MGI ZIP X3 User manual

User Manual
VERSION 1.6

Thank you for purchasing the Game
Changing MGI ZIP X3 motorized caddy.
To get the most out of your caddy please
follow these quick steps before use.
• Register your caddy online [section 1.0]
• Assembling the caddy [section 3.0]
• Charge the battery [section 4.0]
For Customer Support, please contact MGI directly
for immediate and professional advice.
Email: [email protected]
LIVE chat: visit www.mgigolf.com
USA: 760 966 1566
Local Service Centers: visit www.mgigolf.com to locate
your local service center.
NOTE: This user manual was correct at time of printing. The online
version is the most up-to-date and must be referred to as the
correct version. To download the most current user manual
please visit www.mgigolf.com. Images shown throughout this
manual may not be of the particular model you have purchased,
however the instruction they refer to is for the model in the
user manual.
1.0 Registration
Contents
MGI ZIP X3 User Manual 03
1.0 Registration 04
2.0 What Is Included 04
3.0 Assembling the Caddy 05
3.1 Attaching the Rear Wheels 05
3.2 Rear Wheel Positions 06
3.3 Unfolding 07
3.4 Folding 08
3.5 Fourth Foldable Rear Wheel 09
3.6 GPS Holder and Top Handle
Compartment 09
3.7 Inverting Rear Wheels 09
4.0 Battery Charging & Connection 10
4.1 Initial Charge 10
4.2 Connecting the Battery onto the
Caddy 10
4.3 Charging the Battery after Use 11
5.0 Fitting the Golf Bag 11
6.0 Front Wheel 12
7.0 Operating the Digital Top Box 12
7.1 Top Box Display 12
7.2 Start / Stop the Caddy 13
7.3 Turn the Caddy Off 13
7.4 Battery Level Indicator 14
7.5 Unit Measurements 14
7.6 Distances Modes 14
7.7 Control Distance Function 14
7.8 Competition Mode 16
8.0 Adjusting and Aligning the Front Wheel 16
9.0 Warranty 17
9.1 Warranty Policy 17
9.2 Warranty Exclusions 17
9.3 Parts Installed During Warranty 17
10.0 Preventative Maintenance Program 18
10.1 Cleaning Your MGI ZIP Caddy 18
10.2 Rear Wheel Axles Maintenance 18
10.3 Upper and Lower Bag Strap 18
10.4 MGI Service Schedule 18
10.5 Service Record for All Caddies 19
11.0 Service and Repair Centres 21
12.0 Purchasing Parts and Accessories 21
13.0 Contacting MGI 21
14.0 Contacting Local Agent 21
15.0 Frequently Asked Questions 23

It is most important you register your MGI Caddy online
immediately as registration:
• Records your caddy for warranty purposes
• Speeds up any servicing required on your caddy
• Assist us to contact you with any updates to your caddy
To register your caddy, visit www.mgigolf.com
You will need to record your MGI serial number. This is found on
the caddy battery base or in the top box compartment.
Please keep this user manual on file for your own reference
and a copy of your serial number;
My MGI Caddy Serial Number is
[example AZX3V1173401234]
Purchased Date
/ /
You may be required to show proof of purchase so we
recommend you keep your receipt with this manual.
2.0 What’s Included
• MGI ZIP Caddy
• 24v Lithium Battery
• Battery Charger
• GPS Holder
• MGI Pouch with:
– User Manual
– Accessory Guide
3.0 Assembling Your Caddy
3.1 Attaching the Rear Wheels
Step 1. Each wheel is labelled with L or R for left or right. This is very
important as the wheels must be placed on the correct side of the
caddy. Left or right sides are determined when standing behind
the caddy as pictured below.
Step 2. On the wheel, press the grey release button on the wheel
hub. Place the wheel onto the axle. You will notice you need to
match up the inner female groove on the axle and the male
of the wheel. When placed in position simply release the button.
You will notice you hear a “click” when the wheel is properly
secured. To check that the wheel is properly in position pull
on the wheel. If it is properly in position it will not slide off.
Repeat for the other wheel.
MGI ZIP X3 User Manual 0504
Lefthand
side
Righthand
side

