Yukon Trail solar wing 350 User manual

1
Read Instructions Before Using Your New Solar Go Kart

2
NOTICE!
Before using your new Solar Go Kart the first time,
Charge the battery a minimum of 8 hours
Always recharge the battery before the power indicator shows no power.
Failure to follow these instructions nullifies any warranty, whether stated or implied.
Before operating your Solar Go Kart
Warning!
This product does not conform to Federal Motor Vehicles Standards and
is not intended for operation on public streets, roads or highways. Serious injury
can result from the unsafe operations of this vehicle.
This product is not designed to be jumped. If jumped, even from the curb,
the Solar Go Kart Frame could break causing serious injury or death.
If jumped, the warranty is void.
Do not operate this product in traffic, on wet, frozen, oily or
unpaved surfaces or under the influence of drugs and/or alcohol.
Avoid uneven surfaces, potholes, surface cracks and obstacles.
It is recommended that the rider wear leather gloves, kneepads
and leather boots. Always wear a DOT approved helmet.
Never carry passengers on your Solar Go Kart.
Do not ride without the safety identification flag. The flag is a safety
equipment for other drivers/other people to see you.
Minimum age is 16 years.
Weight Limit 150 lbs
Check your state and local laws governing the use
of motorized vehicles in your area.
Yukon Trail, Inc. is not responsible for your
failure to comply with state and local ordinances
relating to the use of the Solar Go Kart.
Failure to follow these operation instructions
can result in serious injury or death.

3
CHARGING THE SOLAR GO KART BATTERY
1. To avoid damage to the battery when charging, use only the charger provided with
your Solar Go Cart. Go Kart should be off when charging.
2. Plug the supplied 24V battery charger into a 110V AC power source. Use only 110V AC
outlet when charging the Solar Go Kart battery.
3. The CHARGER INDICATOR LIGHT will illuminate confirming that power is connected.
4. Plug the POWER INPUT CORD to the charging port on your Solar Go Kart, located on
steering column.
5. When the battery is fully charged, Indicator Light will turn Green.
6. Disconnect the Input Cord from the Charging Port.
7. Disconnect the charger from the 110V power source.
8. Never leave the battery charger connected to the 110V power source when not
charging the battery. This will shorten the life of the charger.
9. When storing your Solar Go Kart, the battery should be charged monthly.
Warning!
FAILURE TO KEEP THE SOLAR GO KART BATTERY CHARGED WILL CAUSE
TOTAL BATTERY FAILURE. DO NOT ALLOW BATTERY TO FULLY DISCHARGE.
BATTERY DISPOSAL
When maintained properly, the Lead Acid Battery in this product has a normal life of
many years. When the battery expires, it should be removed from the Solar Go Cart
and recycled. Please contact your local solid waste authority for recycling information
in your area.
NOTICE: AFTER REMOVAL. COVER BATTERY TERMINALS WITH ELECTRICAL TAPE TO PRE-
VENT SPARK HAZARD FROM SHORTING OF THE TERMINALS.
GO KART SPECIFICATIONS
SPECIFICATIONS
Maximum Speed
10 MPH
Minimum Distance
18 Miles
Recharge Time
8 Hours
Load Capacity
150 lbs
Tires
9” Pneumatic
Dimensions
47.2 x 32.7 x 20.9in
Motor
350W
Transmission
Chain Drive
Battery
12V 16Ahx2
Ignition
On/Off Toggle Switch

4
1. Rear Brake
2. Steering/ Handle Bar
3. Throttle
4. On/Off Switch
5. Bucket Seat
6. Solar Panel
7. Battery
8. Motor
If there is a problem with your Go Kart, DO NOT attempt to return to
the retailer, call Yukon Trail, Inc. at 877-441-6999
MAINTENANCE AND INSPECTION
1. Check brake and throttle cables before each use to insure proper adjustment. Check
to ensure that brake and throttle cables are flexible and that the inner cable moves
freely within the outer sleeve. Check end of cable to be sure that they are tightly
secured to the terminal connections.
2. Check brake pads weekly for wear or damage. Replace immediately at first sign of
wear or damage.
3. Check tires pressure as noted on side walls and inspect tires for tread wear
4. Lubricate wheel bearings regularly.
5. It is recommended that you use Lock tight on screws to prevent them from coming
loose due to motor vibration.

