Operator's Manual 1
©Copyright 2009 Form #37-1085--E/F/S-120209
OPERATING INSTRUCTIONS FOR
HEO-SERIES
HOT WATER PRESSURE WASHERS
CAUTION
RISK OF INJURY!
READ MANUAL BEFORE OPERATING!
This manual is an important part of the
pressure washer and must
remain with the unit when you sell it!

2 Operator's Manual
TABLE OF CONTENTS
INTRODUCTION ................................................................................................................................................3
IMPORTANT SAFETY WARNINGS................................................................................................................4-9
RISK OF EXPLOSION OR FIRE.....................................................................................................4
RISK OF ASPHYXIATION ...............................................................................................................5
RISK OF ELECTROCUTION OR ELECTRICAL SHOCK ...............................................................6
RISK OF INJECTION OR SEVERE CUTTING INJURY .................................................................7
RISK OF BURNS.............................................................................................................................8
RISK OF BURSTING.......................................................................................................................8
RISK FROM MOVING PARTS ........................................................................................................8
RISK OF BODILY INJURY ..............................................................................................................9
FEATURES..................................................................................................................................................10-11
INSTALLATION ...........................................................................................................................................12-15
LOCATION AND PLACEMENT .....................................................................................................12
ELECTRICAL.................................................................................................................................12
VENTILATION ...............................................................................................................................13
WATER SUPPLY ...........................................................................................................................14
HIGH PRESSURE CONNECTION................................................................................................14
PRE-OPERATION CHECKLIST....................................................................................................15
PREPARATION ...........................................................................................................................................16-18
ATTIRE ..........................................................................................................................................16
PRE-START...................................................................................................................................16
BURNER FUEL TANK ...................................................................................................................16
UNLOADER...................................................................................................................................16
QUICK-CONNECT NOZZLES.......................................................................................................17
NOZZLE CONNECTION ...............................................................................................................17
DUAL LANCE ASSEMBLY WITH ADJUSTABLE PRESSURE......................................................18
PRE-START SAFETY INSPECTION.............................................................................................18
OPERATING INSTRUCTIONS .......................................................................................................................................20-22
FLUSHING THE SYSTEM ............................................................................................................20
COLD WATER OPERATION .........................................................................................................20
HOT WATER OPERATION............................................................................................................21
CLEANING WITH DETERGENTS ................................................................................................21
SHUTDOWN .................................................................................................................................22
OPTIONS ......................................................................................................................................22
MAINTENANCE ..........................................................................................................................................23-26
PREVENTIVE MAINTENANCE ....................................................................................................23
DELIME COIL................................................................................................................................24
WINTERIZING...............................................................................................................................25
MAINTENANCE CHARTS ...............................................................................................................................26
TROUBLESHOOTING ................................................................................................................................27-29
STATEMENT OF WARRANTY.........................................................................................................................30
NOTES............................................................................................................................................................. 31
NATIONAL CODES:
ANSI Z223.1 (NFPA NO. 54) NATIONAL FUEL GAS CODE.
NFPA NO. 70 (NEC) NATIONAL ELECTRICAL CODE.
CSA B149.1 GAS INSTALLATION CODE.
CSA C22.1 CANADIAN ELECTRICAL CODE PART 1.

Operator's Manual 3
INTRODUCTION
Congratulations on the purchase of your new HEO-SERIES pressure washer! You can be assured your pressure washer
was constructed and designed with quality and performance in mind. Each component has been rigorously tested to
ensure the highest level of acceptance.
This operator's manual was compiled for your benet. By reading and following the simple safety, installation, operation,
maintenance and troubleshooting steps described in this manual, you will receive years of trouble free operation from
your new pressure washer. The contents of this manual are based on the latest product information available at the time
of publication. Manufacturer reserves the right to make changes in price, color, materials, equipment, specications or
models at any time without notice.
! IMPORTANT !
Theseparagraphsaresurroundedbya"SAFETYALERTBOX." Thisboxisusedtodesignateand
emphasize Safety Warnings that must be followed when operating this pressure washer.
Accompanying the Safety Warnings are "signal words" which designate the degree or level
of hazard seriousness. The "signal words" used in this manual are as follows:
DANGER: Indicates an imminently hazardous situation which, if not avoided, WILL
result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, COULD
result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided MAY
result in minor or moderate injury.
The symbols set to the left of this paragraph are "Safety Alert Symbols." These symbols
are used to call attention to items or procedures that could be dangerous to you or other
persons using this equipment.
ALWAYS PROVIDE A COPY OF THIS MANUAL TO ANYONE USING THIS EQUIPMENT. READ
ALL INSTRUCTIONS BEFORE OPERATING THIS PRESSURE WASHER AND ESPECIALLY
POINT OUT THE "SAFETY WARNINGS" TO PREVENT THE POSSIBILITY OF PERSONAL
INJURY TO THE OPERATOR.
Once the unit has been removed from the box, immediately write in the serial number of your unit in the space provided
below.
SERIAL NUMBER_________________________________
Inspect for signs of obvious or concealed freight damage. If damage does exist, le a claim with the transportation
company immediately. Be sure that all damaged parts are replaced and that the mechanical and electrical problems are
corrected prior to operation of the unit. If you require service, contact Customer Service Representative.
Please have the following information available for all service calls:
1. Model Number
2. Serial Number
3. Date and Place of Purchase