3.2 Rear Wheels Positions
The MGI ZIP caddy is designed to allow the rear wheels to be in
two positions. The position is determined by where the wheel is
locked on the axle in either of the two grooves [see picture]. The
drive position is used during the normal operation of the caddy.
The free wheel position is used to freely push the caddy should
you experience battery or caddy issues on the course.
i. Drive position – Lock the wheel onto the groove closest to the
battery base. To do this, press the grey release button on the
wheel hub, push the wheel on to the axle as far as possible. To
test for drive position try rolling the wheel backwards. If you feel
resistance then the wheel is now in drive position and ready to
use. Repeat for both wheels.
ii. Free wheel – Lock the wheel into the groove closest to the
end of the axle. To do this, press the grey release button on
the wheel hub, push the wheel on to the axle and release the
release button onto the groove. To test for free wheel position try
rolling the wheel backwards. The wheel should spin freely with no
resistance. Repeat for both wheels.
3.3 Unfolding
Please see below
the steps to unfold
a ZIP Caddy Handle.
Step 7: Push the Top Bag support down to move it into position.
MGI ZIP X3 User Manual 0706
Free wheel position
Drive position Step 1: Ensure both rear
wheels are attached.
Step 2: Release Fold Lever.
Step 4: The handle is now free to pull
upwards. The handle will naturally
unfold as you continue to pull until the
handle is completely open.
Step 6: Close the fold lever to lock
the handle into place in one
of three positions.
Step 5: Ensure that
the latch at the bottom
of the handle clicks into
place.
Please note that the handle can only be locked into
one position – it is not height adjustable.
Step 3: Move Top Bag
Support away from front
wheel assembly until you
hear it click.

3.5 Fourth Foldable Rear Wheel
The MGI ZIP X3 comes standard with a fourth foldable rear wheel.
This wheel MUST be unfolded into position at all times when
the caddy is in use. This will reduce damaging the caddy, and
provide the ultimate in stability across all terrains. This fourth wheel
should be cleaned regularly with a cloth to ensure it can be
folded as required for storage.
3.6 GPS Holder and Top Handle Compartment
In the top handle compartment there is a position for a GPS/
mobile device holder. Open the compartment and connect the
holder into position. To open the holder always press the button
at the top of the holder. Place the GPS into the cradle, then close
the holder by squeezing the two sides closer together.
3.7 Inverting Rear wheels
The rear wheels can be inverted on the axle to reduce the size of
the caddy when folded.
MGI ZIP X3 User Manual 0908
3.4 Folding
Step 1: Disconnect the battery. It
can left on or removed from the
caddy.
Step 2: Open the fold lever
to release the handle.
Step 3: Pull up the latch at the
bottom of the handle.
Step 4: Lower the handle down flat.
Step 6: Close the fold lever to lock
the handle into place.
Step 5: Push the
toggle down on the
top bag support and
then move the Top
Bag Support down so
that it locks over the
front wheel assembly.
Toggle

MGI ZIP X3 User Manual 1110
4.0 Battery Charging & Connection
The ZIP X3 is designed to take either ZIP battery:
• MGI 24v 250Wh Lithium battery [Standard]
• MGI 24v 380Wh Lithium battery [Optional]
4.1 Initial Charge
• Before using your MGI ZIP caddy for the first time you must
fully charge the battery overnight.
• Plug the charger AC lead into a power point - the Green LED
illuminates to indicate the charger is power on.
• Plug the charger output connection into the connector on
the front of the battery - the Red LED illuminates to indicate
charging.
• When the charging LED indicator has turned green, the
battery is fully charged and ready to be used.
Please refer to the battery charger user manual for further
information.
4.2 Connecting the Battery onto the Caddy
Position the battery on the caddy and push the battery down to
secure it.
Push the handle down to connect the battery to the caddy.
Your caddy has been equipped with fail safe battery connection,
so the caddy will not move when you connect the battery. Your
caddy will only start once the speed control is switched on.
4.3 Charging the Battery after Use
• Disconnect the battery by lifting the handle.
• The battery can be left on or removed from the caddy for
charging.
• Plug the charger AC lead into a power point - the Green LED
illuminates to indicate the charger is power on.
• Plug the charger output connection into the connector on
the front of the battery - the Red LED illuminates to indicate
charging.
• When the charging LED indicator has turned green, the
battery is fully charged and ready to be used.
5.0 Fitting the Golf Bag
Ensure that the top bag support straps are disconnected.
Position the golf bag on the caddy.
Secure the top bag support strap
• Select a good position for the elasticized straps to be put
around the golf bag
• Stretch the longer end of the strap and loop the rounded
plastic bar underneath the hook on the shorter end
• The top bag support straps should now be connected.
Please ensure the top bag support straps are hooked in place
securely before releasing. Failure to do so could result in injury to
the user.
Adjusting the length of the top bag support strap
The rounded plastic bar on the longer strap can be adjusted to
ensure the bag is secured properly in place.
Secure the lower bag strap
Pull the lower bag strap over the base of the golf bag

