Mezzo CVC 1607 User manual

Upright Cyclonic Vacuum Cleaner
Thank you for choosing to purchase one of our MEZZO®products, we appreciate your business and believe
that we have provided you with a product that is both reliable and value for money. We encourage you and your
friends to choose from our range of MEZZO® products again in future.
TECHNICAL SPECIFICATIONS
Model No. CVC 1607 Upright Cyclonic Vacuum Cleaner
Supply Voltage 230-240V ~ AC 50 Hz
Power 1600 Watts
PACKAGE CONTENTS
1 x Upright Cyclonic Vacuum Cleaner
1 x Dust Canister (will be fitted to unit)
1 x Removable Filter (will be inside dust canister)
2 x Plastic Tubes
1 x Accessory brush tool
1 x Accessory crevice tool (will be inside one of the plastic tubes)
1 x Instruction Manual
Confirm all parts before disposing of carton.
OPERATION
This vacuum has been designed for general household use only. Carry the vacuum and required accessories to the
area to be vacuumed.
For any customer query or in the unlikely event of a product failure, please phone or
email the helpline contact details below for assistance.
DO NOT RETURN THE PRODUCT TO THE RETAILER.
Toll Free Help line: 1300 366 144
Email: [email protected]
1

PARTS GUIDE
1. Upper handle 8. Handle
2. Brush head tool 9. Front panel
3. Flexible hose 10. Bag full indicator
4. Power head 11. Air Filter
5. Extension tubes and crevice tool 12. Main body
(Located inside tube) 13. Securing screws
6. On/Off switch 14. Hose support/Cord wrap
7. Power selector 15. Foot pedal
SAFETY INSTRUCTIONS
Carefully read this manual before using this appliance. Make sure that you know how the appliance functions and
how to operate it. Maintain the appliance in accordance with the instructions to ensure that it functions properly.
Keep this manual with the appliance. If the appliance is to be used by a third party, this instruction manual must
be supplied with it. The safety instructions, by themselves, do not eliminate danger completely, and proper
accident prevention measures must always be used.
BEFORE INITIAL USE
Remove all packaging. Carefully wipe the outer case with a soft damp cloth and dry it afterwards with a dry
towel. Do not immerse the appliance in water or any other liquid. Check for any damage that may have occurred
during transit. Do not use if the appliance is damaged in any way or if the supply cord is damaged. Immediately
return to supplier for replacement or repair.
OPERATION GUIDE
Assembly
Take the Vacuum Cleaner out of the box and ensure that you have all components and that there are no damaged
parts.
Place the main unit and all parts on the floor in front of you.
Slide the upper handle (1) assembly into the joining socket of the body (12). Make sure the two parts are aligned
and connected and secure with the three screws (13).
Adjusting the Vacuum Cleaner Angle
The angle of your Vacuum Cleaner adjusts easily as you vacuum for easy use on carpets and floors. Press the
foot pedal (15) with your foot to release, and then tilt the unit to the desired position. As a guide, use the
Vacuum Cleaner in an UPRIGHT position for storage and when using the Cleaning Attachments, and use in the
SLIGHTLY TILTED position for general operation on carpets and floors.
2 3

Brush Height Adjustment Storage
To adjust the brush height, simply slide the height-adjusting slide located in front of the exhaust
filter (11) from Low to High (or High to Low). When not in use store the vacuum cleaner, accessories and these instructions in a dry place.
The brush height should be set to low when vacuuming most hard floors (such as linoleum, tiles or
wood) or when vacuuming short piled carpets. If using on highly polished floors you may want to set
the brush height to high so that the brushes do not scuff the polished surface.
SAFETY PROTECTION
The cleaner is fitted with a thermal cut out that protects it from overheating. Should the unit stop suddenly, there
is a chance it may have overheated. If this occurs switch off the vacuum cleaner and allow it to cool for a period
of 40 minutes before recommencing. Should the vacuum cleaner still not operate, contact the service provider
listed.
The brush height can be set to high when vacuuming long piled carpets, or when you do not want the
brush to be utilised.
Carpet / Floor Hose Assembly
For standard carpet or floor use, ensure that the Stretchable Hose is connected to the Vacuum
Cleaner as shown in the diagram on Page 2. Rest the Hose over the top of the Hose Support (14) and
attach the loose end to the Extension Tube. Slide the Extension Tube into the Bracket and push
firmly over the connection socket.
GENERAL SAFETY
Above Floor Cleaning
To use the cleaner accessories for cleaning furniture, curtains or other high areas simply remove the
hose assembly from the power head assembly and attach the desired accessory. The vacuum cleaner
is supplied with 2 extension pipes, a long crevice tool and a small brush head tool. When using electric appliances basic safety precautions should always be followed to reduce the risk of fire,
electric shock and personal injury. Read all these instructions before attempting to use the machine.
Care
Basic Operation of the Vacuum Cleaner Do not vacuum fine abrasive dust particles, lit cigarettes, embers or hot ash. Do not vacuum large objects that
may block the hose or pipes. Do not tilt the vacuum cleaner when in use. Do not drop the vacuum cleaner onto
the floor.
Plug the cord into a suitable electrical outlet ensuring the voltage is 230-240V.
To turn the vacuum cleaner ON, push the power switch (6) down.
This will start rotating the floor brush and activate the suction operation of the unit.
WARNING! The agitator (rotating floor brush) continues to rotate while the vacuum cleaner is in
the upright position. As such, avoid leaving the vacuum cleaner (when operating) in one position for
extended periods of time. Set the brush height to High when using the cleaning attachments. Consider the environment.
Do not use in damp or wet conditions. Do not use without adequate light. Do not use near flammable or
hazardous materials. Do not use outdoors. Do not leave unattended while connected to the power supply.
To turn the vacuum cleaner OFF, push the power switch (6) down again. Keep children away.
Emptying the Dust Canister. This appliance is not intended for use by young children or infirm persons without supervision. Young children
must be supervised to ensure that they do not play with it.
Ensure the vacuum cleaner is disconnected from the power supply. To empty the dust canister
simply press the release button located on the top of the dust compartment canister and pull outwards
(away from the Vacuum Cleaner). To replace simply re-insert the dust canister bottom-first and lock
into place. To remove the dust canister lid turn anti-clockwise. Remove the filters and dispose of
contents. It is recommended that the filter be cleaned when the dust canister is emptied.
Damaged or dropped.
Always inspect your appliance before use. Do not use this appliance if it has been damaged, dropped, left
outdoors or dropped in water. Return it to an authorised service dealer for examination and repair. Do not attempt
to service this appliance yourself. Refer servicing to qualified service personnel.
Filters.
The main filter on this vacuum cleaner is located inside of the dust canister (10). This filter also has
a protective cover, or secondary filter. This main filter and the filter cover can be washed in a
solution of warm water mixed with a small amount of mild detergent. Do not re-use until completely
dry. Remove the main filter and the filter cover by sliding upwards from its position inside the dust
canister.
Store in a safe place
When not in use store your vacuum cleaner and all its accessories and instruction manual in a safe and dry place.
Liability.
No liability can be accepted for any damage or personal injury caused by non-compliance with these instructions
or any other improper use or mishandling. This appliance is intended for household use only.
The other removable filter is located on the front of the unit (11), at the base. This is an exhaust filter
and should only be cleaned by brush or blown air. Remove the exhaust filter cover by pressing the
release button. Remove the filter from the filter holder and clean. Re-insert the filter and cover by
placing the bottom in first and then pressing the top of the cover, which should click back into place.
4 5