4 Operator's Manual
POTENTIAL CONSEQUENCE PREVENTION
SAFETY WARNINGS
WARNING: When using this product, basic precautions should always be observed, including the following:
READ ALL SAFETY WARNINGS BEFORE INSTALLING AND USING PRESSURE WASHER
HAZARD
RISK OF
EXPLOSION OR FIRE Serious injury or death may
occur from normal sparks in the
multiple ignition sources or burner
exhaust.
Serious injury or death may occur
as a result of improper fueling.
Serious injury or death may
occur if system safety's are not
properly maintained.
Always operate pressure washer in a well
ventilated area free of ammable vapors,
combustible dust, gases or other combustible
materials.
Do not store the pressure washer near an
open ame or any equipment such as a stove,
furnace, water heater, etc., which utilizes a pilot
light or sparking device.
Do not allow lint or dust to collect in burner
area.
Do not use this pressure washer to spray
ammable material!
Do not smoke while lling burner fuel tank.
Never ll the burner fuel tank while the pressure
washer is running or hot. Allow to cool two
minutes before refueling.
Do not refuel in a poorly ventilated area.
Always refuel slowly to avoid the possibility of
spilled fuel which may cause a risk of re.
Burner Fuel Tank:
Use No. 1 or No. 2 fuel oil/diesel or
kerosene.
Do not use gasoline, crankcase drainings or
oil containing gasoline or solvents.
Do not operate the unit if fuel is spilled. Wipe
the pressure washer clean and move it away
from the spill. Avoid creating any ignition until
the fuel has evaporated.
This pressure washer has a Safety Relief
device which should never be altered, modied,
removed or made inoperative. If the device
fails, replace immediately with only genuine
manufacturer replacement part.

Operator's Manual 5
POTENTIAL CONSEQUENCE PREVENTION HAZARD
Serious injury or death may occur
from inhaling burner exhaust or
dangerous vapors.
Always make certain there is adequate
ventilation (fresh outside air) for breathing
and combustion. This will prevent the
buildup of dangerous carbon monoxide
gases. Beware of poorly ventilated areas,
or areas with exhaust fans which can
cause poor air exchange.
Follow all safety instructions provided with
the materials you are spraying. Use of a
respirator may be required when working
with some materials. Do not use this
pressure washer to dispense hazardous
materials.
RISK OF ASPHYXIATION
SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE INSTALLING AND USING PRESSURE WASHER