5
PARTS LIST
1
Battery box assembly bolt
24
Steering knuckle sleeve
2
Battery box
25
Bearing 6001
3
Battery fixed block
26
Inside front rim
4
Battery
27
Outside front rim
5
Brake Housing
28
Front tire sleeve
6
Solar panel
29
Inner tire tube
7
Solar wing
30
Tire
8
Frame
31
Charger
9
Flag <with mast>
32
Electrical box
10
Controller
33
Charging plug
11
Seat
34
Wire sleeve
12
Handle bar fixed block
35
Wire
13
Throttle
36
Handle Bar support
14
Handle bar
37
Brake disc
15
Brake lever
38
Disc holder
16
Left sleeve
39
Sprocket
17
Brake wire
40
Inside rear rim
18
Handle Bar column
41
Rear tire sleeve
19
Short rod
42
Chain cover
20
Rod bearing
43
Motor Guard
21
Long rod
44
Switch cover
22
Steering knuckle
45
Chain
23
Rod sleeve
46
Chain Guard
47
Motor

6
Phone Shipments will be made COD
CALL REPLACEMENT PARTS ORDERS TO:
Toll Free: 888-896-6881
ALLOW 2 WEEKS FOR SHIPPING

7
TROUBLESHOOTING
Number
Problem
Possible Cause
Solution
1
The Go Kart motor
does not operate.
1. Power switch is off.
2. Fuse has burned out.
3. Battery is undercharged or
drained.
Check and/or
replace with 20
amp fuse. Charge
or replace the
battery
2
The speed control
is out of order or
the adjustable speed
is lower than rated.
1. Battery is undercharged.
2. Check the throttle cable.
1. Fully charge
the battery.
2. Tighten
throttle cable.
3
The electric motor
stops functioning.
1. The battery wire is loose.
2. Fuse is burned out.
3. Lead wire of the battery is
broken.
Repair and
reconnect;
Replace the blown
fuse. Reconnect.
4
The driving distance is
less than the rated
distance.
1. Tires have resistance.
2. Failure of the charger.
3. Failure of the controller.
4. The battery is aged or
damaged.
5. Other factors, low
temperature, heavy wind,
the condition of the road
surface, overweight or
overuse of brake.
Lubricate wheels.
Repair the
charger. Change
the controller.
Change the
battery.
5
The battery does not
hold charge.
1. The charging socket is
loose.
2. Fuse is burned out.
3. The lead wire of the battery
has poor connection.
Tighten the
connection
socket. Change
the blown fuse.
Reconnect.

8
SAFETY
This product should not be used by pregnant women, persons impaired vision, balance,
coordination, reflex, muscle and bone
strength and good decision-making capabilities
Operators Only! –No passengers
This product should not be used by minors without adult supervision
This product should not be used by persons unwilling or unable
to take responsibility for their own actions.
The user of this product assumes ALL risks associated with its use.
High speed jumps and trick maneuvers may result in
loss of control, accidents, serious injury or death.
This is the safety alert symbol. When
you see this symbol on your machine or in
this manual, be alert to the potential for
personal injury.
Read and follow all instructions in this
Owner’s/Operator’s manual, any
accompanying supplements before
attempting to operate this Go Kart.
WARNING: Indicates a potential hazard
which could result in severe personal
injury or death.
CAUTION: Indicates a potential hazard
may result in severe personal injury or
damage to the vehicle
NOTE: Use the word “NOTE” will alert you to
key information or instructions.
Important Rules for Safe Operation
WARNING: NEVER operate / charge this Go
Kart indoor or in an enclosed area without
adequate ventilation.
WARNING: This Go Kart is not licensable.
DO NOT operate it on any public road, street,
highway, sidewalk or alley.
This Go Kart may be operated only on private
property and areas approved by local law.
WARNING: This Go Kart may have been
supplied to you completely assembled. To
prevent possible injury or death read and
follow the assembly instructions to make sure
the Go Kart was assembled properly.
WARNING: Always perform Daily Pre-Ride
inspections as outlined in this manual.
WARNING: Check tire pressure before each
use.
Prior to operating the Go Kart check and adjust tire
pressure to the proper operating pressure as
indicated on the sidewall of each tire.A tire pressure
gauge is required to obtain accurate readings.
WARNING: Go Kart modification or removal
of original equipment or safety decals can render
the vehicle unsafe for operation.
WARNING: Safety decals must be replaced if
they become unreadable or detached from the
Go-Kart.
If decals are unreadable or missing, warning of
potential hazards or safety requirements may
be lacking.
WARNING: This Solar Go Kart is not
designed or intended for stunt riding, spinouts,
donuts, racing, or any form of competition.

