DOSISYS
LDM 210 - LDM 220 Hands Free Reade
r
User
Manual
128569B

LDM 210 - LDM 220
Publication, translation and reproduction total or partial of this
document is strictly forbidden without authorization
MGP Instruments recommends that any work to be done
while the instrument is powered should be done by qualified
and authorized personnel.
128569B I
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

LDM 210 - LDM 220 Table of updates
Table of updates
R
e
v
Date Issued by Reason for
modification
Pages modified
A OCTOBER 28, 2003 J. PEREZ/S. LOPEZ Edit and Translation to
English.
ALL
B DECEMBER 16, 2003 J. PEREZ Wrong configuration of the
two jumpers SS2 and SS3.
§3-1-2, page 13
§6-1-1, page 29
Replacing of "ort"
translation by "range"
translation.
§4-5, page 25
II 128569B
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

Table of contents LDM 210 - LDM 220
Table of contents
1. General ...........................................................................................................................1
1.0 Purpose........................................................................................................................... 1
1.1 Of this document ............................................................................................................. 1
1.2 Nomenclature.................................................................................................................. 1
1.3 Presentation of the LDM 210 – LDM 220........................................................................ 1
2. Description - Functionality............................................................................................3
2.1 Description of the LDM 210............................................................................................. 3
2.1.1 LDM 210 dosimeter reader ................................................................................ 3
2.1.2 Power supply...................................................................................................... 5
2.1.3 Identification label .............................................................................................. 6
2.2 Description of the LDM 220............................................................................................. 6
2.2.1 LDM 220 dosimeter reader ................................................................................ 7
2.2.2 Identification label in the face of the LDM 220 ................................................... 8
2.3 Operation ........................................................................................................................ 9
2.3.1 Normal Operating Mode..................................................................................... 9
2.3.2 Test Mode. ....................................................................................................... 10
2.3.3 The Digital Input/Output TOR........................................................................... 10
3. Installation and start-up ..............................................................................................11
3.1 LDM 210 and LDM 220 Configuration........................................................................... 12
3.1.1 Location of jumpers:......................................................................................... 12
3.1.2 Operating Modes (SS2 et SS3)........................................................................ 13
3.1.3 OPERATIONNAL Mode ................................................................................... 14
3.2 Installation of the USB driver for the LDM 220 .............................................................. 15
3.2.1 For WINDOWS 2000........................................................................................ 15
3.2.2 For WINDOWS XP........................................................................................... 17
4. Operation......................................................................................................................21
4.1 Recommendation of use ............................................................................................... 22
4.1.1 LDM210 22
4.1.2 LDM220 22
4.2 Operating significance of the lights ............................................................................... 23
4.3 Example of status indicators with DOSIMASS/ DOSIMED / DOSIFAST ...................... 23
4.4 Reader usage................................................................................................................ 24
4.4.1 DOSIMASS Software ....................................................................................... 24
4.4.2 DOSIMED or DOSIFAST Software .................................................................. 24
4.4.3 Other Software ................................................................................................. 24
4.5 Troubleshooting Guide .................................................................................................. 25
5. Preventive Maintenance..............................................................................................27
128569B III
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

LDM 210 - LDM 220 Table of contents
6. Corrective Maintenance ..............................................................................................29
6.1 Operating TEST Modes................................................................................................. 29
6.1.1 Operating Modes (SS2 et SS3)........................................................................ 29
6.1.2 Test Mode ........................................................................................................ 29
6.1.3 AGC amplifier test Mode .................................................................................. 29
6.1.4 Autonomous test Mode .................................................................................... 29
6.2 Start-up of Maintenance Modes .................................................................................... 30
6.2.1 REMOTE DOWNLADING AND PROGRAMING Mode.................................... 30
6.2.2 TESTS Mode.................................................................................................... 31
6.2.3 Reader in "TESTS" mode................................................................................ 32
7. Spare parts, options ....................................................................................................35
7.1 Spare Parts for the LDM 210......................................................................................... 35
7.2 Spare Parts for the LDM 220......................................................................................... 35
7.3 Software ........................................................................................................................35
8. Technical Characteristics ...........................................................................................37
8.1 Mechanical Characteristics of the LDM 210.................................................................. 37
8.2 Mechanical Characteristics of the LDM 220.................................................................. 37
8.3 Electrical Characteristics of the LDM 210 ..................................................................... 37
8.4 Electrical Characteristics of the LDM 220 ..................................................................... 38
8.5 LDM 210 Serial Link...................................................................................................... 38
8.6 LDM 220 USB link......................................................................................................... 38
8.7 Environmental Conditions LDM 210 and LDM 220 ....................................................... 38
8.8 Input/output digital DIO LDM 210 and LDM 220 ........................................................... 39
8.9 Dosimeter link with LDM 210 and LDM 220 .................................................................. 40
9. Glossary .......................................................................................................................41
IV 128569B
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

