6
3
⁄ 4 " W x 18" H x
7" D, weight 11 lbs (5 kg).
The speaker enclosure shall be the Meyer Sound
MPS-355.
The ultra-compact reinforcement speaker system shall
be a passive 2-way type with a 5-inch low-frequency loud-
speaker front mounted in a hardwood plywood enclosure
and a high-frequency piezo-electric driver mounted on a
2"␣x 5" horn. The enclosure shall be fitted with four
3
⁄ 8 "–16
threaded mounting points, and shall operate with a sepa-
rate Control Electronics Unit.
The speaker system combined with a 125␣W (8 ohm rat-
ing) amplifier shall meet the following performance crite-
ria: Frequency response, 70 Hz to 20 kHz ±4␣dB measured
in half space at 1 meter on axis with pink noise at
1
⁄ 3 octave
resolution ; output of 102 dB SPL measured at 1 meter on
axis with peaks of 112 dB SPL when driven with “A”-
weighted noise. Distribution pattern, 80°H by 60°V.
Speaker enclosure dimensions shall be 6
3
⁄ 4 " W x 10
1
⁄ 2 " H
x 7" D, weight 6.6 lbs (3 kg).
The speaker enclosure shall be the Meyer Sound
MPS-305.
MPS-355 Architect’s and Engineer’s Specifications
The ultra-compact reinforcement speaker system shall
be a passive 3-way type with two 5-inch low-frequency loud-
speakers, front mounted in a ducted bass-reflex plywood en-
closure with a high-frequency piezo-electric driver
mounted on a 2" x 5" horn. The enclosure shall be fitted
with four
3
⁄ 8 "–16 threaded mounting points, and shall oper-
ate with a separate Control Electronics Unit.
The speaker system combined with a 125␣W (16 ohm rat-
MPS-3 Architect’s and Engineer’s Specifications
The Control Electronics Unit shall contain a power sup-
ply capable of 120/240V AC 50/60 Hz operation, equaliza-
tion for amplitude and phase alignment, protection cir-
cuitry which activates under high power conditions, RMS
limiter to protect the speakers from overheating, active bal-
anced input, push-pull output, and LED indicators for
power on and limiters. Total harmonic distortion at
+22␣dBu at the balanced output loaded with 10k Ωshall be
less than .1% at 1kHz. The “A”-weighted noise level shall be
at least 100 dB below maximum rated output of +22 dBu.
Control Electronics Unit dimensions shall be 19" W x
1␣
3
⁄ 4 " H x 7
3
⁄ 4 " D, weight 7␣lbs (3.2 kg).
The Control Electronics Unit shall be the Meyer Sound
MPS-3.
Power A B Mono Lo Cut
A B
Sense / Limit
Stereo Flat
Output Level
010 010
MPS-3 Control Electronics Unit
2
4 6
8 2
4 6
8
Note 1:
1 kHz, 10k ohm load, <0.1% THD. Note 2: “A” weighted, unbalanced.
© 1994 Meyer Sound
04.014.008.01 A2
Meyer Sound Laboratories, Inc.
2832 San Pablo Avenue
Berkeley, CA 94702
[phone]
FAX [phone]
