MHD OBD2 User manual

MHD OBD2 Flasher Wifi Enet Module User Manual
1
Overview
MHD OBD2 Wifi Flasher was specially
developed and designed to operate the
Ethernet OBD2 diagnostic and coding
features via wired J2534 port and
wireless via an embedded module based
on the universal serial interface network
standard,built-in TCP / IP protocol stack,
enabling the user serial port, Ethernet,
wireless network (wifi) interface
between the conversions. the
traditional serial devices do not demand
to change any configuration, data can be
transmitted through the Internet
network. Provide a quick solution for the user’s serial devices to transfer data via Ethernet
Features
• 2.4GHz 802.11b/g/n,compatible
•Support IEEE 802.3、IEEE 802.3u
•WiFi Client/AP/Router Mode
• Support wps/wds
• The range of baudrate: 1200~500000bps
• Support transparent transmission mode
• Support multiple security authenti-cation mechanisms:
WEP64/WEP128/ TKIP/ AES
WEP/WPA-PSK/WPA2-PSK
• Support wireless roam
• Support multiple network protocols:
PPPOE/TCP/UDP/DDDNS /DHCP/DNS/HTTP/Firewre
• Support AT+ instruction set
• Support two config methods:Serial/WEB
• Device Dimensions 87*47*26mm

MHD OBD2 Flasher Wifi Enet Module User Manual
2
Applications
Ethernet OBDII WiFi Diagnose
Specifications
The parameters are defined here.

MHD OBD2 Flasher Wifi Enet Module User Manual
3
Wi-Fi Module Pin Assignment
Electrical Characteristics

MHD OBD2 Flasher Wifi Enet Module User Manual
4
Operation Guidelines to work with car OBDII
Step 1: Ignition ON, plug the MHD OBDII wifi flasher to the OBD2 diagnostic port
Step 2: Search the Wifi ISID started with MHD_XXXX from laptop wifi and access with the
password which sated at the back side of the module.
Step 3: Successfully connected and operated as user demanded via OBD2 diagnostic port.
Step 4: Administration panel setup for administrators only.

MHD OBD2 Flasher Wifi Enet Module User Manual
5
Appendix Disclaimers
The contents of this document aresubject to changewithout notice. Autosvs Technology reserves
the right to makechanges, without notice, in the products, including circuits and/or software,
described or contained therein. Information contained in this document regarding device
applications and the like is intended through suggestion only and may be superseded by updates.
It is your responsibility to ensurethatyour application meets with your specifications.
Autosvs Technology warrants performance of its hardware products to the specifications applicable
at the time of sale in accordance with Autosvs Technology’s standard warranty. Testing and other
quality control techniques are used to the extent Autosvs Technology deems necessary to support
this warranty. Except where mandatory by government requirements, testing of all parameters of
each product is not necessarily performed.
Autosvs Technology assumes no responsibility or liability for the use of any of these products,
conveys no license or title under any patent, copyright, or mask work right to these products, and
makes no representations or warranties that these products are free from patent, copyright, or
mask work infringement, unless otherwise specified.
Autosvs Technology products are not intended for use in life support systems, appliances or
systems where malfunction of these products can reasonably be expected to result in personal
injury, death or severe property or environmental damage. Autosvs Technology customers using or
selling these products for use in such applications do so at their own risk and agree to fully
indemnify Autosvs Technology for any damages resulting from such use.
All products are sold subject to Autosvs Technology 's terms and conditions of sale supplied at the
time of order acknowledgment. All trademarks are the property of their respective owners.
NB Warning:
Manufacturer's Name: JR AutoPerformance Inc.
Sample Description: MG Flasher Enet Wifi
Trade Mark : /
Model number: MG Flasher Enet Wifi
Operating Temperature: -10° C to 40° C
Wireless specification:
2.4G WIFI: Max power 14.38dbm in frequency band 2412-2462MHz
This product is a fixed location. Tocomply with RF exposure requirements, a minimum separation
distance of 20cm must be maintained between the user’s body and the device, including the
antenna. The device complies with RF specifications when the device used at 20cm from your body.
Use only the supplied or an approved antenna.
This device in compliance with the essential requirements and other relevant provisions of
Directive 2014/53/EU. All essential radio test suites have been carried out.

MHD OBD2 Flasher Wifi Enet Module User Manual
6
FCC Warning:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for
compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed
and operated with minimum distance between 20cm the radiator your body: Use only the
supplied antenna.
FCC ID: 2AWSB-MGENET