Table of figures LDM 210 - LDM 220
Table of figures
Figure 1 : Presentation of the LDM 210 reader .................................................................................2
Figure 2 : Presentation of the LDM 220 reader .................................................................................2
Figure 3 : LDM 210 Assembly Description ........................................................................................3
Figure 4 : Description of the LDM 210 enclosure and PCB..............................................................4
Figure 5 : Description of the LDM 210 power pack ...........................................................................5
Figure 6 : LDM 210 Identification and presentation labels ................................................................6
Figure 7 : LDM 220 Assembly Description ........................................................................................6
Figure 8 : LDM 220 enclosure and PCB Description.........................................................................7
Figure 9 : Identification and front face labels for the LDM 220 ..........................................................8
Figure 10 : LDM 210 and LDM 220 Block Diagram............................................................................9
Figure 11 : Location of jumpers for the configuration of the LDM 210...............................................12
Figure 12 : Location of jumpers for the configuration of the LDM 220...............................................13
Figure 13 : View of the reader LDM 210 – LDM 220 .........................................................................21
Figure 14 : Recommendation of use - LDM210.................................................................................22
Figure 15 : Recommendation of use - LDM220.................................................................................22
Figure 16 : Reader LDM 210 – LDM 220 ..........................................................................................24
128569B V
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

LDM 210 - LDM 220 Table of figures
Blank Page
VI 128569B
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

General LDM 210 - LDM 220
1. General
1.1 Purpose Of this document
This document provides all the information necessary for the use, configuration and
maintenance of the hands free readers models LDM 210 and LDM 220.
1.2 Nomenclature
Symbols "" and "" :
These symbols are used for the descriptions and details:
The symbol "" corresponds to the first level of detail.
The symbol "" corresponds to the second level of detail.
For legibility purpose these symbols are aligned vertically.
1.3 Presentation of the LDM 210 – LDM 220
These hands free readers allow centralized dosimetry software (DOSIMASS, DOSIMED
or DOSIFAST) to communicate with a DMC 2000 and SOR family dosimeter.
The dosimeter reader LDM 210 exists in two versions:
 with power supply.
 with power supply and optional battery.
The dosimeter reader LDM 220 is connected to the USB port.
128569B 1
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

LDM 210 - LDM 220 General
Figure 1 : Presentation of the LDM 210 reader
Figure 2 : Presentation of the LDM 220 reader
2 128569B
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

Description - Functionality LDM 210 - LDM 220
2. Description - Functionality
2.1 Description of the LDM 210
The LDM 210 dosimeter reader is provided with:
 An RS232 cable,
 A power supply suitable for use in Europe or U.S.
Cable
RS232
Power
supply
Interchangeable
plug
LDM 210
Figure 3 : LDM 210 Assembly Description
2.1.1 LDM 210 dosimeter reader
The plastic enclosure contains:
 Three transparent lenses (2) for LED protection.
 A label (1) attached to the enclosure front panel.
 An identification label (4) indicating the model and serial number of the readers as
well as the power supply polarity.
 The UC (3) reader board. It includes:
 An antenna that allows communication with the dosimeter within a nominal range of
20 to 30 cm. The antenna is attached to the printed circuit board,
 A power connector JACK (J8),
 A female DB-9 connector (J6) for the RS232 serial connection,
 A 14 pin male connector (J15) for the analog inputs and outputs,
 A 14 pin male connector (J16) for the reader configuration mode,
 Three bicolor diodes green and red for "Power", "Access" and "Status" (CR2, CR3
and CR4),
 An enclosure with a battery compartment soldered to the PCB for the reader with
the battery option.
128569B 3
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

LDM 210 - LDM 220 Description - Functionality
1
2
3
4
J6
MN1
NA1
J8
CR2
CR4
Batter
y
carrie
r
J15
Antenna
CR3
J16
Figure 4 : Description of the LDM 210 enclosure and PCB
4 128569B
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

Description - Functionality LDM 210 - LDM 220
2.1.2 Power supply
The power supply provided is a 9 VDC output wall transformer for the LDM 210. It is
connected to JACK J8.
Two interchangeable adapters allow the use of the power pack in places with the
European or American standard. For other countries, consult MGP Instruments.
Figure 5 : Description of the LDM 210 power pack
128569B 5
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

LDM 210 - LDM 220 Description - Functionality
2.1.3 Identification label
Figure 6 : LDM 210 Identification and presentation labels
2.2 Description of the LDM 220
The LDM 220 dosimeter reader assembly consists of:
 A plastic enclosure,
 An integrated USB cable,
 Three bicolor LED's.
Figure 7 : LDM 220 Assembly Description
6 128569B
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

