MGF 901250 User manual

1
MGF
MGF srl –– Via Chico Mendes, 8 – 43058 Sorbolo Mezzani (PR) I aly – Tel. [phone] Fax: [phone]
e-mail: info@mgf ools.com – www.mgf ools.com – www.nebulife.i – www.nebulizzare.com
Ar . 901250
Manual Threading Tool
1/2''-2'' BSPT(R)
User Manual
Rev. 0 da ed 19/05/2022

Introduction
Introduction
This user manual, supplied wi h he ool, provides impor an ins ruc ions for he correc use and main enance of he ool.
Reading his manual and complying wi h he provisions con ained herein are necessary condi ions for he validi y of he warran y and for he
correc and safe opera ion of he sys em.
I is he responsibili y of he cus omer o keep his manual, o provide adequa e ins ruc ions o any user for he correc use of he sys em.
The manual is available for download in i s la es upda e a www.mgf ools.com
The manufac urer declines all responsibili ies for damage caused by negligence and failure o observe he rules described in his manual.
General informations
General informations
SERVICE
For any form of echnical assis ance you can con ac us in one of he following ways:
elephone: [phone]
fax: [phone]
email: assis enza@mgf ools.com
We will serve you as soon as possible.
The shipmen of ma erial under repair mus be previously au horized by means of he RMA form (binding condi ion for he collec ion of any goods
under repair).
WARRANTY TERM
The produc warran y covers any manufac uring defec for a period of ime equal o one (1) year from he da e of manufac ure for produc s
purchased wi h invoice, 2 years for produc s purchased by priva e individuals.
The following clauses expressly exclude he produc from guaran ee:
•Consumables insofar as he malfunc ion is caused by normal wear of he par s
•Damage caused by improper opera ion
•Bad main enance
•Tool ampering or modifica ion
The company excludes from i s responsibili y any indirec damage, damage caused o people and hings by defec s and machine down ime,
incorrec use, lack of main enance.
The tool
The tool
Manual Threading Tool 1/2''-2'' BSPT(R) is designed o hread pipe or condui using individual die heads for each size of pipe and a manually
opera ed ra che .
Fea ures
•Weigh : 25 kg
•Working range: 1/2'' – 2''
•Wide ou pu for chips
•Machine-made heads
•Quick-clu ch bushes
•Provided in me al case, heads, ra che wi h lever
Warning! Read hese ins ruc ions carefully before using his ool. Failure o follow all ins ruc ions may resul in proper y damage and/or serious
injury.
Open Box Inspection
Open Box Inspection
Open he packing box and please check if he following i ems are deficien or damaged. Please con ac your supplier immedia ely if any i ems is
deficien or damaged.
1. Me al case 1 pc
2. Threding ool and heads 1 se
3. User Manual 1 pc
2
MGF
MGF srl –– Via Chico Mendes, 8 – 43058 Sorbolo Mezzani (PR) I aly – Tel. [phone] Fax: [phone]
e-mail: info@mgf ools.com – www.mgf ools.com – www.nebulife.i – www.nebulizzare.com