6 Operator's Manual
POTENTIAL CONSEQUENCE PREVENTION
HAZARD
RISK OF
ELECTROCUTION
OR
ELECTRIC SHOCK
Serious injury or death could occur if
the pressure washer is not properly
grounded. Your pressure washer
is powered by electricity and may
cause electric shock or electrocution
if not used properly.
Installation of this unit including all
electrical connections must comply
with all local, state and national codes.
(Standards to be followed include NFPA
No. 70/NEC National Electrical Code.
In Canada; Refer to the CSA C22.1
Canadian Electrical Code Part 1)
This unit must be connected to a
grounded, permanent wiring system; or
an equipment-grounding conductor must
be run with the circuit conductors and
connected to the equipment-grounding
lead on the unit.
Make sure the pressure washer is
connected to a properly grounded source
which provides correct voltage and
adequate fuse protection. Disconnect
from power source when not in use or
when making repairs.
Never operate pressure washer with
electrical enclosures open, removed or
damaged.
Do not touch machine while standing in
water or with wet hands. Never let the
electrical supply or any connections lay
in the water.
DO NOT direct spray on or into electrical
installations of any kind! This includes
electrical outlets, light bulbs, fuse boxes,
transformers, the unit itself, etc.
DO NOT allow metal components of the
pressure washer to come in contact with
live electrical components.
Any electrical wiring or repairs performed
on this pressure washer should be
done by authorized service personnel
in accordance with local and national
electrical codes.
Before opening any electrical enclosure,
always shut off the pressure washer,
relieve pressure and disconnect the
pressure washer from the power source.
Allow pressure washer to cool down.
Never assume the pressure washer is
safe to work on just because it is not
operating. It could restart at any time!
Electrical shock may occur if
pressure washer is not operated
properly.
Serious injury or death may occur
from contact with electricity.
Serious injury or death may occur if
electrical repairs are attempted by
unqualied persons.
Serious injury or death could result
from improper installation.
SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE INSTALLING AND USING PRESSURE WASHER

Operator's Manual 7
Serious injury or death could
occur from high pressure spray
penetrating the skin.
Keep clear of nozzle and spray! Never put
your hand, ngers or body directly over the
spray nozzle.
Never point the high pressure discharge
stream at persons.
This equipment is to be used only by
trained operators.
Always keep operating area clear of all
persons.
To reduce the risk of injury, close
supervision is necessary when using this
equipment near children. DO NOT allow
children to operate this unit.
SEEK EMERGENCY MEDICAL CARE if
the spray appears to have penetrated the
skin! DO NOT TREAT AS A SIMPLE CUT!
Be prepared to tell a physician exactly what
kind of cleaning agents you were using
by reading the Material Safety Data Sheet
(MSDS) provided with your detergent.
High pressure hoses should be inspected
daily for signs of wear. If evidence of
failure exists, promptly replace all suspect
hoses to prevent the possibility of injury
from the high pressure spray. If a hose or
tting is leaking, NEVER PLACE YOUR
HAND DIRECTLY ON THE LEAK.
Before using pressure washer, or when
quick connecting high pressure hoses and
spray nozzles, be certain the "collar" on the
female quick connect is locked securely to
prevent accidental discharge and that all
quick coupler ttings are secure.
NEVER operate the gun with the trigger
wired in the open position. To prevent
accidental discharge, the trigger gun
should be securely locked when not in use.
Before removing the spray nozzle or
servicing the unit, ALWAYS shut off the
unit and trigger the gun to release trapped
pressure. (Even after you shut off the
unit, there is high pressure water left in the
pump, hose and gun until you release it by
triggering the gun.)
POTENTIAL CONSEQUENCE PREVENTION
HAZARD
SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE INSTALLING AND USING PRESSURE WASHER
RISK OF INJECTION
OR
SEVERE CUTTING INJURY

8 Operator's Manual
RISK OF BURNS
RISK OF BURSTING
RISK FROM MOVING PARTS
Serious injury may occur from
touching the heat exchanger or
vent piping. These areas can
remain hot for some time after the
pressure washer is shutdown.
Never make adjustments to the factory
set pressures.
Never exceed manufacturers maximum
allowable pressure rating of attachments.
Do not allow any hoses to make contact
with the heat exchanger to prevent the
possibility of bursting. Avoid dragging the
hoses over abrasive surfaces such as
cement.
Use only manufacturer recommended
repair parts for your pressure washer.
In freezing temperatures, the unit must
always be warm enough to ensure there
is no ice formation in the unit. Do not
start the pressure washer without rst
allowing the unit to thaw.
Never allow any part of your body to
contact the heat exchanger or the vent
piping.
POTENTIAL CONSEQUENCE PREVENTION
HAZARD
Serious injury may occur to the
operator from moving parts on the
pressure washer.
Do not operate the unit without all
protective covers in place or make any
adjustments without shutting off the
pressure washer, relieving pressure
and disconnecting the pressure washer
from the power source. Allow pressure
washer to cool down. Never assume
the pressure washer is safe to work on
just because it is not operating. It could
restart at any time!
Serious injury may occur from a
pressure washer malfunction or
exploding accessories if incorrect
system components, attachments
or accessories are used.
Serious injury or death may occur
if attempting to start the pressure
washer when the unit is frozen.
SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE INSTALLING AND USING PRESSURE WASHER