Description - Functionality LDM 210 - LDM 220
128569B 7
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C
2.2.1 LDM 220 dosimeter reader
The plastic enclosure contains:
 The reader PCB UC (1). It includes:
 An Antenna (ANT1) located behind the UC (1) card that allows communication with
the dosimeter within a nominal range of 20 to 30 cm. The antenna is attached to the
printed circuit board,
 A 5 pin male connector (J1) for the connection to the USB cable,
 A 14 pin male connector (J15) for the analog inputs and outputs,
 A 14 pin male connector (J16) for the reader configuration mode,
 Three bicolor LED's green and red for "Power", "Access" and "Status" (CR2, CR3
and CR4),
 A label (2) glued to the enclosure front panel.
 An identification label indicating the model and serial number of the Reader.
1
CR4
J16
CR3
1
2
J15 Antenna
CR2
Antenna
(Underside View)
J1
Figure 8 : LDM 220 enclosure and PCB Description

LDM 210 - LDM 220 Description - Functionality
2.2.2 Identification label in the face of the LDM 220
Label for vertical fixing
Label for horizontal using only (desk)
Figure 9 : Identification and front face labels for the LDM 220
8 128569B
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

Description - Functionality LDM 210 - LDM 220
2.3 Operation
PC link
LED’s
IN DIs
OUT DOs
Antenna
Batteries
Ext. Powe
r
USB powe
r
Hands free link with the
dosimeter
RS232 o
r
USB
Interface
Processor
Reception
link
Emission
link
Power
Figure 10 : LDM 210 and LDM 220 Block Diagram
The following operating modes are defined by the position of jumpers in the J16
connector (see § 3.1, page 12).
 Normal Operating Model.
 Test Mode.
2.3.1 Normal Operating Mode.
This is the normal operating mode of the reader.
In this mode, the reader functions as a slave of the PC.
 It receives commands from the PC.
 It searches for a dosimeter.
 It executes commands – reading or writing dosimeter parameters or information.
 It transmits a report to the PC.
128569B 9
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

LDM 210 - LDM 220 Description - Functionality
2.3.1.1 Retries
By default, the reader resends messages 10 times if the dosimeter fails to respond.
It is possible to disable the retries by relocating jumper SS4.
2.3.1.2 Reduced range
By default, the reader has a normal range of approximately 20 cm.
It is possible to reduce the range by relocating jumpers SS5 and SS8.
2.3.2 Test Mode.
It is a mode designed to verify proper functioning of the reader.
Refer to Corrective Maintenance in page 29.
2.3.3 The Digital Input/Output TOR
4 inputs and 4 outputs are managed by the reader by PC command.
These input/outputs are accessible on the HE10 male 2x7 pin 2.54 mm (0.1”0 spacing
connector).
They are protected against electrostatic discharge by protection diodes.
Inactive status (no exterior cable) of the inputs is a high level 3.3 V (pull up).
Active status is low-level 0 V.
Inactive status (by default) of the outputs is low 0 V.
Active output status is high-level 3.3 V.
These input/outputs can be used for example in an access control case:
 Access LED authorized or refused.
 Locking of access.
 System busy or available.
 Authorization request of passage, etc.
10 128569B
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

Installation and start-up LDM 210 - LDM 220
3. Installation and start-up
Keep the reader away from sources of electromagnetic fields (video
terminals, power supplies, PC, rotary machines, etc.)
Keep readers away from each other to prevent them from interfering with
one another (in case this is not possible, adjust the range of the readers
accordingly)
Keep readers at least 5 cm (2”) from metallic surfaces.
The installation and start-up of the reader consists in sequence:
 Install the software on the PC.
 Connect power to the reader (LDM 210 only).
 Connect the reader to the PC.
Note :
The LDM 210 can be equipped with an optional 2 alkaline AAA1.5 V batteries for operation without an
external power supply.
The LDM 220 is delivered for desk using (horizontally). It can be used in vertical fixing; a specific label is
delivered for this use.
128569B 11
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C

LDM 210 - LDM 220 Installation and start-up
3.1 LDM 210 and LDM 220 Configuration
By default, the reader is delivered from MGP Instruments in "Operating Mode" with
retries and with normal range.
No jumper is positioned.
3.1.1 Location of jumpers:
Jumper DESIGNATION
SS1 * Remote access 1
SS2 *Operating Mode
SS3 *Operating Mode
SS4 Retries
SS5 *Reduced range
SS6 *Remote access 2
SS7 RESET
SS8 Reduced range 2
*Read and effective after Reset (loss of power) or after locating jumper SS7.
SS1
SS2
SS3
SS4
SS5
SS6
SS7
J16
Figure 11 : Location of jumpers for the configuration of the LDM 210
12 128569B
Publication, traduction et reproduction totales ou partielles de ce document sont rigoureusement interdites, sauf autorisation écrite de nos services.
The publication, translation or reproduction, either partly or wholly, of this document is not allowed without our written consent. Format 112175C