MGI ZIP X3 User Manual 1312
6.0 Front Wheel
Unlocking & Locking the Front Wheel
The front swivel wheel can be set in two positions.
1) Unlocked position to allow for 360deg swivel for optimum
turning ability. Move the knob, on top of the front wheel
assembly, to the left hand side.
2) Locked position is best when using the Controlled Distance
function. Move the knob, on top of the front wheel assembly,
to the right hand side.
7.0 Operating the Digital Top Box
7.1 Top Box Display
7.2 Start / Stop the Caddy
ZIP Caddy Speed Control
Please note the following points regarding the ZIP Caddy Speed
Control.
1. To select the desired speed, rotate the speed control button.
Turning the speed control button clockwise will increase the
speed, whilst anti-clockwise will decrease speed.
2. The speed setting chosen is displayed in the center of the
colored screen.
Please note you will feel notches as you rotate the speed control. The notches do not
indicate a change in speed. The speed will only increase or decrease as the number
changes in the display.
3. To start the caddy at this desired speed, tap the top
of the speed control button.
4. Another tap will stop the caddy.
5. The desired speed can be altered up or down while
the caddy is moving.
7.3 Turn the Caddy Off
ZIP Caddy Battery
Please note the following points regarding the Zip Caddy Battery.
Connecting the Battery onto the Caddy
1 Position the battery on the caddy and push the battery
down to secure it. Push the battery handle down to connect
the battery to the caddy.
2. To turn the caddy Top Box Display off:
Hold down the Start/Stop Speed Control Button and Left
Hand Distance Mode Button for four seconds and the display
will turn off thereby disabling the Top Box.
Please note that the battery will still be connected to the caddy and will continue
to drain whilst connected.
3. Please note that the caddy display will also turn off if the
Speed Control is not operated for 30 minutes.
Once again, please note that the battery will still be connected
to the caddy and will continue to drain whilst connected.
4. To reactivate the Top Box Display, whilst the battery is
connected, hold down the Start/Stop Speed Control Button
and Left Hand Distance Mode Button for four seconds and
the display will turn on thereby enabling the Top Box.
5. To fully shut down the caddy and prevent the battery from
discharging, disconnect the battery by lifting its handle. The
battery can be left on or removed from the caddy.
Speed Control
1. Distance Mode Button
2. Unit Setting Button
3. ON / OFF Speed Control
Button
4. Speed Setting Indicator
5. Battery Level Indicator
6. Distance Mode
7. Distance
8. Unit Measurement
1. 3. 2.
8.
7.
6.
5.
4.

MGI ZIP X3 User Manual 1514
7.4 Battery Level Indicator
Battery indication is located on the left side of the top box
screen. Four colored bars are highlighted showing full charge. The
lesser number of bars displayed, means there is less battery life
available. You should always check the battery status before you
play golf to ensure the four bars are there.
7.5 Unit Measurements
You can move from meters / kilometers to yards / miles simply by
pressing the Unit Setting Button [on the right].
7.6 Distance Modes
There are three distance measurement modes. To move between
the modes by pressing the Distance Mode Button [DM] [on the
left]
Distance A and B: resettable distance measurements could be
used to measure how far you hit your shot and to measure how
far you have walked for the day. To reset, simply press the DM
Button [left side] for 3 seconds until the reading displays “0”.
Distance Total: cannot be reset as it is the Odometer for the life of
the caddy. This feature will assist with service reminders which are
recommended at each 500kms or 6 months periods.
7.7 Control Distance Function
The Control Distance Function enables the MGI ZIP caddy to be
sent a preset distance before the caddy auto stops. To use this
function:
It is recommended that you lock the front wheel to ensure the
caddy tracks in a straight line.
Press and hold down Speed control button for 3-4 seconds until
the speed setting changes to 5 [meters or yards] and “ADC
MODE” will appear.
Turn the Speed control button clockwise to increase the distance
or anti-clockwise to decrease the distance until the desired
distance is achieved between 5-60 [meters or yards]
Always look ahead and assess the condition of the terrain of
where you want to send the caddy prior to doing so.
Once the desired distance is reached, press the Speed control
button once to send the caddy off to the desired distance.