Operator's Manual 9
RISK OF BODILY INJURY
Serious injury or death may occur
from detergents contacting or
penetrating the skin.
SEEK EMERGENCY MEDICAL CARE if
the spray appears to have penetrated the
skin! DO NOT TREAT AS A SIMPLE CUT!
Be prepared to tell a physician exactly what
kind of cleaning agents you were using
by reading the Material Safety Data Sheet
(MSDS) provided with your detergent.
Never use any solvents or highly corrosive
detergents or acid type cleaners with this
pressure washer.
Protective equipment such as rubber suits,
gloves and respirators are advisable,
especially when using cleaning detergents.
Keep all detergents out of the reach of
children!
ALWAYS wear protective goggles when
operating the unit to shield the eyes from
ying debris and detergents.
DO NOT direct spray toward fragile
materials such as glass for shattering could
occur.
Stay alert-watch what you are doing. Do
not operate the unit when fatigued or under
the inuence of alcohol or drugs.
NEVER squeeze the trigger unless
securely braced.
DO NOT overreach or stand on unstable
support.
Wet surfaces can be slippery, wear
protective foot gear and keep good footing
and balance at all times.
NEVER trigger the gun while on a ladder
or roof.
ALWAYS hold on rmly to the gun/lance
assembly when starting and operating the
unit. Failure to do so can cause the lance
to fall and whip dangerously.
Know how to stop the pressure washer and
bleed pressures quickly. Be thoroughly
familiar with controls.
DO NOT leave pressurized unit
unattended. Shut off the pressure washer
and release trapped pressure before
leaving.
DO NOT operate the unit if you see any
oil or water leaks from the machine. DO
NOT resume operation until the unit has
been inspected and repaired by a qualied
serviceman.
Never make adjustments on the machine
while in operation.
Before servicing the unit: shut off the
pressure washer, relieve pressure and
disconnect the pressure washer from the
power source. Allow pressure washer to
cool down. Never assume the pressure
washer is safe to work on just because it is
not operating. It could restart at any time!
POTENTIAL CONSEQUENCE PREVENTION
HAZARD
Serious injury can occur from
loose debris being propelled at a
high speed from the spray gun.
Injury may occur if the operator
loses his balance caused by the
thrust of water traveling through
the spray nozzle.
Injury may occur from the
pressure washer.
SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE INSTALLING AND USING PRESSURE WASHER
SAVE THESE INSTRUCTIONS

10 Operator's Manual
HEO-SERIES FEATURES
HEO SERIES FEATURES-112309-CH

Operator's Manual 11
OMWPB027/050796/JTR
FEATURES LISTING
1 Exhaust Outlet
2 Draft Diverter
3 Heat Exchanger
4 Pressure Switch
5 Pressure Trapping Unloader
6 Thermo Relief Valve
7 High Pressure Pump
8 High Pressure Outlet
9 Fork Truck Access
10 Nozzle Storage
11 Detergent Metering Valve
12 Pump Switch W/indicator Light
13 Burner Switch W/indicator Light
14 Detergent Strainer
15 Electrical Enclosure
16 Adjustable Thermostat
17 Electrical Junction Box
18 Float Tank W/lter
19 Water Inlet
20 Burner W/ Fuel Filter/ Water Separator
21 Pressure Relief Valve
22 Decal- Nozzles
23 Decal- Electric Box Switches (Pump/burner)
24 Decal- Operation
25 Decal- Detergent Valve
26 Decal- Warning: Risk Of Injury/exposed Pulleys
27 Decal- Warning/caution
28 Hinged Access Door
29 Decal- Warning: Hot Surfaces
30 Access Door
31 High Pressure Hose
32 Trigger Gun
33 Trigger Safety Lock
34 Insulated Lance
35 Adjustable Pressure Dual Lance
36 High Pressure Nozzles