CARE AND CLEANING
Before cleaning.
When not in use or before cleaning, always disconnect the vacuum from the mains supply. ELECTRICAL SAFETY
Cleaning guide. When using electric appliances always observe safety regulations where applicable to reduce the risk of fire,
electric shock and personal injury.
Regularly clean the outside of the appliance with a soft damp cloth and dry it with a dry towel. Do
not immerse motor housing in water. Do not use harsh solvents to clean the plastic components. Always check that the power supply corresponds to the voltage on the rating plate.
Accessories. Supply cord and plug.
Always keep the hose and pipes clear from obstruction. Always fully unwind any cord to avoid overheating. Never allow the supply cord to come in contact with hot
objects. Do not carry the appliance by the cord or yank the cord to disconnect it from the mains supply. Do not
over extend the cord by pulling out further than the yellow indicator mark. Disconnect by first switching off the
outlet, grasping the plug and pulling it out gently.
Cleaning the dust canister
Follow the steps below to remove, empty, clean and replace the dust canister:
•Remove the dust canister by pressing the release button located on the top of the canister. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly qualified
person in order to avoid a hazard.
•Holding the dust canister with one hand, unscrew the dust cap by turning the cap anti
clockwise and remove the cap.
•Reach inside the container and remove the filter and filter cover by twisting it off of the stem. Children.
•Remove the filter cover from the filter and shake off any dust, which has accumulated. Caution. Keep out of reach of children.
•Clean the dust compartment filter and filter cover each time you empty the dust compartment.
This will help maintain maximum efficiency. These filters should be cleaned with a dusting
brush and regularly washed in warm water with a mild detergent added. NOTE: The filters
must be completely dry before re-inserting into the dust canister.
This appliance is not intended for use by young children or infirm persons. Young children must be supervised to
ensure that they do not play with the appliance.
Water.
Do not immerse any part of this appliance or supply cord in water. Do not use with wet hands or use in damp
situations.
•Empty the contents of the dust container into a rubbish bin.
•Wipe the inside of the dust container with a damp cloth and dry thoroughly.
•Place the filter cover onto the filter and replace back onto the stem inside the dust container. Handling.
•To replace the lid, line the arrow on the lid up with approximately 3cm to the right of the
arrow on the dust canister. The lid should slot into a groove in the lid, and then turn the lid in a
clockwise direction so that the two arrows line up against each other. Do not drop the vacuum cleaner as this may cause damage to the wheels or internal components. Do not use this
appliance if it has been damaged in any way, immersed in water, the supply cord is damaged or the operation is
faulty. Contact with any damaged appliance could result in electric shock.
•Once the lid is in place, to return the canister to its original position, place the base of the dust
canister on to the clip at the bottom of the compartment ensuring the back and top of the unit
are aligned to the original positions.
Unplug the vacuum cleaner when not in use.
•Then simply push back into place. You will know it is successfully in place once the top hinge
has clipped back into position and you hear a “click” sound.
7
6

WARRANTY CARD
This product is guaranteed against faulty materials and workmanship for a period of twelve months
from the date of purchase. This warranty becomes void if the product has been tampered with,
damaged by accident, damaged in any other way by improper use or has been purchased second
hand. All production orders have quality inspections.
For any customer query or in the unlikely event of a product failure, please
phone or email the helpline contact details below for assistance.
DO NOT RETURN THE PRODUCT TO THE RETAILER.
WARRANTY FOR APPLIANCES USED COMMERCIALLY LIMITED TO 90 DAYS
Product: Upright Bagless Vacuum Cleaner
Model No.: CVC1607 Purchase Date:_____________________
Product Purchased From:
_________________________________________________________________________________
_________________________________________________________________________________
Your Name:_____________________________________________________________________
Address:
________________________________________________________________________________
_______________________________________ Phone Number:
IMPORTANT!
Please retain this warranty card along with your purchase receipt. Please do not
post to the retailer Toll Free Help line: 1300 366 144
Email: [email protected]