Instructions
Instructions
Warning! Read hese ins ruc ions carefully before using his ool. Failure o follow all ins ruc ions may resul in proper y damage and/or serious
injury.
1. Inspec he hreader before use. Replace dies or any o her par ha shows damage or wear. To ensure a high quali y hread, only use
MGF
MGF Tools replacemen dies.
WARNING Worn dies can resul in poor hread quali y and high handle forces
2. Moun he pipe firmly in a pipe vise. When hreading an exis ing pipe, make sure i is secure and will no move. Cu he end of he pipe
cleanly and squarely using a pipe cu er (look for he "Hand Tools" sec ion on www.mgf ools.com).
WARNING When working on a scaffold or lif , he opera or should be properly secured o preven injury in he even of a fall.
3. Ream he end of he pipe o remove any burrs ha may have been produced during he cu ing of he pipe
4. Selec he correc die head for he size and ype of pipe o be hreaded and he hread form you require. Inser die head in o he ra che .
Slip he pipe guide a he rear of he hreader over he pipe and gen ly apply pressure o he fron of he die head a he same ime
moving he handle down in order o s ar he hreader.
WARNING Make sure he handle is clean and free from oil and grease. This allows for be er con rol of he ool.
5. Before applying force o he handle, ensure ha he ra che pawl is engaged.
WARNING Pawl may fail o engage if pushed agains he side of he die head. Specific care should be aken when hreading pipe ha is
ver ical.
6. When hand hreading, your weigh should be above he handle ensuring maximum leverage. If possible, do no do all he work wi h your
arms, use your weigh . Do no overreach. Keep proper foo ing and balance o main ain be er con rol.
WARNING Do no slide a pipe or “chea er” over he handle o gain ex ra leverage. This prac ice can resul in serious injury
7. Apply a generous quan i y of MGF MGF Tools Thread Cu ing Oil when hreading (see sec ion "Accessories and Spare Par s"). Use of a
lubrica ing oil or a poor hread cu ing oil can resul in a poor quali y cu hread, leaky join s, shor die life and high handle forces.
8. S op hreading when he end of he dies are flush wi h he end of he pipe. A his poin , he correc size has been reached o produce
he proper join . To con inue beyond his poin would make a s raigh or running hread.
9. When he hread is comple e, back off he die head by reversing he ra che mechanism and urning he die head in he opposi e
direc ion. When he dies are nearly removed from he hread, main ain close con rol of he hreader so ha he hreads are no damaged
when removing he die head.
NOTE! Clean any oil spill or spla er ha is on he ground. A he end of each job, always clean your hreader and s ore in a clean dry area o
pro ec agains damage (see sec ion “”S orage).
If you have any ques ions regarding he use of his hreader, please con ac he MGF MGF Technical Service Depar men , see he “General Informa ion”
paragraph.
Accessories and Spare Parts
Accessories and Spare Parts
Ar . Model Ar . Model
790003 Oil for Threading 100 ml 323005A Die Head 1/2'' BSPT (R)
790005 Spray oil for hreading 400 ml 323007A Die Head 3/4'' BSPT (R)
790006 Spray oil for hreading 600 ml 323009A Die Head 1'' BSPT (R)
790110 Threading Oil 5L 323011A Die Head 1 1/4'' BSPT (R)
320052 Small die heads oc agonal adap er 323015A Die Head 1 1/2'' BSPT (R)
320054 Terminal S ops 323017A Die Head 2'' BSPT (R)
320069 Die adap er 2" 324005A Dies se 1/2'' BSPT (R)
320051 Threading Tool Ra che 2'' wi hou Lever 324007A Dies se 3/4'' BSPT (R)
320056 Ra che Threading Tool 2'' Lever 324009A Dies se 1'' BSPT (R)
324011A Dies se 1 1/4'' BSPT (R)
324013A Dies se 1 1/2'' BSPT (R)
324015A Dies se 2'' BSPT (R)
Use only original MGF MGF spare par s
When ordering spare par s, no e he ar icle number of he ool o find he correc par number for he required spare par .
3
MGF
MGF srl –– Via Chico Mendes, 8 – 43058 Sorbolo Mezzani (PR) I aly – Tel. [phone] Fax: [phone]
e-mail: info@mgf ools.com – www.mgf ools.com – www.nebulife.i – www.nebulizzare.com

Disposal of Waste
Disposal of Waste
Damaged ins rumen s, accessories, and packaging ma erials mus be recovered and reused in an environmen ally friendly manner.
•Recycling and separa e collec ion are he responsibili y of he user.
•S ore he produc a a place ha recycles elec rical and elec ronic equipmen .
•If you do no know where o do his, con ac he municipal office in charge or he garbage collec ion service
Storage
Storage
•When no in use, s ore he ool in a cool place. To pro ec agains dir and dus , use he original packaging
•Follow he main enance ins ruc ions