12 Operator's Manual
1. This unit should be installed indoors by a qualied serviceman in a non-
freezing, dry environment away from damaging winds and rain. If any part of
the unit becomes frozen, excessive pressure may build up in the unit which
could cause it to burst resulting in possible serious injury to the operator or
bystanders. Normal precautions should be taken so that excess moisture
does not reach the electrical controls or the power unit.
2. It should be placed in an area away from ammable or combustible material.
These types of material should be kept at least 20 feet away from the gas-
red units.
3. Avoid small areas and exhaust fans. Combustion becomes difcult and
carbonmonoxidemayresultintheseareas. Allowenoughspaceforservicing.
Some codes will require certain distances from walls and ooring. Two feet
away from the walls should sufce.
4. This unit should only be placed on a level surface to ensure proper lubrication
for the water pump while operating. NEVER spray water directly on the
unit.
5. DO NOT place unit in an area:
a. where ammable gas vapors may be present.
b. with insufcient ventilation.
c. where there is evidence of oil or fuel leaks.
RISK OF EXPLOSION OR FIRE!
DO NOT PLACE UNIT IN AN
AREA WHERE FLAMMABLE
GASVAPORSMAYBEPRESENT.
A SPARK COULD CAUSE AN
EXPLOSION OR FIRE!
RISK OF UNIT BURSTING!
DO NOT LOCATE THE UNIT IN
FREEZING ENVIRONMENTS!
RISK OF ASPHYXIATION!
USE THIS PRODUCT ONLY IN
WELLVENTILATEDAREAS! THE
EXHAUST CONTAINS CARBON
MONOXIDE, A POISONOUS,
ODORLESS AND INVISIBLE
GAS. BREATHING THIS GAS
CAN CAUSE SERIOUS INJURY,
ILLNESS & POSSIBLE DEATH.
INSTALLATION
LOCATION AND PLACEMENT:
DANGER
WARNING
ELECTRICAL:
1. Installation of this unit should be performed by a qualied serviceman and
all electrical installation must conform to all local, state and national codes,
including NFPA No. 70 (NEC) National Electrical Code. In Canada; Refer
to the CSA C22.1 Canadian Electrical Code Part 1.
2. This unit comes to you with the wires terminating in a junction box inside
the cabinet. You must supply the incoming power source.
3. Ensure electrical supply is identical to the specications listed on the pressure
washer data plate.
4. Ensure all connections are secure and covers are replaced.
RISK OF ELECTROCUTION!
THISUNITMUSTBECONNECTED
TO A PROPERLY GROUNDED
OUTLET.
WARNING

Operator's Manual 13
INSTALLATION
VENTILATION:
1. Installationofthisunit inan indooror in an enclosedareashouldbe performed
by a qualied serviceman and all venting must conform to all local, state and
national codes, including the National Fuel Gas Code ANSI Z223.1/NFPA
No. 54. In Canada; Refer to the CSA B149.1 Gas Installation Code. The
burner exhaust should be stacked to the outside atmosphere and a draft
diverter should be installed as well.
NOTE: There should be no more than 6500 BTU per square inch of ue.
2. A draft diverter must be installed above the exhaust outlet. This diverter
breaks the chimney effect and enhances the draft through the burner for a
more efcient ame. It also helps prevent cold air downdrafts from freezing
the heat exchanger. (See illustration #1)
3. Install the recommended ue pipe per local, state and national codes,
including the National Fuel Gas CodeANSI Z223.1/NFPANo. 54. In Canada;
Refer to the CSA B149.1 Gas Installation Code. If the ue pipe exceeds 10
feet in length or contains more than two elbows, the natural draft may be
eliminated and the burner will not ignite. DO NOT install a movable ue
pipe damper.
4. If the unit is being installed in an enclosed room, provide adequate air for
combustion by installing openings to the room near the ceiling for ventilation
and near the oor for burner combustion. These openings should be sized
using one square inch for each 1000 BTU per inch of the machine.
Example: A pressure washer with a 400,000 BTU input requires openings of 400
square inch or approximately 3 feet x 1 foot. (See illustration #2).
5. If the building in which the unit is being installed seems unusually tightly
constructed, it is recommended that air intakes extending to the outside of the
building be employed to supply combustion air. End the intakes outside the
building with a downward opening to protect these intakes from snow and/or
rain. Include a mesh screen no smaller than 1/4" over the opening.
ILLUSTRATION #1
DRAFT DIVERTER
ILLUSTRATION #2
ENCLOSED ROOM VENTILATION