MGI ZIP X3 User Manual 1716
7.8 Competition Mode
In the unlikely event the club you are playing at does not allow
the use of distance devices you will need to disable the distances
feature on the MGI ZIP caddy.
To disable the distance recording feature, simply hold down the
left and right buttons at the same time for 3 seconds and “COMP
MODE” will appear on the screen.
In addition, the distance recording will be removed from the
screen.
To exit COMP MODE hold down the left and right buttons at the
same time.
8.0 Adjusting and Aligning
the Front Wheel
Each caddy is checked for straight tracking prior to leaving the
factory. In the unlikely event the ZIP caddy is not tracking straight,
the front wheel can be adjusted to regain straight tracking as
follows;
1. Lock the swivelling front wheel [6.0] and run the caddy
forward to see if the caddy veers left or right.
2. Unlock the swivelling front wheel, swivel it to see the locking
latch in the middle of the two front wheels, as below Picture
on Left
3. Unlock the latch by pulling down
4. Adjust the direction by turning the thumb screws in the right
hand Picture. Alternate between cogs when adjusting -
suggest a quarter of a turn at a time
– To make the ZIP Caddy go Right - L/H screw anticlockwise,
R/H screw clockwise – [Up on both sides]
– To make the ZIP Caddy go Left - L/H screw clockwise, R/H
screw anticlockwise – [Down on both sides]
5. Lock the latch by pushing it up.
Please note that there is a process in adjusting the tracking. It is
suggested that the users should do a little bit of adjustment, test
the tracking and then adjust again until the caddy goes straight.

MGI ZIP X3 User Manual 1918
9.0 Warranty
9.1 Warranty Policy
The MGI ZIP caddy is covered by a Limited* manufacturer’s
warranty from the date of purchase. Duration of this warranty is:
– 2 years on parts*
– 2 years on Lithium batteries and chargers
*MGI or an authorized service center will repair or replace any
parts found to be defective in materials or workmanship under
normal use provided that:
1. The MGI ZIP caddy has been properly used, maintained and
regularly serviced [see section 10.4]
2. The replacement or repair is performed by an authorized
MGI service center or the owner with MGI approval.
3. The caddy has been registered online.
9.2 Warranty Exclusions
The following events will void warranty:
• Any alteration performed by non-authorized people
or companies.
• Fitting of parts or accessories not recommended by MGI.
• Any damage caused by continued operation of the
motorized caddy after it is known to be defective.
• Damage to seat and/or seat support bracket on caddy
• Damage caused by ingress of water into motor/gearbox
and other major components
• Damage caused by caddy going into bunkers and other
course hazards
• All implied warranties [save those preserved by statute] are
excluded. Liability for consequential damages under any
and all warranties are excluded to the extent exclusion is
permitted by law.
9.3 Parts Installed During Warranty
Warranty coverage for components installed during a motorized
caddy’s warranty period shall consist of the duration of the
caddy’s warranty period, provided the warranty installation is
performed by MGI, an authorized service center or the caddy
owner on approval. Replacement of parts under warranty will not
extend the warranty of the caddy or parts.
10.0 Preventative Maintenance Program
To properly provide for the continued operation of your MGI
ZIP caddy, MGI has introduced its Preventative Maintenance
Program [PMP]. The PMP consists of work to be carried out by
both the owner and authorized service centres. To properly
maintain the warranty of your MGI motorized caddy, it is essential
that this work is carried out. If the work carried out by the
authorized service center is to replace parts that are part of the
maintenance schedule, the owner will be charged for the parts
and labor. If the work to be carried out is part of warranty, MGI will
bear the cost.
10.1 Cleaning Your MGI ZIP Caddy [See Maintenance Schedule]
• For years of good operation, your caddy requires care and
attention.
• Keep your caddy clean by using a cloth with warm water
and a mild detergent.
• Do not hose down your caddy under any circumstance, as
the caddy has electronic components.
• Ensure that the seat stem bracket is free from sand.
• Do not submerge your caddy in water as it will cause
irreparable damage.
• Clean the caddy battery base when the battery is removed
from the caddy.
10.2 Rear Wheel Axles Maintenance [See Maintenance Schedule]
The rear wheel stub axles need to be lubricated regularly. Remove
the rear wheels by depressing the spring clip and at the same
time pull off the wheel. Apply Petroleum Jelly or light grease to
the stub axles. Use a very small amount as the grease can attract
sand. If you play in sandy conditions you should clean the axle
and regrease fortnightly.
10.3 Upper and Lower Bag Strap Maintenance [See Maintenance
Schedule]
The bag straps should be replaced as per the Service Schedule.
The upper bag strap can be replaced by:
• Removing the left and right hand straps form the upper bag
support
• Undo and remove the screws holding the strap in position on
the bag support
• Remove and replace both bag straps
• Insert bag strap securing screws.
10.4 MGI Service Schedule
It is the owner’s responsibility to ensure that all periodical checks,
necessary adjustments and services are carried out. If in doubt
please contact the MGI service center on 1300 644 523. Any work
performed on your caddy should be recorded on your service
record (see page 21) regardless of the work.

