MGI MODERN DIGITAL CLOCKHIDDEN CAMERA User manual

MODERN DIGITAL CLOCK
HIDDEN CAMERA
SKU: MiniClockDeluxe
THANK YOU FOR PURCHASING THE MODERN DIGITAL
CLOCK HIDDEN CAMERA
Please read this manual before operating the modern digital clock
hidden camera and keep it handy.
Our line of mini clock cams is one of our bestselling products. These
functional clocks with hidden cameras are a great option for covert
recording. The sleek design with blue LED display will fit in
anywhere. The display cycles through time, date, and temperature.
This camera can record 280*960 resolution color video with a 72°
viewing angle, which can be stored on a MicroSD card 2GB – 32GB in
size. The battery lasts up to 2 hours on one charge. Use the remote
control to choose between taking photo, recording continuous video,
or using motion detection.
Your purchase should include:
x Modern Digital Clock Hidden Camera
x Remote Control
x USB Cable
x AC Charger with Cable
x Instruction Booklet

3
GET FAMILIAR WITH YOUR MODERN DIGITAL CLOCK
HIDDEM CAMERA
Figure : Front View
Figure 2: Back View
Charging Light
LED Display
Talk Button
Clock Function Buttons
USB Port Power Switch
SD Card Slot
Camera Lens
Indicator Light

OPERATING THE MODERN DIGITAL
CLOCK HIDDEN CAMERA
IMPORTANT NOTICE: Allow the device to
charge 4 – 6 hours be ore using.
HOW TO CHARGE THE MODERN
DIGITAL CLOCK
Using the AC Adapter
. Push the switch to OFF
2. Plug the AC adapter with cable into
a wall outlet
3. Plug the cable into the clock
• The red charging light will be
on while the device is
charging
Using the USB Cable
. Push the switch to OFF
2. Plug the USB cable into your PC
3. Plug the USB cable into the clock
• The red charging light will be
on while the device is
charging
• The red charging light will
turn off when fully charged
HOW TO SET THE TIME AND DATE
The time, date, and temperature will all be
displayed on the front LED display.
The first time you plug in the mini clock
travel, the LED display will count upward
0 – 9.
The LED display will rotate between time,
date, and temperature. The temperature
default is Celsius and the time default is
Military.
Five buttons that you need for setting up
the mini clock travel are located on the back
of the device (see Figure 2):
• TIME
• DOWN
• UP
• SET
• MODE
Set the Year
. Push the SET button on the back of
the device. “20 0” should be
blinking on the LED display.
2. Push the UP button on the back of
the device until the LED display
reads the current year.
Set the Month and Day
. Push the SET button again. There
should be a “ ” blinking on the left
side of the LED display. This is the
month.
2. Push the UP or DOWN button until
the number on the left side reads
the current month.
3. Push the SET button again. There
should be a “ ” blinking on the right
side of the LED display. This is the
day.
4. Push the UP or DOWN button until
the number on the right side reads
the current day.
Set the Time
. Push the SET button again. The hour
should be blinking.
2. Push the UP or DOWN button until
the LED display reads the current
hour.
3. Push the SET button again. The
minutes should be blinking.
4. Push the UP or DOWN button until
the LED display reads the current
minute.
Switch from Military to Civilian Time
. Push the TIME button on the back
of the device.
2. Push the UP button to switch
between military (24:00) and
civilian ( 2:00).
Switch from Celsius to ahrenheit
. Push the TIME button on the back
of the device.
2. Push the DOWN button to switch
between degrees Celsius and
degrees Fahrenheit.