14 Operator's Manual
INSTALLATION
HIGH PRESSURE CONNECTION:
Connect the high pressure discharge hose by connecting one end to the
pressure washer and the other end to the gun assembly. Make certain the
quick connects are securely locked together. (See illustration #4 and #5)
ILLUSTRATION #4
HIGH PRESSURE HOSE CONNECTION
ILLUSTRATION #5
QUICK CONNECT
ILLUSTRATION #3
HOSE CONNECTION
WATER SUPPLY:
1. Select a water supply hose which is a quality grade of garden hose
measuring at least 3/4" ID and no longer than 50'. (See illustration #3)
2. Connect one end of the water supply hose to the water inlet of the unit.
Connect the other end of the hose to your pressurized water supply.
NOTE: If there is a high mineral content in your water, it is recommended
that a water softener be used to prevent the possibility of excessive
scale buildup inside the heat exchanger coil.
3. Be certain all connections are securely tightened.
a. Water supply hose to the Water Inlet on the unit.
b. Water supply hose to the Pressurized Water Supply.
4. Follow the incoming water requirements listed below:
a. Water pressure must be between a minimum of 20 pounds per
square inch (PSI) and a maximum of 65 PSI.
b. Incoming GPM must be approximately one gallon more than
the outgoing GPM stated on the pressure washer I.D. Plate.
(You can check GPM by timing how long it takes to ll a 5 gallon
container.)
c. Incoming water temperature must not exceed 125°F. Excessive
pump damage may result if the water temperature exceeds this
acceptable level.
NOTE: If the water supply is inadequate or the hose is kinked, the unit will
run rough and the burner will not re.
5. Never allow the unit to operate without the incoming water line attached
and the water supply completely turned on.
6. Ensure the water strainers are clean and free of any obstructions.
Periodic cleaning of the water strainer will help prevent pump problems.
As a strainer becomes obstructed, it restricts proper ow of water to the
pump. This can result in cavitation which will cause premature failure
of pump packings. Remove strainer screens, clean or replace.

Operator's Manual 15
INSTALLATION
QUESTIONS
CODES:
1. Does the electrical supply meet respected codes?
2. Does the ventilation system meet respected codes?
LOCATION:
1. Is the unit installed indoors on a level surface in a dry area protected
from excessive wind, rain and moisture?
2. Is the unit located away from flammable and combustible
material?
3. Is the unit located in a large enough area for adequate air ow?
ELECTRICAL:
1. Is the unit properly grounded?
2. Do all electrical components used meet requirements shown on
the unit I.D. Plate and is the voltage correct?
VENTILATION:
1. Are the correct ue pipe and draft hood sizes employed?
2. Is there adequate ventilation for burner combustion?
3. Is the unit properly vented to allow adequate air ow?
4. Is exhaust stacked to outside atmosphere?
GENERAL:
1. Haveall operatorsusing thisunit readthe Installationand Operator's
Manual and understood all safety warnings?
2. Has the unit been installed by qualied service people who followed
the Installation and Operator's Manual instructions?
3. Is there ample water supply?
YES NO
PRE-OPERATION CHECKLIST:
Before starting the unit, answer the questions in this checklist:
IF NO WAS MARKED FOR ANY OF THESE QUESTIONS, CORRECT THE SITUATION BEFORE
OPERATING THIS UNIT.

16 Operator's Manual
PREPARATION
ATTIRE:
Proper attire is essential to your safety. It is advised to utilize whatever means
necessary to protect eyes, ears, and skin. Additional safety attire (such as
respiratory mask) may be required when using detergent cleaning agents with
this pressure washer.
PRE-START:
1. Check to ensure the voltage is on.
2. Pump oil level should be checked before each use. Check the oil level with
the dipstick on top of the pump crankcase. (See illustration #6.) The proper
oil level should be at the notch on the dipstick. If the level appears low, use
pump oil SAE20 or 30 non-detergent.
3. Inspect the water inlet strainer. Clean or replace if necessary. See "Water
Supply", #6, pg 14.
ILLUSTRATION #6
PUMP-REAR OIL GAUGE
BURNER FUEL TANK:
1. Review "Risk of Explosion or Fire" pg. 4, before fueling.
2. Locate the Safety Decals on your unit and heed their warnings.
3. Fill the burner fuel tank with good quality, clean No. 1 or No. 2 fuel oil/diesel
or kerosene. Do not use gasoline!
UNLOADER:
The unloader has been preset at the factory and should only be adjusted by a
trained serviceman.
WARNING
RISK OF EXPLOSION OR FIRE!
ALWAYS STORE FUEL AWAY
FROM THE WASHER WHILE THE
UNIT IS RUNNING OR HOT.
DANGER
RISK OF FIRE!
-DO N OT SM OKE W HIL E
FUELING!
-DO NOT FILL THE FUEL TANK
WHILE UNIT IS RUNNING OR
HOT. ALLOW UNIT TO COOL
FOR TWO MINUTES BEFORE
REFUELING.
-DO NOT FILL FUEL TANK TO
POINT OF OVERFLOWING.