9
WARNING: This Go Kart is not designed to
be used on rental tracks of any kind.
WARNING: The safe operation of this Go
Kart is dependent upon the operator’s ability to
exercise proper judgment.
Operator must not be too small or too large
for controlled operation.
Operator must be of sufficient age,
understanding, mental capacity and physical
capability to safely operate this Go Kart
Go Kart should only be operated after
understanding instructions and sufficient
practice in an uncongested area.
WARNING: Operator of this Go Kart
MUST always wear a properly fitting Safety
Helmet approved by agencies such as the
Department of transportation (DOT).
Most accident fatalities are due to head
inquires.
Operator should also wear helmet, boots,
gloves and other appropriate protective
clothing
WARNING: Long hair, loose clothes, or
jewelry can get caught in moving parts below
and behind the seat or surrounding
environment.
Remove or the back anything loose that can
reach below and behind the seat before
riding.
WARNING: NEVER place hands, feet, any
body parts or clothing near the wheels, chain
and other rotating parts of the Go Kart while
riding.
Use caution in performing required
maintenance on or near motor.
Use caution after the motor has been
running, since the motor and other drive
components may be extremely hot.
WARNING: All screws, nuts and bolts must
be properly tightened to make sure the Go Kart is
in safe operating condition.
Note: Over tightening hardware where parts are
required to move, such as front wheels, spindles,
a-arm pivots, etc, can restrict movement and cause a
loss of control and possible injury.
WARNING: prevailing-torque-type locknuts
must be replaced with new after the old locknuts
have been removed.
Replace with the same type of locknut to make sure
they function properly.
WARNING: Read and keep all supplied
printed material.
Supplements to this Operator’s Manual contain
updated information relative to your specific Go
Kart model. It is important to keep all of these
documents for reference.
NEVER store the Go Kart in close proximity to
appliances such as hot water heaters of
furnaces.
CAUTION: NEVER operate Go Kart while
under the influence of alcohol, drugs or
medication of any kind.
Such operation is dangerous to yourself and/or
others.
CAUTION: If the Go Kart should start making
unusual noise or vibrating abnormally, the motor
should be switched off and the Battery wire
disconnected. The Go Kart should then be
checked for damage. Excessive noise or
vibration is generally a warning of loose or worn
parts.
WARNING: Excessive speed is potentially
dangerous to operator.
WARNING: Wet, slippery, rough or sloped
terrain is potentially dangerous and may result in
injury if proper caution is not observed.
ALWAYS SLOW DOWN.
Operator must use mature judgment, skill and
experience in choosing suitable terrain for
individual operational capabilities.

10
Instructions for Safe Use and Maintenance of Go- Kart
WARNING: When turning on pavement,
loose gravel, or similar surfaces, there is an
increased risk in loss of control.
ALWAYS SLOW DOWN!
WARNING: ALWAYS SLOW DOWN when
turning.
High-speed turning can cause loss of control,
possible vehicle turn-over and/or possible
operator and/or passenger injury.
Turning on a slope increases the risk of
rollover.
Practice operation is required to coordinate
turning skill.
Failure to operate this Go Kart at a safe
speed while turning can result in a strong
possibility of severe personal injury.
1. Go Kart shall not be modified from the
manufacturer’s original design and configuration.
2. Go Kart shall not be used to perform racing,
stunt riding, jumps, spin-outs, donuts or other
maneuvers as they may cause loss of control of
the Go Kart or may cause uncontrolled operator or
Go Kart actions or reactions, As such, these
activities are likely to result in possible injury to the
operator, bystanders or a combination thereof.
3. Prior to each cycle of operation, a supervisor
shall perform the preparation checks specified by
the manufacture, and further verify;
a. Smooth throttle operation and positive return of
the throttle linkage to a closed throttle position
when released;
b. That the steering linkage is adjusted and
operates properly;
c. That all guards and pads originally supplied by
the manufacturer are in proper place on the Go
Kart and in serviceable condition;
d. That the area where the Go Kart is operated is
safe and suitable for Go Kart operation;
f. That the braking system on the Go Kart is
functioning properly;
g. That all safety labels are in place, legible and
understood by the operator.
h. That any and all axle guards, chain guards, or
other covers or guards supplied by the
manufacturer are in place and in serviceable
condition;
i. That tires are in good condition, inflated property,
and have sufficient tread remaining.
j. That all fasteners are in place and tightened
securely.
4. Go Kart motor shall not be started unless the
operator is seated in the proper position for Go Kart
operations with the operator’s hands on the Handle
Bars and the brake fully engaged.
5. Long hair, loose clothes, or jewelry can get caught
in moving parts below the seat or surrounding
environment, Remove or the back anything loose
that can reach below or behind the seat before riding.
6. A supervisor shall verify personally that everyone
operating or riding is knowledgeable, capable, and
has the cognitive capacity to operate the Go Kart
safely, including those items specified in 1 through 5.
a. The supervisor only shall allow the use and
operation of the Go Kart after a demonstration that
each operator can understand and operate all
components of the Go Kart prior to use.
b. The supervisor shall provide continuous
supervision during Go Kart use.
c. The supervisor shall not allow anyone to ride in
or operate Go Kart with long hair, loose clothes, or
jewelry which can get caught in moving parts
below the seat or tie back anything loose that can
reach below or behind the seat before riding.
8. Solar Go Cart operators shall adhere to all
manufacturer’s recommendations and instructions,
as well as comply with all laws and ordinances.
a. Operators shall stay seated with both hands on the
Handle Bars and both feet in the Go Kart at all times,
whether moving or stationary, unless the Go Kart is
stopped completely.
b. Shall observe minimum age restrictions；