MGI ZIP X3 User Manual 2120
MGI ZIP X3 Monthly 6
Monthly
Every
2 yrs
Every
3 yrs
Wipe down the
caddy with a warm
cloth after each use
[do not hose]
BO
Lubricate rear wheel
stub axles BO
Check and tighten
nuts and bolts BO
Check and tighten
handle pivots BO
Check alignment of
caddy – ensure that
it runs straight
BO
Replace Speed
Controller and On/
Off switch assembly
BO /SC
Replace rear and
front wheels BO
Replace upper and
lower bag straps BO
BO = Caddy owner can carry out this work
SC = Charged work to be carried by approved service center
BO/SC = The six monthly service can be completed by either an
authorized service center or the owner of the caddy.
10.5 Service Record for All Caddies
6 month inspection Date:
Invoice #:
Serviced by:
Signature:
1 year inspection Date:
Invoice #:
Serviced by:
Signature:
1 ½ year inspection Date:
Invoice #:
Serviced by:
Signature:
2 year inspection Date:
Invoice #:
Serviced by:
Signature:
2 ½ year inspection Date:
Invoice #:
Serviced by:
Signature:
3 year inspection Date:
Invoice #:
Serviced by:
Signature:
3 ½ year inspection Date:
Invoice #:
Serviced by:
Signature:
4 year inspection Date:
Invoice #:
Serviced by:
Signature:
4 ½ year inspection Date:
Invoice #:
Serviced by:
Signature:
5 year inspection Date:
Invoice #:
Serviced by:
Signature:
5 ½ year inspection Date:
Invoice #:
Serviced by:
Signature:
6 year inspection Date:
Invoice #:
Serviced by:
Signature:

MGI ZIP X3 User Manual 2322
11.0 Service and Repair Centres
For all servicing, please do not go back to your place
of purchase.
MGI offers the largest network of Service Centres in Australia
and New Zealand. To find your nearest Service center visit
www.mgigolf.com
For warranty repairs to be authorized you MUST provide proof of
purchase. Please keep this with you as well as your Serial number
you can record in this manual. It is most important you register
your MGI Caddy online for warranty purposes.
It is most important you register your MGI Caddy online for
warranty purposes.
12.0 Purchasing Parts and Accessories
You are welcome to service your caddy out of warranty,
by purchasing parts direct from MGI. Please call or email
to discuss the right parts and instructions.
13.0 Contacting MGI
MGI Service Center
Address:
629 South Cleveland Street, Oceanside California 93054
SALES Telephone: [phone]
SERVICE CENTER Telephone: [phone]
Email: [email protected] Web: www.mgigolf.com
14.0 Contacting Local Agent
Please refer to www.mgigolf.com to find the distributor in your
country.
15.0 FAQ
Q: My caddy is not tracking straight.
A: You can do a simple realignment on the two front wheels.
See section 5.2 Adjusting and aligning the front wheels.
Q: I would like to have my MGI caddy serviced.
Who do I call?
A: Visit www.mgigolf.com to find your nearest Service Center
using your postcode within Australian and New Zealand.
You can also call MGI Head office using any of the contact
details. See Section 12.0 for details. Internationals please call
your local agent as per Section 13.0

www.mgigolf.com
MGI Service Center
629 South Cleveland Street
Oceanside California 93054
SALES: 855 434 5111
SERVICE CENTER: 760 966 1566
E: [email protected]
Follow us on
Absolute attention has been taken to ensure this manual
is correct at time of printing. Specifications, images
and statistics may change at any time.
Visit www.mgigolf.com for the most current model
information. Printed May 2019. Version 1.6