3
Set the Alarm
. Push the MODE button on the back
of the device. The LED display
should read like the following:
2. Push the SET button on the back of
the device. The hour should be
blinking.
3. Push the UP or DOWN button to set
the hour for which you want the
alarm to sound.
4. Push the SET button again. The
minutes should be blinking.
5. Push the UP or DOWN button to set
the minute for which you want the
alarm to sound.
6. Push the SET button again. The LED
display should read with a “0 .”
• This is the snooze.
• Snooze can last from
– 60 minutes.
7. Push the UP or DOWN button to set
the snooze time.
8. Push the SET button again. The LED
display should read with a “ .”
• This is the alarm ring.
• There are 6 rings from which
to choose
• Rings – 5 are nature sounds
• Ring 6 is a repetitive buzz.
Push the MODE button on the back of the
device to exit the alarm.
NOTICE: You have only set the alarm with
these steps
Turn On the Alarm
. Push the MODE button on the back
of the device.
2. Push the UP button on the back of
the device.
• If the LED screen reads - - : - -
then the alarm is off
• If the LED screen reads the
time for which you set the
alarm, the alarm is on
3. Push the MODE button to exit the
alarm.
4. To stop the alarm after it sounds,
press the button on top of the
device.
HOW TO RESET THE TIME AND DATE
STAMP (Windows Only)
. Connect the device to your PC using
the USB Cable
2. Go to
http://www.mgidownloads.com/
3. Click on "WriteTime.exe"
4. Click on "camstickma.exe"
IMPORTANT NOTICE: You might
receive a warning that this program
contains a virus. Disregard this
warning. The program is sa e to use.
5. Go to Start > Computer > Downloads
> Open WriteTime.exe
6. Click "Run"
7. The program will automatically
detect the device.
8. Click "Update"

3
PREPARING THE DEVICE FOR USE
. Be sure the Power Switch is
switched from OFF to ON.
2. Insert a MicroSD card into the slot
located to the left of the Power
Switch.
3. Make sure your clock has been fully
charged.
4. Place the device where you want to
record.
USING THE REMOTE
Power Button
Motion Detection Button
Video Button
Camera Button
HOW TO TURN ON THE CAMERA
. Push the Power Button on the
remote
• The blue indicator light will
come on
HOW TO RECORD VIDEO
. Push the Video Button on the
remote
• The blue indicator light will
flash 3 times and then turn
off
• The device is now recording
HOW TO TAKE PHOTOS
. Push the Camera Button
HOW TO USE MOTION DETECTION
. Press the Motion Detection Button
• The blue indicator light will
flash quickly

3
RETRIE E THE FILES TO YOUR PC
. Plug the device into your PC using the USB cable.
2. Locate “Removable Disk” inside the (My) Computer folder.
• AutoPlay Removable Disk > Open folder to view files
Or…
• Go to Start > Computer > Removable Disk
3. Open the Removable Disk drive.
4. Open the DCIM folder.
5. Double click the file you want to view.
• VLC Player is recommended for watching videos.

3
TROUBLESHOOTING
THE DEVICE WON T TURN ON
• Charge the device for at least 4 hours before the first use.
• Make sure the charging cable is securely inserted into the
device and into the power source.
THE DEVICE ISN T CHARGING
• Replace the battery or charging cable.
• If you are charging via a wall power source, you may need to
charge via your PC. The A/C adapter might be bad.
THE DEVICE HAS CRASHED
• You need to reset the device.
MY COMPUTER DOESN T RECOGNIZE THE DEVICE
• Unplug the device from your PC and reboot the device.
• Unplug the device from your PC and reboot your PC.
• Try using a different USB slot on your PC.
• Replace the USB cable.
THE SOUND OR VIDEO IS UNCLEAR
• The device needs charging.
OTHER PROBLEMS
• Call our technical support at 770–694–6921
SPECIFICATIONS
Pixels
5 Mega
ideo Resolution
280*960
ideo Format
AVI
Frames per Second
30
Recording Time
2 hours
ision Angle
72°
Motion Detection
Yes
Lux
Rating
Lux
Water Resistant
No
Battery Life
2 hours
Type of Memory
MicroSD Card
Memory Capacity
2GB
–
32GB
Recording Capacity
2GB ≈ hour
4GB ≈ 2 hours
8GB ≈ 4 hours
6GB ≈ 8 hours
32GB
≈ 6 hour
s
USB Interface
2.0 USB
Player Software
VLC
recommended
Operating Systems Windows 2000
Windows Me
Windows XP
Windows Vista
Windows 7
Mac OSX
Linux