11
WARRANTY REGISTRATION
RETURN THE SOLAR GO CART PRODUCT REGISTRATION
WITH A COPY OF YOUR SALES RECEIPT TO :
Yukon Trail, Inc. 4124 Pacific Privado, Ontario, CA 91761
Name: ______________________________________________________________
Address: ____________________________________________________________
City: __________________ State: ________________Zip____________________
Phone: __________________________ E-mail: ____________________________
Date Purchased: _____________________ Model#: _________________________
Store Where Purchased: ________________________________________________
Store Address: ________________________________________________________
Receipt or Transaction #: ________________________________________________
The registration must be returned to Yukon Trail, Inc. within 10days of purchase. It is the only information Yukon Trail
will have for notification to you of any information regarding this product.
This information is for the sole purpose of product/registration and will not be sold or used for any other purpose.
A COPY OF THE SALES RECEIPT AND UPC BAR CODE MUST BE INCLUDED WITH THIS REGISTRATION CARD.
Thank you for purchasing an Yukon Trail, Inc. Solar Go Cart. If there are parts missing or
if your Solar Go Cart does not run properly, do not return your Solar Go Cart to the place of purchase.
Please call Yukon Trail customer Service at 877-441-6999
PLEASE DO NOT RETURN PRODUCT TO RETAILER FOR WARRANTY OR REPLACEMENT PARTS.
*or register online at www. yukontrailinc.com using the warranty link
c. Shall not ride the Go Kart if long hair, loose clothes,
or jewelry reach below or behind the seat;
WARNING: Risk of death or serious injury!
Long hair, loose clothes, or jewelry can get
caught in moving parts below and behind the
seat or surrounding environment,
Remove or tie back anything loose that can
reach below or behind the seat before riding.
d. Shall not allow smoking in vehicle
e. Persons under the influence of drugs, alcohol, or
intoxicants shall not supervise, operate, or ride in a Go
Kart
f. Go kart shall operate only on surface or terrain as
recommended by the manufacturer;
g. Go Kart shall not be operated on roads, streets,
highways ,or at any other location where road
vehicle are intended to travel;
9. persons with the following conditions shall not
operate a Go Kart
a. Those with heart conditions;
b. Pregnant women
c. Persons with head, back, or neck ailments, or
prior surgeries to those areas of the body;
d. Persons with any mental of physical conditions,
which may make them susceptible to injury or impair
their physical dexterity or mental capacities to
recognize, understand, and perform all safety
instructions, and be able to assume the hazards
inherent in Go Kart use.
10. Vehicle operators always shall use appropriate
protective clothing, including but not limited to helmet and
eye protection, with appropriate certification, and any
other equipment recommended by the manufacturer
including gloves, footwear, long sleeve shirts and long
pants.
11. No operator or other person shall contact any
portion of the wheels, or drive train
for any purpose including maintenance until
the motor has been turned off, and the Go Kart is in a
stable and stationary position.
13. Go Kart components shall be maintained and
repaired in accordance with the manufacturer’s
specifications an utilizing only the manufacturer’s
authorized replacement parts with installation
preformed by designated dealer or other skilled
persons.

12
Yukon Trail, Inc.
LIMITED WARRANTY
Your Solar Go Cart is warranted to be free of manufacturing defects in
material or workmanship for a period of 90 days. During the warranty period
Yukon Trail, Inc. will at its option, repair, provide replacement parts
or replace your Solar Go Cart at no charge. This warranty does not cover normal
wear and tear, or damage caused by neglect, or misuse of the product.
Should you experience a problem or need to return your Solar Go Cart
for repair, please call the Yukon Trail customer service department
TOLL FREE AT 877-441-6999 between the hours of 9AM and 4PM PST Monday thru Friday.
You will be instructed how to proceed. A copy of receipt is required.
You may also contact Yukon Trail, Inc. by writing.
Yukon Trail, Inc.
4124 Pacific Privado, Ontario, CA 91761
Or
www.yukontrailinc.com
Made in China