Operator's Manual 17
PREPARATION
QUICK-CONNECT NOZZLES:
Various nozzles may be quick connected into the end of the adjustable pressure
dual lance to change the spray pattern or use the detergent feature. When
using Quick- connects (Q.C.), be certain the connection is securely locked.
(See illustration #7). If not, the high pressure water may shoot the nozzle
from the lance, causing severe injury or serious damage. To determine spray
fan, (see illustration #8) refer to the actual number stamped on the nozzle.
The rst two digits indicate the spray fan in degrees, i.e., 00=0°, 15=15°,
25=25°, 40=40°.
1. The0°nozzle (RED): This is a blasting nozzle. It delivers a very concentrated
stream of water. Be cautious when using the straight narrow stream. It is
not recommended for use on painted or wood surfaces or items attached
with adhesive backings. Uses: Removing weeds from sidewalk cracks,
stubborn stains from concrete, masonry, aluminum and steel, caked mud
from equipment, and cleaning lawn mower undersides.
2. The 15° nozzle (YELLOW): This is a chiseling nozzle. The spray should
be directed at a 45° angle to the surface and used like a scraper to
remove paint, grease and dirt. Uses: Surface preparation (removing
mildew stains and paint chips).
3. The 25° nozzle (GREEN):
a. This is a ushing nozzle. This pattern is best suited for ushing
dirt, mud, and grime. Uses: Wet sweeping leaves from walk,
curbs and driveways, cleaning stable oors, washing swimming
pool bottoms, degreasing engines.
b. On units with steam option, this nozzle is used for 250°F Wet
Steam operation. This nozzle is sized for operation with the
unloader and steam valve (where applicable) to provide hig
pressure wet steam. Replacement of this nozzle with an
improerly sized nozzle may cause operational problems with the
machine.
4. The 40° nozzle (WHITE): This is a wash nozzle. This wide spray pattern
disperses the water pressure over a large area and is recommended
for moderate washing. Uses: Washing down aluminum siding, cleaning
windows, washing vehicles, spraying sidewalks, driveways, and
patios.
ILLUSTRATION #7
QUICK CONNECT
ILLUSTRATION #8
Q.C. NOZZLES
1. Ensure the trigger gun is locked in the OFF position. (See illustration
#9)
2. The quick-connect nozzle should be disconnected from the adjustable
pressure dual lance at this time. As shown in illustration #10, retract the
locking ring on the quick-connect tting to remove the nozzle.
ILLUSTRATION #10
NOZZLE CONNECTION
NOZZLE CONNECTION:
WARNING
RISK OF INJECTION CAUSING
SEVERE INJURY!
THE TRIGGER GUN SHOULD
ALWAYS BE LOCKED IN THE OFF
POSITION WHEN NOT IN USE!
NEVER LOOK DIRECTLY AT
THE NOZZLE UNLESS IT IS
DISCONNECTED FROM THE
TRIGGER GUN/DUAL LANCE
ASSEMBLY!
ILLUSTRATION #9
GUN LOCK

18 Operator's Manual
PREPARATION
1. This unit features an adjustable pressure dual lance with adjustable pressure
which allows the user to select a high or low pressure "fan" spray. Simply
rotate the adjustable grip on the dual lance to achieve the desired pressure
selection.
a. Selection of high pressure can be achieved by turning the adjustable
grip on the dual lance counterclockwise as shown in illustration #11.
b. Selection of low pressure can be achieved by turning the adjustable
grip on the dual lance clockwise as shown in illustration #11. If using
the detergent injector accessory, once the pressure is low enough, this
injector on the pressure washer will draw detergent into the system. A
water/detergent mixture exits from both the spray nozzle and detergent
nozzle.
1. Before starting the unit, perform the following procedures:
a. Check all hose connections to ensure they are securely tightened.
b. Inspect for system water and oil leaks.
c. Inspect high pressure hoses for kinking, cuts and leaks. If a cut or leak
is found, DO NOT USE HOSE! Replace hose before starting unit. See
"Risk of Injection" warnings, pg. 7. Be sure that all damaged parts are
replaced and that the mechanical problems are corrected prior to opera-
tion of the unit. If you require service, contact your Customer Service
Represenative.
ILLUSTRATION #11
DUAL LANCE
DUAL LANCE ASSEMBLY WITH ADJUSTABLE PRESSURE:
PRE-START INSPECTION PROCEDURES:

