Installation and user
manual
CleanWave
18÷280 kVA
English

MGE-UPS CleanWave - Installation and user manual Page 2/13
Version 2.1.4 – 15/01/2007 -
INDEX
1. INTRODUCTION.....................................................................................................3
2. PRESENTATION ....................................................................................................3
2.1. General presentation................................................................................................................................ 3
2.2. Range.........................................................................................................................................................5
2.3. Technical specifications...........................................................................................................................6
3. SAFETY ..................................................................................................................7
3.1. Integration in housing..............................................................................................................................7
3.2. Cooling......................................................................................................................................................7
3.3. Electrical connections ..............................................................................................................................7
3.4. Access to the filter .................................................................................................................................... 7
4. ELECTRICAL ENGINEERING................................................................................8
4.1. Electrical schematic .................................................................................................................................8
4.2. Electrical protections...............................................................................................................................8
4.3. Wiring ....................................................................................................................................................... 8
5. INSTALLATION AND STARTING ..........................................................................9
5.1. Handling.................................................................................................................................................... 9
5.2. Electrical connections ..............................................................................................................................9
5.3. Energising...............................................................................................................................................10
6. MAINTENANCE....................................................................................................11
7. TROUBLESHOOTING..........................................................................................12
8. CONTACT.............................................................................................................12

MGE UPS SYSTEMS CleanWave - Installation and user manual Page 3/13
Version 2.1.4 – 15/01/2007 -
1. INTRODUCTION
The present document is a user manual for the zero-sequenced filters CleanWave.
It is intended to the persons responsible for the installation, the use and the maintenance of the filters.
Each of these aspects is detailed in a specific chapter here under.
2. PRESENTATION
2.1. GENERAL PRESENTATION
The CleanWavefilter exists in 2 versions :
IP00 : Basic version to be integrated by the customer.
IP21 : "Turn-key" version integrated in its housing.
The IP00 version of the Cleanwavefilter appears as follows:
1
2
4
3
5
Fig. 1
Fig. 2
9
7
8
34
6
1 Lo element
2 Zo element
3 Upstream (mains) terminals (1 - 4 )
4 Downstream (load) terminals (5 - 8 )
5 Fixation for optional current transformer for upstream
and downstream neutral current measurements
6 Lifting rings
7 Earth terminal
8 Identification plate
9 Temperature switches terminals

MGE UPS SYSTEMS CleanWave - Installation and user manual Page 4/13
Version 2.1.4 – 15/01/2007 -
The IP21 version of the CleanWavefilter appears as follows :
10 11
14
12
17
15
16
13
Fig. 3
10 Lifting rings
11 Upstream current display
12 Downstream current display
13 Removable top panel
14 Side panel for cabling
15 Ventilation grid
16 Removable front panel
17 Identification plate
Inside the housing, the filter is identical to the IP00 version shown on Fig. 1.

MGE UPS SYSTEMS CleanWave - Installation and user manual Page 5/13
Version 2.1.4 – 15/01/2007 -
2.2. RANGE
The following table summarises the characteristics of the different products of the range (at 400V,
50/60Hz).
Minimum sections 1
TYPE Power.
Iphase
max Ineutral Max
Total
losses
max Phases Neutral (N) Earth (PE) ( PEN 2)
[kVA] [A] [A] [W] [mm²] [mm²] [mm²] [mm²]
CleanWave-18 18 24 43 219 4 10 4 10
CleanWave-30 30 40 72 359 10 25 10 25
CleanWave-40 40 56 101 452 16 35 16 35
CleanWave-55 55 80 144 538 25 2x 25 16 2x 25
CleanWave-90 90 128 231 616 50 2x 50 25 2x 50
CleanWave-140 140 201 361 972 95 2x 95 50 2x 95
CleanWave-180 180 264 476 1212 150 2x 150 95 2x 150
CleanWave-220 220 321 577 1565 2x 95 2x 185 95 2x 185
CleanWave-280 280 401 722 1568 2x 95 2x 240 95 2x 240
Table 4
1According to European standards
2If common conductor for neutral and earth (PEN conductor)