Operator's Manual 19
WARNING
THE FOLLOWING PAGES CONTAIN OPERATING AND
MAINTENANCE INSTRUCTIONS.
DO NOT ATTEMPT TO OPERATE THIS PRESSURE
WASHER UNTIL YOU HAVE READ AND UNDERSTOOD
ALL SAFETY PRECAUTIONS AND INSTRUCTIONS
LISTED IN THIS MANUAL. FOLLOW THE MAINTENACE
INSTRUCTIONS SPECIFIED IN THE MANUAL.
INCORRECT OPERATION OF THIS UNIT CAN CAUSE
SERIOUS INJURY!!
DO NOT ALTER OR MODIFY THIS EQUIPMENT
IN ANY MANNER!

20 Operator's Manual
OPERATING INSTRUCTIONS
Once your unit has been installed by a qualied serviceman and you have
completed the PRE-OPERATION CHECKLIST on pg. 15, you are ready for
operation. The following steps will help you operate your machine safely.
1. This unit has a steel coil which, after setting, will cause the water remaining
in the coil from the previous usage to turn brown or black. This water must
be ushed from the system before start-up. This procedure should be
performed without the gun and adjustable pressure dual lance installed.
a. Verify the water supply is on.
b. Move the pump switch to the "ON" position to start the pumping unit.
c. Run the unit for 3-5 minutes.
d. Turn off machine.
e. Once the system is ushed, connect the trigger gun and
adjustable pressure dual lance to the high pressure hose.
1. Refer to the "Safety Precautions" pgs. 4-9 before starting the unit.
2. Locate the Safety Decals on your unit and heed their warnings.
3. Ensure that the burner switch is in the "OFF" position.
4. Pointing the trigger gun in a safe direction, unlock the trigger gun and
squeeze the trigger. Brace yourself for possible gun kickback when the
pump starts.
5. Move the pump switch to the "ON" position to start the pumping unit.
6. Once the unit has started, perform the following procedures with the gun
open:
a. Inspect for system water and oil leaks.
b. Inspect high pressure hoses for leaks. If a leak is found, DO NOT TOUCH
HOSE AT LEAK!!! TURN UNIT OFF IMMEDIATELY! Replace hose
before using the unit. See "Risk of Injection" warnings, pg. 7. Be sure
that all damaged parts are replaced and that the mechanical problems
are corrected prior to operation of the unit.
7. At this point, the unit is operating as a cold water pressure washer. Trigger
the gun several times and try adjusting the water pressure by rotating the
grip on the dual lance. NEVER place hand or ngers in front of the nozzle
or look directly into the nozzle! High pressure water creates a risk of severe
injury!
8. Do not allow unit to operate in bypass mode (with trigger closed) for more
than three minutes without triggering the gun. Failure to follow this simple
rule can cause premature failure of pump packing seals, resulting in costly
pump repair.
9. Your pressure washer can deliver high pressure spray and a variety of spray
patterns using cold water. If you wish to use the hot water application or
cleaning with detergents, see pg. 21 for the correct procedures.
RISK OF UNIT DAMAGE!
BE CERTAIN THE GUN
& DUAL LANCE ASSY. ARE
NOT CONNECTED TO THE
UNIT WHILE FLUSHING THE
SYSTEM. FLUSHING ALLOWS
MINERAL DEPOSITS TO BE
RELEASED FROM THE SYSTEM
WHICH WOULD OBSTRUCT
OR DAMAGE THE GUN AND
NOZZLEASSEMBLYRESULTING
IN COSTLY REPAIRS.
RISK OF INJECTION CAUSING
SEVERE INJURY!
KEEPCLEAROFNOZZLE!NEVER
PLACE HAND OR FINGERS IN
FRONT OF NOZZLE!
DO NOT DIRECT DISCHARGE
STREAM AT PEOPLE OR PETS!
RISK OF DAMAGE!
DONOTALLOWSPRAYPATTERN
TO REMAIN ON A FIXED AREA
FOR AN EXTENDED PERIOD OF
TIME. POSSIBLE DAMAGE MAY
OCCUR TO THE AREA.
FLUSHING THE SYSTEM:
COLD WATER OPERATION:
CAUTION
DANGER
CAUTION
